孔隙环境特征对高岭土超声波波速影响机理研究

,  ,  ,

文章导航 > 水文地质工程地质 > 2023 > 50(5): 89-95

上一篇

下一篇

金李皓琳, 张敏, 苑成旺, 王占. 孔隙环境特征对高岭土超声波波速影响机理研究[J]. 水文地质工程地质, 2023, 50(5): 89-95. doi: 10.16030/j.cnki.issn.1000-3665.202209011
引用本文: 金李皓琳, 张敏, 苑成旺, 王占. 孔隙环境特征对高岭土超声波波速影响机理研究[J]. 水文地质工程地质, 2023, 50(5): 89-95. doi: 10.16030/j.cnki.issn.1000-3665.202209011
shu
JIN Lihaolin, ZHANG Min, YUAN Chengwang, WANG Zhan. Influence mechanism of pore environment characteristics on ultrasonic wave velocity of kaolin[J]. Hydrogeology & Engineering Geology, 2023, 50(5): 89-95. doi: 10.16030/j.cnki.issn.1000-3665.202209011
Citation: JIN Lihaolin, ZHANG Min, YUAN Chengwang, WANG Zhan. Influence mechanism of pore environment characteristics on ultrasonic wave velocity of kaolin[J]. Hydrogeology & Engineering Geology, 2023, 50(5): 89-95. doi: 10.16030/j.cnki.issn.1000-3665.202209011
shu

孔隙环境特征对高岭土超声波波速影响机理研究

  • 吉林大学建设工程学院，吉林 长春　130015

  • 基金项目: 吉林省自然科学基金项目（20220101166JC）
详细信息
    作者简介: 金李皓琳（1999-），女，硕士研究生，主要从事岩土体力学性质研究。E-mail：jlhl21@mails.jlu.edu.cn
    通讯作者: 张敏（1986-），女，博士，副教授，主要从事地质灾害防控及岩土体力学分析研究。E-mail：minzhang@jlu.edu.cn

  • 中图分类号: TU442

Influence mechanism of pore environment characteristics on ultrasonic wave velocity of kaolin

  • College of Construction Engineering, Jilin University, Changchun, Jilin　130015, China

More Information

    摘要

  • 高岭土是工程中常见的黏性土体，其微观结构对孔隙环境的变化十分敏感。目前针对高岭土孔隙环境特征与声波波速关系的研究还有待深入。基于超声波测试理论，采用RSM-SY6超声波检测仪，研究了不同孔隙环境条件下，高岭土超声波波速的变化规律，并从黏土颗粒的排列方式及其与孔隙溶液的相互作用等微观角度，分析了孔隙环境特征对高岭土超声波波速的影响机理，为超声波检测技术在土体中的应用提供了一定的理论依据。结果表明：（1）孔隙比越大，高岭土超声波波速越低；（2）随着含水率的增加，高岭土超声波波速先小幅度降低，后大幅度升高；（3）孔隙溶液酸碱度对高岭土超声波波速的影响与边缘等电pH值有关，当孔隙溶液pH值等于边缘等电pH值时，超声波波速最大；（4）盐分的加入使高岭土超声波波速降低，当盐溶液浓度在0～0.5 mol/L时，波速下降最快。相同阴离子条件下，高价阳离子对超声波波速的降低作用更明显。研究结果可为黏性土体声学特性研究提供参考，同时也为超声波检测技术在土体中的应用提供了 一定的理论依据。

    Kaolin is a common clay in engineering. The microstructure of kaolin is very sensitive to the change of pore environment. At present, the research on the relationship between pore environment characteristics and acoustic wave velocity of kaolin remains to be further studied. In this paper, based on the ultrasonic test theory, RSM-SY6 ultrasonic detector is used to study the change rule of ultrasonic wave velocity of kaolin under different pore environment conditions. In addition, the influence mechanism of pore environment characteristics on ultrasonic wave velocity of kaolin is analyzed from the microscopic perspective of the arrangement mode of clay particles and the interaction between clay particles and pore solution. The results show that (1) the ultrasonic wave velocity of kaolin decreases with the increasing void ratio. (2) With the increasing water content, the ultrasonic wave velocity of kaolin decreases slightly at first and then increases greatly. (3) The effect of pore solution pH value on ultrasonic wave velocity of kaolin is related to the edge isoelectric pH value. When the pore solution pH value is equal to the edge isoelectric pH value, the ultrasonic wave velocity is the maximum. (4) The addition of salt reduces the ultrasonic wave velocity of kaolin. When the concentration of saline solution ranges from 0 to 0.5 mol/L, the wave velocity decreases rapidly. Under the same anion condition, the high valence cation has a more obvious effect on the reduction of ultrasonic wave velocity. This paper provides a reference for the study of the acoustic characteristics of viscous soil, and also provides a theoretical basis for the application of ultrasonic detection technology in soil.

