Experimental study on prevention measures of extruded ice on highway subgrade slope in Sichuan-Tibet cold region
-
摘要:
涎流冰是川藏寒区道路工程常见病害，严重威胁道路建设及运营安全。防止地下水出露地表或者地下水位过高可减缓或消除涎流冰病害。野外调查和卫图判识表明川藏寒区涎流冰以溢流型为主。通过室内物理模拟试验研究采用含砾粗砂或卵石换填疏导地下水以及铺设防水土工布隔水对涎流冰的防治效果。试验表明：当冻结深度大于地下水位埋深时会逐渐形成涎流冰；采用含砾粗砂或卵石作为换填渗流层，加快地下水排泄，可有效减少孔隙水压力，相对于未处治边坡，涎流冰体积分别减少85.4%和93.9%，孔隙水压力分别减少46.2%和58.1%；采用防水土工布阻隔地下水，涎流冰面积减少97.5%，但孔隙压力会增加。考虑到川藏交通廊道区卵（碎）石材料充足，推荐采用渗透性良好的卵（碎）石作为换填层，加强地下水疏导，并在换填层上铺设防水土工布隔水。研究成果可为川藏地区交通道路涎流冰防治提供参考。
Abstract:Extruded ice is a common disease in road engineering in Sichuan-Tibet cold region, which seriously threatens the safety of road construction and operation. Preventing groundwater from being exposed to the surface or the groundwater level being too high can slow down or eliminate the formation of extruded ice. Field investigation and satellite map identification show that extruded ice in Sichuan-Tibet cold region is mainly overflow type. The prevention effects on extruded ice of backfilling with gravelly coarse sand or pebbles to dredge groundwater and laying waterproof geotextiles are analyzed by indoor physical simulation experiments. The results show that extruded ice will gradually form when the frozen depth is lower than the depth of groundwater level. Backfilling seepage layer with gravelly coarse sand or pebbles can accelerate the discharge of groundwater and reduce the pore water pressure effectively. Compared with the untreated slope, the volume of extruded ice is reduced by 85.4% and 93.9% respectively, and the pore water pressure is reduced by 46.2% and 58.1% respectively. By blocking groundwater with waterproof geotextile, the volume of extruded ice is reduced by 97.5%, but the pore pressure will increase. Considering the sufficient pebble (or gravel) materials in Sichuan-Tibet alpine region, it is recommended to use permeable pebble (or gravel) as backfill layer to accelerate groundwater drainage and control extruded ice disease in subgrade slope. And waterproof geotextile is recommended to be laid on backfill layer. The research results can provide reference for the prevention of extruded ice in Sichuan-Tibet traffic roads.
-
Key words:
- extruded ice /
- prevention measures /
- backfill layer /
- frozen depth /
- model test
-
-
表 1 涎流冰防治效果对比
Table 1. Comparison of prevention effect of extruded ice
模型试验 最大孔隙水压力 冻结体体积 涎流冰体积 未处治边坡/kPa 处治边坡/kPa 变化率/% 未处治边坡/cm3 处治边坡/cm3 变化率/% 未处治边坡/cm3 处治边坡/cm3 变化率/% 含砾粗砂换填 13.00 7.00 −46.20 14645.16 6423.04 −56.10 4393.50 642.30 −85.40 卵石换填 15.50 6.50 −58.10 15494.41 3334.30 −78.50 4338.40 266.70 −93.90 铺设隔水层 12.70 25.10 97.60 16310.49 2013.88 −87.70 4077.60 100.70 −97.50
下载: 导出CSV
-
[1] 朱根桥,李霞. 西藏那嘉路涎流冰病害分析与防治[J]. 公路交通技术,2013,29(1):21 − 23. [ZHU Genqiao,LI Xia. Analysis and control for disease of salivary flow ice on Tibetan Naqu—Jiali Road techniques[J]. Technology of Highway and Transport,2013,29(1):21 − 23. (in Chinese) doi: 10.3969/j.issn.1009-6477.2013.01.006
