A study of the capillary rise characteristics of LNAPL based on the vertical pipes method
-
摘要:
被称为“工业血液”的轻非水相液体(LNAPL)及其衍生物在开采、生产、运输过程中所产生的污染已经成为常见的污染物，目前诸多学者对LNAPL污染进行了广泛研究，但对于LNAPL在土壤中的迁移及毛细作用研究尚不充分。本次试验的目的是通过室内模拟试验分析不同竖管直径条件下LNAPL在不同介质中的毛细上升规律，为研究LNAPL对地下水污染提供一定的理论依据。结果表明：影响毛细上升高度的因素大小依次为：溶液>介质>竖管直径；竖管直径与最大毛细上升高度并不是完全成比例关系，并且对毛细上升高度的影响相对较小；水与柴油在不同介质中毛细上升高度、毛细上升速率变化趋势基本一致，但是具体数值上存在差异，柴油的最大毛细上升高度与水相比降低了40%～50%，柴油的最大毛细上升速率与水相比降低30%～50%。这些特征都能够较好地体现LNAPL在不同介质中的毛细上升规律，在认识LNAPL对地下水的污染以及污染土地修复方面具有重要意义。
Abstract:The pollution caused by light non-aqueous phase liquid (LNAPL) and its derivatives, known as "industrial blood", in the process of mining, production and transportation, has become a common pollutant. At present, many researchers have carried out extensive researches on LNAPL pollution, but the researches on the migration and hairiness of LNAPL in soil is still insufficient. The purpose of this test is to study and analyze the capillary rise law of LNAPL in different media under different standpipe diameters through indoor simulation tests, so as to provide a certain theoretical basis for studying the groundwater pollution caused by LNAPL. The results show that the factors influencing the height of capillary rise are, in order, the solution > medium> vertical tube diameter. The diameter of the vertical tube is not completely proportional to the maximum capillary rise height, and the influence on the capillary rise height is relatively small. The capillary rise height and capillary rise rate of water and diesel in different media are basically the same, but there are differences in specific values. The maximum capillary rise height of diesel is 40%−50% lower than that of water, and the maximum capillary rise rate of diesel is 30%−50% lower than that of water. The average particle size of sand is inversely proportional to the capillary rise height and rate. These characteristics can better reflect the capillary rise law of LNAPL in different media, which are of important significance to understand the pollution of LNAPL to groundwater and the remediation of contaminated lands.
-
Key words:
- LNAPL /
- vertical pipe diameter /
- capillary rise height /
- capillary rise rate
-
-
表 1 试验砂样颗粒级配
Table 1. Particle gradation of the experimental sand samples
试样 不均匀系数 曲率系数 平均粒径/mm 质量占比/% 0.5～2.0 0.25～<0.5 0.075～<0.25 0.005～<0.075 <0.005 粉砂 1.89 0.87 0.131 94.4 3 2.6 细砂 30.67 4.78 0.205 17.5 26.2 38.1 12.9 5.3 粗砂 5.37 1.16 0.610 58.3 24.7 15.3 1.2 0.5 注：表中空白表示无此项。
下载: 导出CSV
表 2 毛细上升试验方案
Table 2. Capillary rise test schemes
试验编号 介质 竖管直径/cm 溶液 试验编号 介质 竖管直径/cm 溶液 1# 粉砂 1.6 水 10# 细砂 3.0 柴油 2# 粉砂 1.6 柴油 11# 细砂 5.0 水 3# 粉砂 3.0 水 12# 细砂 5.0 柴油 4# 粉砂 3.0 柴油 13# 粗砂 1.6 水 5# 粉砂 5.0 水 14# 粗砂 1.6 柴油 6# 粉砂 5.0 柴油 15# 粗砂 3.0 水 7# 细砂 1.6 水 16# 粗砂 3.0 柴油 8# 细砂 1.6 柴油 17# 粗砂 5.0 水 9# 细砂 3.0 水 18# 粗砂 5.0 柴油
下载: 导出CSV
表 3 极差分析结果
Table 3. Range analysis results
因素 类别 Kavg/cm R/cm d R′/cm 竖管直径 1.6 cm 36.92 2.23 0.52 2.84 3.0 cm 39.15 5.0 cm 38.18 介质 粉砂 48.48 21.10 0.52 26.88 细砂 38.38 粗砂 27.38 溶液 水 48.26 20.35 0.71 43.55 柴油 27.91 注：Kavg为某因素某水平最大毛细上升高度试验数据的平均值；R为指某因素条件下最大毛细上升高度的极差，该值等于某因素时Kavg最大值减去Kavg最小值；d为折算系数；R′为折算后的极差。
下载: 导出CSV
表 4 毛细上升高度与时间关系拟合参数
Table 4. Fitting parameters of the relationship between capillary rise height and time
竖管
