Application of sand-well load immersion test to deep loess collapsibility evaluation
-
摘要:
针对深层湿陷性黄土自重湿陷量室内试验结果不准确、测试黄土地基湿陷量的原位试验方法少等不足，基于已有的砂井浸水试验，提出了新的现场试验方法——砂井载荷浸水试验方法。其核心是井底地层在试验压力作用下沉降稳定后，利用井中砂砾石的强透水性，将水直接导入井底湿陷性黄土地层及砂井周围土体，使其快速浸水饱和，以此来测定砂井井底地层的湿陷量和砂井周围黄土的自重湿陷量。通过2组砂井载荷浸水试验，测试了不同压力和浸水条件下不同深度地层的湿陷变形，对比分析了砂井载荷浸水试验和临近场地大型试坑浸水试验，结果表明砂井载荷浸水试验的判定结果与试坑浸水试验一致，说明砂井载荷浸水试验是可行的。砂井载荷浸水试验具有周期短、费用低、场地条件要求低、用水量小等优点，适用于深层黄土湿陷性的研究，对黄土地区（尤其是深层黄土）工程的湿陷性评价有一定的参考意义。
Abstract:Because of the inaccuracy of laboratory test results of self-weight collapsibility of deep collapsible loess and the lack of in-situ test methods for testing loess foundation collapsibility, a new field test method, the sand-well load immersion test method, is proposed based on the existing sand-well immersion test. The core is that after the loess under the sand well has settled stably under the action of test pressure, the collapsible loess under the bottom of the sand well and around the sand well can be quickly saturated due to the strong permeability of sand and gravel in the well, therefore the collapsibility of the loess under the bottom of the sand well and the self-weight collapsibility of the loess around the sand well can be measured. Through two sets of sand-well load immersion tests, the collapsible deformation of different depth strata under different pressure and immersion conditions is tested, and the sand-well load immersion test and the large test pit immersion test adjacent to the site are compared and analyzed. The results show that the judgment results of the sand-well load immersion test are consistent with the test pit immersion test, indicating that the sand-well load immersion test is feasible. In addition, the sand-well load immersion test has the advantages of short cycle, low cost, low site condition requirements, small water consumption, etc. The sand-well load immersion test is suitable for the study of collapsibility of deep loess. The results are of a certain reference significance for the collapsibility evaluation of loess engineering in the loess area (especially deep loess).
-
Key words:
- sand-well load immersion test /
- loess /
- collapsibility /
- Shenhe Plateau /
- large test pit immersion test
-
-
表 1 试验场地地层
Table 1. Lithology of the test site
地层 深度/m 土壤类型
0～1.0 填土
1.0～9.5 黄土
9.5～12.6 古土壤
12.6～22.8 黄土
22.8～25.0 古土壤
下载: 导出CSV
表 2 砂井试验整体方案布置
Table 2. Overall scheme of sand-well tests
试验
名称砂井编号 深度/m 底面
位置试验压力/kPa 砂井载荷
浸水试验1号 5
190 2号 15
380
下载: 导出CSV
-
[1] 马闫,王家鼎,彭淑君,等. 大厚度黄土自重湿陷性场地浸水湿陷变形特征研究[J]. 岩土工程学报,2014,36(3):537 − 546. [MA Yan,WANG Jiading,PENG Shujun,et al. Immersion tests on characteristics of deformation of self-weight collapsible loess under overburden pressure[J]. Chinese Journal of Geotechnical Engineering,2014,36(3):537 − 546. (in Chinese with English abstract) doi: 10.11779/CJGE201403017
[2] 机械工业勘察设计研究院. 西安财经学院新校区一期工程湿陷性黄土场地现场试坑浸水试验报告[R]. 西安: 机械工业勘察设计研究院, 2004
China Jikan Institute of Engineering Investigations and Design. Report on soaking test of collapsible loess site of the first phase of the new campus of Xi’an Institute of Finance and Economics[R]. Xi’an: China Jikan Institute of Engineering Investigations and Design, 2004. （in Chinese）
[3] 西安市地下铁道有限责任公司. 西安地铁穿越湿陷性黄土工程性质及应对措施研究成果报告[R]. 西安: 西安市地下铁道有限责任公司, 2013
Xi’an Subway Limited Liability Company. Research results report on Xi’an subway engineering through the collapsible loess engineering characteristics and countermeasures[R]. Xi’an: Xi’an Subway Limited Liability Company, 2013. （in Chinese）
[4] 徐强,陈浩然,李良成,等. 黄土地层湿陷对整体管廊破坏作用研究[J]. 灾害学,2022,37(4):23 − 29. [XU Qiang,CHEN Haoran,LI Liangcheng,et al. Study on failure effect of loess stratum collapsibility on integral utility tunnel[J]. Journal of Catastrophology,2022,37(4):23 − 29. (in Chinese with English abstract)
