Field test on the construction deformation characteristics for a loess highway tunnel at the shallow portal section
-
摘要:
以某黄土公路隧道工程为依托，借助现场测试方法研究浅埋洞口段黄土公路隧道地表沉降、拱顶下沉和周边收敛时态分布规律，并结合实测数据建立隧道施工变形统计分析预测模型。研究结果表明：（1）黄土隧道施工变形呈现显著的时间和空间效应，其时态分布曲线符合指数函数型发展规律；（2）地表沉降随时间呈增长趋势，约60 d后逐渐趋于稳定，其最大值（wmax）的统计变化范围为（−30.78～−105.20）mm；（3）横向地表沉降曲线分布呈凹槽形，沉降槽宽度约（3～5）倍隧道跨度（B），且隧道开挖引起的地层损失率为0.74%～3.08%；（4）拱顶下沉与周边收敛时态曲线可分为线性增长、持续变形和平稳发展3个阶段，且线性增长阶段占总变形量的60%以上；（5）vmax的统计值变化范围为（−17.1～−201.1）mm，其95%置信区间为[−51.53，−65.11]，umax的统计值变化范围为（−12.1～−122.0）mm，其95%置信区间为[−35.08，−43.39]，建议V级围岩黄土隧道预留变形量取值范围为（−100～−150）mm；（6）拱顶下沉与周边收敛速率时态曲线呈先急剧增加后逐渐衰减趋势，最终稳定后的拱顶下沉速率（Δv）和周边收敛速率（Δu）依次为（−0.05～−0.80）mm/d和（−0.02～−0.60）mm/d。
Abstract:Based on a loess highway tunnel project, the temporal distribution rules of ground settlement, vault settlement and peripheral convergence for the loess highway tunnel at shallow portal section are studied with the field test method, and the statistical analysis predictive model for the loess tunnel construction deformation is established combining with the actual measurement data. The results show that (1) the construction deformation of the loess tunnel presents significant time and spatial effects, and the temporal distribution curve can be expressed by an exponential function. (2) The ground settlement shows the growth movement with time, approaching stability after about 60 days, and the maximum ground settlement, wmax, ranges from −30.78 to −105.20 mm. (3) The transverse ground settlement curve is of the trough shape, the width of trough is around 3−5 times that ofB, and the ground loss rate caused by tunnel excavation ranges from 0.74% to 3.08%. (4) The vault settlement and peripheral convergence experiences successively three stages: linear growth stage, continuous deformation stage and steady development stage, and the deformation of linear growth stage accounts for more than 60% of total deformation. (5) The maximum vault settlement, vmax, ranges from −17.1 to −201.1 mm, and its variance estimation for sampling is [−51.53, −65.11] based on the 95% confidence interval. The maximum peripheral convergence, umax, ranges from −12.1 to −122.0 mm, and its variance estimation for sampling is [−35.08, −43.39] based on the 95% confidence interval. It is suggested that the reasonable reserved deformation values of grade Ⅴ surrounding rock loess tunnel range from −100 to −150 mm. (6) The rate curves of vault settlement and peripheral convergence increase first, and then decreases sharply with time. The steady displacement rate of vault settlement (Δv) and peripheral convergence (Δu) ranges from 0.05 to 0.80 mm/d and from 0.02 to 0.60 mm/d, respectively.
