Ground vibration test of the Zhengzhou-Xi’an high-speed railway and analyses of the vibration isolation trench effect
-
摘要:
高铁列车动载会引起环境振动问题。为研究高速列车运行在高架段和路堤段引起的环境振动差异，文章对郑西线高速铁路展开现场测试，对比分析高架段和路堤段地面振动特征及其衰减规律。测试结果表明，路基段的振动响应大于高架段，高架段近场区衰减作用高于路堤段近场区域。振动传播过程中存在多次反弹增大现象，路堤段地面振动反弹增大位置滞后于高架段。高架段和路堤段的二次反弹增大率均明显大于一次反弹增大率。Z振级随距离的衰减符合对数衰减规律，拟合得到黄土地区Z振级衰减公式，最大偏差均出现在反弹增大区。引入无限元-黏弹性耦合边界条件，建立路堤段三维轨道-土体-隔振沟数值模型分析高速铁路隔振沟对减隔振的影响。研究发现空沟对中高频（30~60 Hz）振动波的隔振效果较低频（1~20 Hz）振动波明显，其具有低通滤波作用。空沟比填充沟隔振效果好，但是考虑到沟壁的稳定性，可在空沟中填入软质材料。研究成果可为高速铁路的设计及其环境振动的评价和控制提供参考。
Abstract:The dynamic load of high-speed railway train can cause environmental vibration problems. In order to study the environmental vibration effect caused on the viaduct bridge section and embankment section by high-speed train, the field test of the Zhengzhou - Xi’an high-speed railway is carried out, and the ground vibration characteristics and attenuation law of viaduct bridge section and embankment section are compared and analyzed. The test results show that the vibration response of the embankment section is greater than that of the viaduct bridge section, and the attenuation effect in the near-field area of the viaduct bridge section is higher than that in the near-field area of the embankment section. There are multiple rebound increases in the process of vibration propagation, and the ground vibration rebound of the embankment section lags behind that of the viaduct bridge section. The increase rate of secondary rebound in the viaduct bridge section and embankment section is significantly greater than that of primary rebound. The attenuation of Z vibration level with the distance conforms to the law of logarithmic attenuation. The Z vibration level attenuation formula in the loess area is obtained by fitting, and the maximum deviation appears in the rebound increasing area. The infinite element-viscoelastic coupling boundary is introduced to establish a 3D track-soil-vibration isolation trench numerical model of the embankment section. The influence of vibration isolation trench on vibration reduction and isolation of high-speed railway is analyzed. The results show that the vibration isolation effect of empty trench on the medium and high frequency (30 - 60 Hz) vibration wave is more obvious than that of low frequency (1 - 20 Hz), and it has the function of low-pass filtering. The vibration isolation effect of empty trench is better than that of filled trench, but soft materials can be filled in the trench considering the stability of trench walls. The research results can provide references for the design of high-speed railway and the evaluation and control of environmental vibration.
-
-
表 1 典型车速下列车几何特征频率
Table 1. Geometrical characteristic frequencies of the train at typical speeds
列车运行速度
/（km·h−1）特征频率 /Hz 固定轴距
激励频率车辆定距
激励频率前后车相邻转向架
中心距激励频率车长激励
频率200 22.22 3.17 7.41 2.22 240 26.67 3.81 8.89 2.67 250 27.78 3.97 9.26 2.78 300 33.33 4.76 11.11 3.33 350 38.89 5.56 12.96 3.89
下载: 导出CSV
适用地带范围 昼间/dB 夜间/dB 特殊住宅区 65 65 居民、文教区 70 67 混合区、商业中心区 75 72 工业集中区 75 72 交通干线道路两侧 75 72 铁路干线两侧 80 80
下载: 导出CSV
表 3 基本材料参数
Table 3. Basic material parameters
类型 密度
