氧气反应模式-电感耦合等离子体串联质谱法测定土壤中的镉

赵志飞; 任小荣; 李策; 郭朝; 宋娟娥; 龚华

doi:10.15898/j.cnki.11-2131/td.202003150034

氧气反应模式-电感耦合等离子体串联质谱法测定土壤中的镉

1.
安捷伦科技(中国)有限公司, 北京 100102

2.
湖北省地质实验测试中心, 湖北武汉 430022

3.
中国科学院南京土壤研究所, 江苏南京 210000

详细信息

作者简介: 赵志飞, 硕士, 应用工程师, 从事原子光谱方法开发与研究。E-mail: zzfeel@126.com

中图分类号: S151.93;O657.63

收稿日期: 2020-03-15

修回日期: 2020-04-17

录用日期: 2020-08-24

刊出日期: 2021-01-28

Determination of Cadmium in Soil Samples by ICP-MS/MS Using Oxygen Reaction Mode

1.
Agilent Technologies(China) Co., LTD, Beijing 100102, China

2.
Hubei Geological Research Laboratory, Wuhan 430022, China

3.
Institute of Soil Science, Chinese Academy of Sciences, Nanjing 210000, China

Received Date: 15 March 2020

Revised Date: 17 April 2020

Accepted Date: 24 August 2020

Publish Date: 28 January 2021

摘要

摘要:
应用电感耦合等离子体质谱法(ICP-MS)分析土壤中的镉元素时，锆的氢氧化物、钼的氧化物、锡的同位素会对镉造成严重的干扰，导致准确测定土壤中镉的难度较大。本文采用电感耦合等离子体串接质谱法(ICP-MS/MS)，选取无同质异位素干扰的¹¹¹Cd为分析谱线，在MS/MS模式下碰撞反应池中通入的氧气可以与⁹⁴Zr¹⁶O¹H⁺、⁹⁵Mo¹⁶O⁺进行电子转移、去氢、加氧等反应，抑制这些多原子离子对¹¹¹Cd的重叠干扰。结果表明：氧气流量越大，去除多原子离子的效果越好，当氧气流量在0.45mL/min时，溶液中2000μg/L以下的锆、1000μg/L以下的钼在¹¹¹Cd处形成的多原子重叠干扰小于0.005μg/L。实验在石墨消解仪中采用氢氟酸-硝酸-高氯酸消解样品，盐酸复溶，溶液定容稀释至1000倍测定，方法检出限(3δ)达到0.003μg/g；本方法经过国家土壤一级标准物质验证，11个国家土壤一级标准物质的测量值和认定值的相对误差在±7%以内，3个国家土壤一级标准物质的精密度(RSD，n=12)小于5%。本方法可以作为土壤样品中痕量镉元素的分析方法。
- 土壤 /
- 镉 /
- 氧气反应模式 /
- 多原子离子 /
- 电感耦合等离子体串接质谱法
Abstract: BACKGROUND
When using inductively coupled plasma-mass spectrometry (ICP-MS) to analyze soil, the zirconium hydroxide, molybdenum oxide, and tin isotopes can cause serious interference on cadmium, which makes it difficult to accurately determine cadmium in soil samples.
OBJECTIVES
To develop a method for accurate determination of Cd in soil samples.
METHODS
ICP-MS/MS was used, and ¹¹¹Cd without isobaric interference was selected as the analysis line. In MS/MS mode, the oxygen introduced into the collision reaction cell can be reacted with ¹¹¹Zr¹⁶O¹H⁺, ¹¹¹Mo¹⁶O⁺, inducing electron transfer, dehydrogenation, oxygenation and other reactions to inhibit the overlapping interference of these polyatomic ions on ¹¹¹Cd.
RESULTS
Oxygen flow was the key factor in this method. 0.45mL/min oxygen flow can reduce oxide interference to less than 0.005μg/L when zirconium concentration was lower than 2000μg/L and molybdenum concentration was below 1000μg/L. The method has been verified by the national reference materials. The relative error of the measured value and recognized value of the 11 national reference materials was within ±7%, and the relative standard deviation (n=12) of three soil reference materials was less than 5%.
CONCLUSIONS
Triple quadrupole ICP-MS oxygen reaction mode can eliminate Zr and Mo polyatomic ion interference on Cd, and this method can be used for the determination of trace Cd in soil samples.
- soil /
- cadmium /
- oxygen reaction mode /
- polyatomic ion /
- triple quadrupole inductively coupled plasma-mass spectrometry

HTML全文

图 1 ICP-MS/MS氧气模式分析¹¹¹Cd示意图

Figure 1.