-
Key words:
- tunnel engineering /
- loess tunnel /
- shallow portal section /
- field test /
- deformation characteristic
-
-
表 1 隧道开挖引起的地表沉降（测点DB0）与时间的关系
Table 1. Fitting equations between ground settlement（point DB0）caused by tunnel excavation and time
测试断面 拟合函数：w（t）=a*exp（−t/b）+w0 R2 ZK86+515 w=304.32*exp（−t/162.97）−304.36 0.922 ZK87+625 w=27.09*exp（−t/23.86）−32.08 0.908 ZK87+630 w=25.15*exp（−t/13.55）−27.43 0.912 YK87+605 w=64.81*exp（−t/30.34）−57.35 0.978 YK87+610 w=51.59*exp（−t/23.24）−46.82 0.984
下载: 导出CSV
表 2 横向地表沉降分布曲线预测结果对比
Table 2. Comparison of the predicted results of transversal ground settlement
测试断面 拟合函数：w（x）=−a*exp（−x2/b） R2 最大地表沉降计算值wc/mm 最大地表沉降实测值wmax/mm wc/wmax i/m η/% ZK86+515 w=−111.28*exp（−x2/254.33） 0.958 111.28 105.20 1.058 11.28 3.08 ZK87+625 w=−34.31*exp（−x2/218.54） 0.903 34.31 34.85 0.985 10.45 0.88 ZK87+630 w=−32.95*exp（−x2/167.65） 0.931 32.95 30.78 1.071 9.16 0.74 YK87+605 w=−51.70*exp（−x2/128.43） 0.941 51.70 54.00 0.957 8.01 1.02 YK87+610 w=−47.67*exp（−x2/127.03） 0.787 47.67 47.18 1.010 7.97 0.93
下载: 导出CSV
表 3 隧道开挖引起的拱顶下沉与时间的关系
Table 3. Fitting equations between vault settlement caused by tunnel excavation and time
测试断面 拟合函数：v（t）=a*exp（−t/b）+v0 R2 ZK86+610 v=50.49*exp（−t/6.75）−49.57 0.998 ZK86+715 v=47.73*exp（−t/8.00）−46.96 0.998 YK86+630 v=37.95*exp（−t/7.94）−40.80 0.962 YK86+670 v=51.17*exp（−t/7.06）−50.56 0.998 ZK87+485 v=64.22*exp（−t/8.36）−59.82 0.984 ZK87+625 v=29.21*exp（−t/26.39）−32.09 0.979 YK87+385 v=76.46*exp（−t/13.79）−81.24 0.979 YK87+610 v=22.07*exp（−t/15.27）−24.33 0.979
下载: 导出CSV
-
[1] 江金硕, 李荣建, 刘军定, 等. 基于黄土联合强度的黄土隧道围岩应力及位移研究[J]. 岩土工程学报,2019,41(增刊2):189 − 192. [JIANG Jinshuo, LI Rongjian, LIU Junding, et al. Stress and displacement of surrounding rock of loess tunnels based on joint strength[J]. Chinese Journal of Geotechnical Engineering,2019,41(Sup2):189 − 192. (in Chinese with English abstract)
[2] 干啸洪, 陈立平, 张素磊, 等. 浅埋偏压隧道地表沉降规律及其预测方法[J]. 现代隧道技术,2019,56(2):78 − 84. [GAN Xiaohong, CHEN Liping, ZHANG Sulei, et al. On law of ground settlements and its prediction method for the shallow-buried tunnel under asymmetrical pressures[J]. Modern Tunnelling Technology,2019,56(2):78 − 84. (in Chinese with English abstract)
[3] 李骏, 邵生俊, 李国良, 等. 黄土隧道的湿陷变形规律及其对衬砌结构的作用[J]. 岩石力学与工程学报,2018,37(1):251 − 260. [LI Jun, SHAO Shengjun, LI Guoliang, et al. Collapse deformation of loess tunnel and its effect[J]. Chinese Journal of Rock Mechanics and Engineering,2018,37(1):251 − 260. (in Chinese with English abstract)
[4] 胡炜, 谭信荣, 蒋尧, 等. 深埋顺层偏压隧道围岩破坏机理及规律研究—以郑万线某隧道为例[J]. 水文地质工程地质,2020,47(3):60 − 68. [HU Wei, TAN Xinrong, JIANG Yao, et al. A study of the mechanism and regularity of failures in the surrounding rock of a deep buried bias tunnel embedded in geologically bedding strata: taking one tunnel of the Zhengwan line as an example[J]. Hydrogeology & Engineering Geology,2020,47(3):60 − 68. (in Chinese with English abstract)
[5] 董林, 王兰民, 夏坤, 等. 原状黄土遇水及饱和后软化特征研究[J]. 水文地质工程地质,2016,43(3):148 − 152. [DONG Lin, WANG Lanmin, XIA Kun, et al. A study of soften characteristics of wet and saturated loess[J]. Hydrogeology & Engineering Geology,2016,43(3):148 − 152. (in Chinese with English abstract)
[6] 陈建勋, 王梦恕, 轩俊杰, 等. 两车道公路黄土隧道变形规律[J]. 交通运输工程学报,2012,12(3):9 − 18. [CHEN Jianxun, WANG Mengshu, XUAN Junjie, et al. Deformation rule of loess highway tunnel with two lanes[J]. Journal of Traffic and Transportation Engineering,2012,12(3):9 − 18. (in Chinese with English abstract) doi: 10.3969/j.issn.1671-1637.2012.03.005