/（kg·m−3）弹性
模量
/MPa泊松比 黏聚力
/kPa内摩擦角
/（°）钢轨 7800 210000 0.3 / / 轨道板 2500 34500 0.15 / / 砂浆填充层 1800 10.0 0.35 / / 支撑层 2400 32500 0.17 / / 基床表层 2000 180 0.25 70 27 基床底层 1950 110 0.25 50 23
下载: 导出CSV
表 4 填充材料参数
Table 4. Filling material parameters
类型 密度/（kg·m−3） 弹性模量/MPa 泊松比 阻尼比 混凝土 2500 28000 0.20 0.05 橡胶 1150 6.8 0.47 0.32 石膏 900 800 0.41 0.20 泡沫塑料 500 400 0.38 0.25
下载: 导出CSV
-
[1] 高广运,何俊锋,李宁,等. 饱和地基上列车运行引起的地面振动隔振分析[J]. 岩土力学,2011,32(7):2191 − 2198. [GAO Guangyun,HE Junfeng,LI Ning,et al. Analysis of isolating ground vibration induced by trains running on saturated ground[J]. Rock and Soil Mechanics,2011,32(7):2191 − 2198. (in Chinese with English abstract)
[2] 高广运,赵宏,张博,等. 饱和分层地基上列车运行引起的地面振动分析[J]. 同济大学学报(自然科学版),2013,41(12):1805 − 1811. [GAO Guangyun,ZHAO Hong,ZHANG Bo,et al. Analysis of ground vibration induced by trains on saturated layered ground[J]. Journal of Tongji University (Natural Science),2013,41(12):1805 − 1811. (in Chinese with English abstract)
[3] 姚锦宝,夏禾,胡敬梁. 空沟对列车运行产生的环境振动隔振效果研究[J]. 中国铁道科学,2018,39(2):44 − 51. [YAO Jinbao,XIA He,HU Jingliang. Study on vibration isolation effect of open trench on environmental vibration induced by train operation[J]. China Railway Science,2018,39(2):44 − 51. (in Chinese with English abstract) doi: 10.3969/j.issn.1001-4632.2018.02.06
[4] 刘晶磊,张雷刚,宋绪国,等. 高速铁路空沟减隔振措施数值分析与模型试验[J]. 铁道标准设计,2017,61(3):42 − 46. [LIU Jinglei,ZHANG Leigang,SONG Xuguo,et al. Numerical analysis and model test of vibration reduction by open trench on high-speed railway[J]. Railway Standard Design,2017,61(3):42 − 46. (in Chinese with English abstract)
[5] 孟祥连,周福军. 西宝高铁黄土地区路基振动效应空间分析研究[J]. 铁道工程学报,2017,34(8):28 − 33. [MENG Xianglian,ZHOU Fujun. Spatial analysis and study of roadbed vibration effect on loess area for Xi’an-Baoji high-speed railway[J]. Journal of Railway Engineering Society,2017,34(8):28 − 33. (in Chinese with English abstract)
[6] 李小珍,陈桂媛,朱艳,等. 高速铁路轨道-桥梁-土体系统的振动传递特性试验研究[J]. 振动与冲击,2019,38(17):58 − 64. [LI Xiaozhen,CHEN Guiyuan,ZHU Yan,et al. Tests for vibration transmission characteristics of a high-speed railway track-bridge-soil system[J]. Journal of Vibration and Shock,2019,38(17):58 − 64. (in Chinese with English abstract)
[7] 路德春,马一丁,王国盛. 近接隧道列车运行时地表振动响应数值模拟[J]. 吉林大学学报(地球科学版),2021,51(5):1452 − 1462. [LU Dechun,MA Yiding,WANG Guosheng. Numerical Study on ground surface vibration response under train load in multi adjacent tunnels[J]. Journal of Jilin University (Earth Science Edition),2021,51(5):1452 − 1462. (in Chinese with English abstract)
[8] 高广运,李志毅,冯世进,等. 秦-沈铁路列车运行引起的地面振动实测与分析[J]. 岩土力学,2007,28(9):1817 − 1822. [GAO Guangyun,LI Zhiyi,FENG Shijin,et al. Experimental results and numerical predictions of ground vibration induced by high-speed train running on Qin-Shen Railway[J]. Rock and Soil Mechanics,2007,28(9):1817 − 1822. (in Chinese with English abstract)
[9] 李小珍,张志俊,冉汶民,等. 桥上列车高速运行引起的地面振动试验研究[J]. 西南交通大学学报,2016,51(5):815 − 823. [LI Xiaozhen,ZHANG Zhijun,RAN Wenmin,et al. Field test of ground vibration induced by high-speed train on elevated bridge[J]. Journal of Southwest Jiaotong University,2016,51(5):815 − 823. (in Chinese with English abstract)
