Centrifuge model test and numerical simulation on evolution characteristics of fracture surface of the anti-dipped layered slope
-
摘要:
破裂面形成演化特征是反倾层状斜坡研究的重点之一，也是稳定性评价和工程设计治理的基础。利用室内大型土工离心机，获取坡体受力和变形参数，同时结合PFC数值模拟成果，展示斜坡破裂面的形成演化过程和特征，并讨论破裂面的形成机理。结果表明：（1）首先在坡体内部产生压剪裂隙，随后向中下部扩展，坡体压剪分区；（2）裂隙向中上部发展，破裂面初步形成，深部坡体发生弯折；（3）浅层裂隙完全贯通，形成由坡顶至坡脚的完整破裂面Ⅰ，内部潜在破裂面（Ⅱ、Ⅲ）中上部近似平行坡面，下部合并后至坡脚，而稳定受压区域与弯折区分界潜在破裂面Ⅳ呈阶梯形，同时浅层存在3条次级破裂面；（4）斜坡的变形破坏由于重力作用，使得岩层差异性受力，在压剪、拉剪及弯折作用下，裂隙由预制裂隙尖端萌生、扩展，最终贯通形成破裂面。重力是内在原因，而坡体结构特征是基础条件。研究成果可以为反倾层状斜坡进一步深入研究和实践提供参考。
Abstract:The formation and evolution characteristics of fracture surface is one of the key points in anti-inclined layered slope research, and it is also the basis of stability evaluation as well as engineering design and treatment. In this study, the stress and deformation parameters of the slope are obtained by using the indoor large-scale geotechnical centrifuge. At the same time, combined with the PFC numerical simulation results, the formation and evolution process and characteristics of the slope fracture surface are displayed: firstly, the compression shear crack is generated and extends to the middle and lower part of the slope, and the compression shear zone of the slope is divided; secondly, the developments of cracks toward to the middle and upper part of the slope, and with the initial formation of fracture surface, the deep slope body is bent; finally, the shallow cracks are completely connected to form a complete fracture surface Ⅰ from the top to the foot of the slope. The middle and upper parts of the internal potential fracture surface (Ⅱ, Ⅲ) are approximately parallel to the slope surface, and the lower parts are merged gradually at the foot of the slope. While the potential fracture surface Ⅳ at the boundary between the stable compression area and the bending area is stepped. At the same time, there are three secondary fracture surfaces in the shallow layer of the slope. The formation mechanism of the fracture surface is revealed that the deformation and failure of the slope causes the differential stress of the rock stratum due to the action of gravity. Under the action of compression shear, tension shear and bending, the crack initiates and expands from the tip of the prefabricated crack, and finally penetrates to form the fracture surface. Therefore, gravity is the internal reason, and the structural characteristics of slope are the basic conditions. The research results provide a basis for further research and practice of anti-inclined layered slope.
-
-
表 1 离心机模型试验主要比例关系
Table 1. Major parameters of the centrifuge model tests
物理量 单位符号 相似比符号 相似比关系 几何尺寸 L Cl 1∶120 密度 ρ Cφ 1∶1 应力 σ Cσ 1∶1 应变 ε Cε 1∶1 位移 u Cu 1∶120 加速度 α Ca 120∶1 泊松比 μ Cμ 1∶1 弹性模量 E CE 1∶1 黏聚力 c Cc 1∶1 内摩擦角 φ Cφ 1∶1
下载: 导出CSV
表 2 原型和相似材料物理力学参数
Table 2. Physico-mechanical parameters of prototypes and similar materials
指标 密度/（g·cm−3） 弹性模量/GPa 抗压强度/MPa 原型 2.41 1.161 36.19 模型 2.40 1.592 36.16
下载: 导出CSV
表 3 数值模型细观力学参数
Table 3. Microscopic mechanical parameters of the numerical model