下载: 全尺寸图片幻灯片

表 1 ZrOH/MoO和氧气主要产物的质量数及信号强度

Table 1. Main reaction products and signal intensity of ZrOH/MoO and oxygen

标准溶液	Q1和Q2分析的质量数 m/z	信号强度 (cps)
锆单标溶液	111 → 32	39817
	111 → 127	4073
	111 → 110	868
	111 → 126	813
钼单标溶液	111 → 32	36109
钼单标溶液	111 → 127	1750

下载: 导出CSV

表 2 氧气流速的优化

Table 2. Optimization of oxygen flow

氧气流速 (mL/min)	Zr单标m/z=111处信号强度(cps)	Cd单标m/z=111处信号强度(cps)
0.000	623.35	6288.14
0.075	670.02	6024.69
0.150	593.35	8971.34
0.225	335.50	12464.13
0.300	138.00	16208.14
0.375	45.00	18299.17
0.450	21.00	18905.01
0.525	4.50	18352.57
0.600	2.00	17020.81
0.675	2.00	16071.31
0.750	2.50	14624.65

下载: 导出CSV

表 3 不同模式下¹¹¹Cd干扰情况对比

Table 3. Interference elimination effects in different modes

标准溶液	浓度 (μg/L)	氦气模式下¹¹¹Cd测定结果		干扰系数	氧气模式下¹¹¹Cd测定结果
标准溶液	浓度 (μg/L)	浓度(μg/L)	信号强度(cps)	干扰系数	浓度(μg/L)	信号强度(cps)
锆单标溶液	100	0.014	87	0.00014	0.000	3
	200	0.028	173	0.00014	0.000	3
	400	0.040	247	0.00010	0.001	10
	800	0.095	580	0.00012	0.001	20
	2000	0.171	1047	0.00009	0.004	60
钼单标溶液	20	0.006	37	0.0003	0.000	3
	50	0.014	87	0.0003	0.000	3
	100	0.020	120	0.0002	0.000	7
	200	0.049	303	0.0002	0.001	13
	1000	0.172	1053	0.0002	0.005	70
	2000	0.353	2167	0.0002	0.018	237
注：表中分析的是Zr单标溶液和Mo单标溶液，镉的预测浓度都为0。

下载: 导出CSV

表 4 土壤一级标准物质镉分析结果

Table 4. Analytical results of Cd in soil national standard substances

标准物质编号	认定值 (μg/g)	测定值 (μg/g)	相对误差 (%)
GBW07385	0.28 ± 0.02	0.285	1.8
GBW07385	0.28 ± 0.02	0.282	0.7
GBW07388	0.066 ± 0.007	0.067	1.5
GBW07388	0.066 ± 0.007	0.068	3.0
GBW07389	0.14 ± 0.01	0.143	2.1
GBW07389	0.14 ± 0.01	0.141	0.7
GBW07407	0.08 ±0.02	0.079	-1.3
GBW07407	0.08 ±0.02	0.079	-1.3
GBW07408	0.13 ±0.02	0.131	0.8
GBW07408	0.13 ±0.02	0.132	1.5
GBW07426	0.15 ±0.02	0.149	-0.7
GBW07426	0.15 ±0.02	0.154	2.7
GBW07427	0.13 ±0.01	0.131	0.8
GBW07427	0.13 ±0.01	0.127	-2.3
GBW07449	0.108 ± 0.011	0.105	-2.8
GBW07449	0.108 ± 0.011	0.108	0.0
GBW07451	0.065 ±0.012	0.061	-6.2
GBW07451	0.065 ±0.012	0.062	-4.6
GBW07452	0.15 ± 0.02	0.148	-1.3
GBW07452	0.15 ± 0.02	0.152	1.3
GBW07453	0.106 ±0.007	0.103	-2.8
GBW07453	0.106 ±0.007	0.105	-0.9

下载: 导出CSV

表 5 方法检出限和精密度

Table 5. Detection limit and precision tests of the method

项目	Cd空白值 (μg/L)			Cd测定值(μg/g)
项目	Cd空白值 (μg/L)			GBW07408			GBW07451			GBW7389
12次测定值	-0.0004	0.0018	0.0007	0.131	0.127	0.132	0.061	0.062	0.065	0.134	0.143	0.142
	0.0021	-0.0012	0.0019	0.130	0.130	0.132	0.065	0.069	0.070	0.139	0.139	0.145
	0.0011	0.0013	0.0015	0.133	0.132	0.126	0.067	0.071	0.066	0.146	0.138	0.141
	0.0014	-0.0002	0.0010	0.127	0.130	0.132	0.068	0.065	0.064	0.136	0.142	0.140
标准偏差	0.0010			0.0024			0.0029			0.0034