[10] 李小珍,刘全民,张迅,等. 高架轨道交通附近自由地表振动试验研究[J]. 振动与冲击,2014,33(16):56 − 61. [LI Xiaozhen,LIU Quanmin,ZHANG Xun,et al. Ground vibration induced by inter-city express train[J]. Journal of Vibration and Shock,2014,33(16):56 − 61. (in Chinese with English abstract)
[11] 马骙骙,李斌,王东,等. 宝兰客专路堤段地面振动特性试验研究与数值分析[J]. 铁道科学与工程学报,2019,16(2):294 − 301. [MA Kuikui,LI Bin,WANG Dong,et al. Experimental study and numerical analysis on ground vibration characteristics of subgrades section of Baoji-Lanzhou high-speed railway[J]. Journal of Railway Science and Engineering,2019,16(2):294 − 301. (in Chinese with English abstract)
[12] 何鉴辞,童湘雄,唐剑,等. 某高速铁路高架线路直线与曲线段环境振动实测对比分析[J]. 铁道标准设计,2018,62(6):40 − 44. [HE Jianci,TONG Xiangxiong,TANG Jian,et al. Contrastive analysis of environment vibration of elevated straight and curved lines of high-speed railway[J]. Railway Standard Design,2018,62(6):40 − 44. (in Chinese with English abstract)
[13] 翟婉明,韩海燕. 高速列车运行于软土地基线路引起的地面振动研究[J]. 中国科学:技术科学,2012,42(10):1148 − 1156. [ZHAI Wanming,HAN Haiyan. Research on ground vibration caused by high-speed train running on soft soil foundation line[J]. Scientia Sinica(Technologica),2012,42(10):1148 − 1156. (in Chinese with English abstract)
[14] 董海山,周青,贺玉龙,等. 高速铁路桥梁路段地面环境振动衰减特性研究[J]. 四川环境,2013,32(6):7 − 10. [DONG Haishan,ZHOU Qing,HE Yulong,et al. Study of ground environmental vibration attenuation characteristics at high-speed train bridge section[J]. Sichuan Environment,2013,32(6):7 − 10. (in Chinese with English abstract)
[15] 毛昆明,陈国兴,张杨,等. 高架桥段与路堤段CRH动车组运行引起的地面振动对比测试[J]. 南京工业大学学报(自然科学版),2011,33(5):19 − 23. [MAO Kunming,CHEN Guoxing,ZHANG Yang,et al. Comparative testing on ground surface vibration caused by CRH train running on viaduct and embankment[J]. Journal of Nanjing University of Technology (Natural Science Edition),2011,33(5):19 − 23. (in Chinese with English abstract) doi: 10.3969/j.issn.1671-7627.2011.05.004
[16] 崔涛,郝志明,贾彬,等. 移动荷载作用下隔振沟隔振性能数值模拟分析[J]. 四川建筑科学研究,2015,41(2):183 − 187. [CUI Tao,HAO Zhiming,JIA Bin,et al. Numerical simulation analysis of the vibration isolation trench performance under moving load[J]. Sichuan Building Science,2015,41(2):183 − 187. (in Chinese with English abstract) doi: 10.3969/j.issn.1008-1933.2015.02.047
[17] 巴振宁,梁建文,王靖雅. 空沟对层状饱和地基中列车移动荷载的隔振性能研究[J]. 岩土工程学报,2017,39(5):848 − 858. [BA Zhenning,LIANG Jianwen,WANG Jingya. Isolation effect of an open trench against train-induced vibrations in a saturated layered ground[J]. Chinese Journal of Geotechnical Engineering,2017,39(5):848 − 858. (in Chinese with English abstract) doi: 10.11779/CJGE201705009
[18] 张立群,侯恩品,刘晶磊,等. 空沟减隔振对路基本体影响效果的试验研究[J]. 铁道科学与工程学报,2017,14(4):752 − 761. [ZHANG Liqun,HOU Enpin,LIU Jinglei,et al. Research on the test of the effect of vibration isolation measures of empty groove on the subgrade body[J]. Journal of Railway Science and Engineering,2017,14(4):752 − 761. (in Chinese with English abstract) doi: 10.19713/j.cnki.43-1423/u.2017.04.013
[19] 曹志刚,蔡袁强,徐长节. 空沟对列车运行引起的地基振动隔振效果研究[J]. 岩土力学,2012,33(8):2373 − 2382. [CAO Zhigang,CAI Yuanqiang,XU Changjie. Screening efficiency of open trenches to train-induced ground vibration[J]. Rock and Soil Mechanics,2012,33(8):2373 − 2382. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-7598.2012.08.021