直径/cm系数 水 柴油 粉砂 细砂 粗砂 粉砂 细砂 粗砂 1.6 a 28.855 23.649 19.239 13.085 13.067 10.571 b 6.672 5.919 2.863 4.570 3.726 1.939 $ {R}^{2} $ 0.996 0.990 0.985 0.996 0.995 0.977 3.0 a 31.446 26.440 20.339 15.143 11.408 10.181 b 7.155 5.938 2.888 4.374 3.480 2.438 $ {R}^{2} $ 0.994 0.991 0.918 0.990 0.994 0.997 5.0 a 29.673 25.220 21.058 13.315 12.536 10.295 b 6.466 6.300 3.045 3.454 3.692 2.287 $ {R}^{2} $ 0.990 0.992 0.969 0.996 0.989 0.998
下载: 导出CSV
-
[1] 沈欢,黄勇,苏悦,等. 裂隙介质中LNAPL污染物迁移研究进展[J]. 环境科技,2021,34(2):68 − 72. [SHEN Huan,HUANG Yong,SU Yue,et al. Research progress on the migration of LNAPL pollutants in fractured media[J]. Environmental Science and Technology,2021,34(2):68 − 72. (in Chinese with English abstract)
SHEN Huan, HUANG Yong, SU Yue, et al. Research progress on the migration of lnapl pollutants in fractured media[J]. Environmental Science and Technology, 2021, 34（2）: 68-72. （in Chinese with English abstract）]
[2] XIA Teng,DONG Yanhui,MAO Deqiang,et al. Delineation of LNAPL contaminant plumes at a former perfumery plant using electrical resistivity tomography[J]. Hydrogeology Journal,2021,29(3):1189 − 1201. doi: 10.1007/s10040-021-02311-5
[3] PAN Yuying,ZHANG Qian,YU Yewei,et al. Three-dimensional migration and resistivity characteristics of crude oil in heterogeneous soil layers[J]. Environmental Pollution,2021,268:115309. doi: 10.1016/j.envpol.2020.115309
[4] 段纪淼,王岩,刘慧姝,等. 油品在土壤中的运移特性[J]. 油气储运,2019,38(7):798 − 803. [DUAN Jimiao,WANG Yan,LIU Huishu,et al. Migration characteristics of oils in soil[J]. Oil & Gas Storage and Transportation,2019,38(7):798 − 803. (in Chinese with English abstract)
DUAN Jimiao, WANG Yan, LIU Huishu, et al. Migration characteristics of oils in soil[J]. Oil & Gas Storage and Transportation, 2019, 38（7）: 798-803. （in Chinese with English abstract）
[5] ALAZAIZA M Y D,TAHRA A M,AHMED A,et al. Diesel migration and distribution in capillary fringe using different spill volumes via image analysis[J]. Fluids,2021,6(5):189. doi: 10.3390/fluids6050189
[6] 童玲,陈伟胜,郑西来,等. 柴油污染土壤中毛细水上升规律研究[J]. 灌溉排水学报,2011,30(6):131 − 134. [TONG Ling,CHEN Weisheng,ZHENG Xilai,et al. Capillary rise of water in diesel oil contaminated soils[J]. Journal of Irrigation and Drainage,2011,30(6):131 − 134. (in Chinese with English abstract)
TONG Ling, CHEN Weisheng, ZHENG Xilai, et al. Capillary rise of water in diesel oil contaminated soils[J]. Journal of Irrigation and Drainage, 2011, 30（6）: 131-134. （in Chinese with English abstract）
[7] 潘明浩,时健,左锐,等. 水位波动下包气带透镜体影响LNAPL迁移的数值模拟研究[J]. 水文地质工程地质,2022,49(1):154 − 163. [PAN Minghao,SHI Jian,ZUO Rui,et al. A numerical simulation study of the effect of the vadose zone with lenses on LNAPL migration under the fluctuating water table[J]. Hydrogeology & Engineering Geology,2022,49(1):154 − 163. (in Chinese with English abstract)
PAN Minghao, SHI Jian, ZUO Rui, et al. A numerical simulation study of the effect of the vadose zone with lenses on LNAPL migration under the fluctuating water table[J]. Hydrogeology & Engineering Geology, 2022, 49（1）: 154-163. （in Chinese with English abstract）
[8] 赵科锋,王锦国,曹慧群. 含单裂隙非饱和带中轻非水相流体修复的数值模拟[J]. 水文地质工程地质,2020,47(5):43 − 55. [ZHAO Kefeng,WANG Jinguo,CAO Huiqun. Numerical simulation oflight non-aqueous phase liquids remediation in the unsaturated zone with single fractures[J]. Hydrogeology & Engineering Geology,2020,47(5):43 − 55. (in Chinese with English abstract)