下载: 导出CSV

参考文献(34)

[1]	邵文军, 张激光, 刘晶晶. 石墨炉原子吸收光谱法测定岩石和土壤中痕量镉[J]. 岩矿测试, 2008, 27(4): 310-312. http://www.ykcs.ac.cn/article/id/ykcs_200804102 Shao W J, Zhang J G, Liu J J. Determination of trace cadmium in rocks and soil by graphite furnace atomic absorption spectrometry[J]. Rock and Mineral Analysis, 2008, 27(4): 310-312. http://www.ykcs.ac.cn/article/id/ykcs_200804102
[2]	何恬叶, 张颖红, 胡子文. 微波消解ICP-OES法测定土壤样品中22种元素[J]. 分析试验室, 2018, 37(1): 84-87. https://www.cnki.com.cn/Article/CJFDTOTAL-FXSY201801018.htm He T Y, Zhang Y H, Hu Z W. Determination of 22 elements in soil by ICP-OES with microwave digestion[J]. Chinese Journal of Analysis Laboratory, 2018, 37(1): 84-87. https://www.cnki.com.cn/Article/CJFDTOTAL-FXSY201801018.htm
[3]	张更宇, 刘伟, 崔世荣, 等. 分类消解-电感耦合等离子体原子发射光谱法测定环境土壤中15种金属元素的含量[J]. 理化检验(化学分册), 2018, 54(4): 428-432. https://www.cnki.com.cn/Article/CJFDTOTAL-LHJH201804014.htm Zhang G Y, Liu W, Cui S Y, et al. Determination of 15 metal elements in soil by inductively coupled plasma atomic emission spectrometry[J]. Physical Testing and Chemical Analysis (Part B: Chemical Analysis), 2018, 54(4): 428-432. https://www.cnki.com.cn/Article/CJFDTOTAL-LHJH201804014.htm
[4]	乔军, 佟克兴, 李安. 电感耦合等离子体质谱(ICP-MS)法测定葡萄酒中的铜、镉、铅[J]. 中国无机分析化学, 2017, 7(4): 33-36. https://www.cnki.com.cn/Article/CJFDTOTAL-WJFX201704007.htm Qiao J, Tong K X, Li A. Determination of copper, cadmium, lead in wine by inductively coupled plasma-mass spectrometry (ICP-MS)[J]. Chinese Journal of Inorganic Analytical Chemistry, 2017, 7(4): 33-36. https://www.cnki.com.cn/Article/CJFDTOTAL-WJFX201704007.htm
[5]	宋阳, 李现忠, 黄文氢, 等. ICP-MS技术在石油化工中的应用[J]. 石油化工, 2016, 45(10): 1279-1287. https://www.cnki.com.cn/Article/CJFDTOTAL-SYHG201610025.htm Song Y, Li X Z, Huang W Q, et al. Application of ICP-MS in petrochemical industry[J]. Petrochemical Technology, 2016, 45(10): 1279-1287. https://www.cnki.com.cn/Article/CJFDTOTAL-SYHG201610025.htm
[6]	赵志南, 严冬, 何群华, 等. ICP-MS测定《全国土壤污染状况详查》项目中14种元素[J]. 环境化学, 2017, 36(2): 448-452. https://www.cnki.com.cn/Article/CJFDTOTAL-HJHX201702028.htm Zhao Z N, Yan D, He Q H, et al. Determination of 14 elements in China Soil Pollution Survey by ICP-MS[J]. Environmental Chemistry, 2017, 36(2): 448-452. https://www.cnki.com.cn/Article/CJFDTOTAL-HJHX201702028.htm
[7]	张保科, 温宏利, 王蕾, 等. 封闭压力酸溶-盐酸提取-电感耦合等离子体质谱法测定地质样品中的多元素[J]. 岩矿测试, 2011, 30(6): 737-744. http://www.ykcs.ac.cn/article/id/ykcs_20110615 Zhang B K, Wen H L, Wang L, et al. Determination of multiple elements in geological samples by closed pressure acid solution-hydrochloric acid extraction inductively coupled plasma-mass spectrometry[J]. Rock and Mineral Analysis, 2011, 30(6): 737-744. http://www.ykcs.ac.cn/article/id/ykcs_20110615
[8]	戴冠苹, 高敬铭, 张红云, 等. ICP-MS和GFAAS测定粮食中镉的对比研究[J]. 粮油食品科技, 2018, 26(4): 36-39. https://www.cnki.com.cn/Article/CJFDTOTAL-SYKJ201804009.htm Dai G P, Gao J M, Zhang H Y, et al. Comparative study on the determination of cadmium in grain by ICP-MS and GFAAS[J]. Science and Technology of Cereals, Oils and Foods, 2018, 26(4): 36-39. https://www.cnki.com.cn/Article/CJFDTOTAL-SYKJ201804009.htm
