含裂隙近水平红层软岩边坡渗透稳定性模型试验

邓威, 肖世国. 含裂隙近水平红层软岩边坡渗透稳定性模型试验[J]. 水文地质工程地质, 2024, 51(1): 57-68. doi: 10.16030/j.cnki.issn.1000-3665.202210050
引用本文: 邓威, 肖世国. 含裂隙近水平红层软岩边坡渗透稳定性模型试验[J]. 水文地质工程地质, 2024, 51(1): 57-68. doi: 10.16030/j.cnki.issn.1000-3665.202210050
DENG Wei, XIAO Shiguo. Model test on stability of soft rock slopes composed of nearly horizontal redbeds with cracks[J]. Hydrogeology & Engineering Geology, 2024, 51(1): 57-68. doi: 10.16030/j.cnki.issn.1000-3665.202210050
Citation: DENG Wei, XIAO Shiguo. Model test on stability of soft rock slopes composed of nearly horizontal redbeds with cracks[J]. Hydrogeology & Engineering Geology, 2024, 51(1): 57-68. doi: 10.16030/j.cnki.issn.1000-3665.202210050

含裂隙近水平红层软岩边坡渗透稳定性模型试验

  • 基金项目: 四川省交通运输科技项目(2020-A-01);国家自然科学基金项目(51578466)
详细信息
    作者简介: 邓威(1998—),男,硕士研究生,主要从事边坡工程研究工作。E-mail:2950883042@qq.com
    通讯作者: 肖世国(1973—),男,博士,教授,主要从事边坡与支挡结构研究工作。E-mail:xiaoshiguo@swjtu.cn
  • 中图分类号: P642.22

Model test on stability of soft rock slopes composed of nearly horizontal redbeds with cracks

More Information
  • 针对川东地区含裂隙近水平红层软岩边坡在长时强降雨条件下易产生滑坡灾害的问题,依托含双软弱夹层的此类典型坡体实例,以弹性模量和抗拉强度为主控因素制备可表征软岩遇水软化开裂特性的相似材料,构建了含裂隙近水平红层软岩边坡的室内物理试验模型,研究了边坡在长期雨水入渗作用下的坡体变形、裂隙扩展和稳定性演变规律。结果表明:(1)坡体变形发展可分为初始变形阶段、匀速变形阶段、加速变形破坏阶段;(2)坡体裂隙扩展主要包括在坡体后部的自下而上发育的“上窄下宽”裂隙,以及在坡体前部的自上而下发育的“上宽下窄”裂隙。裂隙扩展区域主要集中在上、下软弱夹层之间,其中易产生超孔隙水压力;(3)试验模型的FLAC3D数值模拟再现了该推移式滑坡的渗流过程,超孔隙水压力随时间呈现先增大后逐渐趋于稳定的变化特征,在软弱夹层和竖向裂隙处,超孔隙水压力呈累计增大的特征;(4)坡体滑面形成及失稳破坏演变过程可划分为浅表层裂隙发育贯通阶段、裂隙向软弱夹层延伸发育并逐步贯通阶段、裂隙扩展与坡体滑动失稳阶段。长期雨水入渗致岩体强度弱化,以及裂隙逐渐向坡体深部发育并与软弱夹层贯通形成多级阶梯式滑裂面,是造成含裂隙近水平红层软岩边坡滑动失稳的根本原因。

  • 加载中
  • 图 1  安乐寺滑坡地质剖面图(改自文献[20])

    Figure 1.

    图 2  试验模型示意图

    Figure 2.

    图 3  模型岩层1#—3#中预设裂隙平面示意图

    Figure 3.

    图 4  试验加载装置

    Figure 4.

    图 5  边坡模型测点布置图

    Figure 5.

    图 6  试验采用的测试元器件

    Figure 6.

    图 7  试验数据采集系统

    Figure 7.

    图 8  试验降雨装置

    Figure 8.

    图 9  整体试验模型及加载测试系统

    Figure 9.

    图 10  坡体模型裂隙发育特征

    Figure 10.

    图 11  坡表位移随时间变化曲线

    Figure 11.

