Rapid Purification of Sr and Nd for Isotope Analysis with Multiple-column Method
-
摘要: 样品放射性成因Sr-Nd同位素比值受控于源区初始同位素组成、放射性元素母体与子体相对丰度，以及衰变时间等因素。它们具有极强的示踪能力，因而在地质学领域有广泛的应用。传统的Sr-Nd同位素分析使用的是阳离子树脂，提纯Nd元素时往往涉及有机试剂以及调节pH值等操作，其分析效率较低。近年来特效树脂的出现使得分离这些元素变得简单，但是受硫酸根等因素影响，特效树脂使用次数有限。为了提高分析效率，缩短分析时间，本文开发了一种套柱法，该方法结合阳离子树脂和特效树脂，实现了Sr-Nd元素的快速分离，并且能延长特效树脂的使用寿命。实验采用阳离子树脂、Sr特效树脂和LN稀土特效树脂对玄武岩BCR-2标样进行了分析。Sr-Nd回收率均>90%，BCR-2玄武岩87Sr/86Sr比值为0.705016±0.000016（n=36，1SD），143Nd/144Nd比值为0.512624±0.000012（n=39，1SD），与前人TIMS法获得的结果吻合（87Sr/86Sr：0.705000~0.705023；143Nd/144Nd：0.512630~0.512650）。最终分离提纯的溶液中85Rb/86Sr值小于0.01，147Sm/144Nd值小于0.001，表明该方法可以高效分离Rb-Sr和Sm-Nd，实现Sr、Nd同位素的准确分析。Abstract:
BACKGROUNDThe Sr and Nd isotopic compositions of a sample depend on its initial isotopic ratios, the ratios between the parent nuclide and daughter product, and the decay time. Due to their significance for the tracing of reservoirs, they were widely applied in the geological studies. Traditional cation resin was applied to purify Sr and Nd for isotope analysis, which involved the organic reagent and pH adjustment. The complex chemical procedure was time-consuming. In recent years, the appearance of special resins has made it easy to separate these elements. However, due to the influence of sulfates and other factors, the use of special resins is limited. OBJECTIVESTo shorten the chemical purification time of Sr and Nd, and to avoid the damage of sulfate ions on the Sr and REE specific resins, we proposed a new chemical purification method, where multiple columns were utilized. METHODSThe method combines cationic resin and special resin to realize the rapid separation of Sr and Nd and can extend the using time of special resin. The experiment uses cationic resin, Sr special resin and LN rare earth special resin to analyze the basalt standard BCR-2. RESULTSThe recoveries of Sr and Nd with this method were larger than 90%. The 87Sr/86Sr and 143Nd/144Nd isotope ratios were 0.705016±0.000016 (n=36, 1SD) and 0.512624±0.000012 (n=39, 1SD), respectively, which were in coincidence with the values previously reported by TIMS method within the analytical error. The complied 87Sr/86Sr and 143Nd/144Nd isotope ratios obtained TIMS were 0.705000-0.705023 and 0.512630-0.512650, respectively. The 85Rb/86Sr and 147Sm/144Nd rations of the purified Sr and Nd solution were less than 0.01 and 0.001, respectively. CONCLUSIONSThe proposed chemical purification procedure can efficiently separate Rb, Sr, Sm and Nd, and realize the accurate analysis of Sr and Nd isotopes. -
Key words:
- Sr-Nd isotopes /
- specific resins /
- tailing /
- in-series columns method /
- rapid purification
-
-
[1] Fisher C, Bauer A, Vervoort J.Disturbances in the Sm-Nd isotope system of the Acasta Gneiss Complex-Implications for the Nd isotope record of the early Earth[J].Earth and Planetary Science Letters, 2020, 530:115900. doi: 10.1016/j.epsl.2019.115900
[2] Tillberg M, Drake H, Zack T, Kooijman E, et al.In situ Rb-Sr dating of slicken fibres in deep crystalline basement faults[J]. Scientific Reports, 2020, 10(1):1-13. doi: 10.1038/s41598-019-56847-4
[3] Pin C, Gannoun A, Dupont A.Rapid, simultaneous separation of Sr, Pb, and Nd by extraction chromatography prior to isotope ratios determination by TIMS and MC-ICP-MS[J].Journal of Analytical Atomic Spectrometry, 2014, 29(10):1858-1870. doi: 10.1039/C4JA00169A
[4] Wang M, Audi G, Kondev F G, et al.The AME2016 atomic mass evaluation (Ⅱ).Tables, graphs and references[J].Chinese Physics C, 2017, 41(3):030003. doi: 10.1088/1674-1137/41/3/030003
[5] Vanhaecke F, Degryse P.Isotopic analysis[M].Weinheim:Wiley-VCH Verlag GmbH & Co.KGaA, 2012.
[6] Makishima A.Thermal ionization mass spectrometry (TIMS):Silicate digestion, separation, and measurement[M].New Jersey:John Wiley & Sons, 2016.
