Determination of Iodide in Groundwater by Suppressed Conductance-Ion Chromatography
-
摘要:
在无外来碘食物的环境下，水中碘含量是衡量人体碘摄入量的重要指标，因此准确测定饮用水中碘化物的含量对人类健康有着至关重要的作用。具有烷醇基季铵功能团的IonPac AS23色谱柱，具有较强亲水性，可在很宽的pH范围内(0~14)保持高容量，适于氢氧根淋洗液体系和碳酸根淋洗液体系，基于此，本文建立了一种抑制型电导-离子色谱法检测地下水中碘化物的方法。采用IonPac AS23型阴离子分析柱和IonPac AS23阴离子保护柱，50mmol/L的KOH淋洗液，其流速为1.2mL/min，抑制型电导检测器电流为125mA，对地下水中碘化物进行检测。该方法在8.980min出峰，方法检测限为0.5μg/L，方法标准曲线的相关性r=0.9998，线性范围较广(0.01~2mg/L)。该方法检测限更低、出峰时间更短，且不受水中7种无机阴离子的测定干扰，提高了氢氧根淋洗液体系下，烷醇基季铵功能团色谱柱AS23测定地下水中碘化物的准确度。
-
关键词:
- 离子色谱法 /
- AS23型阴离子分析柱 /
- 烷醇基季铵功能团 /
- 氢氧化钾淋洗液
Abstract:BACKGROUND In an environment without foreign iodine food, the iodine content of water is an important index to measure the iodine intake of the human body, so the accurate determination of iodide content in drinking water has a crucial role in human health. The detection limit of ion chromatography-amperometric detection method is generally lower than that of conductance detection method, and the sensitivity is higher. This method is suitable for the determination of trace iodide in water, but the apparent peak time is later than that of the conductance detection method. Under the same test conditions, for the ion chromatography-hydroxide eluent detection method for the determination of iodide in water, the peak time is obviously better than that of the carbonate body eluent detection method. Using carbonate eluent to analyze iodide requires adding toxic organic improvers, which is complicated, difficult to elute, has a long analysis time, high detection limit and low sensitivity.
OBJECTIVES IonPac AS23 column with alkanol-based quaternary ammonium functional group has strong hydrophilicity and can maintain high capacity in a wide pH range (0-14), which is suitable for hydroxide and carbonate leaching systems. Based on this, a method for the determination of iodide in groundwater by suppressed conduction-ion chromatography was developed.
METHODS IonPac AS23 (4mm×250mm) anion analysis column and IonPac AS23 anion protection column, Dionex AERS 500(4mm) anion inhibited conductivity detector, HPIC separation method, were used to detect iodide in groundwater with 50mmol/L KOH eluent (hydroxide eluent, the product after conductivity inhibition is zero conductivity water, providing an ideal conductivity baseline) at a flow rate of 1.2mL/min (the concentration and flow rate of the eluent increased, and the retention time was shortened) and a suppressive conductance detector current of 125mA (the current increased, the instrument detection sensitivity increased). The sample volume was 250μL, and the samples were filtered through a 0.45μm water microporous filter membrane. 10mL of initial filtrate was discarded, and about 10mL of subsequent filtrate was collected. After that the iodide in the groundwater samples was detected.
RESULTS The chromatographic peak separation was good, peak shape was symmetrical, and no trailing extension. The iodide peak emerged in 8.980min, the detection limit of the method was 0.5μg/L, the correlation coefficient of the calibration curve was 0.9998, and the linear range was wide (0. 01-2mg/L).
CONCLUSIONS This method has a lower detection limit than that of the existing standard method for the determination of iodide in water, shorter peak time, and the detection range is better than that of the existing ion chromatography method. The experimental results show that the peak time is faster than that reported by its predecessors. This method is used to determine iodide in groundwater and is not disturbed by seven inorganic anions (F-, Cl-, NO3-, NO2-, SO42-, PO43-, Br-) in water. This method improves the accuracy of the determination of iodide in groundwater by alkanol-based quaternary ammonium functional group column AS23 under the hydroxide eluent system.
