Research on evaluation and early warning of groundwater resources carrying capacity in Hebei Province
-
摘要:
河北省由于地下水持续超采引发一系列生态环境问题，其根源在于人类活动强度超出了地下水资源承载能力，并缺乏及时有效的预警。为了构建更符合河北省实际的地下水资源承载能力评价体系，解决以往预警方法需要设置固定的水位、水量预警区间值，水位的区域差异导致的宏观性评价困难、工作量巨大且无法动态修正的问题，从地下水的资源属性和社会属性出发，采用指标体系综合分析评判法，建立承载本底、承载状态2个层面的承载能力评价体系；采用地下水开发利用程度为主，水位变化幅度加以修正的“双控联动”预警方法，实现两指标的动态联动且无需设置固定的水位、水量区间。研究表明河北省地下水资源承载本底整体较好，但由于开发利用程度高，承载状态多处于超载状态，承载能力太行山中南部高于北部及燕山山区、坝上地区，山前冲洪积平原优于中部湖积平原和滨海平原；受咸水分布、工农业生产取水量大等因素影响，地下水红色及橙色预警区域主要分布于河北平原中部冲湖积平原的沧州、衡水地区、太行山山前平原邯邢交界区域及城市市区周边。评价及预警结果与河北省实际情况吻合。该评价方法具有区域适用性强、可操作性好、数据易获取等优点。
Abstract:A series of ecological and environmental problems occur in Hebei Province due to the continuous over-exploitation of groundwater. The reasons for these are that human activity intensity is beyond the groundwater resources carrying capacity and there is lack of timely and effective early warning method. The aims of this study is to build the groundwater resources carrying capacity evaluation system conforming to the reality of Hebei Province, improve previous warning methods that need to set the fixed warning interval value of groundwater levels and water volume and address some problems caused by the regional differences of groundwater level, such as macroscopic evaluation difficulty, huge workload and being unable to correct dynamically. Based on resource attributes and social attributes of the groundwater resources, this paper uses the comprehensive analysis and judgement method of index system and builds the carrying capacity evaluation system on two levels: carrying background and carrying status. The “dual-control linkage” warning system is used, which mainly focuses on the degree of groundwater development and utilization and modifies the extent of groundwater level changes, to achieve dynamical linkage of the two indexes without setting the fixed interval value of groundwater level and water volume. The research results show that the overall carrying background of groundwater resources in Hebei Province is good. Because the degree of groundwater development and utilization is high, the carrying status of groundwater is mostly in the over-load state.The results show that the bearing capacity of the central and southern parts of the Taihang Mountains is higher than that of the northern part, Yanshan mountain area and the Bashang region, and the bearing capacity of the piedmont alluvial plain is better than those of the central lacustrine plain and coastal plain. Influenced by the salt water distribution, the huge water consumption in industrial and agricultural production and other factors, red and orange warning areas of groundwater are mainly distributed in the Cangzhou and Hengshui areas of the central alluvial lake plain of the Hebei plain, Hanxing junction area of the Taihang piedmont plain and urban peripheries. Evaluation and warning results conform to the reality of Hebei Province and the system has the advantages of strong regional applicability, good operability and easy access to data.