[7] Egli D, Müller W, Mancktelow N.Laser-cut Rb-Sr microsampling dating of deformational events in the Mont Blanc-Aiguilles Rouges region (European Alps)[J].Terra Nova, 2016, 28(1):35-42. doi: 10.1111/ter.12184
[8] Bolea-Fernandez E, van Malderen S J M, Balcaen L, et al.Laser ablation-tandem ICP-mass spectrometry (LA-ICP-MS/MS) for direct Sr isotopic analysis of solid samples with high Rb/Sr ratios[J].Journal of Analytical Atomic Spectrometry, 2016, 31(2):464-472. doi: 10.1039/C5JA00404G
[9] Hogmalm K J, Zack T, Karlsson A K O, et al.In situ Rb-Sr and K-Ca dating by LA-ICP-MS/MS:An evaluation of N2O and SF6 as reaction gases[J].Journal of Analytical Atomic Spectrometry, 2017, 32(2):305-313. doi: 10.1039/C6JA00362A
[10] Zack T, Hogmalm K J.Laser ablation Rb/Sr dating by online chemical separation of Rb and Sr in an oxygen-filled reaction cell[J].Chemical Geology, 2016, 437:120-133. doi: 10.1016/j.chemgeo.2016.05.027
[11] Korkisch J.Handbook of ion exchange resins:Their application to inorganic analytical chemistry (Volume Ⅵ)[M].Boca Raton:CRC Press, 1989.
[12] 濮魏, 高剑锋, 凌洪飞, 等.利用DCTA和HIBA快速有效分离Rb-Sr、Sm-Nd的方法[J].南京大学学报(自然科学版), 2005, 41(4):445-450. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=njdxxb200504017
Pu W, Gao J F, Ling H F, et al.Separation method of Rb-Sr, Sm-Nd using DCTA and HIBA[J].Journal of Nanjing University (Natural Sciences), 2005, 41(4):445-450. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=njdxxb200504017
[13] Strelow F W E.Distribution coefficients and ion exchange behavior of 46 elements with a macroreticular cation exchange resin in hydrochloric acid[J].Analytical Chemistry, 1984, 56(6):1053-1056. doi: 10.1021/ac00270a045
[14] Strelow F W E.An ion exchange selectivity scale of cations based on equilibrium distribution coefficients[J].Analytical Chemistry, 1960, 32(9):1185-1188. doi: 10.1021/ac60165a042
[15] Strelow F W E, Rethemeyer R, Bothma C J C.Ion exchange selectivity scales for cations in nitric acid and sulfuric acid media with a sulfonated polystyrene resin[J].Analytical Chemistry, 1965, 37(1):106-111. http://pubs.acs.org/doi/10.1021/ac60220a027
[16] Li C F, Li X H, Li Q L, et al.Rapid and precise deter-mination of Sr and Nd isotopic ratios in geological samples from the same filament loading by thermal ionization mass spectrometry employing a single-step separation scheme[J]. Analytica Chimica Acta, 2012, 727:54-60. doi: 10.1016/j.aca.2012.03.040
[17] Li C F, Chu Z Y, Guo J H, et al.A rapid single column separation scheme for high-precision Sr-Nd-Pb isotopic analysis in geological samples using thermal ionization mass spectrometry[J].Analytical Methods, 2015, 7(11):4793-4802. doi: 10.1039/C4AY02896A
[18] 尹鹏, 何倩, 何会军, 等.离子交换树脂法分离沉积物中锶和钕的影响因素研究[J].岩矿测试, 2018, 37(4):379-387. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.201804170046
Yin P, He Q, He H J, et al.Study on the factors influencing the separation of Sr and Nd in sediments by ion exchange resin[J].Rock and Mineral Analysis, 2018, 37(4):379-387. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.201804170046
[19] 韦刚健, 刘颖, 涂湘林, 等.利用选择性特效树脂富集分离岩石样品中的锶钐和钕[J].岩矿测试, 2004, 23(1):11-14. http://www.ykcs.ac.cn/article/id/ykcs_20040105
Wei G J, Liu Y, Tu X L, et al.Separation of Sr, Sm and Nd in mineral and rock samples using selective specific resins[J].Rock and Mineral Analysis, 2004, 23(1):11-14. http://www.ykcs.ac.cn/article/id/ykcs_20040105
[20] Glennon K J, Osborn J M, Burns J D, et al.Measuring key Sm isotope ratios in irradiated UO2 for use in plutonium discrimination nuclear forensics[J].Journal of Radioanalytical and Nuclear Chemistry, 2019, 320(2):405-414. doi: 10.1007/s10967-019-06486-w
[21] Zhu Z Y, Yang T, Zhu X K.Achieving rapid analysis of Li isotopes in high-matrix and low-Li samples with MC-ICP-MS:New developments in sample preparation and mass bias behavior of Li in ICPMS[J].Journal of Analytical Atomic Spectrometry, 2019, 34(7):1503-1513. doi: 10.1039/C9JA00076C
[22] 朱志勇, 朱祥坤, 杨涛.自动分离提纯系统的研制及其在同位素分析测试中的应用[J].岩矿测试, 2020, 39(3):384-390. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.201908120123
Zhu Z Y, Zhu X K, Yang T.A fully automated chemical separation and purification system and its application to isotope analysis[J].Rock and Mineral Analysis, 2020, 39(3):384-390. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.201908120123
