An improved Green-Ampt model for rainfall infiltration in the inner dumping site of an open pit coal mine
-
摘要:
矿山内排土场因其储量大、结构松散和强度低等特点，在降雨条件下极易产生侵蚀或整体失稳破坏，因此降雨入渗分析对预测内排土场稳定性至关重要。以元宝山露天煤矿内排土场为原型，按相似试验理论进行物理模型试验，研究降雨入渗特征，根据试验结果对经典Green-Ampt入渗模型进行改进。结果表明：雨水入渗过程中，随着浸润锋的向下运移，坡面侵蚀由溅蚀凹槽开始，逐渐过渡为径流侵蚀，最后呈现为溯源侵蚀破坏，整体呈现平行于坡表面的浅层滑坡特征；浸润锋之上非饱和浸润层的存在，导致经典Green-Ampt模型计算结果不准确；在考虑浸润层厚度和累积入渗量基础上，推导出改进的Green-Ampt模型；改进后的Green-Ampt模型为分段函数，能够反映降雨入渗使坡面由非饱和向饱和过渡的实际特征。验证结果显示，使用改进模型，浸润锋入渗深度和累积入渗量的预测精度显著提升，虽然冲蚀破坏和初始含水率的差异导致降雨入渗后期的预测精度有所下降，但相关结果对煤矿内排土场降雨初期稳定性分析具有重要意义。改进后的Green-Ampt模型的计算结果与实测数据更为接近，能为分析露天煤矿内排土场降雨入渗规律及边坡稳定性研究提供参考。
-
关键词:
- 内排土场 /
- 降雨入渗 /
- 改进的Green-Ampt模型 /
- 非饱和浸润层 /
- 浸润锋
Abstract:Due to the characteristics of large reserves, loose structure and low strength, an inner dumping site in the open pit coal mine is prone to erosion or overall instability under the rainfall conditions. The analysis of rainfall infiltration is quite important to estimate the stability of a dump. The inner dump of the Yuanbaoshan open pit coal mine is taken as the prototype, the physical model test is carried out according to the similar theory to study the characteristics of rainfall infiltration, and the classic Green-Ampt infiltration model is improved. The results show that during the process of rainwater infiltration, with the downward migration of the wetting peak, the erosion of the slope surface starts from the splash groove, gradually transits to runoff erosion, and finally appears as traceable erosion damage, showing the characteristics of shallow landslide parallel to the slope surface. The existence of unsaturated wetting layer above the wetting peak leads to the inaccurate calculation results if the classical Green-Ampt model is used. Based on consideration of the thickness of the infiltration layer and cumulative infiltration amount, an improved Green-Ampt model is derived. The improved Green-Ampt model is a piecewise function, which can reflect the actual characteristics of the transition from unsaturated to saturated slope caused by rainfall infiltration. The validation results show that the prediction accuracy of infiltration depth and cumulative infiltration volume is significantly improved. Because of the erosion damage and the difference in the initial water content, the prediction accuracy of the improved model decreases for the later stage of the rainfall, but it is of great significance for the stability analysis of an open pit coal mine dump at the initial stage of rainfall. The calculation result of the improved model is closer to the measured data.The improved infiltration model can provide an important reference for the studies of rainfall infiltration and slope stability of open-pit coal mine inner dumping sites.