ZHAO Kefeng, WANG Jinguo, CAO Huiqun. Numerical simulation oflight non-aqueous phase liquids remediation in the unsaturated zone with single fractures[J]. Hydrogeology & Engineering Geology, 2020, 47（5）: 43-55. （in Chinese with English abstract）
[9] 杜川, 李厚恩. 有机污染场地LNAPL分布特征与形成机理分析[C]//中国环境科学学会2021年科学技术年会——环境工程技术创新与应用分会场论文集（三）. 2021: 602 − 606
Du Chuan, LI Houen. Distribution characteristics and formation mechanism of LNAPL in origanic contaminated sites[C]//Proceedings of the 2021 Annual Conference of Science and Technology of the Chinese Society of Environmental Sciences: Technological Innovation and Application of Environmental Engineering （III）. 2021: 602 − 606. （in Chinese with English abstract）
[10] 胡明鉴,张晨阳,崔翔,等. 钙质砂中毛细水高度与影响因素试验研究[J]. 岩土力学,2019,40(11):4157 − 4164. [HU Mingjian,ZHANG Chenyang,CUI Xiang,et al. Experimental study on capillary rise and influencing factors in calcareous sand[J]. Rock and Soil Mechanics,2019,40(11):4157 − 4164. (in Chinese with English abstract)
HU Mingjian, ZHANG Chenyang, CUI Xiang, et al. Experimental study on capillary rise and influencing factors in calcareous sand[J]. Rock and Soil Mechanics, 2019, 40（11）: 4157-4164. （in Chinese with English abstract）
[11] LIU Qiang,YASUFUKU N,MIAO Jiali,et al. An approach for quick estimation of maximum height of capillary rise[J]. Soils and Foundations,2014,54(6):1241 − 1245. doi: 10.1016/j.sandf.2014.11.017
[12] MOL L,VILES H. Exposing drying patterns:using electrical resistivity tomography to monitor capillary rise in sandstone under varying drying conditions[J]. Environmental Earth Sciences,2013,68(6):1647 − 1659. doi: 10.1007/s12665-012-1858-x
[13] 崔浩浩,张光辉,刘鹏飞,等. 包气带岩性结构对地下水生态功能影响特征[J]. 水文地质工程地质,2022,49(5):52 − 62. [CUI Haohao,ZHANG Guanghui,LIU Pengfei,et al. Characteristics of influence of lithologic structure of vadose zone on groundwater ecological function[J]. Hydrogeology & Engineering Geology,2022,49(5):52 − 62. (in Chinese with English abstract)
CUI Haohao, ZHANG Guanghui, LIU Pengfei, et al. Characteristics of influence of lithologic structure of vadose zone on groundwater ecological function[J]. Hydrogeology & Engineering Geology, 2022, 49（5）: 52-62. （in Chinese with English abstract）
[14] 董斌,张喜发,李欣,等. 毛细水上升高度综合试验研究[J]. 岩土工程学报,2008,30(10):1569 − 1574. [DONG Bin,ZHANG Xifa,LI Xin,et al. Comprehensive tests on rising height of capillary water[J]. Chinese Journal of Geotechnical Engineering,2008,30(10):1569 − 1574. (in Chinese with English abstract)
DONG Bin, ZHANG Xifa, LI Xin, et al. Comprehensive tests on rising height of capillary water[J]. Chinese Journal of Geotechnical Engineering, 2008, 30（10）: 1569-1574. （in Chinese with English abstract）
[15] 何建新,糟凯龙,杨海华. 塔里木河胡杨实现自我恢复的新方法探索[J]. 水电能源科学,2021,39(7):33 − 37. [HE Jianxin,ZAO Kailong,YANG Haihua. Exploration of new methods to realize self-recovery of populus euphonium from Tarim River[J]. Water Resources and Power,2021,39(7):33 − 37. (in Chinese with English abstract)
HE Jianxin, ZAO Kailong, YANG Haihua. Exploration of new methods to realize self-recovery of populus euphonium from Tarim River[J]. Water Resources and Power, 2021, 39（7）: 33-37. （in Chinese with English abstract）