类别 参数名称 参数值 颗粒参数 密度/（kg·m−3） 2400 最小颗粒半径/mm 0.30 颗粒体模量/GPa 1.428 法向刚度/切向刚度 1.52 摩擦系数 0.83 颗粒阻尼 0.50 黏结参数 径比 1.55 平行黏结模量/GPa 1.428 法向刚度/切向刚度 1.52 平行黏结刚度比 1.21
下载: 导出CSV
-
[1] 黄润秋. 20世纪以来中国的大型滑坡及其发生机制[J]. 岩石力学与工程学报,2007,26(3):433 − 454. [HUANG Runqiu. Large-scale landslides and their sliding mechanisms in China since the 20th century[J]. Chinese Journal of Rock Mechanics and Engineering,2007,26(3):433 − 454. (in Chinese with English abstract) doi: 10.3321/j.issn:1000-6915.2007.03.001
HUANG Runqiu . Large-scale landslides and their sliding mechanisms in China since the 20th century[J]. Chinese Journal of Rock Mechanics and Engineering,2007 ,26 （3 ）:433 −454 . （in Chinese with English abstract）[2] 黄润秋,李渝生,严明. 斜坡倾倒变形的工程地质分析[J]. 工程地质学报,2017,25(5):1165 − 1181. [HUANG Runqiu,LI Yusheng,YAN Ming. The implication and evaluation of toppling failure in engineering geology practice[J]. Journal of Engineering Geology,2017,25(5):1165 − 1181. (in Chinese with English abstract) doi: 10.13544/j.cnki.jeg.2017.05.001
HUANG Runqiu, LI Yusheng, YAN Ming . The implication and evaluation of toppling failure in engineering geology practice[J]. Journal of Engineering Geology,2017 ,25 （5 ）:1165 −1181 . （in Chinese with English abstract）[3] 马洪生,庄卫林,刘阳,等. 顺层岩质边坡静力开挖物理模拟试验研究[J]. 水文地质工程地质,2016,43(3):37 − 43. [MA Hongsheng,ZHUANG Weilin,LIU Yang,et al. Physical excavation test research on a bedding rock slope[J]. Hydrogeology & Engineering Geology,2016,43(3):37 − 43. (in Chinese with English abstract)
MA Hongsheng, ZHUANG Weilin, LIU Yang, et al . Physical excavation test research on a bedding rock slope[J]. Hydrogeology & Engineering Geology,2016 ,43 （3 ）:37 −43 . （in Chinese with English abstract）[4] 母剑桥. 反倾边坡倾倒破裂面优势形态及变形稳定性分析方法研究[D]. 成都:成都理工大学,2017. [MU Jianqiao. Study on dominant shape and deformation stability analysis method of toppling fracture surface of reverse slope[D]. Chengdu:Chengdu University of Technology,2017. (in Chinese with English abstract)
MU Jianqiao. Study on dominant shape and deformation stability analysis method of toppling fracture surface of reverse slope[D]. Chengdu: Chengdu University of Technology, 2017. （in Chinese with English abstract） [5] 张御阳. 陡缓结构面反倾层状岩质斜坡变形破坏演化机制研究[D]. 成都:成都理工大学,2019. [ZHANG Yuyang. Study on the evolution mechanism of deformation and failure of layered rock slope with steep and gentle structural plane[D]. Chengdu:Chengdu University of Technology,2019. (in Chinese with English abstract)
ZHANG Yuyang. Study on the evolution mechanism of deformation and failure of layered rock slope with steep and gentle structural plane[D]. Chengdu: Chengdu University of Technology, 2019. （in Chinese with English abstract） [6] 黄达,马昊,孟秋杰,等. 软硬互层岩质反倾边坡弯曲倾倒离心模型试验与数值模拟研究[J]. 岩土工程学报,2020,42(7):1286 − 1295. [HUANG Da,MA Hao,MENG Qiujie,et al. Centrifugal model test and numerical simulation for anaclinal rock slopes with soft-hard interbedded structures[J]. Chinese Journal of Geotechnical Engineering,2020,42(7):1286 − 1295. (in Chinese with English abstract) doi: 10.11779/CJGE202007012