    • HTML全文
  • 加载中

  • 图 1  高岭土超声波波速测试

    Figure 1.

    下载: 全尺寸图片 幻灯片

    图 2  高岭土超声波波速与孔隙盐溶液浓度的关系曲线

    Figure 2.

    下载: 全尺寸图片 幻灯片

    图 3  高岭土黏土颗粒间的3种接触方式示意图

    Figure 3.

    下载: 全尺寸图片 幻灯片

    表 1  高岭土孔隙比与超声波波速

    Table 1.  Void ratio and ultrasonic wave velocity of kaolin

    参数取值 孔隙比
    0.89 0.93 0.97 1.08 1.20 1.32
    波速/（km·s−1） 1.110 1.080 1.030 0.975 0.901 0.864
    下载: 导出CSV

    表 2  高岭土含水率与超声波波速

    Table 2.  Water content and ultrasonic wave velocity of kaolin

    参数取值 含水率/%
    3.41 8.93 14.50 21.20 23.40 27.63 33.72
    波速/（km·s−1） 1.210 1.030 0.897 1.003 1.178 1.531 1.977
    下载: 导出CSV

    表 3  高岭土孔隙溶液pH值与超声波波速

    Table 3.  Pore solution pH value and ultrasonic wave velocity of kaolin

    参数取值 pH值
    1 2 3 4 5 6 7 8 9 10 11 12
    波速/（km·s−1） 1.010 1.017 1.028 1.036 1.040 1.035 1.032 1.028 1.027 1.017 0.980 0.970
    下载: 导出CSV
    • 参考文献(31)
  • [1]

    刘建刚,刘明玮,牛传业. 声呐之所以不能用来进行渗流测试之我见[J]. 水文地质工程地质,2022,49(5):214 − 216. [LIU Jiangang,LIU Mingwei,NIU Chuanye. My opinion on why sonar can’t be used for seepage test[J]. Hydrogeology & Engineering Geology,2022,49(5):214 − 216. (in Chinese with English abstract)

    LIU Jiangang, LIU Mingwei, NIU Chuanye. My opinion on why sonar can’t be used for seepage test[J]. Hydrogeology & Engineering Geology, 2022, 49（5）: 214 − 216. （in Chinese with English abstract）

    [2]

    STEPHENSON R W. Ultrasonic testing for determining dynamic soil moduli[M]//American Society for Testing and Materials. Dynamic Geotechnical Testing. West Conshohocken,PA:ASTM International,1978:179 – 195.

    [3]

    ALBA P D,BALDWIN K,CELIKKOL B,et al. Elastic-wave velocities and liquefaction potential[J]. Geotechnical Testing Journal,1984,7(2):77 − 88. doi: 10.1520/GTJ10596J

    [4]

    王大雁,朱元林,马巍,等. 冻土超声波波速与冻土物理力学性质试验研究[J]. 岩石力学与工程学报,2003,22(11):1837 − 1840. [WANG Dayan,ZHU Yuanlin,MA Wei,et al. Testing study on relationship between ultrasonic wave velocities and physico-mechanical property of frozen soils[J]. Chinese Journal of Rock Mechanics and Engineering,2003,22(11):1837 − 1840. (in Chinese with English abstract)

    WANG Dayan, ZHU Yuanlin, MA Wei, et al. Testing study on relationship between ultrasonic wave velocities and physico-mechanical property of frozen soils[J]. Chinese Journal of Rock Mechanics and Engineering, 2003, 22（11）: 1837 − 1840. （in Chinese with English abstract）

    [5]

    韦秉旭,龚树,刘斌,等. 膨胀土细观结构变化及与声波波速的关系[J]. 长江科学院院报,2016,33(9):93 − 97. [WEI Bingxu,GONG Shu,LIU Bin,et al. Changes of expansive soil’s meso-structure and its relation with acoustic velocity[J]. Journal of Yangtze River Scientific Research Institute,2016,33(9):93 − 97. (in Chinese with English abstract)

    WEI Bingxu, GONG Shu, LIU Bin, et al. Changes of expansive soil’s meso-structure and its relation with acoustic velocity[J]. Journal of Yangtze River Scientific Research Institute, 2016, 33（9）: 93 − 97. （in Chinese with English abstract）

    [6]