    图 12  试验中坡面开裂及局部岩块滑落

    Figure 12.

    图 13  坡体中各测点总压应力随时间变化曲线

    Figure 13.

    图 14  坡体模型的裂隙演变发展过程

    Figure 14.

    图 15  坡体中各测点超孔隙水压力随时间变化曲线

    Figure 15.

    图 16  试验坡体渗流数值模型

    Figure 16.

    图 17  数值模拟与模型试验的超孔隙水压力对比

    Figure 17.

    图 18  不同降雨时长下坡体超孔隙水压力分布云图

    Figure 18.

    图 19  边坡内部渗流路径分布

    Figure 19.

    图 20  阶段Ⅲ时坡体中潜在滑裂面

    Figure 20.

    图 21  边坡潜在滑体受力分析模型

    Figure 21.

    图 22  坡体后侧加载推力变化曲线

    Figure 22.

    表 1  岩层原型与模型材料的主控力学参数

    Table 1.  Main mechanical parameters of rock prototype and model materials

    岩层 σt/MPa σc/MPa E/MPa c/kPa φ/(°)
    粉砂岩 原型 1.440 44.95 4803.24 6630.0 59.6
    设计 0.029 0.90 96.07 132.6 59.6
    试验 0.027 0.66 82.07 128.2 58.9
    泥岩 原型 0.300 3.20 588.00 280.0 34.3
    设计 0.006 0.06 11.76 5.6 34.3
    试验 0.005 0.06 10.92 5.0 33.1
    下载: 导出CSV

    表 2  数值模型主要物理力学参数

    Table 2.  Main physical and mechanical parameters of the numerical model

    材料 c/kPa φ/(°) σt/kPa E/MPa k/(cm·s−1
    软弱层 23.5 15.2 30 0.459 6E-3
    岩层 132 41 800 82.7 0
    裂隙 23.5 15.2 30 0.459 1E-1
    下载: 导出CSV

    表 3  坡体模型稳定性分析的滑面参数取值

    Table 3.  Parameters of the sliding surface in the slope model for stability analysis

    阶段φ/(°)c/kPaPJ/kPaV/kPaL/mS/m2
    I16.43117.5330.850.2
    15.82831.5851.30.31
    15.22533.8861.40.6
    下载: 导出CSV

    表 4  坡体稳定性分析结果

    Table 4.  Analysis results of the slope stability

    阶段 滑面 R/(kN·m−1 F/(kN·m−1 K
    I I 27.30 12.42 2.20
    37.67 27.36 1.38
    37.68 42.26 0.89
    下载: 导出CSV
  • [1]

    张涛,谢忠胜,石胜伟,等. 南江县石板沟滑坡特征、成因及演化过程研究[J]. 长江科学院院报,2013,30(7):33 − 37. [ZHANG Tao,XIE Zhongsheng,SHI Shengwei,et al. Characteristics,geological causes and evolution of shibangou landslide in Nanjiang County[J]. Journal of Yangtze River Scientific Research Institute,2013,30(7):33 − 37. (in Chinese with English abstract)

    ZHANG Tao, XIE Zhongsheng, SHI Shengwei, et al. Characteristics, geological causes and evolution of shibangou landslide in Nanjiang County[J]. Journal of Yangtze River Scientific Research Institute, 2013, 307): 3337. (in Chinese with English abstract)

    [2]

    谢小帅,陈华松,肖欣宏,等. 水岩耦合下的红层软岩微观结构特征与软化机制研究[J]. 工程地质学报,2019,27(5):966 − 972. [XIE Xiaoshuai,CHEN Huasong,XIAO Xinhong,et al. Micro-structural characteristics and softening mechanism of red-bed soft rock under water-rock interaction condition[J]. Journal of Engineering Geology,2019,27(5):966 − 972. (in Chinese with English abstract)

    XIE Xiaoshuai, CHEN Huasong, XIAO Xinhong, et al. Micro-structural characteristics and softening mechanism of red-bed soft rock under water-rock interaction condition[J]. Journal of Engineering Geology, 2019, 275): 966972. (in Chinese with English abstract)