-
-
表 1 离子色谱分离和检测方式的选择(无机阴离子)
Table 1. Selection of separation and detection methods of ion chromatography (inorganic anions)
检测方式 分离方式 测定离子 电导，UV 高效离子交换色谱(HPIC) 无机阴离子F-、Cl-、NO3-、NO2-、SO42-、PO43-、Br-等，低分子量有机酸 安培 高效离子排斥色谱(HPICE) SO32-、亚砷酸 电导 高效离子交换色谱(HPIC) 砷酸盐、硒酸盐、亚硒酸盐 电导 高效离子排斥色谱(HPICE) BO3-、CO32- 电导/安培 高效离子交换色谱(HPIC)，离子对色谱(MPIC) I-、BF4-、SCN-、ClO4-、S2O32- 电导/安培 高效离子排斥色谱(HPICE) CN-、HS-、高离子强度基体 电导 高效离子交换色谱(HPIC)，离子对色谱(MPIC) 金属络合物 电导，柱后衍生VIS 高效离子交换色谱(HPIC) 缩合磷酸盐多价螯合剂
下载: 导出CSV
表 2 现有水中碘化物标准检测方法检出限、测定范围及适用范围汇总
Table 2. Summary of detection limits, determination ranges and applicable ranges of existing standard methods for iodide detection in water
标准名称 检测方法 检测限 测定范围 样品适用范围 《生活饮用水标准检验方法无机非金属指标》(GB/T 5750.5—2006)，《食品安全国家标准饮用天然矿泉水检验方法》(GB 8538—2022) 硫酸铈催化比色法 1μg/L 低浓度：1~10μg/L
高浓度：10~100μg/L生活饮用水及其水源水，饮用天然矿泉水 高浓度碘化物比色法 0.05mg/L 0.05~0.1mg/L 气相色谱法 1μg/L 1~10μg/L，10~100μg/L 《生活饮用水标准检验方法无机非金属指标》(GB/T 5750.5—2006) 高浓度碘化物容量法 0.025mg/L / 生活饮用水及其水源水 《地下水质分析方法第56部分碘化物的测定淀粉分光光度法》(DZ/T 0064.56—2021) 淀粉比色法 25μg/L 25~500μg/L 地下水 《地下水质分析方法第55部分碘化物的测定催化还原分光光度法》(DZ/T 0064.55—2021) 催化还原法 1μg/L 1~16μg/L 地下水 《食品安全国家标准饮用天然矿泉水检验方法》(GB 8538—2022) 离子色谱法 10.25μg/L 0.25~100μg/L 饮用天然矿泉水 《水质碘化物的测定离子色谱法》(HJ 778—2017) 离子色谱法 0.002mg/L 0.01~1mg/L 地表水和地下水
下载: 导出CSV
表 3 方法精密度和回收率
Table 3. Precision and recovery results of the method
DXS01-16
样品I-测定值
(μg/L)加标低测定结果
(0.050mg/L)加标中测定结果
(0.100mg/L)加标高测定结果
(1.00mg/L)DXS01-20
样品I-测定值
(μg/L)加标低测定结果
(0.050mg/L)加标中测定结果
(0.100mg/L)加标高测定结果
(1.00mg/L)平行测定值(mg/L) ND 0.0435 0.1090 1.046 平行测定值(mg/L) ND 0.0455 0.1040 1.042 ND 0.0444 0.1030 1.049 ND 0.0464 0.1040 1.043 ND 0.0442 0.1019 1.044 ND 0.0432 0.1039 1.046 ND 0.0466 0.1043 1.042 ND 0.0476 0.1043 1.046 ND 0.0454 0.1015 1.043 ND 0.0434 0.1055 1.044 ND 0.0477 0.0995 1.049 ND 0.0467 0.1059 1.044 平均值(mg/L) ND 0.045 0.103 1.04 平均值(mg/L) ND 0.045 0.105 1.04 标准偏差(mg/L) － 0.0016 0.0033 0.0030 标准偏差(mg/L) － 0.0018 0.0008 0.0016 RSD(%) － 3.50 3.15 0.29 RSD(%) － 3.97 0.83 0.15 加标量(μg) － 1.0 2.0 20.0 加标量(μg) － 1.0 2.0 20.0 平均加标回收率(%) － 90.0 103.0 104.0 平均加标回收率(%) － 90.0 105.0 104.0 注：ND表示检测结果低于方法检测限(0.5μg/L)，未检出。
下载: 导出CSV
-