    刘鹏,韦秉旭,欧阳运清,等. 膨胀土纵波波速与裂隙率关系试验[J]. 长沙理工大学学报(自然科学版),2016,13(3):12 − 18. [LIU Peng,WEI Bingxu,OUYANG Yunqing,et al. The longitudinal wave velocity of expansive soil and experimental study of the relationship between fracture rate[J]. Journal of Changsha University of Science & Technology (Natural Science),2016,13(3):12 − 18. (in Chinese with English abstract)

    LIU Peng, WEI Bingxu, OUYANG Yunqing, et al. The longitudinal wave velocity of expansive soil and experimental study of the relationship between fracture rate[J]. Journal of Changsha University of Science & Technology （Natural Science）, 2016, 13（3）: 12 − 18. （in Chinese with English abstract）

    [7]

    李君,徐岩,姜锐,等. 超声波土壤含水量检测装置的模型建立与验证[J]. 农业工程学报,2017,33(13):127 − 133. [LI Jun,XU Yan,JIANG Rui,et al. Establishment and verification of model for ultrasonic soil water content detector[J]. Transactions of the Chinese Society of Agricultural Engineering,2017,33(13):127 − 133. (in Chinese with English abstract) doi: 10.11975/j.issn.1002-6819.2017.13.017

    LI Jun, XU Yan, JIANG Rui, et al. Establishment and verification of model for ultrasonic soil water content detector[J]. Transactions of the Chinese Society of Agricultural Engineering, 2017, 33（13）: 127 − 133. （in Chinese with English abstract） doi: 10.11975/j.issn.1002-6819.2017.13.017

    [8]

    张智,周黎明,徐涛,等. 膨胀土力学特性参数的声-电响应特征分析[J]. 人民长江,2022,53(10):183 − 188. [ZHANG Zhi,ZHOU Liming,XU Tao,et al. Analysis on acoustic-electrical response characteristics of mechanical parameters of expansive soil[J]. Yangtze River,2022,53(10):183 − 188. (in Chinese with English abstract)

    ZHANG Zhi, ZHOU Liming, XU Tao, et al. Analysis on acoustic-electrical response characteristics of mechanical parameters of expansive soil[J]. Yangtze River, 2022, 53（10）: 183 − 188. （in Chinese with English abstract）

    [9]

    罗津辉,蔡忠理. 高岭土容重、含水量、结构特性与声波速度及动力学参数相关性的实验研究[J]. 岩土力学,1991,12(2):75 − 80. [LUO Jinhui,CAI Zhongli. Experimental study on the correlativity between physical-structrual characteristics and wave velocities in kaolinite[J]. Rock and Soil Mechanics,1991,12(2):75 − 80. (in Chinese with English abstract)

    LUO Jinhui, CAI Zhongli. Experimental study on the correlativity between physical-structrual characteristics and wave velocities in kaolinite[J]. Rock and Soil Mechanics, 1991, 12（2）: 75 − 80. （in Chinese with English abstract）

    [10]

    DING Wuquan,LIU Xinmin,HU Feinan,et al. How the particle interaction forces determine soil water infiltration:Specific ion effects[J]. Journal of Hydrology,2019,568:492 − 500. doi: 10.1016/j.jhydrol.2018.11.017

    [11]

    MITCHELL J K. Components of pore water pressure and their engineering significance[C]//INGERSON E. Clays and Clay Minerals-Proceeding of the Ninth National Conference on Clays and Clay Mineerals. Amsterdam:Elsevier,1962:162 − 184.

    [12]

    KAYA A,ÖREN A H,YÜKSELEN Y. Settling of kaolinite in different aqueous environment[J]. Marine Georesources & Geotechnology,2006,24(3):203 − 218.

    [13]

    WANG Yuxing,SIU W K. Structure characteristics and mechanical properties of kaolinite soils. I. Surface charges and structural characterizations[J]. Canadian Geotechnical Journal,2006,43(6):587 − 600. doi: 10.1139/t06-026

    [14]

    于海浩,韦昌富,颜荣涛,等. 孔隙溶液浓度的变化对黏土强度的影响[J]. 岩土工程学报,2015,37(3):564 − 569. [YU Haihao,WEI Changfu,YAN Rongtao,et al. Effects of pore solution concentrations on shear strength of clay[J]. Chinese Journal of Geotechnical Engineering,2015,37(3):564 − 569. (in Chinese with English abstract) doi: 10.11779/CJGE201503023

    YU Haihao, WEI Changfu, YAN Rongtao, et al. Effects of pore solution concentrations on shear strength of clay[J]. Chinese Journal of Geotechnical Engineering, 2015, 37（3）: 564 − 569. （in Chinese with English abstract） doi: 10.11779/CJGE201503023

