A study of the micro-macro-physical and mechanical properties of silty mudstone in the bottom drum section of a railway tunnel
-
摘要: 西南地区YD隧道在运营期间隧道底部多段发生隆起变形，造成无砟轨道板开裂，导致轨道结构受损不稳定，影响行车安全。为了探明其底鼓原因，现对底鼓段紫红色缓倾层状粉砂质泥岩进行微宏观工程特性研究，分析其对隧道底鼓的影响。采用室内试验的方法，对该处粉砂质泥岩的物质组成成分、微观结构、膨胀性、抗剪抗压强度、压缩变形等围岩性质开展全面试验，并对围岩地应力、水文地质条件进行现场调查。试验和调查结果表明：研究区围岩根据岩石质量评价标准可以判定为Ⅳ级围岩；其岩石成分主要为伊利石、石英、绿泥石等，不含蒙脱石这种膨胀性黏土矿物，自由膨胀率最大为1.96%，不具备膨胀性；岩石的层理面上分布有2~8 μm大小的孔隙，岩石内部存在长度为3~8 μm的原生裂纹；岩石的单轴饱和抗压强度为11.3~21.8 MPa，属于较软岩；岩石的物理力学参数受含水量的影响较大，随着含水量的增加，内聚力缩减50%，抗压强度缩减了45%~55%，弹性模量缩减了50%。研究结果显示研究区岩体在水理作用下岩石强度会大幅度降低，但不含膨胀性矿物，不具备膨胀性。且根据现场监测，地下水位无变化，因此地下水和膨胀性不是隧道底鼓的直接诱因。Abstract: During the operation of the southwestern YD tunnel, heaving appeared in multiple sections at the bottom of the tunnel, which caused the ballastless track slab to crack, resulting in damage and instability to the track structure and affecting the driving safety. The bottom drum of a tunnel is of strong regional characteristics, and the causes of the bottom drum are various. Studies at home and abroad can only discuss some tunnels. In order to find out the cause of the floor structure heaving, the micro-macro-engineering characteristics of the purplish red gently dipping layered silty mudstone in the floor structure heaving section are examined, and its influence on the tunnel floor structure heaving is analyzed. The laboratory experiment method is used to conduct comprehensive experiments on the surrounding rock properties such as the material compositions, microstructure, swelling, shear compressive strength, compression deformation of the silt mudstone, and the ground stress and hydrogeological conditions of the surrounding rock. Experiments and investigations show that the surrounding rocks in the study area can be judged as grade IV surrounding rocks according to rock quality evaluation standards. Its rocks are mainly composed of illite, quartz, chlorite, etc. It does not contain swelling clay minerals such as montmorillonite. There are pores with a size ranging from 2 to 8 μm on the bedding plane of the rock, and there are primary cracks with a length of 3~8 μm inside the rock. The uniaxial saturated compressive strength of the rock ranges from 11.3 to 21.8 MPa, and the rock belong to softer rocks. The physical and mechanical parameters of the rocks are greatly affected by water content. As the water content increases, the cohesion decreases by 50%, the compressive strength decreases by 45%~55%, and the elastic modulus decreases by 50%. The rock mass in the study area does not contain swellable minerals and is not expansive. At the same time, the groundwater level has not changed through on-site monitoring, so groundwater and expansion are not the direct inducements of the tunnel bottom drum. In short, the geological characteristics of the surrounding rocks of the tunnel are complex and special, and the cause of the tunnel bottom drum is not necessarily single. For the analysis of a tunnel bottom drum, multiple angles need to be analyzed.