[16] 洒永芳. 含水层中污染物向土壤垂向迁移的水力调控措施及其影响研究[D]. 成都: 西南交通大学, 2018
SA Yongfang. Study on hydraulic control measures and its influence of vertical migration of pollutants from aquifer to soil[D]. Chengdu: Southwest Jiaotong University, 2018. （in Chinese with English abstract）
[17] 刘伟佳,吴军虎,裴青宝,等. 不同地下水埋深条件下均质土壤毛管上升水运动特性试验研究[J]. 水资源与水工程学报,2010,21(1):67 − 70. [LIU Weijia,WU Junhu,PEI Qingbao,et al. Experimental research on capillary water upward movement in homogeneous soil under different ground water tables[J]. Journal of Water Resources and Water Engineering,2010,21(1):67 − 70. (in Chinese with English abstract)
LIU Weijia, WU Junhu, PEI Qingbao, et al. Experimental research on capillary water upward movement in homogeneous soil under different ground water tables[J]. Journal of Water Resources and Water Engineering, 2010, 21（1）: 67-70. （in Chinese with English abstract）
[18] JAIR A B, RONALDO I, CARLOS M P, et al. The capillary rise in fine and coarse-grained soils considering the matric suction[J]. Journal of Xi’an Unniversity of Architecture & Technology 2021, 29（4）: 1608 − 1615.
[19] 姚华,张喜发,张冬青. 影响粗粒土毛细水上升高度的因素研究[J]. 勘察科学技术,2007(1):10 − 12. [YAO Hua,ZHANG Xifa,ZHANG Dongqing. Research on affecting factors of rising height of capillary water on coarse grained soil[J]. Site Investigation Science and Technology,2007(1):10 − 12. (in Chinese with English abstract)
YAO Hua, ZHANG Xifa, ZHANG Dongqing. Research on affecting factors of rising height of capillary water on coarse grained soil[J]. Site Investigation Science and Technology, 2007（1）: 10-12. （in Chinese with English abstract）
[20] 王兴照,李英杰,胡晶,等. 表面活性剂对土壤毛细水上升特性的影响[J]. 安徽农业科学,2018,46(18):98 − 101. [WANG Xingzhao,LI Yingjie,HU Jing,et al. Effects of surfactants on the characteristic of soil capillary water rising[J]. Journal of Anhui Agricultural Sciences,2018,46(18):98 − 101. (in Chinese with English abstract)
WANG Xingzhao, LI Yingjie, HU Jing, et al. Effects of surfactants on the characteristic of soil capillary water rising[J]. Journal of Anhui Agricultural Sciences, 2018, 46（18）: 98-101. （in Chinese with English abstract）
[21] 邓改革,何建国,康宁波. 基于多物理场耦合的毛细水高度研究[J]. 水土保持研究,2021,28(4):136 − 141. [DENG Gaige,HE Jianguo,KANG Ningbo. Research on capillary water height based on multi-physical field coupling[J]. Research of Soil and Water Conservation,2021,28(4):136 − 141. (in Chinese with English abstract) doi: 10.13869/j.cnki.rswc.2021.04.018
DENG Gaige, HE Jianguo, KANG Ningbo. Research on capillary water height based on multi-physical field coupling[J]. Research of Soil and Water Conservation, 2021, 28（4）: 136-141. （in Chinese with English abstract） doi: 10.13869/j.cnki.rswc.2021.04.018
[22] 魏样,王益权,蔡苗,等. 石油污染对土壤毛细水上升特性的影响[J]. 灌溉排水学报,2017,36(9):50 − 56. [WEI Fan,WANG Yiquan,CAI Miao,et al. Effects of petroleum pollution on the rising characteristics of soil capillary water[J]. Journal of Irrigation and Drainage,2017,36(9):50 − 56. (in Chinese with English abstract)
WEI Fan, WANG Yiquan, CAI Miao, et al. Effects of petroleum pollution on the rising characteristics of soil capillary water[J]. Journal of Irrigation and Drainage, 2017, 36（9）: 50-56. . （in Chinese with English abstract）