    [15]

    LIU Di,EDRAKI M,BERRY L. Investigating the settling behaviour of saline tailing suspensions using kaolinite,bentonite,and illite clay minerals[J]. Powder Technology,2018,326:228 − 236. doi: 10.1016/j.powtec.2017.11.070

    [16]

    康馨,苏晨曦,陈仁朋,等. 不同水化环境下高岭土微观结构各向异性研究[J]. 湖南大学学报(自然科学版),2023,50(1):161 − 170. [KANG Xin,SU Chenxi,CHEN Renpeng,et al. Study on microstructure anisotropy of kaolin under different hydration environments[J]. Journal of Hunan University (Natural Sciences),2023,50(1):161 − 170. (in Chinese with English abstract)

    KANG Xin, SU Chenxi, CHEN Renpeng, et al. Study on microstructure anisotropy of kaolin under different hydration environments[J]. Journal of Hunan University （Natural Sciences）, 2023, 50（1）: 161 − 170. （in Chinese with English abstract）

    [17]

    杨德欢. 孔隙水溶液对高岭土变形特性的影响机理[D]. 桂林:桂林理工大学,2016. [YANG Dehuan. Influencing mechanism of pore water chemistry on volume change behavior of kaolinite[D]. Guilin:Guilin University of Technology,2016. (in Chinese with English abstract)

    YANG Dehuan. Influencing mechanism of pore water chemistry on volume change behavior of kaolinite[D]. Guilin: Guilin University of Technology, 2016. （in Chinese with English abstract）

    [18]

    中华人民共和国住房和城乡建设部. 土工试验方法 标准:GB/T 50123—2019[S]. 北京:中国计划出版社,2019. [Ministry of Housing and Urban-Rural Development of the People’s Republic of China. Standard for geotechnical testing method:GB/T 50123—2019[S]. Beijing:China Planning Press,2019. (in Chinese)

    Ministry of Housing and Urban-Rural Development of the People’s Republic of China. Standard for geotechnical testing method: GB/T 50123—2019[S]. Beijing: China Planning Press, 2019. （in Chinese）

    [19]

    张丹,晏鄂川,梁风. 红黏土物理力学性质与声波波速关系的初步研究[J]. 安全与环境工程,2019,26(2):190 − 194. [ZHANG Dan,YAN E’chuan,LIANG Feng. Preliminary research on the relationship between physical and mechanical properties of red clay and acoustic wave velocity[J]. Safety and Environmental Engineering,2019,26(2):190 − 194. (in Chinese with English abstract)

    ZHANG Dan, YAN E’chuan, LIANG Feng. Preliminary research on the relationship between physical and mechanical properties of red clay and acoustic wave velocity[J]. Safety and Environmental Engineering, 2019, 26（2）: 190 − 194. （in Chinese with English abstract）

    [20]

    郭守国,何斌. 非金属矿产开发利用[M]. 武汉:中国地质大学出版社,1991:219 – 271. [GUO Shouguo,He Bin. Development and utilization of nonmetallic minerals[M]. Wuhan:China University of Geosciences Press,1991:219 – 271. (in Chinese)

    GUO Shouguo, He Bin. Development and utilization of nonmetallic minerals[M]. Wuhan: China University of Geosciences Press, 1991: 219 – 271. （in Chinese）

    [21]

    王峥辉. 下蜀黄土超声波波速与物理力学性质试验研究[D]. 南京:河海大学,2007. [WANG Zhenghui. Testing study on relationship among P-wave velocity and physico-mechanical in Xiashu loess[D]. Nanjing:Hohai University,2007. (in Chinese with English abstract)

    WANG Zhenghui. Testing study on relationship among P-wave velocity and physico-mechanical in Xiashu loess[D]. Nanjing: Hohai University, 2007. （in Chinese with English abstract）

    [22]

    刘佳婷,付昱凯,李同录,等. 黄土与其矿物颗粒表面水膜类型及其定量表征[J]. 水文地质工程地质,2022,49(6):105 − 113. [LIU Jiating,FU Yukai,LI Tonglu,et al. Types of water film on the surface of loess and related mineral particles and their quantitative characterization[J]. Hydrogeology & Engineering Geology,2022,49(6):105 − 113. (in Chinese with English abstract)

    LIU Jiating, FU Yukai, LI Tonglu, et al. Types of water film on the surface of loess and related mineral particles and their quantitative characterization[J]. Hydrogeology & Engineering Geology, 2022, 49（6）: 105 − 113. （in Chinese with English abstract）

    [23]

