考虑土拱效应及中主应力影响的桩间挡板土压力计算方法

尤静霖; 王士杰; 王昊岚

doi:10.16030/j.cnki.issn.1000-3665.202201032

考虑土拱效应及中主应力影响的桩间挡板土压力计算方法

河北农业大学城乡建设学院, 河北保定　071001

基金项目: 河北省建设科技研究指导性计划项目(2016-236)

详细信息

作者简介: 尤静霖（1997-），女，硕士研究生，主要从事边坡稳定性分析与滑坡防治研究。E-mail：Yoojiln@163.com

通讯作者: 王士杰（1963-），男，博士，教授，博士研究生导师，主要从事岩土工程教学与科研工作。E-mail：wshj_wshj@163.com

中图分类号: TU432

收稿日期: 2022-01-17

修回日期: 2022-03-23

刊出日期: 2022-09-15

A calculation method of earth pressure on sheeting between two piles considering soil arching effect and intermediate principal stress

Urban and Rural Construction Institute, Hebei Agricultural University, Baoding, Hebei　071001, China

More Information

Corresponding author: WANG Shijie, wshj_wshj@163.com

Received Date: 17 January 2022

Revised Date: 23 March 2022

Publish Date: 15 September 2022

摘要

摘要:
基于M-C强度准则的经典土压力理论，因未考虑土拱效应及中主应力的影响，导致土压力理论计算值较实际值明显偏大。在该方面，现有研究成果亦不能同时考虑二者的影响。为考虑土拱效应、中主应力和土体黏聚力等对桩间挡板土压力的综合影响，借助统一强度理论，对桩间土拱强度进行分析，给出了桩间挡板土压力计算的新方法。另外，基于Lode参数与应变类型的关系，提出了统一强度指标${\varphi _{\text{t}}}$的实用计算方法。结合工程实例，将计算结果与已有相关研究成果和现行规范确定的土压力进行了对比分析。结果表明，采用该方法，不同中主应力系数b值条件下，计算所得总主动土压力约为经典朗肯理论土压力的1/3~1/2，与实测土压力分布规律基本吻合。研究成果对桩板支挡结构的优化设计、降低工程造价，具有重要理论指导意义和工程实用价值。
- 桩板墙 /
- 挡板 /
- 土压力 /
- 土拱效应 /
- 中主应力 /
- 统一强度理论
Abstract:
The classical theories of earth pressure are based on the M-C strength criterion, which do not consider the influence of soil arching effect and intermediate principal stress on earth pressure, so the theoretical earth pressures are significantly larger than the actual values. In this respect, the existing research results also cannot consider the impact of both. In order to consider the comprehensive effect of soil arching effect, intermediate principal stress and soil cohesion on the earth pressure on the sheeting between two piles, the unified strength theory is used to analyze the strength of soil arching between piles, and a new method for calculating the earth pressure on the sheeting between piles is derived. In addition, based on the relationship between the Lode parameters and strain types, a practical calculation method of the unified strength index ${\varphi _{\text{t}}}$ is proposed. Finally, combined with an engineering example, the calculated results are compared with the existing research results and the earth pressure determined by using the current code. The results indicate that the total active earth pressure calculated with this method is about 1/3~1/2 of that calculated by the traditional Rankine theory under the condition of different b values, and it is in accordance with the distribution law of the measured earth pressure. The research results are of important theoretical significance and practical value for the optimal design of pile-sheet retaining and the reduction of engineering cost.
- pile-sheet retaining /
- sheeting /
- earth pressure /
- soil arching effect /
- intermediate principal stress /
- unified strength theory

HTML全文

图 1 桩板墙土拱效应示意图

Figure 1.

下载: 全尺寸图片幻灯片

图 2 土拱受力简图

Figure 2.

下载: 全尺寸图片幻灯片

图 3 板后土拱随深度变化示意图

Figure 3.

下载: 全尺寸图片幻灯片

图 4 板后土拱受力分析示意图

Figure 4.

下载: 全尺寸图片幻灯片

图 5 统一强度理论的极限应力圆

Figure 5.

下载: 全尺寸图片幻灯片

图 6 挡板土压力值随深度变化曲线

Figure 6.

下载: 全尺寸图片幻灯片

表 1 土层主要物理力学参数

Table 1. Main physical and mechanical parameters of different soil layers

序号	土层名称	土层厚度/m	重度/ （kN·m⁻³）	黏聚力/ kPa	内摩擦角/（°）
①	杂填土	3.26	18.5	6.0	13.0
②	含碎石粉质黏土	5.50	19.5	22.0	17.0
③₁	松散碎石	2.00	20.0	8.0	22.0
③₂	稍密碎石	4.00	20.5	5.0	25.0
④₁	稍密卵石	4.50	21.0	−	28.0
④₂	中密卵石	0.74	21.5	−	32.0

下载: 导出CSV

表 2 不同方法计算所得挡板总主动土压力

Table 2. Total active earth pressure of baffle calculated with different methods

计算方法	总主动土压力/（kN·m⁻¹）
朗肯理论	1038.46
文献[4]方法	808.37
本文方法（b = 0）	537.62
本文方法（b = 0.25）	479.69
本文方法（b = 0.5）	438.62
本文方法(b = 0.75）	407.97
本文方法（b = 1.0）	384.19

下载: 导出CSV