[9]	徐迪伟, 陈荣乐. ICP-MS检测饮用水中31种元素的方法研究[J]. 中国卫生检验杂志, 2018, 27(19): 2761-2764. https://www.cnki.com.cn/Article/CJFDTOTAL-ZWJZ201719006.htm Xu D W, Chen R L. Study on the determination of 31 metal elements in drinking water by inductively coupled plasma-mass spectrometry[J]. Chinese Journal of Health Laboratory Technology, 2018, 27(19): 2761-2764. https://www.cnki.com.cn/Article/CJFDTOTAL-ZWJZ201719006.htm
[10]	鲁淼娟, 凌飞, 柳展飞. 电感耦合等离子体质谱法测定水中20种金属元素[J]. 能源环境保护, 2016, 30(4): 56-58. https://www.cnki.com.cn/Article/CJFDTOTAL-NYBH201606016.htm Lu M J, Ling F, Liu Z F. Study on determination of 20 kinds of elements in the water by ICP-MS[J]. Energy Environmental Protection, 2016, 30(4): 56-58. https://www.cnki.com.cn/Article/CJFDTOTAL-NYBH201606016.htm
[11]	王静, 王鑫, 耿哲, 等. 碰撞池-电感耦合等离子体质谱测定海水重金属[J]. 环境工程学报, 2016, 10(4): 2139-2143. https://www.cnki.com.cn/Article/CJFDTOTAL-HJJZ201604089.htm Wang J, Wang X, Geng Z, et al. Determination of heavy metal in marine waters by collision cell inductively coupled plasma-mass spectrometry[J]. Chinese Journal of Environmental Engineering, 2016, 10(4): 2139-2143. https://www.cnki.com.cn/Article/CJFDTOTAL-HJJZ201604089.htm
[12]	王佳翰, 冯俊, 王达成, 等. 电感耦合等离子体质谱法测定地球化学样品中钼镉钨铀锡[J]. 冶金分析, 2017, 37(6): 20-25. https://www.cnki.com.cn/Article/CJFDTOTAL-YJFX201706004.htm Wang J H, Feng J, Wang D C, et al. Determination of molybdenum, cadmium, tungsten, uranium and tin in geochemical samples by inductively coupled plasma-mass spectrometry[J]. Metallurgical Analysis, 2017, 37(6): 20-25. https://www.cnki.com.cn/Article/CJFDTOTAL-YJFX201706004.htm
[13]	李刚, 曹小燕. 电感耦合等离子体质谱法测定地质样品中锗和镉的干扰及校正[J]. 岩矿测试, 2008, 27(3): 197-200. http://www.ykcs.ac.cn/article/id/ykcs_20080369 Li G, Cao X Y. Interference and its elimination in determination of germanium and cadmium in geological samples by inductively coupled plasma-mass spectrometry[J]. Rock and Mineral Analysis, 2008, 27(3): 197-200. http://www.ykcs.ac.cn/article/id/ykcs_20080369
[14]	孙朝阳, 董利明, 贺颖婷, 等. 电感耦合等离子体质谱法测定地质样品中钪镓锗铟镉铊时的干扰及其消除方法[J]. 理化检验(化学分册), 2016, 52(9): 1026-1030. https://www.cnki.com.cn/Article/CJFDTOTAL-LHJH201609007.htm Sun Z Y, Dong L M, He Y T, et al. Interference and elimination method of Sc, Ga, Ge, In, Cd, Tl in geological samples by inductively coupled plasma-mass spectrometry[J]. Physical Testing and Chemical Analysis (Part B: Chemical Analysis), 2016, 52(9): 1026-1030. https://www.cnki.com.cn/Article/CJFDTOTAL-LHJH201609007.htm
[15]	常学东. ICP-MS方法测定镉的干扰现象分析[J]. 新疆有色金属, 2011(6): 47-49. https://www.cnki.com.cn/Article/CJFDTOTAL-XJYS201106018.htm Chang X D. Analysis of interference phenomena in determination of cadmium by ICP-MS method[J]. Xinjiang Nonferrous Metals, 2011(6): 47-49. https://www.cnki.com.cn/Article/CJFDTOTAL-XJYS201106018.htm
[16]	罗策, 雷小燕, 黄永红, 等. 电感耦合等离子体质谱法测定锆及锆合金中镉含量的质谱干扰分析[J]. 分析科学学报, 2016, 32(4): 515-519. https://www.cnki.com.cn/Article/CJFDTOTAL-FXKX201604015.htm Luo C, Lei X Y, Huang Y H, et al. Determination of cadmium in zirconium and zirconium alloys by ICP-MS[J]. Journal of Analytical Science, 2016, 32(4): 515-519. https://www.cnki.com.cn/Article/CJFDTOTAL-FXKX201604015.htm