-
-
表 1 河北省地下水资源承载能力评价指标体系
Table 1. Evaluation index system of groundwater resources carrying capacity of Hebei Province
指标类型 本底评价 状态评价 基础指标 地下水可开采资源模数 地下水开发利用程度 修正指标 可饮用地下水资源量占比 水位相对下降区占比 可灌溉地下水资源量占比 地下水用水量占比
下载: 导出CSV
表 2 地下水可开采资源模数本底分级标准
Table 2. Standard for the module background classification of exploitable groundwater resources
等级 地下水可开采资源模数/（104 m3·km−2·a−1） 高 ≥10 较高 [7.5, 10) 中 [3.5, 7.5) 较低 [2, 3.5) 低 <2
下载: 导出CSV
表 3 地下水承载本底修正指标阈值
Table 3. Threshold for groundwater carrying background correction index
修正指标 不降级 降一级 降二级 可饮用的地下水资源量占比/% (70, 100] （30~70] [0, 30] 可灌溉的地下水资源量占比/% (60, 100] （25~60] [0, 25]
下载: 导出CSV
表 4 地下水承载状态修正指标阈值
Table 4. Groundwater carrying state correction index threshold
修正指标 不降级 降一级 地下水水位下降区面积占比/% [0, 30] (30, 100] 地下水用水量占比/% [0, 50] (50, 100]
下载: 导出CSV
表 5 地下水资源承载能力分级表
Table 5. Scale for groundwater resources carrying capacity
承载能力等级 承载本底等级 高 较高 中 较低 低 承载状态等级 盈余 强 强 较强 中 较弱 均衡 强 较强 中 较弱 弱 超载 较强 中 较弱 弱 弱
下载: 导出CSV
表 6 地下水预警等级判别矩阵
Table 6. Discriminant matrix of groundwater warning grade
预警级别 承载状态级别 轻度超载 中度超载 重度超载 发展趋势类型 变优 蓝色 黄色 橙色 稳定 黄色 橙色 红色 变劣 橙色 红色 红色
下载: 导出CSV
-
[1] 张真源, 黄锡生. 资源环境承载能力监测预警的制度功能与完善[J]. 北京理工大学学报(社会科学版),2019,21(1):162 − 170. [ZHANG Zhenyuan, HUANG Xisheng. System functions and perfection of monitoring and early warning of resources and environment carrying capacity[J]. Journal of Beijing Institute of Technology (Social Sciences Edition),2019,21(1):162 − 170. (in Chinese with English abstract)
[2] 王哲,付宇,朱静思,等. 华北典型河道地下水回补效果评价[J]. 吉林大学学报(地球科学版),2021,51(3):843 − 853. [WANG Zhe, FU Yu, ZHU Jingsi, et al. Effect assessment on groundwater recharge for typical rivers in North China[J]. Journal of Jilin University (Earth Science Edition),2021,51(3):843 − 853. (in Chinese with English abstract)
[3] KHANNA P, BABU P R, GEORGE M S. Carrying-capacity as a basis for sustainable development a case study of National Capital Region in India[J]. Progress in Planning,1999,52(2):101 − 166. doi: 10.1016/S0305-9006(99)00004-5
[4] RIJSBERMAN M A, VAN DE VEN F H M. Different approaches to assessment of design and management of sustainable urban water systems[J]. Environmental Impact Assessment Review,2000,20(3):333 − 345. doi: 10.1016/S0195-9255(00)00045-7
[5] HARRIS J M, KENNEDY S. Carrying capacity in agriculture: global and regional issues[J]. Ecological Economics,1999,29(3):443 − 461. doi: 10.1016/S0921-8009(98)00089-5
[6] HUQ S M I, JOARDAR J C, PARVIN S, et al. Arsenic contamination in food-chain:Transfer of arsenic into food materials through groundwater irrigation[J]. Journal of Health, Population and Nutrition,2006,24(3):305 − 316.
[7] VARIS O, VAKKILAINEN P. China’s 8 challenges to water resources management in the first quarter of the 21st Century[J]. Geomorphology,2001,41(2/3):93 − 104.
[8] 施雅风, 曲耀光. 乌鲁木齐河流域水资源承载力及其合理利用[M]. 北京: 科学出版社, 1992: 48 − 63
SHI Yafeng, QU Yaoguang. Water resources carrying capacity and rationalutilization of Urumqi River basin[M]. Beijing: Science Press, 1992: 48 − 63. （in Chinese）
[9] 王顺久, 杨志峰, 丁晶. 关中平原地下水资源承载力综合评价的投影寻踪方法[J]. 资源科学,2004,26(6):104 − 110. [WANG Shunjiu, YANG Zhifeng, DING Jing. Projection pursuit method of comprehensive evaluation on groundwater resources carrying capacity in Guanzhong plain[J]. Resources Science,2004,26(6):104 − 110. (in Chinese with English abstract) doi: 10.3321/j.issn:1007-7588.2004.06.015
[10] 贺中华, 梁虹, 黄法苏, 等. 喀斯特地区地下水资源承载力综合评价研究:以贵州省为例[J]. 水文,2010,30(3):22 − 27. [HE Zhonghua, LIANG Hong, HUANG Fasu, et al. Assessment of groundwater resources carrying capacity in Karst areas:Taking Guizhou Province as a case[J]. Journal of China Hydrology,2010,30(3):22 − 27. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-0852.2010.03.005
[11] 于钋, 尚熳廷, 姚梅, 等. 水足迹与主成分分析法耦合的新疆水资源承载能力评价[J]. 水文,2021,41(1):49 − 54. [YU Po, SHANG Manting, YAO Mei, et al. Water resources carrying capacity evaluation based on water footprint and principal component analysis in Xinjiang[J]. Journal of China Hydrology,2021,41(1):49 − 54.