[2] 张维建,刘昆赟. 羌塘高原冻土区公路山坡涎流冰形成与对策分析[J]. 林业建设,2020(1):57 − 61. [ZHANG Weijian,LIU Kunyun. Analysis on the formation and countermeasures of salivary flow ice on the hillside of highway in the northern Tibet region[J]. Forestry Construction,2020(1):57 − 61. (in Chinese with English abstract)
[3] 陈安,彭振斌,杜长学,等. 高寒地区公路涎流冰灾害及防治[J]. 现代地质,2006,20(1):181 − 184. [CHEN An,PENG Zhenbin,DU Changxue,et al. Drift ices along the road located in the tableland chilliness mountain area and method to deal with them[J]. Geoscience,2006,20(1):181 − 184. (in Chinese with English abstract)
[4] 宋章,张广泽,蒋良文,等. 川藏铁路主要地质灾害特征及地质选线探析[J]. 铁道标准设计,2016,60(1):14 − 19. [SONG Zhang,ZHANG Guangze,JIANG Liangwen,et al. Analysis of the characteristics of major geological disasters and geological alignment of Sichuan-Tibet Railway[J]. Railway Standard Design,2016,60(1):14 − 19. (in Chinese with English abstract)
[5] 薛翊国,孔凡猛,杨为民,等. 川藏铁路沿线主要不良地质条件与工程地质问题[J]. 岩石力学与工程学报,2020,39(3):445 − 468. [XUE Yiguo,KONG Fanmeng,YANG Weimin,et al. Main unfavorable geological conditions and engineering geological problems along Sichuan-Tibet railway[J]. Chinese Journal of Rock Mechanics and Engineering,2020,39(3):445 − 468. (in Chinese with English abstract) doi: 10.13722/j.cnki.jrme.2019.0737
[6] 郭长宝,王保弟,刘建康,等. 川藏铁路交通廊道地质调查工程主要进展与成果[J]. 中国地质调查,2020,7(6):1 − 12. [GUO Changbao,WANG Baodi,LIU Jiankang,et al. Main progress and achievements of the geological survey project of Sichuan-Tibet Railway traffic corridor[J]. Geological Survey of China,2020,7(6):1 − 12. (in Chinese with English abstract)
[7] 肖阳. 高寒地区潜水型涎流冰路基施工与效益分析[J]. 黑龙江交通科技,2011(12):115 − 116. [XIAO Yang. Construction and benefit analysis of roadbed with diving saliva ice in alpine area[J]. Communications Science and Technology Heilongjiang,2011(12):115 − 116. (in Chinese) doi: 10.3969/j.issn.1008-3383.2011.12.079
[8] 刘鑫,赵振国. 公路涎流冰成因类型、发育机理及防治措施[J]. 西南公路,2014(4):33 − 36. [LIU Xin,ZHAO Zhenguo. Formation type,development mechanism and prevention measures of highway saliva ice[J]. Southwest Highway,2014(4):33 − 36. (in Chinese)
[9] 武鹤,王莉,赵逵. 高寒山区高等级公路涎流冰的形成与防治[J]. 黑龙江交通科技,2003,26(4):32 − 33. [WU He,WANG Li,ZHAO Kui. Formation and prevention of saliva ice of high-grade highway in alpine mountain area[J]. Communications Science and Technology Heilongjiang,2003,26(4):32 − 33. (in Chinese) doi: 10.3969/j.issn.1008-3383.2003.04.023
[10] 赵梦怡,谢强,朱磊,等. 高原季节性粗颗粒冻土边坡破坏的现场观测试验[J]. 铁道科学与工程学报,2019,16(7):1666 − 1672. [ZHAO Mengyi,XIE Qiang,ZHU Lei,et al. Field observation of slope failure of seasonal coarse grained frozen soil in plateau[J]. Journal of Railway Science and Engineering,2019,16(7):1666 − 1672. (in Chinese with English abstract) doi: 10.19713/j.cnki.43-1423/u.2019.07.009
[11] KONRAD J M,MORGENSTERN N R. A mechanistic theory of ice lens formation in fine-grained soils[J]. Canadian Geotechnical Journal,1980,17(4):473 − 486. doi: 10.1139/t80-056