HUANG Da, MA Hao, MENG Qiujie, et al . Centrifugal model test and numerical simulation for anaclinal rock slopes with soft-hard interbedded structures[J]. Chinese Journal of Geotechnical Engineering,2020 ,42 （7 ）:1286 −1295 . （in Chinese with English abstract）[7] 郑达,毛峰,王沁沅,等. 上硬下软反倾边坡开挖变形响应的物理模拟[J]. 水文地质工程地质,2019,46(5):89 − 95. [ZHENG Da,MAO Feng,WANG Qinyuan,et al. Physical simulation of the excavation deformation response of counter-tilt slope with rigid layers on the soft[J]. Hydrogeology & Engineering Geology,2019,46(5):89 − 95. (in Chinese with English abstract)
ZHENG Da, MAO Feng, WANG Qinyuan, et al . Physical simulation of the excavation deformation response of counter-tilt slope with rigid layers on the soft[J]. Hydrogeology & Engineering Geology,2019 ,46 （5 ）:89 −95 . （in Chinese with English abstract）[8] 郑达,王沁沅,毛峰,等. 反倾层状岩质边坡深层倾倒变形关键致灾因子及成灾模式的离心试验研究[J]. 岩石力学与工程学报,2019,38(10):1954 − 1963. [ZHENG Da,WANG Qinyuan,MAO Feng,et al. Centrifuge model test study on key hazard-inducing factors of deep toppling deformation and disaster patterns of counter-tilt layered rock slopes[J]. Chinese Journal of Rock Mechanics and Engineering,2019,38(10):1954 − 1963. (in Chinese with English abstract) doi: 10.13722/j.cnki.jrme.2018.1484
ZHENG Da, WANG Qinyuan, MAO Feng, et al . Centrifuge model test study on key hazard-inducing factors of deep toppling deformation and disaster patterns of counter-tilt layered rock slopes[J]. Chinese Journal of Rock Mechanics and Engineering,2019 ,38 （10 ）:1954 −1963 . （in Chinese with English abstract）[9] 姚晔,章广成,陈鸿杰,等. 反倾层状碎裂结构岩质边坡破坏机制研究[J]. 岩石力学与工程学报,2021,40(2):365 − 381. [YAO Ye,ZHANG Guangcheng,CHEN Hongjie,et al. Study on the failure mechanisms of counter-tilt rock slopes with layered cataclastic structure[J]. Chinese Journal of Rock Mechanics and Engineering,2021,40(2):365 − 381. (in Chinese with English abstract) doi: 10.13722/j.cnki.jrme.2020.0631
YAO Ye, ZHANG Guangcheng, CHEN Hongjie, et al . Study on the failure mechanisms of counter-tilt rock slopes with layered cataclastic structure[J]. Chinese Journal of Rock Mechanics and Engineering,2021 ,40 （2 ）:365 −381 . （in Chinese with English abstract）[10] 杨豪,魏玉峰,张御阳,等. 基于离心试验的反倾层状岩质边坡内非贯通性裂缝变形特性分析[J]. 水文地质工程地质,2022,49(6):152 − 161. [YANG Hao,WEI Yufeng,ZHANG Yuyang,et al. Analysis of deformation characteristics of non-penetrating cracks in anti-dip layered rock slope based on centrifugal test[J]. Hydrogeology & Engineering Geology,2022,49(6):152 − 161. (in Chinese with English abstract)
YANG Hao, WEI Yufeng, ZHANG Yuyang, et al . Analysis of deformation characteristics of non-penetrating cracks in anti-dip layered rock slope based on centrifugal test[J]. Hydrogeology & Engineering Geology,2022 ,49 （6 ）:152 −161 . （in Chinese with English abstract）[11] 吴昊,赵维,年廷凯,等. 反倾层状岩质边坡倾倒破坏的离心模型试验研究[J]. 水利学报,2018,49(2):223 − 231. [WU Hao,ZHAO Wei,NIAN Tingkai,et al. Study on the anti-dip layered rock slope toppling failure based on centrifuge model test[J]. Journal of Hydraulic Engineering,2018,49(2):223 − 231. (in Chinese with English abstract)