    [3]

    李安润,邓辉,王红娟,等. 水-岩作用下粉砂质泥岩含水损伤本构模型[J]. 水文地质工程地质,2021,48(2):106 − 113. [LI Anrun,DENG Hui,WANG Hongjuan,et al. Constitutive model of water-damaged silty mudstone under water-rock interactions[J]. Hydrogeology & Engineering Geology,2021,48(2):106 − 113. (in Chinese with English abstract)

    LI Anrun, DENG Hui, WANG Hongjuan, et al. Constitutive model of water-damaged silty mudstone under water-rock interactions[J]. Hydrogeology & Engineering Geology, 2021, 482): 106113. (in Chinese with English abstract)

    [4]

    王迎春,陈剑. 红层软岩微观结构与抗剪强度关系实验分析[J]. 现代地质,2013,27(3):738 − 742. [WANG Yingchun,CHEN Jian. Preliminary research on the relationship between microscopic structure and shear strength of red-bed soft rocks[J]. Geoscience,2013,27(3):738 − 742. (in Chinese with English abstract)

    WANG Yingchun, CHEN Jian. Preliminary research on the relationship between microscopic structure and shear strength of red-bed soft rocks[J]. Geoscience, 2013, 273): 738742. (in Chinese with English abstract)

    [5]

    ZHANG Shuai,XU Qiang,HU Zeming. Effects of rainwater softening on red mudstone of deep-seated landslide,Southwest China[J]. Engineering Geology,2016,204:1 − 13. doi: 10.1016/j.enggeo.2016.01.013

    [6]

    邓华锋,周美玲,李建林,等. 水-岩作用下红层软岩力学特性劣化规律研究[J]. 岩石力学与工程学报,2016,35(增刊2):3481 − 3491. [DENG Huafeng,ZHOU Meiling,LI Jianlin,et al. Mechanical properties deteriorating change rule research of red-layer soft rock under water-rock interaction[J]. Chinese Journal of Rock Mechanics and Engineering,2016,35(Sup 2):3481 − 3491. (in Chinese with English abstract)

    DENG Huafeng, ZHOU Meiling, LI Jianlin, et al. Mechanical properties deteriorating change rule research of red-layer soft rock under water-rock interaction[J]. Chinese Journal of Rock Mechanics and Engineering, 2016, 35(Sup 2): 3481 − 3491. (in Chinese with English abstract)

    [7]

    邓华锋,支永艳,段玲玲,等. 水-岩作用下砂岩力学特性及微细观结构损伤演化[J]. 岩土力学,2019,40(9):3447 − 3456. [DENG Huafeng,ZHI Yongyan,DUAN Lingling,et al. Mechanical properties of sandstone and damage evolution of microstructure under water-rock interaction[J]. Rock and Soil Mechanics,2019,40(9):3447 − 3456. (in Chinese with English abstract)

    DENG Huafeng, ZHI Yongyan, DUAN Lingling, et al. Mechanical properties of sandstone and damage evolution of microstructure under water-rock interaction[J]. Rock and Soil Mechanics, 2019, 409): 34473456. (in Chinese with English abstract)

    [8]

    郭永春,谢强,文江泉. 水热交替对红层泥岩崩解的影响[J]. 水文地质工程地质,2012,39(5):69 − 73. [GUO Yongchun,XIE Qiang,WEN Jiangquan. Effect of the alternation of heat and water on the slaking phenomenon of redbeds[J]. Hydrogeology & Engineering Geology,2012,39(5):69 − 73. (in Chinese with English abstract)

    GUO Yongchun, XIE Qiang, WEN Jiangquan. Effect of the alternation of heat and water on the slaking phenomenon of redbeds[J]. Hydrogeology & Engineering Geology, 2012, 395): 6973. (in Chinese with English abstract)

    [9]

    ZHANG Dan,CHEN Anqiang,LIU Gangcai. Laboratory investigation of disintegration characteristics of purple mudstone under different hydrothermal conditions[J]. Journal of Mountain Science,2012,9(1):127 − 136. doi: 10.1007/s11629-012-2204-1

