An analysis of the stability of the spherical-cap shaped slope at the Five-hundred-meter Aperture Spherical radio Telescope (FAST), China
-
摘要:
中国科学院国家天文台500米口径球面射电望远镜（Five-hundred-meter Aperture Spherical radio Telescope, FAST）台址位于岩溶洼地内，开挖完成后的洼地边坡外形接近球冠型边坡，属于轴对称圆形凹坡，坡体由胶结的土石混合体和石灰岩组成，局部稳定性良好，整体稳定性有待评价。目前边坡整体稳定性评价通常采用基于平面应变假定的极限平衡法，由于未考虑边坡外形，该方法用于轴对称圆形凹坡稳定性的评价结果有偏差。为消除上述偏差，将轴对称圆形凹坡滑体划分为多个环形条块，考虑环形条块轴力的抗滑作用，提出了针对轴对称圆形凹坡的极限平衡法改进方法；并采用数值分析方法对改进后的简化Bishop法进行验证，结果表明改进后的简化Bishop法安全系数计算结果较未改进方法略有提高，与数值分析法结果基本一致。同时给出轴对称圆形凸坡的安全系数计算公式，计算结果表明圆形凸坡稳定性与直线形边坡较为接近。上述两种计算方法为类似外形的边坡稳定性评价提供了新的途径。
-
关键词:
- 国家天文台500米口径球面射电望远镜 /
- 球冠型边坡 /
- 轴对称圆形凹坡 /
- 极限平衡法 /
- 边坡稳定性
Abstract:The site of Five-hundred-meter Aperture Spherical radio Telescope is located in karst depression, and the depression slope shape after excavation is like a spherical cap shape slope which belongs to an axisymmetric circular concave slope. The slope is composed of cemented soil-rock mixture and limestone. The slope is locally stable, but the stability of slope in a whole is still unknown. At present, evaluation of the slope stability in a whole is usually using the limit equilibrium method which is based on plane strain, and error arises in the evaluation results of the axisymmetric circular concave slope because of ignoring the slope shape. To eliminate the error, the slide body of the axisymmetric circular concave slope is divided into many annulus slices in the study, the anti-slide capacity of annulus slices axial force is considered and the improved limit equilibrium method which is suitable to the axisymmetric circular concave slope is proposed. The improved simplified Bishop method is verified with the numerical analysis method. The results show that the safety factor of the improved simplified Bishop method is a little larger than that with the traditional calculation method, and the safety factor of the improved simplified Bishop method is close to the numerical method result. The safety factor equation of the axisymmetric circular convex slope is given, and the results show that the stability of the axisymmetric circular convex slope is close to that of the ordinary slope. The above two calculation methods may provide new ways to evaluate the stability of slope with similar slope shape.
-
-
表 1 10 m高度边坡土体参数
Table 1. Soil parameters of slope with a height of 10 m
土层 容重/（kN·m−3） 黏聚力/kPa 内摩擦角/（°） 弹性模量/MPa 泊松比 土体 20 15 30 100 0.35 岩体 26.51 1500 35 10000 0.2
下载: 导出CSV
表 2 30 m高度边坡土体参数
Table 2. Soil parameters of slope with a height of 30 m
土层 容重/（kN·m−3） 黏聚力/kPa 内摩擦角/（°） 弹性模量/MPa 泊松比 土体 22 40 39.6 100 0.35 岩石 26.51 1500 35 10000 0.2
下载: 导出CSV
-
[1] FELLENIUS W. Erdstatische berechnungen[M]. Berlin: Ernst and Sohn, 1927.
[2] BISHOP A W. The use of the slip circle in the stability analysis of slopes[J]. Géotechnique,1955,5(1):7 − 17.
[3] JANBU N. Slope stability computations[C]// Proceedings of embankment dam engineering. New York: John Wiley & Sons, 1973: 47-86.