[7] 乔雄, 陈建勋, 王梦恕. 黄土公路隧道洞口段变形规律测试研究[J]. 岩石力学与工程学报,2013,32(增刊2):3552 − 3556. [QIAO Xiong, CHEN Jianxun, WANG Mengshu. Test study of deformation law of entrance section for loess highway tunnel[J]. Chinese Journal of Rock Mechanics and Engineering,2013,32(Sup2):3552 − 3556. (in Chinese with English abstract)
[8] 扈世民, 张顶立, 郭婷, 等. 大断面黄土隧道变形特征分析[J]. 铁道学报,2012,34(8):117 − 122. [HU Shimin, ZHANG Dingli, GUO Ting, et al. Analysis on deformation characteristics of large-section loess tunnel[J]. Journal of the China Railway Society,2012,34(8):117 − 122. (in Chinese with English abstract) doi: 10.3969/j.issn.1001-8360.2012.08.018
[9] 李志清, 丁春林, 窦世学, 等. 大断面浅埋黄土隧道围岩变形特性分析[J]. 地下空间与工程学报,2014,10(增刊1):1623 − 1628. [LI Zhiqing, DING Chunlin, DOU Shixue, et al. Analysis on deformation characteristics of surrounding rock in large section shallow loess tunnels[J]. Chinese Journal of Underground Space and Engineering,2014,10(Sup1):1623 − 1628. (in Chinese with English abstract)
[10] 孟德鑫, 谭忠盛. 大断面黄土隧道变形控制技术及支护受力特征[J]. 土木工程学报,2015,48(增刊1):383 − 387. [MENG Dexin, TAN Zongsheng. Deformation control technology and supporting structure stress of large section loess tunnel[J]. China Civil Engineering Journal,2015,48(Sup1):383 − 387. (in Chinese with English abstract)
[11] 赖金星, 樊浩博, 来弘鹏, 等. 软弱黄土隧道变形规律现场测试与分析[J]. 岩土力学,2015,36(7):2003 − 2012. [LAI Jinxing, FAN Haobo, LAI Hongpeng, et al. In-situ monitoring and analysis of tunnel deformation law in weak loess[J]. Rock and Soil Mechanics,2015,36(7):2003 − 2012. (in Chinese with English abstract)
[12] 孔庆祥. 铁路黄土隧道变形规律及建设管理要点研究[J]. 现代隧道技术,2019,56(2):18 − 23. [KONG Qingxiang. Study on deformation law and key points of construction management of loess tunnels[J]. Modern Tunnelling Technology,2019,56(2):18 − 23. (in Chinese with English abstract)
[13] 尚海松, 曹海静, 周济兵. 蒙华铁路隧道施工变形监测数据统计分析[J]. 现代隧道技术,2019,56(增刊1):66 − 72. [SHANG Haisong, CAO Haijing, ZHOU Jibing. Statistical analysis of monitored deformation data of Menghua railway tunnels during construction[J]. Modern Tunnelling Technology,2019,56(Sup1):66 − 72. (in Chinese with English abstract)
[14] 周鹏, 高金仓, 李磊, 等. 穿越陡坎地形的偏压黄土隧道大变形时空特征研究[J]. 隧道建设(中英文),2020,40(5):652 − 659. [ZHOU Peng, GAO Jincang, LI Lei, et al. Temporal and spatial characteristics of large deformation of unsymmetrically-pressured loess tunnel passing through scarp terrain[J]. Tunnel Construction,2020,40(5):652 − 659. (in Chinese with English abstract)
[15] 刘小伟, 原鹏博, 谌文武, 等. Q2饱和黄土隧洞围岩变形特征研究[J]. 冰川冻土,2019,41(6):1422 − 1429. [LIU Xiaowei, YUAN Pengbo, CHEN Wenwu, et al. Study on characteristic of deformation of Q2 saturated loess tunnel's surrounding rock[J]. Journal of Glaciology and Geocryology,2019,41(6):1422 − 1429. (in Chinese with English abstract)
[16] 李明, 严松宏, 潘春阳, 等. 富水大断面黄土隧道开挖流固耦合效应分析[J]. 现代隧道技术,2019,56(4):81 − 88. [LI Ming, YAN Songhong, PAN Chunyang, et al. Analysis of fluid-solid coupling effect during excavation of the water-rich large-section loess tunnel[J]. Modern Tunnelling Technology,2019,56(4):81 − 88. (in Chinese with English abstract)
[17] 王道远, 袁金秀, 朱永全, 等. 硬塑-流塑浅埋黄土隧道变形特性及合理预留变形量模型试验研究[J]. 岩土力学,2019,40(10):3813 − 3822. [WANG Daoyuan, YUAN Jinxiu, ZHU Yongquan, et al. Model test study of deformation characteristics and reasonable reserved deformation of shallow-buried loess tunnel with hard-flow plastic[J]. Rock and Soil Mechanics,2019,40(10):3813 − 3822. (in Chinese with English abstract)
-