[17]	靳兰兰, 王秀季, 李会来, 等. 电感耦合等离子体质谱技术进展及其在冶金分析中的应用[J]. 冶金分析, 2016, 36(7): 1-14. https://www.cnki.com.cn/Article/CJFDTOTAL-YJFX201607001.htm Jin L L, Wang X J, Li H L, et al. Progress in inductively coupled plasma-mass spectrometry technology and its application in metallurgical analysis[J]. Metallurgical Analysis, 2016, 36(7): 1-14. https://www.cnki.com.cn/Article/CJFDTOTAL-YJFX201607001.htm
[18]	Jackson S L, Spence J, Janssen D J, et al. Determination of Mn, Fe, Ni, Cu, Zn, Cd and Pb in seawater using offline extraction and triple quadrupole ICP-MS/MS[J]. Journal of Analytical Atomic Spectrometry, 2018, 33: 304-313. doi: 10.1039/C7JA00237H
[19]	Luo M Y, Xing S, Yang Y G, et al. Sequential analyses of actinides in large-size soil and sediment samples with total sample dissolution[J]. Journal of Environmental Radioactivity, 2018, 187: 73-80. doi: 10.1016/j.jenvrad.2018.01.028
[20]	Taylor V F, Li Z G, Sayarath V, et al. Distinct arsenic metabolites following seaweed consumption in humans[J]. Scientific Reports, 2017, 7: 3920. doi: 10.1038/s41598-017-03883-7
[21]	Gondikas A, Kammer F, Kaegi R, et al. Where is the nano? Analytical approaches for the detection and quantification of TiO₂ engineered nanoparticles in surface waters[J]. Environmental Science Nano, 2018, 5: 313-326. doi: 10.1039/C7EN00952F
[22]	Thomas Z, Johan H K. Laser ablation Rb/Sr dating by online chemical separation of Rb and Sr in an oxygen-filled reaction cell[J]. Chemical Geology, 2016, 437: 120-133. doi: 10.1016/j.chemgeo.2016.05.027
[23]	Amr M A, Dawood N D A, Helal A I, et al. Rare earth elements and ¹⁴³Nd/¹⁴⁴Nd isotope ratio measurements using tandem ICP-CRC-MS/MS: Characterization of Date Palm (Phoenix Dactylifera L. )[J]. Journal of Analytical Atomic Spectrometry, 2017, 32: 1554-1565. doi: 10.1039/C7JA00126F
[24]	Pinheiro F C, Amaral C D B, Schiavo D, et al. Determination of arsenic in fruit juices using inductively coupled plasma-tandem mass spectrometry (ICP-MS/MS)[J]. Food Analytical Methods, 2017, 10(4): 992-998. doi: 10.1007/s12161-016-0663-7
[25]	Guo W, Jin L L, Hu S H, et al. Method development for the determination of total fluorine in foods by tandem ICP-mass spectrometry with mass-shift strategy[J]. Journal of Agricultural and Food Chemistry, 2017, 65(16): 3406-3412. doi: 10.1021/acs.jafc.7b00535
[26]	宋威, 胡长春. 电感耦合等离子体质谱法测定土壤中的镉[J]. 广州化工, 2018, 46(6): 95-96. https://www.cnki.com.cn/Article/CJFDTOTAL-GZHA201806035.htm Song W, Hu C C. Determination of cadmium in soil by inductively coupled plasma-mass spectrometry[J]. Guangzhou Chemical Industry, 2018, 46(6): 95-96. https://www.cnki.com.cn/Article/CJFDTOTAL-GZHA201806035.htm
[27]	乐淑葵, 段永梅. 电感耦合等离子体质谱法(ICP-MS)测定土壤中的重金属元素[J]. 中国无机分析化学, 2015, 5(3): 16-19. https://www.cnki.com.cn/Article/CJFDTOTAL-WJFX201503005.htm Le S K, Duan Y M. Determination of heavy metal elements in soil by ICP-MS[J]. Chinese Journal of Inorganic Analytical Chemistry, 2015, 5(3): 16-19. https://www.cnki.com.cn/Article/CJFDTOTAL-WJFX201503005.htm