-
-
表 1 土料的物理力学参数
Table 1. Physical and mechanical parameters of the waste dump
参数 天然干密度/（g·cm−1） 天然含水率/% 重度/（kN·m−3） 黏聚力/kPa 内摩擦角/（°） 饱和渗透系数/（cm·s−1） 取值 1.63 10.4 17 35.4 22.5 0.0023
下载: 导出CSV
表 2 van Genuchten 模型拟合参数
Table 2. Fitting parameters of the van Genuchten model
参数 饱和体积含水率/% 残余体积含水率/% α n 拟合度（R2） 取值 34 11 0.12 1.94 0.9956
下载: 导出CSV
-
[1] 杨洪才. 浅谈临时内排土场在露天矿生产中的应用[J]. 露天采矿技术,2003,18(1):4 − 5. [YANG Hongcai. Discussion on the application of temporary internal dump in open-pit mine production[J]. Opencast Coal Mining Technology,2003,18(1):4 − 5. (in Chinese) doi: 10.3969/j.issn.1671-9816.2003.01.002
[2] 王雪冬, 李世宇, 孙延峰, 等. 冻融循环作用对露天矿排土场土料土水特征的影响[J]. 煤田地质与勘探,2019,47(5):138 − 143. [WANG Xuedong, LI Shiyu, SUN Yanfeng, et al. Influence of the freezing-thawing cycles on soil-water characteristics of soil in open-pit mine dumping sites[J]. Coal Geology & Exploration,2019,47(5):138 − 143. (in Chinese with English abstract) doi: 10.3969/j.issn.1001-1986.2019.05.019
[3] 庄建琦, 彭建兵, 张利勇. 不同降雨条件下黄土高原浅层滑坡危险性预测评价[J]. 吉林大学学报(地球科学版),2013,43(3):867 − 876. [ZHUANG Jianqi, PENG Jianbing, ZHANG Liyong. Risk assessment and prediction of the shallow landslide at different precipitation in loess plateau[J]. Journal of Jilin University (Earth Science Edition),2013,43(3):867 − 876. (in Chinese with English abstract)
[4] 陈洪凯, 唐红梅. 散体滑坡室内启动模型试验[J]. 山地学报,2002,20(1):112 − 115. [CHEN Hongkai, TANG Hongmei. Research on start-up of loose landslide in lab[J]. Journal of Mountain Research,2002,20(1):112 − 115. (in Chinese with English abstract) doi: 10.3969/j.issn.1008-2786.2002.01.020
[5] 邱潇, 涂国祥, 赵石力, 等. 堆积体内部裂隙对降雨入渗的影响[J]. 长江科学院院报,2021,38(4):110 − 117. [QIU Xiao, TU Guoxiang, ZHAO Shili, et al. Effect of fissures in accumulation body on rainfall infiltration[J]. Journal of Yangtze River Scientific Research Institute,2021,38(4):110 − 117. (in Chinese with English abstract) doi: 10.11988/ckyyb.20200035
[6] 王晓峰, 刘光焰, 刘均利, 等. 降雨入渗与滑坡关系研究综述[J]. 人民黄河,2006,28(8):25 − 27. [WANG Xiaofeng, LIU Guangyan, LIU Junli, et al. Review on the relationship between rainfall infiltration and landslide[J]. Yellow River,2006,28(8):25 − 27. (in Chinese) doi: 10.3969/j.issn.1000-1379.2006.08.013
[7] 张勇, 温智, 程英建. 四川巴中市滑坡灾害与降雨雨型关系探讨[J]. 水文地质工程地质,2020,47(2):178 − 182. [ZHANG Yong, WEN Zhi, CHENG Yingjian. A discussion of the relationship between landslide disaster and rainfall types in Bazhong of Sichuan[J]. Hydrogeology & Engineering Geology,2020,47(2):178 − 182. (in Chinese with English abstract)
[8] 史振宁, 戚双星, 刘登生. 考虑初始含水率分布的覆盖层边坡非饱和入渗过程与稳定性计算方法[J/OL]. 工程地质学报[2020-06-19].
SHI Zhenning, QI Shuangxing, LIU Dengsheng. Unsaturated infiltration process and stability calculation method of overburden slope considering initial water content distribution[J/OL]. Journal of Engineering Geology[2020-06-19]. https://doi.org/10.13544/j.cnki.jeg.2020-009,2020-06-19. (in Chinese with English abstract)
[9] 徐翔, 王义兴, 方正. 降雨和库水联合作用下边坡稳定性变化规律[J]. 中国地质灾害与防治学报,2019,30(2):51 − 58. [XU Xiang, WANG Yixing, FANG Zheng. Analysis on stability of a slope under rainfall and reservoir water level variation[J]. The Chinese Journal of Geological Hazard and Control,2019,30(2):51 − 58. (in Chinese with English abstract)
[10] KALE R V, SAHOO B. Green-Ampt infiltration models for varied field conditions: a revisit[J]. Water Resources Management,2011,25(14):3505 − 3536. doi: 10.1007/s11269-011-9868-0