    [10]

    郭永春,赵峰先,闫圣龙,等. 红层泥岩三轴膨胀力的试验研究[J]. 水文地质工程地质,2022,49(3):87 − 93. [GUO Yongchun,ZHAO Fengxian,YAN Shenglong,et al. An experimental study of the triaxial expansion force of red-bed mudstone[J]. Hydrogeology & Engineering Geology,2022,49(3):87 − 93. (in Chinese with English abstract)

    GUO Yongchun, ZHAO Fengxian, YAN Shenglong, et al. An experimental study of the triaxial expansion force of red-bed mudstone[J]. Hydrogeology & Engineering Geology, 2022, 493): 8793. (in Chinese with English abstract)

    [11]

    张涛,谢忠胜,石胜伟,等. 川东红层缓倾岩质滑坡的演化过程及其识别标志探讨[J]. 工程地质学报,2017,25(2):496 − 503. [ZHANG Tao,XIE Zhongsheng,SHI Shengwei,et al. Discussion on evolution process of flat rock landslide and its identification in red strata at eastern Sichuan[J]. Journal of Engineering Geology,2017,25(2):496 − 503. (in Chinese with English abstract)

    ZHANG Tao, XIE Zhongsheng, SHI Shengwei, et al. Discussion on evolution process of flat rock landslide and its identification in red strata at eastern Sichuan[J]. Journal of Engineering Geology, 2017, 252): 496503. (in Chinese with English abstract)

    [12]

    许强,唐然. 红层及其地质灾害研究[J]. 岩石力学与工程学报,2023,42(1):28 − 50. [XU Qiang,TANG Ran. Study on red beds and their geological disasters[J]. Chinese Journal of Rock Mechanics and Engineering,2023,42(1):28 − 50. (in Chinese with English abstract)

    XU Qiang, TANG Ran. Study on red beds and their geological disasters[J]. Chinese Journal of Rock Mechanics and Engineering, 2023, 421): 2850. (in Chinese with English abstract)

    [13]

    MIKOŠ M,ČETINA M,BRILLY M. Hydrologic conditions responsible for triggering the Stože landslide,Slovenia[J]. Engineering Geology,2004,73(3/4):193 − 213.

    [14]

    张明,胡瑞林,殷跃平,等. 川东缓倾红层中降雨诱发型滑坡机制研究[J]. 岩石力学与工程学报,2014,33(增刊2):3783 − 3790. [ZHANG Ming,HU Ruilin,YIN Yueping,et al. Study of mechanism of landslide induced by rainfall in gently inclined red stratum in East Sichuan Basin[J]. Chinese Journal of Rock Mechanics and Engineering,2014,33(Sup 2):3783 − 3790. (in Chinese with English abstract)

    ZHANG Ming, HU Ruilin, YIN Yueping, et al. Study of mechanism of landslide induced by rainfall in gently inclined red stratum in East Sichuan Basin[J]. Chinese Journal of Rock Mechanics and Engineering, 2014, 33(Sup 2): 3783 − 3790. (in Chinese with English abstract)

    [15]

    ZHANG Zhenping,FU Xiaodong,SHENG Qian,et al. Effect of rainfall pattern and crack on the stability of a red bed slope:A case study in Yunnan Province[J]. Advances in Civil Engineering,2021,2021:1 − 21.

    [16]

    李龙起,罗书学,王运超,等. 不同降雨条件下顺层边坡力学响应模型试验研究[J]. 岩石力学与工程学报,2014,33(4):755 − 762. [LI Longqi,LUO Shuxue,WANG Yunchao,et al. Model tests for mechanical response of bedding rock slope under different rainfall conditions[J]. Chinese Journal of Rock Mechanics and Engineering,2014,33(4):755 − 762. (in Chinese with English abstract)

    LI Longqi, LUO Shuxue, WANG Yunchao, et al. Model tests for mechanical response of bedding rock slope under different rainfall conditions[J]. Chinese Journal of Rock Mechanics and Engineering, 2014, 334): 755762. (in Chinese with English abstract)