[5] 侯乐乐,翁效林,黄文鹏,等. 湿陷性黄土地铁隧道基底注浆加固处治试验[J]. 长安大学学报(自然科学版),2022,42(2):91 − 102. [HOU Lele,WENG Xiaolin,HUANG Wenpeng,et al. Experimental on grouting reinforcement and treatment of metro tunnel basement in collapsible loess[J]. Journal of Chang’an University (Natural Science Edition),2022,42(2):91 − 102. (in Chinese with English abstract)
[6] LU Quanzhong,QIAO Jianwei,PENG Jianbing,et al. A typical Earth fissure resulting from loess collapse on the loess plateau in the Weihe Basin,China[J]. Engineering Geology,2019,259:105189. doi: 10.1016/j.enggeo.2019.105189
[7] WENG Xiaolin,ZHOU Rongming,RAO Wei,et al. Research on subway shield tunnel induced by local water immersion of collapsible loess[J]. Natural Hazards,2021,108(1):1197 − 1219. doi: 10.1007/s11069-021-04727-4
[8] XIAO Qinghua,LEI Shengxiang,CUI Kai,et al. Effect of the longitudinal local wetting-induced collapse on tunnel structure in loess strata[J]. Tunnelling and Underground Space Technology,2022,122:104361. doi: 10.1016/j.tust.2022.104361
[9] ZHU Guangxing,HAN Yan. Treatment of collapsible loess foundation[J]. IOP Conference Series:Earth and Environmental Science,2019,218:012006. doi: 10.1088/1755-1315/218/1/012006
[10] WEN Hua,DENG Songyin,ZHANG Wei,et al. A simplified approach to estimating the collapsible behavior of loess[J]. Advances in Civil Engineering,2020,2020:1 − 13.
[11] 王小军,米维军,熊治文,等. 郑西客运专线黄土地基湿陷性现场浸水试验研究[J]. 铁道学报,2012,34(1):83 − 90. [WANG Xiaojun,MI Weijun,XIONG Zhiwen,et al. Water immersion field tests of collapsibility of loess foundation of Zhengzhou— Xi’an passenger dedicated line[J]. Journal of the China Railway Society,2012,34(1):83 − 90. (in Chinese with English abstract) doi: 10.3969/j.issn.1001-8360.2012.01.015
[12] 魏亚妮,范文,麻广林. 黄土高原马兰黄土微结构特征及湿陷机理[J]. 地球科学与环境学报,2022,44(4):581 − 592. [WEI Yani,FAN Wen,MA Guanglin. Characteristics of microstructure and collapsible mechanism of Malan loess in Loess Plateau,China[J]. Journal of Earth Sciences and Environment,2022,44(4):581 − 592. (in Chinese with English abstract) doi: 10.19814/j.jese.2022.03047
[13] WANG Liqin,SHAO Shengjun,SHE Fangtao. A new method for evaluating loess collapsibility and its application[J]. Engineering Geology,2020,264:105376. doi: 10.1016/j.enggeo.2019.105376
[14] 范文,魏亚妮,于渤,等. 黄土湿陷微观机理研究现状及发展趋势[J]. 水文地质工程地质,2022,49(5):144 − 156. [FAN Wen,WEI Yani,YU Bo,et al. Research progress and prospect of loess collapsible mechanism in micro-level[J]. Hydrogeology & Engineering Geology,2022,49(5):144 − 156. (in Chinese with English abstract) doi: 10.16030/j.cnki.issn.1000-3665.202108064
[15] 中华人民共和国住房和城乡建设部, 国家市场监督管理总局. 湿陷性黄土地区建筑标准: GB 50025—2018[S]. 北京: 中国建筑工业出版社, 2019
Ministry of Housing and Urban-Rural Development of the People’s Republic of China, State Administration for Market Regulation. Code for building construction in collapsible loess regions: GB 50025—2018[S]. Beijing: China Architecture & Building Press, 2019. （in Chinese）
[16] 杨校辉,黄雪峰,朱彦鹏,等. 大厚度自重湿陷性黄土地基处理深度和湿陷性评价试验研究[J]. 岩石力学与工程学报,2014,33(5):1063 − 1074. [YANG Xiaohui,HUANG Xuefeng,ZHU Yanpeng,et al. Experimental study on collapsibility evaluation and treatment depths of collapsible loess upon self weight with thick depth[J]. Chinese Journal of Rock Mechanics and Engineering,2014,33(5):1063 − 1074. (in Chinese with English abstract) doi: 10.13722/j.cnki.jrme.2014.05.022
[17] 苏忍, 张恒睿, 张稳军, 等. 兰州地铁大厚度湿陷性黄土地层的现场浸水试验研究[J]. 土木工程学报, 2020, 53（增刊1）: 186 − 193
SU Ren, ZHANG Hengrui, ZHANG Wenjun, et al. Immersion tests on self-weight collapsible loess site with large depth of Lanzhou metro line[J]. China Civil Engineering Journal, 2020, 53（Sup 1）: 186 − 193. （in Chinese with English abstract）
[18] XU Yuanjun,WANG Jiading,GU Tianfeng,et al. Study on the loess immersion test of metro line 2 in Xi’an,Shaanxi Province,China[J]. Advances in Civil Engineering,2021,2021:1 − 14.