[28]	侯鹏飞, 江冶, 曹磊. 无高氯酸常压酸溶-ICP-MS法同时测定土壤中的As, Cd, Pb, Cr, Zn, Cu, Ni[J]. 地质学刊, 2019, 43(1): 166-170. https://www.cnki.com.cn/Article/CJFDTOTAL-JSDZ201901026.htm Hou P F, Jiang Y, Cao L. Determination of As, Cd, Pb, Cr, Zn, Cu and Ni in soil by ICP-MS method without perchloric acid[J]. Journal of Geology, 2019, 43(1): 166-170. https://www.cnki.com.cn/Article/CJFDTOTAL-JSDZ201901026.htm
[29]	李自强, 李小英, 钟琦, 等. 电感耦合等离子体质谱法测定土壤重金属普查样品中铬铜镉铅的关键环节研究[J]. 岩矿测试, 2016, 35(1): 37-41. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.2016.01.007 Li Z Q, Li X Y, Zhong Q, et al. Determination of Cr, Cu, Cd and Pb in soil samples by inductively coupled plasma-mass spectrometry for an investigation of heavy metal pollution[J]. Rock and Mineral Analysis, 2016, 35(1): 37-41. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.2016.01.007
[30]	王妃, 王德淑, 汤德能. 浅析锡对电感耦合等离子体质谱法测定镉的干扰[J]. 中国无机分析化学, 2015, 5(2): 12-18. https://www.cnki.com.cn/Article/CJFDTOTAL-WJFX201502004.htm Wang F, Wang D S, Tang D N. Study on interference of tin in the determination of cadmium by inductively coupled plasma-mass spectrometry[J]. Chinese Journal of Inorganic Analytical Chemistry, 2015, 5(2): 12-18. https://www.cnki.com.cn/Article/CJFDTOTAL-WJFX201502004.htm
[31]	禹莲玲, 郭斌, 柳昭, 等. 电感耦合等离子体质谱法测定高锡地质样品中的痕量镉[J]. 岩矿测试, 2020, 39(1): 77-84. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.201906270094 Yu L L, Guo B, Liu Z, et al. Trace cadmium in geological samples with high content of tin determined by inductively coupled plasma-mass spectrometry[J]. Rock and Mineral Analysis, 2020, 39(1): 77-84. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.201906270094
[32]	王岚, 杨丽芳, 谭西早, 等. 膜去溶-电感耦合等离子体质谱法测定环境地质样品中的镉[J]. 岩矿测试, 2017, 36(6): 574-580. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.201703130032 Wang L, Yang L F, Tan X Z, et al. Determination of cadmium in environmental geological samples by inductively coupled plasma-mass spectrometry with desolvation[J]. Rock and Mineral Analysis, 2017, 36(6): 574-580. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.201703130032
[33]	马晓龙, 李刚, 李艳, 等. 碰撞反应池-电感耦合等离子体质谱法测定锆基合金中痕量镉[J]. 理化检验(化学分册), 2014, 50(3): 345-348. https://www.cnki.com.cn/Article/CJFDTOTAL-LHJH201403024.htm Ma X L, Li G, Li Y, et al. Determination of trace cadmium in zirconium-based alloys by impact reactor inductively coupled plasma-mass spectrometry[J]. Physical Testing and Chemical Analysis (Part B: Chemical Analysis), 2014, 50(3): 345-348. https://www.cnki.com.cn/Article/CJFDTOTAL-LHJH201403024.htm
[34]	徐进力, 邢夏, 唐瑞玲, 等. 动能歧视模式ICP-MS测定地球化学样品中14种痕量元素[J]. 岩矿测试, 2019, 38(4): 394-402. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.201812070131 Xu J L, Xing X, Tang R L, et al. Determination of 14 trace elements in geochemical samples by ICP-MS using kinetic energy discrimination mode[J]. Rock and Mineral Analysis, 2019, 38(4): 394-402. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.201812070131
