A study of mineral compositions and micro-structure characteristics for the Jinping marble
-
摘要:
为了研究锦屏大理岩受载过程中内部孔隙结构的演化规律，文章先对其进行矿物成分测定和单轴压缩试验；随后对施加不同轴压后的试样开展了核磁共振（nuclear magnetic resonance，NMR）测试，并分析相应试验结果；最后，根据NMR孔隙度参数，建立起试样损伤度、有效应力比系数与轴压比之间函数关系。结果表明：大理岩内部孔隙分布具有多尺度特性；加载过程中核磁共振 T 2谱分布曲线整体向右移动，小尺寸孔隙占比减少而中等尺寸孔隙占比增加；岩样内部孔隙具有多重分形结构，小孔占比影响孔隙的分形维数和连通性。当小孔占比小时，孔隙结构相对简单，分形维数较低；当小孔占比大时，孔隙结构则较复杂，分形维数增大。大理岩孔隙度和损伤度均随荷载增加呈指数增大，且损伤和未损状态下有效应力比也增大。此项研究对揭示岩石损伤与破坏机理具有重要指导意义，同时在岩石损伤检测方面也具有一定参考价值。
Abstract:To study the evolution law of internal pore structure of Jinping marble under loading, the mineral composition and uniaxial compression test were first conducted. Then, the nuclear magnetic resonance (NMR) tests were carried out on the samples subjected to different axial pressures, and the corresponding test results were further analyzed. Finally, the functional relationships of the damage degree and effective stress ratio with the axial compression ratio were established according to the NMR porosity parameters. It is found that the pore distribution in the marble has multi-scale characteristics. During the loading process, the T 2 spectrum distribution curve of NMR shifts to the right as a whole, and the proportion of small-sized pores decreases while the proportion of medium-sized pores increases. There exist multi-fractal structures of pores inside the rock samples, and the fractal dimension and connectivity of pores are affected by the small pore proportion. When the small pore proportion is low, the pore structure is relatively simpler and the fractal dimension is lower. When the small pore proportion is high, the pore structure is more complex and the fractal dimension increases. Both the porosity and damage degree of the marble increase exponentially with the increase of load, and the effective stress ratio of damaged and undamaged state also increases. This study has important guiding significance for revealing the mechanism of rock damage and failure, and also own certain reference value in rock damage detection.
-
Key words:
- marble /
- nuclear magnetic resonance /
- porosity /
- fractal dimension /
- damage degree
-
-
表 1 大理岩试样核磁共振谱面积
Table 1. NMR spectrum area of the marble samples
轴向荷载/MPa 0 100 125 T2谱面积 1 555.89 1 752.63 2 406.01
下载: 导出CSV
表 2 大理岩试样内部孔隙孔径划分
Table 2. Pore size partition of pores inside marble samples
轴向荷载/MPa 小孔占比 中孔占比 大孔占比 0 0.47 0.20 0.33 100 0.40 0.32 0.28 125 0.34 0.49 0.17
下载: 导出CSV
表 3 分形维数计算结果
Table 3. Calculation results of fractal dimension
荷载/MPa D1 D2 D3 DNMR 0 −0.20 2.81 2.89 2.39 100 −0.51 2.82 2.64 2.24 125 −0.87 2.63 2.61 2.11
下载: 导出CSV
-
[1] 张治亮, 徐卫亚, 王伟, 等. 韧性岩石常规三轴压缩试验及变形与损伤演化规律研究[J]. 岩石力学与工程学报, 2011, 30（增刊2）: 3857 − 3862
ZHANG Zhiliang, XU Weiya, WANG Wei, et al. Investigation on conventional triaxial compression tests of ductile rock and law of deformation and damage evolution[J]. Chinese Journal of Rock Mechanics and Engineering, 2011, 30（Sup 2）: 3857 − 3862.（in Chinese with English abstract）
[2] LIU B X,SHU Z L,HAN J J,et al. Real-time CT experimental research on creep microscopic damage evolution of coal rock under compression[J]. Disaster Advances,2012,5(4):667 − 674.