[19] 屈宏录,刘德仁,孙英萍,等. 深厚黄土地基浸水湿陷变形及竖向土压力作用分析[J]. 水文地质工程地质,2022,49(4):157 − 164. [QU Honglu,LIU Deren,SUN Yingping,et al. Analysis of collapsible deformation and vertical soil pressure action of thick loess foundation[J]. Hydrogeology & Engineering Geology,2022,49(4):157 − 164. (in Chinese with English abstract) doi: 10.16030/j.cnki.issn.1000-3665.202109012
[20] AN Peng,ZHANG Aijun,XING Yichuan,et al. Experimental study on settling characteristics of thick self-weight collapsible loess in Xinjiang Ili region in China using field immersion test[J]. Soils and Foundations,2018,58(6):1476 − 1491. doi: 10.1016/j.sandf.2018.08.005
[21] 王立新,邵帅,邵生俊,等. 西安洪庆地铁车站地基湿陷性研究[J]. 地下空间与工程学报,2022,18(3):1006 − 1014. [WANG Lixin,SHAO Shuai,SHAO Shengjun,et al. Evaluation of foundation collapse of Xi’an Hongqing metro station[J]. Chinese Journal of Underground Space and Engineering,2022,18(3):1006 − 1014. (in Chinese with English abstract) doi: 10.3969/j.issn.1673-0836.2022.3.dxkj202203034
[22] 王玉涛,刘小平,曹晓毅. 基于主成分分析法的Q2黄土湿陷特性研究[J]. 水文地质工程地质,2020,47(4):141 − 148. [WANG Yutao,LIU Xiaoping,CAO Xiaoyi. A study of the collapsibility of Q2 loess based on principal component analysis[J]. Hydrogeology & Engineering Geology,2020,47(4):141 − 148. (in Chinese with English abstract)
[23] YAO Yongguo,ZHANG Yuchuan,GAO Xulong,et al. Study on permeability and collapsibility characteristics of sandy loess in northern Loess Plateau,China[J]. Journal of Hydrology,2021,603:126883. doi: 10.1016/j.jhydrol.2021.126883
[24] WANG Li,LI Xian,LI Lincui,et al. Characterization of the collapsible mechanisms of Malan loess on the Chinese Loess Plateau and their effects on eroded loess landforms[J]. Human and Ecological Risk Assessment:An International Journal,2020,26(9):2541 − 2566. doi: 10.1080/10807039.2020.1721265
[25] 邵生俊,李骏,邵将,等. 大厚度湿陷性黄土地层的现场砂井浸水试验研究[J]. 岩土工程学报,2016,38(9):1549 − 1558. [SHAO Shengjun,LI Jun,SHAO Jiang,et al. In-situ sand well immersion tests on self-weight collapsible loess site with large depth[J]. Chinese Journal of Geotechnical Engineering,2016,38(9):1549 − 1558. (in Chinese with English abstract) doi: 10.11779/CJGE201609001
[26] 李骏,邵生俊,佘芳涛,等. 砂井浸水试验在黄土隧道地基湿陷变形评价中的应用研究[J]. 岩石力学与工程学报,2019,38(9):1937 − 1944. [LI Jun,SHAO Shengjun,SHE Fangtao,et al. Application research of sand well immersion test in collapsibility evaluation of loess tunnel foundations[J]. Chinese Journal of Rock Mechanics and Engineering,2019,38(9):1937 − 1944. (in Chinese with English abstract) doi: 10.13722/j.cnki.jrme.2018.1342
[27] 王永鑫, 邵生俊, 韩常领, 等. 湿陷性黄土砂井浸水试验的应用研究[J]. 岩土工程学报, 2018, 40（增刊1）: 159 − 164
WANG Yongxin, SHAO Shengjun, HAN Changling, et al. Application of sand drain immersion tests on collapsible loess[J]. Chinese Journal of Geotechnical Engineering, 2018, 40（Sup 1）: 159 − 164. （in Chinese with English abstract）
[28] 赵金刚,吕远强,晁军,等. 典型黄土-古土壤系列浸水渗透及湿陷变形规律[J]. 煤田地质与勘探,2020,48(3):152 − 159. [ZHAO Jingang,LYU Yuanqiang,CHAO Jun,et al. The law of soaking infiltration and collapse deformation in typical loess-paleosol series[J]. Coal Geology & Exploration,2020,48(3):152 − 159. (in Chinese with English abstract) doi: 10.3969/j.issn.1001-1986.2020.03.022
[29] 王治军,潘俊义,马闫,等. 董志塬大厚度自重湿陷性黄土场地浸水试验研究[J]. 水文地质工程地质,2016,43(2):75 − 82. [WANG Zhijun,PAN Junyi,MA Yan,et al. Immersion test on the self-weight collapsible loess in the Dongzhiyuan area[J]. Hydrogeology & Engineering Geology,2016,43(2):75 − 82. (in Chinese with English abstract) doi: 10.16030/j.cnki.issn.1000-3665.2016.02.11
-