[12] 王泽浩,张明发. 涎流冰病害的防治[J]. 公路,1980(11):28 − 31. [WANG Zehao,ZHANG Mingfa. Prevention of salivary flow ice diseases[J]. Highway,1980(11):28 − 31. (in Chinese)
[13] 王影,刘轶平. 公路涎流冰形成特征、条件及分类[J]. 黑龙江交通科技,2006,29(6):47 − 48. [WANG Ying,LIU Yiping. Formation characteristics,conditions and classification of salivary flow ice on highway[J]. Communications Science and Technology Heilongjiang,2006,29(6):47 − 48. (in Chinese) doi: 10.3969/j.issn.1008-3383.2006.06.034
[14] 张雪华. 无管式保温渗沟治理林区公路涎流冰[J]. 东北林业大学学报,1987(4):79 − 84. [ZHANG Xuehua. Heat preservation sewer of non-pipe form to harness forestry highway saliva-ice[J]. Journal of Northeast Forestry University,1987(4):79 − 84. (in Chinese with English abstract) doi: 10.13759/j.cnki.dlxb.1987.04.012
[15] 刘宏伟,刘磊. 塑料防水板保温墙治理路基边坡渗水根治路基涎流冰[J]. 黑龙江交通科技,2013,33(6):55 − 56. [LIU Hongwei,LIU Lei. Plastic waterproof board insulation wall to govern the roadbed slope seepage eradication of roadbed saliva ice[J]. Communications Science and Technology Heilongjiang,2013,33(6):55 − 56. (in Chinese) doi: 10.3969/j.issn.1008-3383.2013.06.040
[16] 马磊. 新疆公路涎流冰的成因分析与防治方法[J]. 广东公路交通, 2006（增刊1）: 207-208
MA Lei. Analysis and prevention method of salivary ice ice for highway in Xinjiang[J]. Guangdong Highway Communications, 2006（Sup1）: 207-208. （in Chinese）
[17] 李海亮,丁姣月,段德峰,等. 高原冻土地区公路涎流冰的成因分析及防治[J]. 河南科技大学学报(自然科学版),2021,42(1):61 − 67. [LI Hailiang,DING Jiaoyue,DUAN Defeng,et al. Cause analysis and prevention of salivary ice on highways in plateau permafrost regions[J]. Journal of He’nan University of Science and Technology (Natural Science),2021,42(1):61 − 67. (in Chinese with English abstract)
[18] 张浩. 公路涎流冰形成机理与防治技术研究[D]. 西安: 长安大学, 2016
ZHANG Hao. Study on formation mechanism and control techniques of extruded ice for highway[D]. Xi’an: Chang’an University, 2016. （in Chinese with English abstract）
[19] SAARELAINEN S, VASKLAINEN J. Problems of arctic road construction and maintenance in Finland[C]//KAARE SENNESET. Proceedings of 5th International Conference on Permafrost. Tronheim: Tapir Publishers, 1988: 1466-1491.
[20] VARLAMOV S. Temperature study of railway embankments on ice-rich permafrost in Yakutia[J]. Journal of Engineering of Heilongjiang University, 2014, 5（3）: 90 − 99.
VARLAMOV S. 雅库特铁路路堤富冰冻土的温度研究[J]. 黑龙江大学工程学报, 2014, 5（3）: 90 − 99. （in English with Chinese abstract）
[21] 王崇艮,赵文,王国生,等. 涎流冰对西部某铁路的影响研究[J]. 高速铁路技术,2021,12(1):17 − 21. [WANG Chonggen,ZHAO Wen,WANG Guosheng,et al. Study on impact of salivary flowice on a railway in Western China[J]. High Speed Railway Technology,2021,12(1):17 − 21. (in Chinese with English abstract)
[22] 高玉佳,王清,陈慧娥,等. 温度对季节性冻土水分迁移的影响研究[J]. 工程地质学报,2010,18(5):698 − 702. [GAO Yujia,WANG Qing,CHEN Huie,et al. Effect of temperature on migration of water in seasonal frozen soils[J]. Journal of Engineering Geology,2010,18(5):698 − 702. (in Chinese with English abstract) doi: 10.3969/j.issn.1004-9665.2010.05.014
-