[3] YANG Y S,LI K Y,ZHOU H,et al. Investigation on the relationship between CT numbers and marble failure under different confining pressures[J]. Reviews on Advanced Materials Science,2021,60(1):846 − 852. doi: 10.1515/rams-2021-0070
[4] LI X M,ZHANG D M,YU G,et al. Research on damage and acoustic emission properties of rock under uniaxial compression[J]. Geotechnical and Geological Engineering,2021,39(5):3549 − 3562. doi: 10.1007/s10706-021-01710-5
[5] 付腾飞,徐涛,朱万成,等. 基于多晶离散元法的砂岩三轴压缩损伤特性[J]. 东北大学学报(自然科学版),2020,41(7):968 − 974. [FU Tengfei,XU Tao,ZHU Wancheng,et al. Damage compression based on polycrystalline discrete element method[J]. Journal of Northeastern University (Natural Science),2020,41(7):968 − 974. (in Chinese with English abstract)
[6] 张国凯,李海波,王明洋,等. 岩石单轴压缩下损伤表征及演化规律对比研究[J]. 岩土工程学报,2019,41(6):1074 − 1082. [ZHANG Guokai,LI Haibo,WANG Mingyang,et al. Comparative study on damage characterization and damage evolution of rock under uniaxial compression[J]. Chinese Journal of Geotechnical Engineering,2019,41(6):1074 − 1082. (in Chinese with English abstract)
[7] 张国凯, 李海波, 夏祥, 等. 岩石单轴压缩下能量与损伤演化规律研究[J]. 岩土力学, 2015, 36（增刊1）: 94−100
ZHANG Guokai, LI Haibo, XIA Xiang, et al. Research on energy and damage evolution of rock under uniaxial compression[J]. Rock and Soil Mechanics, 2015, 36（Sup 1）: 94−100. （in Chinese with English abstract）
[8] 李杰林,周科平,张亚民,等. 基于核磁共振技术的岩石孔隙结构冻融损伤试验研究[J]. 岩石力学与工程学报,2012,31(6):1208 − 1214. [LI Jielin,ZHOU Keping,ZHANG Yamin,et al. Experimental study of rock porous structure damage characteristics under condition of freezing-thawing cycles based on nuclear magnetic resonance technique[J]. Chinese Journal of Rock Mechanics and Engineering,2012,31(6):1208 − 1214. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-6915.2012.06.016
[9] 李杰林,刘汉文,周科平,等. 冻融作用下岩石细观结构损伤的低场核磁共振研究[J]. 西安科技大学学报,2018,38(2):266 − 272. [LI Jielin,LIU Hanwen,ZHOU Keping,et al. An LF-NMR study of the micro-structural deterioration of rocks under the effect of freeze-thaw cycles[J]. Journal of Xi’an University of Science and Technology,2018,38(2):266 − 272. (in Chinese with English abstract)
[10] 许玉娟,周科平,李杰林,等. 冻融岩石核磁共振检测及冻融损伤机制分析[J]. 岩土力学,2012,33(10):3001 − 3005. [XU Yujuan,ZHOU Keping,LI Jielin,et al. Study of rock NMR experiment and damage mechanism analysis under freeze-thaw condition[J]. Rock and Soil Mechanics,2012,33(10):3001 − 3005. (in Chinese with English abstract) doi: 10.16285/j.rsm.2012.10.011
[11] 张元中,肖立志. 单轴载荷下岩石核磁共振特征的实验研究[J]. 核电子学与探测技术,2006,26(6):731 − 734. [ZHANG Yuanzhong,XIAO Lizhi. Experimental study of the NMR characteristics in rock under uniaxial load[J]. Nuclear Electronics & Detection Technology,2006,26(6):731 − 734. (in Chinese with English abstract) doi: 10.3969/j.issn.0258-0934.2006.06.009
[12] 周科平,胡振襄,高峰,等. 基于核磁共振技术的大理岩三轴压缩损伤规律研究[J]. 岩土力学,2014,35(11):3117 − 3122. [ZHOU Keping,HU Zhenxiang,GAO Feng,et al. Study of marble damage laws under triaxial compression condition based on nuclear magnetic resonance technique[J]. Rock and Soil Mechanics,2014,35(11):3117 − 3122. (in Chinese with English abstract)
[13] ANOVITZ L M,COLE D R. Characterization and analysis of porosity and pore structures[J]. Reviews in Mineralogy and Geochemistry,2015,80(1):61 − 164. doi: 10.2138/rmg.2015.80.04
[14] WANG Z L,SHI G Y. Effect of heat treatment on dynamic tensile strength and damage behavior of medium-fine-grained Huashan granite[J]. Experimental Techniques,2017,41(4):365 − 375. doi: 10.1007/s40799-017-0180-7
[15] 郭常霖. 多晶材料X射线衍射无标样定量方法[J]. 无机材料学报,1996,11(1):1 − 8. [GUO Changlin. X-ray standardless quantitative analysis method for polycrystalline materials[J]. Journal of Inorganic Materials,1996,11(1):1 − 8. (in Chinese with English abstract) doi: 10.3321/j.issn:1000-324X.1996.01.001
[16] ONDRÁŠIK M,KOPECKÝ M. Rock pore structure as main reason of rock deterioration[J]. Studia Geotechnica et Mechanica,2014,36(1):79 − 88. doi: 10.2478/sgem-2014-0010
[17] 胡鑫,王超勇,孙强,等. 核磁共振技术对热解煤孔隙结构分形特征研究[J]. 矿业研究与开发,2021,41(11):67 − 75. [HU Xin,WANG Chaoyong,SUN Qiang,et al. Study on fractal characteristics of pore structure of pyrolysis coal by nuclear magnetic resonance technology[J]. Mining Research and Development,2021,41(11):67 − 75. (in Chinese with English abstract) doi: 10.13827/j.cnki.kyyk.2021.11.011
[18] 王伟祥,王志亮,贾帅龙,等. 动态载荷下大理岩断口形貌特征试验研究[J]. 水文地质工程地质,2022,49(3):118 − 124. [WANG Weixiang,WANG Zhiliang,JIA Shuailong,et al. An experimental study of the fracture morphology of marble under dynamic loading[J]. Hydrogeology & Engineering Geology,2022,49(3):118 − 124. (in Chinese with English abstract)
[19] ZHAO G J, CHEN C, YAN H. A thermal damage constitutive model for oil shale based on Weibull statistical theory[J]. Mathematical Problems in Engineering, 2019.https: //doi.org/10.1155/2019/4932586
-
