Investigation of the Microstructure and Play of Color Mechanism of a Synthetic Opal by FTIR-SEM
-
摘要: 近些年来，相关人工合成欧泊的研究工作主要聚焦于天然与合成欧泊的鉴别与筛选，而相关合成欧泊的微结构、变彩机制及其中水的赋存状态的深入研究鲜见报道。本文通过傅里叶变换红外光谱（FTIR）、场发射扫描电镜（FE-SEM）对一类合成欧泊的微结构、结构缺陷进行较系统的研究。同时，结合对样品的热处理就该合成欧泊体色、变彩机制及其中水的赋存状态作了初步探讨。结果表明：该样品的红外光谱中，在约2900 cm-1、1737 cm-1处出现合成欧泊特征吸收，且在4000~6000 cm-1波段，合成欧泊相比天然欧泊的吸收峰更为复杂。合成欧泊的颜色由体色与变彩两者共同构成，该体色与存在于其微结构中准球状、粒径约205 nm的二氧化硅颗粒的间隙填充物直接关联，且在热处理条件下随着间隙物的析出而渐退。同时，该类合成欧泊的变彩归因于结构致色并由其内部SiO2颗粒周期性排列而构成的三维的光子带隙结构所致。此外，在欧泊的微观结构发生重构前，变彩所呈现的颜色主要由准球状二氧化硅颗粒粒径与间隙填充物决定。Abstract: In recent years considerable research has been focused on distinguishing natural from synthetic opals. However, with regard to synthetic opals, less attention has been paid to investigate their microstructure, the formation mechanism of play of color and the form of water content. Fourier Transform Infrared Spectroscopy (FTIR) combined with Field Emission-Scanning Electron Microscopy (FE-SEM) were used to systematically investigate the microstructure of a synthetic opal. With the help of heat treatment, the formation mechanism of body color, play of color and the occurrence state of water have been preliminarily studied. Results show that the synthetic opal had typical absorption peaks at 2900 cm-1 and 1737 cm-1 in FTIR Spectroscopy. The absorption peaks of synthetic opal were more complex than those of natural opal-between 6000 cm-1 and 4000 cm-1 (in Fig.2). The color of synthetic opal consists of body color and play of color. The body color has a direct association with the substances filling in the pores among these quasi-spherical SiO2 particles with a diameter of 205 nm, and it gradually disappeared as the substances escaped from the pores (in Fig.5). The play-of-color of synthetic opal originated from three dimensional photonic band gap structures, which consisted of periodicity-arranged SiO2 particles. In addition, before the micro-architecture made by SiO2 particles was broken, the main color depended on the particle size and the substances filling the pores.
-
-
[1] Sanders J V.Microstructure and crystallinity of gem opals[J].American Mineralogist, 1975, 60:749-757.
[2] Gajiew G M, Golubev V G, Kurdyukov D A, et al.Bragg reflection spectroscopy of opal-like photonic crystals[J].Physical Review B, 2005, 72(20):5115(1-9).
[3] Cui N D, Liang J Q, Liang Z Z, et al.Influence of particle's deformation on the optical properties of silica photonic crystals[J].Chinese Journal of Luminescence, 2011, 32(6):542-547. doi: 10.3788/fgxb
[4] Choudhary G, Bhandari R.A new type of synthetic fire opal:Mexifire[J].Gems & Gemology, 2008, 44(3):228-233.
[5] Hernández-Ortiz M, Hernández-Padrón G, Bernal R, et al.Nanocrystal mimetic opals:Synthesis and comparative characterization vs. natural stones[J].International Journal of Basic and Applied Sciences, 2015, 4(2):238-243. doi: 10.14419/ijbas.v4i2
[6] Jones J B, Segnit E R.Nomenclature and the structure of natural disordered (Opaline) silica[J].Contributions to Mineralogy and Petrology, 1975, 51(3):231-234. doi: 10.1007/BF00372083
[7] Jones J B, Segnit E R.The nature of opal Ⅰ.Nomenclature and constituent phases[J].Australian Journal of Earth Science, 2007, 18(1):57-68.
[8] Li D, Bancroft G M, Kasrai M, et al.X-ray absorption spectroscopy of silicon dioxide (SiO2) polymorphs:The structural characterization of opal[J].American Mineralogist, 1994, 79:622-632.