WU Hao, ZHAO Wei, NIAN Tingkai, et al . Study on the anti-dip layered rock slope toppling failure based on centrifuge model test[J]. Journal of Hydraulic Engineering,2018 ,49 （2 ）:223 −231 . （in Chinese with English abstract）[12] 蔡国军, 陈锡锐, 孙文鹏, 等. 强震作用下斜坡表面放大效应的三维离散元模拟[J]. 地质科技通报,2022,41(2):104 − 112. [CAI Guojun, CHEN Xirui, SUN Wenpeng, et al. Three-dimensional discrete element simulation of the amplification effect of the slope surface under the action of strong earthquakes[J]. Bulletin of Geological Science and Technology,2022,41(2):104 − 112. (in Chinese with English abstract)
CAI Guojun, CHEN Xirui, SUN Wenpeng, et al . Three-dimensional discrete element simulation of the amplification effect of the slope surface under the action of strong earthquakes[J]. Bulletin of Geological Science and Technology,2022 ,41 （2 ）:104 −112 . (in Chinese with English abstract)[13] 李彦奇,黄达,孟秋杰. 基于离心机和数值模拟的软硬互层反倾层状岩质边坡变形特征分析[J]. 水文地质工程地质,2021,48(4):141 − 150. [LI Yanqi,HUANG Da,MENG Qiujie. An analysis of the deformation characteristics of soft-hard interbedded anti-tilting layered rock slope based on centrifuge and numerical simulation[J]. Hydrogeology & Engineering Geology,2021,48(4):141 − 150. (in Chinese with English abstract)
LI Yanqi, HUANG Da, MENG Qiujie. An analysis of the deformation characteristics of soft-hard interbedded anti-tilting layered rock slope based on centrifuge and numerical simulation[J]. Hydrogeology & Engineering Geology, 2021, 48（4）: 141 − 150. （in Chinese with English abstract） [14] 李任杰,胡富杭,石豫川,等. 基于底摩擦试验的硬岩岩质边坡变形过程及破坏机制研究[J]. 水文地质工程地质,2022,49(3):145 − 152. [LI Renjie,HU Fuhang,SHI Yuchuan,et al. A study of deformation process and failure mechanism of hard rock slope based on the bottom friction test[J]. Hydrogeology & Engineering Geology,2022,49(3):145 − 152. (in Chinese with English abstract)
LI Renjie, HU Fuhang, SHI Yuchuan, et al . A study of deformation process and failure mechanism of hard rock slope based on the bottom friction test[J]. Hydrogeology & Engineering Geology,2022 ,49 （3 ）:145 −152 . （in Chinese with English abstract）[15] 孟凡非,浦海,陈家瑞,等. 基于颗粒离散元的薄基岩裂隙扩展规律[J]. 煤炭学报,2017,42(2):421 − 428. [MENG Fanfei,PU Hai,CHEN Jiarui,et al. Extension law of thin bedrock fissure based on particle discrete element[J]. Journal of China Coal Society,2017,42(2):421 − 428. (in Chinese with English abstract)
MENG Fanfei, PU Hai, CHEN Jiarui, et al . Extension law of thin bedrock fissure based on particle discrete element[J]. Journal of China Coal Society,2017 ,42 （2 ）:421 −428 . （in Chinese with English abstract）[16] 张波,郭帅,杨学英,等. 含X型裂隙类岩石材料水力裂缝扩展研究[J]. 煤炭学报,2019,44(7):2066 − 2073. [ZHANG Bo,GUO Shuai,YANG Xueying,et al. Hydraulic fracture propagation of rock-like material with X-type flaws[J]. Journal of China Coal Society,2019,44(7):2066 − 2073. (in Chinese with English abstract) doi: 10.13225/j.cnki.jccs.2018.1358
ZHANG Bo, GUO Shuai, YANG Xueying, et al . Hydraulic fracture propagation of rock-like material with X-type flaws[J]. Journal of China Coal Society,2019 ,44 （7 ）:2066 −2073 . （in Chinese with English abstract）[17] 武东阳,蔚立元,苏海健,等. 单轴压缩下加锚裂隙类岩石试块裂纹扩展试验及PFC3D模拟[J]. 岩土力学,2021,42(6):1681 − 1692. [WU Dongyang,YU Liyuan,SU Haijian,et al. Experimental study and PFC3D simulation on crack propagation of fractured rock-like specimens with bolts under uniaxial compression[J]. Rock and Soil Mechanics,2021,42(6):1681 − 1692. (in Chinese with English abstract)