[23] 王聪,张平,谢长青,等. 不同浓度盐溶液及盐渍土对毛细水上升影响的研究[J]. 节水灌溉,2014(12):26 − 28. [WANG Cong,ZHANG Ping,XIE Changqing,et al. Effect of different concentration salt solution and saline soil on capillary water upward movement[J]. Water Saving Irrigation,2014(12):26 − 28. (in Chinese with English abstract)
WANG Cong, ZHANG Ping, XIE Changqing, et al. Effect of different concentration salt solution and saline soil on capillary water upward movement[J]. Water Saving Irrigation, 2014（12）: 26-28. （in Chinese with English abstract）
[24] 张平,吴昊,殷洪建,等. 颗粒级配对毛细水上升影响的研究[J]. 节水灌溉,2010(7):24 − 26. [ZHANG Ping,WU Hao,YIN Hongjian,et al. Effect of particle size distribution on capillary water upward movement[J]. Water Saving Irrigation,2010(7):24 − 26. (in Chinese with English abstract)
ZHANG Ping, WU Hao, YIN Hongjian, et al. Effect of particle size distribution on capillary water upward movement[J]. Water Saving Irrigation, 2010（7）: 24-26. （in Chinese with English abstract）
[25] 沈宇鹏,曹权,陈芷航,等. 含盐石英砂的毛细上升特性及其影响因素研究[J]. 铁道工程学报,2022,39(3):13 − 18. [SHEN Yupeng,CAO Quan,CHEN Zhihang,et al. Research on the capillary rising characteristics and influencing factors of salt-containing quartz sand[J]. Journal of Railway Engineering Society,2022,39(3):13 − 18. (in Chinese with English abstract) doi: 10.3969/j.issn.1006-2106.2022.03.003
SHEN Yupeng, CAO Quan, CHEN Zhihang, et al. Research on the capillary rising characteristics and influencing factors of salt-containing quartz sand[J]. Journal of Railway Engineering Society, 2022, 39（3）: 13-18. （in Chinese with English abstract） doi: 10.3969/j.issn.1006-2106.2022.03.003
[26] 董荣泽,于明英,邱照宁,等. 沙土上升毛管水运动特性研究[J]. 节水灌溉,2018(4):19 − 25. [DONG Rongze,YU Mingying,QIU Zhaoning,et al. A study on capillary water movement characteristics in sandy soil[J]. Water Saving Irrigation,2018(4):19 − 25. (in Chinese with English abstract)
DONG Rongze, YU Mingying, QIU Zhaoning, et al. A study on capillary water movement characteristics in sandy soil[J]. Water Saving Irrigation, 2018（4）: 19-25. （in Chinese with English abstract）
[27] 何艳平. 低液限粉土毛细上升特征的影响因素研究[J]. 工程勘察,2020,48(4):11 − 18. [HE Yanping. Study on influencing factors of capillary rise characteristics of low liquid limit silt[J]. Geotechnical Investigation & Surveying,2020,48(4):11 − 18. (in Chinese with English abstract)
HE Yanping. Study on influencing factors of capillary rise characteristics of low liquid limit silt[J]. Geotechnical Investigation & Surveying, 2020, 48（4）: 11-18. （in Chinese with English abstract）
[28] 苗强强, 陈正汉, 田卿燕, 等. 非饱和含黏土砂毛细上升试验研究[J]. 岩土力学, 2011, 32（增刊1）: 327-333
MIAO Qiangqiang, CHEN Zhenghan, TIAN Qingyan, et al. Experimental study of capillary rise of unsaturated clayey sand[J]. Rock and Soil Mechanics, 2011, 32（Sup 1）: 327-333. （in Chinese with English abstract）
[29] LIU Di,LU Caiwu,LIAN Minjie,et al. Experimental study on capillary water migration characteristics of tailings with different particle sizes[J]. Geofluids,2022,2022:1 − 12.
[30] 中华人民共和国水利部. 土工试验规程: SL237—1999[S]. 北京: 中国水利水电出版社, 1999.
Ministry of Water Resources of the People’s Republic of China. Soil test regulations: SL237—1999[S]. Beijing: China Water Power Press,1999. （in Chinese）
[31] 黄志全. 土力学[M]. 郑州: 黄河水利出版社, 2011: 221 − 223
HUANG Zhiquan. Soil mechanics[M]. Zhengzhou: Yellow River Water Conservancy Press, 2011: 221 − 223. （in Chinese）
-