[11] GREEN W H, AMPT G A. Studies of soil physics I.The flow of air and water through soils[J]. Journal of Agricultual Science,1911,4:1 − 24. doi: 10.1017/S0021859600001441
[12] 王文焰, 汪志荣, 王全九, 等. 黄土中Green-Ampt入渗模型的改进与验证[J]. 水利学报,2003,34(5):30 − 34. [WANG Wenyan, WANG Zhirong, WANG Quanjiu, et al. Improvement and evaluation of the Green-Ampt model in loess soil[J]. Journal of Hydraulic Engineering,2003,34(5):30 − 34. (in Chinese with English abstract) doi: 10.3321/j.issn:0559-9350.2003.05.005
[13] 温馨, 胡志平, 张勋, 等. 基于Green-Ampt模型的饱和-非饱和黄土入渗改进模型及其参数研究[J]. 岩土力学,2020,41(6):1991 − 2000. [WEN Xin, HU Zhiping, ZHANG Xun, et al. Modified infiltration model for saturated-unsaturated loess based on Green-Ampt model and its parametric study[J]. Rock and Soil Mechanics,2020,41(6):1991 − 2000. (in Chinese with English abstract)
[14] 张杰, 韩同春, 豆红强, 等. 基于降雨入渗分层假定的黄土边坡稳定性分析[J]. 中南大学学报(自然科学版),2014,45(12):4355 − 4361. [ZHANG Jie, HAN Tongchun, DOU Hongqiang, et al. Stability of loess slope considering infiltration zonation[J]. Journal of Central South University (Science and Technology),2014,45(12):4355 − 4361. (in Chinese with English abstract)
[15] 潘永亮, 简文星, 李林均, 等. 基于改进Green-Ampt模型的花岗岩残积土边坡降雨入渗规律研究[J]. 岩土力学,2020,41(8):2685 − 2692. [PAN Yongliang, JIAN Wenxing, LI Linjun, et al. A study on the rainfall infiltration of granite residual soil slope with an improved Green-Ampt model[J]. Rock and Soil Mechanics,2020,41(8):2685 − 2692. (in Chinese with English abstract)
[16] 李三川, 王晨光, 白润才, 等. 元宝山露天煤矿内排土场变形特性研究[J]. 煤炭科学技术,2018,46(3):85 − 89. [LI Sanchuan, WANG Chenguang, BAI Runcai, et al. Study on deformation features of in-pit dumping site in Yuanbaoshan Surface Mine[J]. Coal Science and Technology,2018,46(3):85 − 89. (in Chinese with English abstract)
[17] 中华人民共和国住房和城乡建设部. 土工试验方法标准: GB/T 50123—2019[S]. 北京: 中国计划出版社, 2019
Ministry of Housing and Urban-Rural Development of the People's Republic of China. Geotechnical test method standard:GB/T 50123—2019[S]. Beijing: China Planning Press, 2019. (in Chinese)
[18] 周必凡, 李德基, 罗德富, 等. 泥石流防治指南[M]. 北京: 科学出版社, 1991.
ZHOU Bifan, LI Deji, LUO Defu, et al. Guidelines for debris flow prevention and control [M]. Beijing: Science Press, 1991. (in Chinese)
[19] 王乐, 秦世伟. 不同降雨类型与库水位波动耦合作用下的土质滑坡稳定性分析[J]. 中国地质灾害与防治学报,2018,29(6):103 − 111. [WANG Le, QIN Shiwei. Landslide instability induced by sudden lower in water level combined with different rainfall types[J]. The Chinese Journal of Geological Hazard and Control,2018,29(6):103 − 111. (in Chinese with English abstract)
[20] 苏永华, 李诚诚. 间歇性强降雨下基于Green-Ampt入渗模型的边坡稳定性分析[J]. 湖南大学学报(自然科学版),2020,47(3):28 − 36. [SU Yonghua, LI Chengcheng. Slope stability analysis based onGreen-Ampt infiltration model under intermittent heavy rainfall[J]. Journal of Hunan University (Natural Sciences),2020,47(3):28 − 36. (in Chinese with English abstract)
[21] 陈卫金, 程东会, 陶伟. van Genuchten模型参数的物理意义[J]. 水文地质工程地质,2017,44(6):147 − 153. [CHEN Weijin, CHENG Donghui, TAO Wei. Physical significance of the parameters in the van Genuchten model[J]. Hydrogeology & Engineering Geology,2017,44(6):147 − 153. (in Chinese with English abstract)
[22] MUALEM Y. A new model for predicting the hydraulic conductivity of unsaturated porous media[J]. Water Resources Research,1976,12(3):513 − 522. doi: 10.1029/WR012i003p00513
-