    [17]

    杨旭,周翠英,刘镇,等. 华南典型巨厚层红层软岩边坡降雨失稳的模型试验研究[J]. 岩石力学与工程学报,2016,35(3):549 − 557. [YANG Xu,ZHOU Cuiying,LIU Zhen,et al. Model tests for failure mechanism of typical soft rock slopes of red beds under rainfall in South China[J]. Chinese Journal of Rock Mechanics and Engineering,2016,35(3):549 − 557. (in Chinese with English abstract)

    YANG Xu, ZHOU Cuiying, LIU Zhen, et al. Model tests for failure mechanism of typical soft rock slopes of red beds under rainfall in South China[J]. Chinese Journal of Rock Mechanics and Engineering, 2016, 353): 549557. (in Chinese with English abstract)

    [18]

    王海,张梓钦,杨国香,等. 五盂高速公路顺层岩质边坡变形破坏模型试验[J]. 科学技术与工程,2021,21(9):3754 − 3762. [WANG Hai,ZHANG Ziqin,YANG Guoxiang,et al. Model tests of deformation and failure of bedding rock slope in Wuyu expressway[J]. Science Technology and Engineering,2021,21(9):3754 − 3762. (in Chinese with English abstract)

    WANG Hai, ZHANG Ziqin, YANG Guoxiang, et al. Model tests of deformation and failure of bedding rock slope in Wuyu expressway[J]. Science Technology and Engineering, 2021, 219): 37543762. (in Chinese with English abstract)

    [19]

    简文星,殷坤龙,罗冲,等. 三峡库区万州安乐寺滑坡滑带特征[J]. 地球科学,2008,33(5):672 − 678. [JIAN Wenxing,YIN Kunlong,LUO Chong,et al. Slip zone characteristics of anlesi landslide in Wanzhou of Three Gorges Reservoir area[J]. Earth Science,2008,33(5):672 − 678. (in Chinese with English abstract)

    JIAN Wenxing, YIN Kunlong, LUO Chong, et al. Slip zone characteristics of anlesi landslide in Wanzhou of Three Gorges Reservoir area[J]. Earth Science, 2008, 33(5): 672 − 678. (in Chinese with English abstract)

    [20]

    崔政权. 三峡工程库岸稳态评价预测概念[R]. 武汉:长江水利委员会勘测局,1993. [Cui Zheng Quan. The concept of steady-state evaluation and prediction for Three Gorges Reservoir Bank[R]. Wuhan:Survey Bureau of Changjiang Water Resources Commission,1993. (in Chinese)

    Cui Zheng Quan. The concept of steady-state evaluation and prediction for Three Gorges Reservoir Bank[R]. Wuhan: Survey Bureau of Changjiang Water Resources Commission, 1993. (in Chinese)

    [21]

    吉随旺,张倬元,王凌云,等. 近水平软硬互层斜坡变形破坏机制[J]. 中国地质灾害与防治学报,2000,11(3):49 − 52. [JI Suiwang,ZHANG Zhuoyuan,WANG Lingyun,et al. The mechanism of deformation and failure for the slope composed of nearly horizontal competent and incompetent intercalated rock mass strata[J]. The Chinese Journal of Geological Hazard and Control,2000,11(3):49 − 52. (in Chinese with English abstract)

    JI Suiwang, ZHANG Zhuoyuan, WANG Lingyun, et al. The mechanism of deformation and failure for the slope composed of nearly horizontal competent and incompetent intercalated rock mass strata[J]. The Chinese Journal of Geological Hazard and Control, 2000, 113): 4952. (in Chinese with English abstract)

    [22]

    《工程地质手册》编委会. 工程地质手册[M]. 5版. 北京:中国建筑工业出版社,2017:175. [Editorial Board of Geological Engineering Handbook. Geological engineering handbook[M]. 5th ed. Beijing:China Architecture & Building Press,2017:175. (in Chinese)

    Editorial Board of Geological Engineering Handbook. Geological engineering handbook[M]. 5th ed. Beijing: China Architecture & Building Press, 2017: 175. (in Chinese)