    李强,李同录,李华,等. 毛细水作用下非饱和土压缩过程的微观非连续变形数值分析[J]. 水文地质工程地质,2022,49(4):135 − 143. [LI Qiang,LI Tonglu,LI Hua,et al. Numerical analysis of evolution of the unsaturated soil microstructure with capillary action during compression[J]. Hydrogeology & Engineering Geology,2022,49(4):135 − 143. (in Chinese with English abstract)

    LI Qiang, LI Tonglu, LI Hua, et al. Numerical analysis of evolution of the unsaturated soil microstructure with capillary action during compression[J]. Hydrogeology & Engineering Geology, 2022, 49（4）: 135 − 143. （in Chinese with English abstract）

    [24]

    孟祥波. 土质与土力学[M]. 北京:人民交通出版社,2002:12 – 13. [MENG Xiangbo. Soil quality and soil mechanics[M]. Beijing:China Communications Press,2002:12 – 13. (in Chinese)

    MENG Xiangbo. Soil quality and soil mechanics[M]. Beijing: China Communications Press, 2002: 12 – 13. （in Chinese）

    [25]

    曾立峰,邵龙潭,牛庚,等. 考虑孔隙水微观赋存形态的非饱和粉土有效应力方程及其验证[J]. 水文地质工程地质,2022,49(4):37 − 46. [ZENG Lifeng,SHAO Longtan,NIU Geng,et al. An effective stress equation for unsaturated silt considering the microstructure of pore water and its verification[J]. Hydrogeology & Engineering Geology,2022,49(4):37 − 46. (in Chinese with English abstract)

    ZENG Lifeng, SHAO Longtan, NIU Geng, et al. An effective stress equation for unsaturated silt considering the microstructure of pore water and its verification[J]. Hydrogeology & Engineering Geology, 2022, 49（4）: 37 − 46. （in Chinese with English abstract）

    [26]

    常锦,杨和平,肖杰,等. 酸性环境对百色膨胀土胀缩性能的影响及其微观解释[J]. 交通运输工程学报,2019,19(1):24 − 32. [CHANG Jin,YANG Heping,XIAO Jie,et al. Effect of acid environment on swelling-shrinkage properties of Baise expansive soil and its microscopic interpretation[J]. Journal of Traffic and Transportation Engineering,2019,19(1):24 − 32. (in Chinese with English abstract) doi: 10.3969/j.issn.1671-1637.2019.01.004

    CHANG Jin, YANG Heping, XIAO Jie, et al. Effect of acid environment on swelling-shrinkage properties of Baise expansive soil and its microscopic interpretation[J]. Journal of Traffic and Transportation Engineering, 2019, 19（1）: 24 − 32. （in Chinese with English abstract） doi: 10.3969/j.issn.1671-1637.2019.01.004

    [27]

    BRAGGS B,FORNASIERO D,RALSTON J,et al. The effect of surface modification by an organosilane on the electrochemical properties of kaolinite[J]. Clays and Clay Minerals,1994,42(2):123 − 136. doi: 10.1346/CCMN.1994.0420203

    [28]

    常锦,杨和平,肖杰,等. 酸雨湿干循环作用下百色膨胀土裂隙发育规律及其微观机制[J]. 中国公路学报,2021,34(1):47 − 56. [CHANG Jin,YANG Heping,XIAO Jie,et al. Fissure development law and micro-mechanism of Baise expansive soil under wet-dry cycles of acid rain[J]. China Journal of Highway and Transport,2021,34(1):47 − 56. (in Chinese with English abstract)

    CHANG Jin, YANG Heping, XIAO Jie, et al. Fissure development law and micro-mechanism of Baise expansive soil under wet-dry cycles of acid rain[J]. China Journal of Highway and Transport, 2021, 34（1）: 47 − 56. （in Chinese with English abstract）

    [29]

    KANG Xin,XIA Zhao,CHEN Renpeng,et al. Effects of inorganic cations and organic polymers on the physicochemical properties and microfabrics of kaolinite suspensions[J]. Applied Clay Science,2019,176:38 − 48. doi: 10.1016/j.clay.2019.04.024

    [30]

    MA Kunsong,PIERRE A C. Clay sediment-structure formation in aqueous kaolinite suspensions[J]. Clays and Clay Minerals,1999,47(4):522 − 526. doi: 10.1346/CCMN.1999.0470415

    [31]

    CHEN Jie,ANANDARAJAH A. Influence of pore fluid composition on volume of sediments in kaolinite suspensions[J]. Clays and Clay Minerals,1998,46(2):145 − 152. doi: 10.1346/CCMN.1998.0460204