-
Key words:
- railway tunnel /
- floor structure heaving /
- material composition /
- microstructure /
- expansion
-
-
[1] 谢勇谋. 国道317线鹧鸪山隧道施工地质预报研究[D]. 成都:成都理工大学, 2004.[XIE Y M. Cnostruction geology prediction research on Zhegu-mountain tunnel of 317 national highway[D]. Chengdu:Chengdu University of Technology, 2004.(in Chinese)]
[2] 张洋. 隧道工程软弱围岩大变形控制体系研究[D]. 成都:西南交通大学, 2006.[ZHANG Y. Research on the controlling system of large deformation in the soft rock tunnel[D]. Chengdu:Southwest Jiaotong University, 2006.(in Chinese)]
[3] 张后全, 韩立军, 贺永年, 等. 构造复杂区域膨胀软岩巷道底鼓控制研究[J]. 采矿与安全工程学报, 2011, 28(1):16-21.[ZHANG H Q, HAN L J, HE Y N, et al. Floor heave control in roadways with soft-and-swelling rocks in complicated structural area[J]. Journal of Mining & Safety Engineering, 2011, 28(1):16-21.(in Chinese)]
[4] 曲永新, 陈历鸿, 金春山. 膨胀岩学术讨论会概况[J]. 水文地质工程地质, 1986, 13(6):12-13.[QU Y X, CHEN L H, JIN C S. Overview of swelling rock symposium[J]. Hydrogeology & Engineering Geology, 1986, 13(6):12-13.(in Chinese)]
[5] 姜耀东, 赵毅鑫, 刘文岗, 等. 深部开采中巷道底鼓问题的研究[J]. 岩石力学与工程学报, 2004, 23(14):2396-2401.[JIANG Y D, ZHAO Y X, LIU W G, et al. Research on floor heave of roadway in deep mining[J]. Chinese Journal of Rock Mechanics and Engineering, 2004, 23(14):2396-2401.(in Chinese)]
[6] 薛晓辉, 张军, 宿钟鸣, 等. 武都西隧道底鼓机理及防治措施研究[J]. 公路工程, 2015, 40(5):124-128.[XUE X H, ZHANG J, SU Z M, et al. Study on mechanism and prevention measures of floor heave in Wuduxi tunnel[J]. Highway Engineering, 2015, 40(5):124-128.(in Chinese)]
[7] 腾俊洋, 唐建新. 层状炭质页岩隧道底鼓机理分析[J]. 铁道科学与工程学报, 2017, 14(1):110-116.[TENG J Y, TANG J X. Mechanism analysis of floor heave in layered carbonaceous shale tunnel[J]. Journal of Railway Science and Engineering, 2017, 14(1):110-116.(in Chinese)]
[8] 樊纯坛. 大断面富水泥岩隧道受力特性及仰拱底鼓机理研究[D]. 兰州:兰州交通大学, 2017.[FAN C T. Research on mechanical characteristics of large-section cement-rich rock tunnel and mechanism of bottom arch drum[D]. Lanzhou:Lanzhou Jiatong University, 2017.(in Chinese)]
[9] 王进博. 水平页岩隧道底鼓机理及控制技术研究[D]. 重庆:重庆大学, 2017.[WANG J B. Mechanism and disposal technology of floor heave in horizontal shale tunnel[D]. Chongqing:Chongqing University, 2017.(in Chinese)]
[10] HEUZE F E. High-temperature mechanical, physical and Thermal properties of granitic rocks-A review[J]. International Journal of Rock Mechanics and Mining Sciences & Geomechanics Abstracts, 1983, 20(1):3-10.
[11] Suggested methods for determining the strength of rock materials in triaxial compression:Revised version[J]. International Journal of Rock Mechanics and Mining Sciences & Geomechanics Abstracts, 1983,20(6):285-290.