[12] 王威, 张鑫, 胡笑涛. 基于主成分分析法的灌区地下水资源承载力评价[J]. 水利与建筑工程学报,2010,8(1):5 − 6. [WANG Wei, ZHANG Xin, HU Xiaotao. Evaluation on carrying capacity of ground water in irrigation districts based on principal components analysis method[J]. Journal of Water Resources and Architectural Engineering,2010,8(1):5 − 6. (in Chinese with English abstract) doi: 10.3969/j.issn.1672-1144.2010.01.002
[13] 雷能忠, 许峰, 阮丽缘, 等. 多级模糊综合评判在自然资源承载力评价中的应用—以阜阳地区地下水资源为例[J]. 安徽技术师范学院学报,2004,18(1):53 − 57. [LEI Nengzhong, XU Feng, RUAN Liyuan, et al. Application of multi-level fuzzy comprehensive discrimination in evaluation of regional natural resources carrying capacity[J]. Journal of Anhui Technical Teachers College,2004,18(1):53 − 57. (in Chinese with English abstract)
[14] 何青, 成建梅. 基于模糊权物元理论的地下水资源承载力评价分析[J]. 水利水电技术,2018,49(5):25 − 29. [HE Qing, CHENG Jianmei. Fuzzy weight matter element theory-based evaluation and analysis on groundwater resources carrying capacity[J]. Water Resources and Hydropower Engineering,2018,49(5):25 − 29. (in Chinese with English abstract)
[15] 李瑞敏, 殷志强, 李小磊, 等. 资源环境承载协调理论与评价方法[J]. 地质通报,2020,39(1):80 − 87. [LI Ruimin, YIN Zhiqiang, LI Xiaolei, et al. A study of the coordination theory and evaluation method of resource environment carrying capacity[J]. Geological Bulletin of China,2020,39(1):80 − 87. (in Chinese with English abstract) doi: 10.12097/j.issn.1671-2552.2020.01.008
[16] 李瑞敏, 杨楠, 李小磊, 等, 资源环境承载能力评价方法探索与实践[M]. 北京: 地质出版社, 2019: 5 − 6
LI Ruimin, YANG Nan, LI Xiaolei, et al. Exploration andpractice of geological resources and environmental carrying capacity evaluation method[M]. Beijing: Geological Publishing House, 2019: 5 − 6. （in Chinese）
[17] 刘琼, 李瑞敏, 王轶, 等. 区域地下水资源承载能力评价理论与方法研究[J]. 水文地质工程地质,2020,47(6):173 − 183. [LIU Qiong, LI Ruimin, WANG Yi, et al. Theory and methodology for evaluation of carrying capacity of regional groundwater resources in China[J]. Hydrogeology & Engineering Geology,2020,47(6):173 − 183. (in Chinese with English abstract)
[18] 王轶, 李瑞敏, 高萌萌, 等. 基于双曲距离协调度模型的地下水资源与经济承载协调关系[J]. 地质通报,2020,39(1):88 − 93. [WANG Yi, LI Ruimin, GAO Mengmeng, et al. An analysis of coordination relationship between groundwater resources and economic carrying capacity based on hyperbolic distance coordination model[J]. Geological Bulletin of China,2020,39(1):88 − 93. (in Chinese with English abstract) doi: 10.12097/j.issn.1671-2552.2020.01.009
[19] 殷志强, 李瑞敏, 李小磊, 等. 地质资源环境承载能力研究进展与发展方向[J]. 中国地质,2018,45(6):1103 − 1115. [YIN Zhiqiang, LI Ruimin, LI Xiaolei, et al. Research progress and future development directions of geo-resources and environment carrying capacity[J]. Geology in China,2018,45(6):1103 − 1115. (in Chinese with English abstract)
[20] FARHADI S, NIKOO M R, RAKHSHANDEHROO G R, et al. An agent-based-Nash modeling framework for sustainable groundwater management: a case study[J]. Agricultural Water Management,2016,177:348 − 358. doi: 10.1016/j.agwat.2016.08.018