WU Dongyang, YU Liyuan, SU Haijian, et al . Experimental study and PFC3D simulation on crack propagation of fractured rock-like specimens with bolts under uniaxial compression[J]. Rock and Soil Mechanics,2021 ,42 （6 ）:1681 −1692 . （in Chinese with English abstract）[18] KOLARI K. A complete three-dimensional continuum model of wing-crack growth in granular brittle solids[J]. International Journal of Solids and Structures,2017,115/116:27 − 42. doi: 10.1016/j.ijsolstr.2017.02.012
[19] 李学华,牛志军,姚强岭,等. 孔洞式三叉裂隙砂岩裂纹扩展特征颗粒流分析[J]. 煤炭学报,2020,45(11):3735 − 3747. [LI Xuehua,NIU Zhijun,YAO Qiangling,et al. Particle flow analysis of crack propagation characteristics of hole-type trident cracks sandstone[J]. Journal of China Coal Society,2020,45(11):3735 − 3747. (in Chinese with English abstract)
LI Xuehua, NIU Zhijun, YAO Qiangling, et al . Particle flow analysis of crack propagation characteristics of hole-type trident cracks sandstone[J]. Journal of China Coal Society,2020 ,45 （11 ）:3735 −3747 . （in Chinese with English abstract）[20] 张艳博,徐跃东,刘祥鑫,等. 基于CT的岩石三维裂隙定量表征及扩展演化细观研究[J]. 岩土力学,2021,42(10):2659 − 2671. [ZHANG Yanbo,XU Yuedong,LIU Xiangxin,et al. Quantitative characterization and mesoscopic study of propagation and evolution of three-dimensional rock fractures based on CT[J]. Rock and Soil Mechanics,2021,42(10):2659 − 2671. (in Chinese with English abstract)
ZHANG Yanbo, XU Yuedong, LIU Xiangxin, et al . Quantitative characterization and mesoscopic study of propagation and evolution of three-dimensional rock fractures based on CT[J]. Rock and Soil Mechanics,2021 ,42 （10 ）:2659 −2671 . （in Chinese with English abstract）[21] 王辉,李勇,曹树刚,等. 含预制裂隙黑色页岩裂纹扩展过程及宏观破坏模式巴西劈裂试验研究[J]. 岩石力学与工程学报,2020,39(5):912 − 926. [WANG Hui,LI Yong,CAO Shugang,et al. Brazilian splitting test study on crack propagation process and macroscopic failure mode of pre-cracked black shale[J]. Chinese Journal of Rock Mechanics and Engineering,2020,39(5):912 − 926. (in Chinese with English abstract)
WANG Hui, LI Yong, CAO Shugang, et al . Brazilian splitting test study on crack propagation process and macroscopic failure mode of pre-cracked black shale[J]. Chinese Journal of Rock Mechanics and Engineering,2020 ,39 （5 ）:912 −926 . （in Chinese with English abstract）[22] 周子涵,陈忠辉,王建明,等. 卸荷条件下岩石平行偏置双裂隙的扩展规律研究[J]. 岩土工程学报,2020,42(4):721 − 730. [ZHOU Zihan,CHEN Zhonghui,WANG Jianming,et al. Propagation of offset parallel cracks in rock under unloading conditions[J]. Chinese Journal of Geotechnical Engineering,2020,42(4):721 − 730. (in Chinese with English abstract) doi: 10.11779/CJGE202004015
ZHOU Zihan, CHEN Zhonghui, WANG Jianming, et al . Propagation of offset parallel cracks in rock under unloading conditions[J]. Chinese Journal of Geotechnical Engineering,2020 ,42 （4 ）:721 −730 . （in Chinese with English abstract） -