[4] 郑颖人, 杨明成. 边坡稳定安全系数求解格式的分类统一[J]. 岩石力学与工程学报,2004,23(16):2836 − 2841. [ZHENG Yingren, YANG Mingcheng. Classification unification of calculation formulation for safety factor of slope stability[J]. Chinese Journal of Rock Mechanics and Engineering,2004,23(16):2836 − 2841. (in Chinese with English abstract) doi: 10.3321/j.issn:1000-6915.2004.16.031
[5] 麻官亮, 邵玉刚. 基于Spencer法的三维极限平衡边坡稳定性研究[J]. 水文地质工程地质,2016,43(3):118 − 123. [MA Guanliang, SHAO Yugang. Study on three-dimensional limit equilibrium for slope stability based on Spencer method[J]. Hydrogeology & Engineering Geology,2016,43(3):118 − 123. (in Chinese with English abstract)
[6] DRUCKER D C, PRAGER W, GREENBERG H J. Extended limit design theorems for continuous media[J]. Quarterly of Applied Mathematics,1952,9(4):381 − 389. doi: 10.1090/qam/45573
[7] DRUCKER D C, PRAGER W. Soil mechanics and plastic analysis or limit design[J]. Quarterly of Applied Mathematics,1952,10(2):157 − 165. doi: 10.1090/qam/48291
[8] CHEN W F. Limit analysis and soil plasticity[M]. Amsterdam:Elsevier Science, 1975.
[9] 陈祖煜. 土力学经典问题的极限分析上、下限解[J]. 岩土工程学报,2002,24(1):1 − 11. [CHEN Zuyu. Limit analysis for the classic problems of soil mechanics[J]. Chinese Journal of Geotechnical Engineering,2002,24(1):1 − 11. (in Chinese with English abstract) doi: 10.3321/j.issn:1000-4548.2002.01.001
[10] 闫金凯, 马娟, 冯春. FAST台址巨石混合体边坡开挖稳定性分析[J]. 中国地质灾害与防治学报,2012,23(2):25 − 29. [YAN Jinkai, MA Juan, FENG Chun. Stability analysis of large rock mixture slope under excavation in FAST location[J]. The Chinese Journal of Geological Hazard and Control,2012,23(2):25 − 29. (in Chinese with English abstract) doi: 10.3969/j.issn.1003-8035.2012.02.005
[11] 宋二祥. 土工结构安全系数的有限元计算[J]. 岩土工程学报,1997,19(2):1 − 7. [SONG Erxiang. Finite element analysis of safety factor for soil structures[J]. Chinese Journal of Geotechnical Engineering,1997,19(2):1 − 7. (in Chinese with English abstract) doi: 10.3321/j.issn:1000-4548.1997.02.001
[12] 陈晓洋, 张宏阳, 冀东, 等. 重庆某不稳定斜坡变形监测及稳定性分析[J]. 地质力学学报,2011,17(4):402 − 409. [CHEN Xiaoyang, ZHANG Hongyang, JI Dong, et al. Deformation monitoring and stability analysis of an unstable slope in Chongqing City[J]. Journal of Geomechanics,2011,17(4):402 − 409. (in Chinese with English abstract) doi: 10.3969/j.issn.1006-6616.2011.04.010
[13] 邓琴, 郭明伟, 李春光, 等. 基于边界元法的边坡矢量和稳定分析[J]. 岩土力学,2010,31(6):1971 − 1976. [DENG Qin, GUO Mingwei, LI Chunguang, et al. Vector sum method for slope stability analysis based on boundary element method[J]. Rock and Soil Mechanics,2010,31(6):1971 − 1976. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-7598.2010.06.049
[14] 侯连成, 王笑二, 王家伟, 等. 基于强度折减法的某变电所边坡稳定性分析[J]. 水文地质工程地质,2012,39(1):72 − 74. [HOU Liancheng, WANG Xiaoer, WANG Jiawei, et al. Slope stability analysis for a substation based on strength reduction[J]. Hydrogeology & Engineering Geology,2012,39(1):72 − 74. (in Chinese with English abstract)
[15] 赵尚毅, 郑颖人, 时卫民, 等. 用有限元强度折减法求边坡稳定安全系数[J]. 岩土工程学报,2002,24(3):343 − 346. [ZHAO Shangyi, ZHENG Yingren, SHI Weimin, et al. Analysis on safety factor of slope by strength reduction FEM[J]. Chinese Journal of Geotechnical Engineering,2002,24(3):343 − 346. (in Chinese with English abstract) doi: 10.3321/j.issn:1000-4548.2002.03.017