[9] Gaillou E, Fritsch E, Aguilar-Reyes B, et al.Common gem opal:An investigation of micro-to nano-structure[J].American Mineralogist, 2008, 93(11-12):1865-1873. doi: 10.2138/am.2008.2518
[10] Eckert J, Gourdon O, Jacob D E, et al.Ordering of water in opals with different microstructures[J].European Journal of Mineralogy, 2015, 27(2):203-213.
[11] Wilson M J.The structure of opal-CT revised[J].Journal of Non-crystalline Solids, 2014, 405(1):68-75.
[12] Adamo I, Ghisoli C, Caucia F.A contribution to the study of FTIR spectra of opals[J].Neues Jahrbuch für Mineralogie-Abhandlungen, 2010, 187(1):63-68. doi: 10.1127/0077-7757/2010/0161
[13] 严俊, 胡仙超, 方飚, 等.应用XRF-SEM-XRD-FTIR等分析测试技术研究丽水蓝色类欧泊 (蛋白石) 的矿物学与光学特征[J].岩矿测试, 2014, 33(6):795-801. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20140606&flag=1
Yan J, Hu X C, Fang B, et al.Study on the mineralogical and optical characteristics of blue opal from Lishui investigated by XRF-SEM-XRD-FTIR[J].Rock and Mineral Analysis, 2014, 33(6):795-801. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20140606&flag=1
[14] 薛秦芳.天然欧泊、合成欧泊、塑料欧泊的鉴别研究[J].宝石和宝石学杂志, 1999, 1(2):49-52. http://www.cnki.com.cn/Article/CJFDTOTAL-BSHB199902018.htm
Xue Q F.Identification of natural, synthetic and plastic simulated opals[J].Journal of Gems and Gemmology, 1999, 1(2):49-52. http://www.cnki.com.cn/Article/CJFDTOTAL-BSHB199902018.htm
[15] 陈全莉, 亓利剑, 张琰.绿松石及其处理品与仿制品的红外吸收光谱表征[J].宝石和宝石学杂志, 2006, 8(1):9-11. http://www.cnki.com.cn/Article/CJFDTOTAL-BSHB200601002.htm
Chen Q L, Qi L J, Zhang Y.IR absorption spectrum representation of turquoise, treated turquoise and imitation[J].Journal of Gems and Gemmology, 2006, 8(1):9-11. http://www.cnki.com.cn/Article/CJFDTOTAL-BSHB200601002.htm
[16] 亓利剑, 黄艺兰, 殷科.俄罗斯人工欧泊的特征及其变彩效应[J].宝石与宝石学杂志, 2006, 8(3):10-15. http://www.cnki.com.cn/Article/CJFDTOTAL-BSHB200603004.htm
Qi L J, Huang Y L, Yin K.Gemmological characteristics and play of colour effect of artificial opals from Russia[J].Journal of Gems and Gemmology, 2006, 8(3):10-15. http://www.cnki.com.cn/Article/CJFDTOTAL-BSHB200603004.htm
[17] 亓利剑, 杨梅珍, 胡永兵, 等.秘鲁蓝欧泊[J].宝石与宝石学杂志, 2001, 3(3):13-16 http://www.cnki.com.cn/Article/CJFDTOTAL-BSHB200103002.htm
Qi L J, Yang M Z, Hu Y B, et al.Blue opal from Peru[J].Journal of Gems and Gemmology, 2001, 3(3):13-16. http://www.cnki.com.cn/Article/CJFDTOTAL-BSHB200103002.htm
[18] 李明海, 马懿, 徐岭, 等.二氧化硅人工蛋白石晶体的制备及其结构性质研究[J].物理学报, 2003, 52(5):1302-1306. http://www.cnki.com.cn/Article/CJFDTOTAL-WLXB200305049.htm
Li M H, Ma Y, Xu L, et al.Formation and structure of artificial opal based on the colloidal silica sphere[J].Acta Physica Sinica, 2003, 52(5):1302-1306. http://www.cnki.com.cn/Article/CJFDTOTAL-WLXB200305049.htm
[19] Gadzhiew G M, Golubev V G, Kurdyukov D A, et al.Characterization of photonic crystal based on opal-semiconductor composites by Bragg reflection spectroscopy[J].Semiconductors, 2005, 39(12):1374-1380. doi: 10.1134/1.2140307
-