[23] Woodhead J, Swearer S, Hergt J, et al.In situ Sr-isotope analysis of carbonates by LA-MC-ICP-MS:Interference corrections, high spatial resolution and an example from otolith studies[J].Journal of Analytical Atomic Spectrometry, 2005, 20(1):22-27. doi: 10.1039/b412730g
[24] Yang Y H, Wu F Y, Wilde S A, et al.In situ perovskite Sr-Nd isotopic constraints on the petrogenesis of the Ordovician Mengyin kimberlites in the North China Craton[J].Chemical Geology, 2009, 264(1-4):24-42. doi: 10.1016/j.chemgeo.2009.02.011
[25] Davidson J, Tepley Ⅲ F, Palacz Z, et al.Magma recharge, contamination and residence times revealed by in situ laser ablation isotopic analysis of feldspar in volcanic rocks[J].Earth and Planetary Science Letters, 2001, 184(2):427-442. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dc35649a7c954e014ed0c4942f43d5e3
[26] Khawassek Y M, Eliwa A A, El Sayed A H, et al.Adsorption of rare earth elements by strong acid cation exchange resin thermodynamics, characteristics and kinetics[J]. Applied Sciences, 2019, 1(1):51. http://link.springer.com/10.1007/s42452-018-0051-6
[27] Zawisza B, Pytlakowska K, Feist B, et al.Determination of rare earth elements by spectroscopic techniques:A review[J].Journal of Analytical Atomic Spectrometry, 2011, 26(12):2373-2390. doi: 10.1039/c1ja10140d
[28] Li W, Jin X, Gao B, et al.Analysis of ultra-low level rare earth elements in magnetite samples from banded iron formations using HR-ICP-MS after chemical separation[J].Analytical Methods, 2014, 6(15):6125-6132. doi: 10.1039/C4AY00685B
[29] Chu Z, Chen F, Yang Y, et al.Precise determination of Sm, Nd concentrations and Nd isotopic compositions at the nanogram level in geological samples by thermal ionization mass spectrometry[J].Journal of Analytical Atomic Spectrometry, 2009, 24(11):1534-1544. doi: 10.1039/b904047a
[30] 唐索寒, 李津, 梁细荣, 等.钕同位素比值143Nd/144Nd标准溶液研制[J].岩矿测试, 2017, 36(2):163-170. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.2017.02.010
Tang S H, Li J, Liang X R, et al.Reference material preparation of 143Nd/144Nd isotope ratio[J].Rock and Mineral Analysis, 2017, 36(2):163-170. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.2017.02.010
[31] Li C F, Wang X C, Li Y L, et al.Ce-Nd separation by solid-phase micro-extraction and its application to high-precision 142Nd/144Nd measurements using TIMS in geological materials[J].Journal of Analytical Atomic Spectrometry, 2015, 30(4):895-902. doi: 10.1039/C4JA00328D
[32] Pin C, Gannoun A.A triple tandem columns extraction chromatography method for isolation of highly purified neodymium prior to 143Nd/144Nd and 142Nd/144Nd isotope ratios determinations[J].Journal of Analytical Atomic Spectrometry, 2019, 34(2):310-318. doi: 10.1039/C8JA00360B
[33] Caro G, Bourdon B, Birck J L, et al.High-precision 142Nd/144Nd measurements in terrestrial rocks:Con-straints on the early differentiation of the Earth's mantle[J].Geochimica et Cosmochimica Acta, 2006, 70(1):164-191. doi: 10.1016/j.gca.2005.08.015
[34] Upadhyay D, Scherer E E, Mezger K.Fractionation and mixing of Nd isotopes during thermal ionization mass spectrometry:Implications for high precision 142Nd/144Nd analyses[J].Journal of Analytical Atomic Spectrometry, 2008, 23(4):561-568. doi: 10.1039/b715585a
[35] Rudnick R L, Gao S.Composition of the continental crust[J].Treatise on Geochemistry, 2003, 3:659. http://www.sciencedirect.com/science/article/pii/B9780080959757003016
[36] Lei H L, Yang T, Jiang S Y, et al.A simple two-stage column chromatographic separation scheme for strontium, lead, neodymium and hafnium isotope analyses in geological samples by thermal ionization mass spectrometry or multi-collector inductively coupled plasma mass spectrometry[J].Journal of Separation Science, 2019, 42(20):3261-3275. doi: 10.1002/jssc.201900579
[37] Jweda J, Bolge L, Class C, et al.High precision Sr-Nd-Hf-Pb isotopic compositions of USGS reference material BCR-2[J].Geostandards and Geoanalytical Research, 2016, 40(1):101-115. doi: 10.1111/j.1751-908X.2015.00342.x
[38] Weis D, Kieffer B, Maerschalk C, et al.High-precision isotopic characterization of USGS reference materials by TIMS and MC-ICP-MS[J].Geochemistry, Geophysics, Geosystems, 2006, 7(8):1-30. http://onlinelibrary.wiley.com/doi/10.1029/2006GC001283/full
-