[16] 陈子玉, 宋彦辉, 严豪, 等. 双参数强度折减法研究中存在的问题分析[J]. 水文地质工程地质,2019,46(2):125 − 132. [CHEN Ziyu, SONG Yanhui, YAN Hao, et al. Analyses of the existing problems in the double parameters reduction method[J]. Hydrogeology & Engineering Geology,2019,46(2):125 − 132. (in Chinese with English abstract)
[17] 徐明, 宋二祥, 沈志平, 等. FAST大型岩溶洼地场地岩土治理关键技术研究[J]. 土木工程学报,2019,52(3):87 − 99. [XU Ming, SONG Erxiang, SHEN Zhiping, et al. Key techniques in geotechnical treatment of a large karst depression for FAST[J]. China Civil Engineering Journal,2019,52(3):87 − 99. (in Chinese with English abstract)
[18] 刘蕾, 闫金凯, 陈亮, 等. 巨石混合体力学性质的数值试验分析[J]. 中国地质灾害与防治学报,2014,25(1):108 − 114. [LIU Lei, YAN Jinkai, CHEN Liang, et al. Numerical simulation on mechanical characteristics of large rock fragment mixture[J]. The Chinese Journal of Geological Hazard and Control,2014,25(1):108 − 114. (in Chinese with English abstract)
[19] 王家臣, 杜竞中. 水平凸型边坡破坏分析[J]. 中国矿业大学学报,1992,21(2):102 − 108. [WANG Jiachen, DU Jingzhong. The failure analysis of horizontal convex earth slopes[J]. Journal of China University of Mining & Technology,1992,21(2):102 − 108. (in Chinese with English abstract)
[20] BAKER R, LESHCHINSKY D. Stability analysis of conical heaps[J]. Soils and Foundations,1987,27(4):99 − 110. doi: 10.3208/sandf1972.27.4_99
[21] FARZANEH O, ASKARI F, GANJIAN N. Three-dimensional stability analysis of convex slopes in plan view[J]. Journal of Geotechnical and Geoenvironmental Engineering,2008,134(8):1192 − 1200. doi: 10.1061/(ASCE)1090-0241(2008)134:8(1192)
[22] 沈志平, 宋二祥, 朱博勤, 等.FAST开挖系统关键技术及安全性研究[M]. 北京: 科学出版社, 2018.
SHEN Zhiping, SONG Erxiang, ZHU Boqin, et al. Study on key technology and safety of the FAST excavation system[M]. Beijing: Science Press, 2018.(in Chinese)
[23] 赵衡, 宋二祥. 圆形凸坡的稳定性分析[J]. 岩土工程学报,2011,33(5):730 − 737. [ZHAO Heng, SONG Erxiang. Stability analysis of circular convex slopes[J]. Chinese Journal of Geotechnical Engineering,2011,33(5):730 − 737. (in Chinese with English abstract)
[24] ZHANG X. Three – dimensional stability analysis of concave slope in plan view[J]. Journal of Geotechnical Engineering,1988,114(6):658 − 671. doi: 10.1061/(ASCE)0733-9410(1988)114:6(658)
[25] ZHANG T W, CAI Q X. 3D stability analysis method of concave slope based on the Bishop method[J]. International Journal of Mining Science and Technology,2017,27:365 − 370. doi: 10.1016/j.ijmst.2017.01.020
[26] 黎莉, 刘子儒. 凹型边坡稳定性分析中的侧面力取值方法探讨[J]. 岩土工程学报,2018,40(增刊2):137 − 141. [LI Li, LIU Ziru. Method for lateral forces in stability analysis of concave slopes in plan view[J]. Chinese Journal of Geotechnical Engineering,2018,40(Sup2):137 − 141. (in Chinese with English abstract)
[27] 张鲁渝, 郑颖人, 赵尚毅, 等. 有限元强度折减系数法计算土坡稳定安全系数的精度研究[J]. 水利学报,2003,34(1):21 − 27. [ZHANG Luyu, ZHENG Yingren, ZHAO Shangyi, el at. The feasibility study of strength-reduction method with FEM for calculating safety factors of soil slope stability[J]. Journal of Hydraulic Engineering,2003,34(1):21 − 27. (in Chinese with English abstract) doi: 10.3321/j.issn:0559-9350.2003.01.005
-