[12] 王立川, 肖小文, 林辉. 某铁路隧道底部结构隆起病害成因分析及治理对策探讨[J]. 隧道建设, 2014, 34(9):823-836.[WANG L C, XIAO X W, LIN H. Analysis on causes for and renovation of floor structure of a high-speed railway tunnel located in slightly-dipping interbedded rock mass[J]. Tunnel Construction, 2014, 34(9):823-836.(in Chinese)]
[13] 孙良倩. 甘肃天水地区新近系泥岩工程特性试验研究[J]. 隧道建设(中英文), 2017, 37(增刊2):54-59.[SUN L Q. Experimental study of engineering properties of Neogene mudstone in Tianshui, Gansu[J]. Tunnel Construction, 2017, 37(Sup 2):54-59.(in Chinese)]
[14] 郑清松. 龙泉山红层砂岩微结构对其工程力学性质的影响研究[D]. 成都:西南交通大学, 2016.[ZHENG Q S. Research on the influence of microstructure of red beds sandstone on its engineering mechanical properties in Longquan mountain area[D]. Chengdu:Southwest Jiaotong University, 2016.(in Chinese)]
[15] 中华人民共和国铁道部.铁路工程岩石试验规程:TB 10115-2014[S].北京:中国铁道出版社,2015.[Ministry of Railways of the People's Republic of China. Railway engineering rock test regulations:TB 10115-2014)[S]. Beijing:China Railway Publishing House, 2015.(in Chinese)]
[16] 黄宏伟, 车平. 泥岩遇水软化微观机理研究[J]. 同济大学学报(自然科学版), 2007, 35(7):866-870.[HUANG H W, CHE P. Research on micro-mechanism of softening and argillitization of mudstone[J]. Journal of Tongji University (Natural Science), 2007, 35(7):866-870.(in Chinese)]
[17] 孙小明, 武雄, 何满潮, 等. 强膨胀性软岩的判别与分级标准[J]. 岩石力学与工程学报, 2005, 24(1):128-132.[SUN X M, WU X, HE M C, et al. Differentiation and grade criterion of strong swelling soft rock[J]. Chinese Journal of Rock Mechanics and Engineering, 2005, 24(1):128-132.(in Chinese)]
[18] 刘长武, 陆士良. 泥岩遇水崩解软化机理的研究[J]. 岩土力学, 2000, 21(1):28-31.[LIU C W, LU S L. Research on mechanism of mudstone degradation and softening in water[J]. Rock and Soil Mechanics, 2000, 21(1):28-31.(in Chinese)]
[19] 郭永春, 谢强, 文江泉. 红层特殊岩土化学性质工程判别准则试验研究[J]. 水文地质工程地质, 2009, 36(6):85-88.[GUO Y C, XIE Q, WEN J Q. Experimental study of the engineering criterion of the chemical stability of red beds rock[J]. Hydrogeology & Engineering Geology, 2009, 36(6):85-88.(in Chinese)]
[20] 中华人民共和国铁道部.铁路工程特殊岩土勘察规程:TB 10038-2012[S].北京:中国铁道出版社,2012.[Ministry of Railways of the People's Republic of China. Special Geotechnical Investigation Procedures for Railway Engineering:TB 10038-2012[S]. Beijing:China Railway Publishing House, 2012.(in Chinese)]
[21] 谢云鹏, 陈秋南, 黄小城, 等. 深埋隧道炭质板岩微观结构及单轴压缩试验研究[J]. 水文地质工程地质, 2020, 47(1):96-102.[XIE Y P, CHEN Q N, HUANG X C, et al. An experimental study of microstructure and uniaxial compression test of carbonaceous slate in a deep buried tunnel[J]. Hydrogeology & Engineering Geology, 2020, 47(1):96-102.(in Chinese)]
[22] 袁广祥, 张路青, 曾庆利, 等. 花岗岩矿物组成与其单轴抗压强度的相关性研究[J]. 水文地质工程地质, 2018, 45(5):93-100.[YUAN G X, ZHANG L Q, ZENG Q L, et al. Correlation of the mineralogical characteristics with the uniaxial compressive strength of granite[J]. Hydrogeology & Engineering Geology, 2018, 45(5):93-100.(in Chinese)]
[23] 国家铁路局.铁路隧道设计规范:TB 10003-2005[S].北京:中国铁道出版社,2005.[National Railway Administration. Design specification for railway tunnels:TB 10003-2005[S]. Beijing:China Railway Publishing House, 2005.(in Chinese)]
[24] 中华人民共和国住房和城乡建设部.工程岩体分级标准:GB/T 50218-2014[S]. 北京:中国计划出版社,2014.[Ministry of Housing and Urban-Rural Development of the People's Republic of China. Engineering rock mass classification standard:GB/T 50218-2014[S].Beijing:China Planning Press, 2014.(in Chinese)]
-