[21] 李文鹏, 郑跃军, 郝爱兵. 北京平原区地下水位预警初步研究[J]. 地学前缘,2010,17(6):166 − 173. [LI Wenpeng, ZHENG Yuejun, HAO Aibing. A preliminary study of groundwater level pre-warning in Beijing Plain[J]. Earth Science Frontiers,2010,17(6):166 − 173. (in Chinese with English abstract)
[22] 刘莎, 谢义华, 柴娟, 等. 陕西省地下水水位预警机制研究[J]. 地下水,2020,42(4):63 − 65. [LIU Sha, XIE Yihua, CHAI Juan, et al. Study of groundwater level early-warning in Shannxi Province[J]. Ground Water,2020,42(4):63 − 65. (in Chinese with English abstract)
[23] 李福臻. 区域水资源预警研究与应用[D]. 济南: 山东大学, 2020
LI Fuzhen. Research and application of regional water resources early warning[D]. Jinan: Shandong University, 2020. （in Chinese with English abstract）
[24] 戴长雷, 王羽, 王美玉, 等. 区域地下水水位水量双控管理研究[J]. 黑龙江大学工程学报,2021,12(1):1 − 8. [DAI Changlei, WANG Yu, WANG Meiyu, et al. Study on dual control management of regional groundwater level and groundwater volume[J]. Journal of Engineering of Heilongjiang University,2021,12(1):1 − 8. (in Chinese with English abstract)
[25] 王晓玮. 我国西北超采区地下水水量-水位双控指标确定研究: 以民勤盆地为例[D]. 北京: 中国地质大学（北京）, 2017
WANG Xiaowei. Study on the dual control of groundwater abstraction amount and table in groundwater over-exploitation zones in northwest China: A case study in Minqin Basin[D]. Beijing: China University of Geosciences, 2017. （in Chinese with English abstract）
[26] 哈建强, 朱艳飞, 史洪飞, 等. 黑龙港平原区地下水利用水位水量控制指标分析[J]. 人民长江,2018,49(7):52 − 57. [HA Jianqiang, ZHU Yanfei, SHI Hongfei, et al. Controlling indexes of water level and pumped groundwater in Heilonggang plain area, Hebei Province[J]. Yangtze River,2018,49(7):52 − 57. (in Chinese with English abstract)
[27] 王晓玮, 邵景力, 王卓然, 等. 西北地区地下水水量-水位双控指标确定研究—以民勤盆地为例[J]. 水文地质工程地质,2020,47(2):17 − 24. [WANG Xiaowei, SHAO Jingli, WANG Zhuoran, et al. A study of the determination of indicators of dual control of groundwater abstraction amount and water table in northwest China: a case study of the Minqin Basin[J]. Hydrogeology & Engineering Geology,2020,47(2):17 − 24. (in Chinese with English abstract)
[28] 李文鹏, 王龙凤, 杨会峰, 等. 华北平原地下水超采状况与治理对策建议[J]. 中国水利,2020(13):26 − 30. [LI Wenpeng, WANG Longfeng, YANG Huifeng, et al. The groundwater over exploitation status and countermeasure suggestions of the North China Plain[J]. China Water Resources,2020(13):26 − 30. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-1123.2020.13.017
[29] 水利部网站. 河北省2020年度地下水超采综合治理成效考核结果公布[EB/OL]. (2021-04-14). http://www.mwr.gov.cn/xw/dfss/202104/t20210414_1513818.html
Ministry of Water Resources Website. Evaluation results of comprehensive treatment of groundwater overexploitation in Hebei Province in 2020[EB/OL]. （2021-04-14）. http://www.mwr.gov.cn/xw/dfss/202104/t20210414_1513818.html. （in Chinese）
-