[20] 康海伟,李萍,侯晓坤,等. 原状黄土土水特征滞后性研究[J]. 水文地质工程地质,2020,47(2):76 − 83. [KANG Haiwei,LI Ping,HOU Xiaokun,et al. A study of hysteresis of soil and water characteristics of intact loess[J]. Hydrogeology & Engineering Geology,2020,47(2):76 − 83. (in Chinese with English abstract)
[21] 刘乐青,张吾渝,张丙印,等. 冻融循环作用下黄土无侧限抗压强度和微观规律的试验研究[J]. 水文地质工程地质,2021,48(4):109 − 115. [LIU Leqing,ZHANG Wuyu,ZHANG Bingyin,et al. Effect of freezing-thawing cycles on mechanical properties and microscopic mechanisms of loess[J]. Hydrogeology & Engineering Geology,2021,48(4):109 − 115. (in Chinese with English abstract)
[22] 国家环境保护局. 城市区域环境振动标准: GB 10070—88[S]. 北京: 中国标准出版社, 1988. [State Bureau of Environmental Protection of the People’s Republic of China. STANDARD of environmental vibration in urban area: GB 10070—88[S]. Beijing: Standards Press of China, 1988. （in Chinese）]
[23] 国家铁路局. 高速铁路设计规范: TB 10621—2014[S]. 北京: 中国铁道出版社, 2015
National Railway Administration of the People’s Republic of China. Code for design of high speed railway: TB 10621—2014[S]. Beijing: China Railway Publishing House, 2015. （in Chinese）
[24] 权登州,王毅红,井彦林,等. 黄土区地铁车站动力分析中的无限元传输边界[J]. 西安建筑科技大学学报(自然科学版),2015,47(4):537 − 542. [QUAN Dengzhou,WANG Yihong,JING Yanlin,et al. Infinite-element transmitting boundary in dynamic analysis of subway station in loess area[J]. Journal of Xi’an University of Architecture & Technology (Natural Science Edition),2015,47(4):537 − 542. (in Chinese with English abstract)
[25] 刘晶波,谷音,杜义欣. 一致粘弹性人工边界及粘弹性边界单元[J]. 岩土工程学报,2006,28(9):1070 − 1075. [LIU Jingbo,GU Yin,DU Yixin. Consistent viscous-spring artificial boundaries and viscous-spring boundary elements[J]. Chinese Journal of Geotechnical Engineering,2006,28(9):1070 − 1075. (in Chinese with English abstract)
[26] 刘晶波,杜义欣,闫秋实. 黏弹性人工边界及地震动输入在通用有限元软件中的实现[J]. 防灾减灾工程学报,2007,27(4):37 − 42. [LIU Jingbo,DU Yixin,YAN Qiushi. The implementation of viscoelastic artificial boundary and the ground motion input in the general finite element software[J]. Journal of Disaster Prevention and Mitigation Engineering,2007,27(4):37 − 42. (in Chinese with English abstract)
[27] 叶茂,曹保兴,郑志华,等. 列车动荷载下某古遗址隔振沟的减振效果研究[J]. 应用力学学报,2015,32(4):682 − 688. [YE Mao,CAO Baoxing,ZHENG Zhihua,et al. Effect of vibration isolation trench on an ancient ruin subjected to train dynamic loads[J]. Chinese Journal of Applied Mechanics,2015,32(4):682 − 688. (in Chinese with English abstract)
[28] 皮音培,叶茂,金晶,等. 列车诱发环境振动在某古遗址内的应力分布规律研究[J]. 应用力学学报,2014,31(2):224 − 229. [PI Yinpei,YE Mao,JIN Jing,et al. Research on the stress distribution in an ancient ruin caused by train environmental vibration[J]. Chinese Journal of Applied Mechanics,2014,31(2):224 − 229. (in Chinese with English abstract) doi: 10.11776/cjam.31.02.C021
[29] 梁波,蔡英. 不平顺条件下高速铁路路基的动力分析[J]. 铁道学报,1999,21(2):84 − 88. [LIANG Bo,CAI Ying. Dynamic analysis on subgrade of high speed railways in geometric irregular condition[J]. Journal of the China Railway Society,1999,21(2):84 − 88. (in Chinese with English abstract) doi: 10.3321/j.issn:1001-8360.1999.02.019
-
