综合物探探测豫北灰岩区薄覆盖层隐伏断层方法研究

,  ,  ,

文章导航 > 水文地质工程地质 > 2024 > 51(1): 154-166

上一篇

下一篇

朱瑞, 任云峰, 熊奇, 薛寒. 综合物探探测豫北灰岩区薄覆盖层隐伏断层方法研究[J]. 水文地质工程地质, 2024, 51(1): 154-166. doi: 10.16030/j.cnki.issn.1000-3665.202211058
引用本文: 朱瑞, 任云峰, 熊奇, 薛寒. 综合物探探测豫北灰岩区薄覆盖层隐伏断层方法研究[J]. 水文地质工程地质, 2024, 51(1): 154-166. doi: 10.16030/j.cnki.issn.1000-3665.202211058
shu
ZHU Rui, REN Yunfeng, XIONG Qi, XUE Han. Study on the method of comprehensive geophysical prospecting for detecting the thin overburden buried faults in limestone area in northern Henan[J]. Hydrogeology & Engineering Geology, 2024, 51(1): 154-166. doi: 10.16030/j.cnki.issn.1000-3665.202211058
Citation: ZHU Rui, REN Yunfeng, XIONG Qi, XUE Han. Study on the method of comprehensive geophysical prospecting for detecting the thin overburden buried faults in limestone area in northern Henan[J]. Hydrogeology & Engineering Geology, 2024, 51(1): 154-166. doi: 10.16030/j.cnki.issn.1000-3665.202211058
shu

综合物探探测豫北灰岩区薄覆盖层隐伏断层方法研究

  • 河南省水利勘测设计研究有限公司，河南 郑州　450016

  • 基金项目: 信阳市四水同治及城市供水工程科研项目（YSY2023JF070）；河南省水利厅水利攻关科技项目（GG201907）
详细信息
    作者简介: 朱瑞（1989—），男，硕士，工程师，主要从事地质工程和工程物探方面的研究工作。E-mail：huashuizhurui@163.com

  • 中图分类号: P631

Study on the method of comprehensive geophysical prospecting for detecting the thin overburden buried faults in limestone area in northern Henan

  • Henan Water & Power Engineering Consulting Co. Ltd., Zhengzhou，Henan　450016, China

    摘要

  • 隐伏断层的精准识别对于水利建设工程至关重要。物探是快速识别隐伏断层的有效方法。由于地球物理问题的多解性，单一物探方法又带有片面性。如何选用优化物探方法组合快速准确识别隐伏断层，是目前亟须解决的难点和热点问题。在综合分析豫北太行山灰岩区各类岩土体物性特征和现场地质条件的基础上，分别对F1小尺度张扭性正断层和F16大尺度扭性平移-正断层开展高密度电法、地震反射波法、折射层析法和瞬态瑞雷面波法等综合物探方法的探测研究工作。研究发现，折射层析法和地震反射波法联合探测成果分别从横波速度和反射波同相轴变化特征完整揭示了F1断层的发育特征。而对于F16断层，高密度电法、地震反射波法和瞬态瑞雷面波法综合探测成果异常区高度吻合，折射层析法也取得一定效果。经钻探和孔内电视验证，F16断层规模庞大，并伴生溶洞，与物探结果吻合。研究结果表明，地震反射波法和折射层析法相结合探测类似F1断层，可有效降低解译成果的多解性，节省探测成本。采用高密度电法普查、地震反射波法和瞬态瑞雷面波法详查，实现了类似F16断层的快速准确识别。两种组合探测技术能够快速确定灰岩区两类典型薄覆盖隐伏断层的位置、深度、产状和性质，有效避免探测工作的盲目性和片面性，为类似工况的高效探测提供了新思路，也将会在该领域发挥更大作用。

    Accurate identification of the buried faults is crucial for the water conservancy projects construction. Geophysical exploration is an effective method for identifying buried faults quickly. However, due to the multi-solution nature of geophysical problems, a single geophysical method is also one-sided. Therefore, the selection of an optimized combination of geophysical methods to identify buried faults quickly and accurately is currently a difficult and hot issue to be addressed. Based on the comprehensive analysis of the physical characteristics of various rock and soil masses and on-site geological conditions in limestone area of Taihang Mountain in northern Henan, the comprehensive geophysical exploration methods such as electrical resistivity tomography, seismic reflection survey, refraction tomography and transient Rayleigh surface wave method were carried out for the F1 small-scale tensional torsional normal fault and F16 large-scale torsional translational normal fault respectively. It is found that the combined exploration results of refraction tomography and seismic reflection survey fully revealed the development characteristics of F1 fault from the characteristics of shear wave velocity and reflection wave events respectively. For the F16 fault, the comprehensive detection results of electrical resistivity tomography, seismic reflection survey, and transient Rayleigh surface wave method are highly consistent in the abnormal areas, and the refraction tomography has also achieved complete results. F16 fault was verified by drilling and borehole television to be massive and associated with caves, which is consistent with the physical results. The research results show that the combination of seismic reflection survey and refraction tomography for detecting similar F1 fault can reduce the multiplicity of interpretation results and save exploration costs effectively. Using electrical resistivity tomography, seismic reflection survey and transient Rayleigh surface wave method for detailed investigation, rapid and accurate identification of faults similar to F16 has been achieved. The two combined detection techniques can determine the location, depth, occurrence and nature of two types of typical thin overburden buried faults in limestone areas quickly, and could reduce blindness and one-sidedness in the detection work effectively, provide a new idea for efficient detection for similar condition. The proposed method could play a greater role in this field.

    • HTML全文
  • 加载中

  • 图 1  工作区地形及物探测线布置图

    Figure 1.

    下载: 全尺寸图片 幻灯片

    图 2  上坝址左岸F1断层

    Figure 2.

    下载: 全尺寸图片 幻灯片

    图 3  下坝址左岸F16断层

    Figure 3.

    下载: 全尺寸图片 幻灯片

    图 4  F1断层综合物探成果图

    Figure 4.

    下载: 全尺寸图片 幻灯片

    图 5  F1断层关键高程不同物性参数随水平距离变化规律

    Figure 5.

    下载: 全尺寸图片 幻灯片

    图 6  F16断层综合物探成果图

    Figure 6.

    下载: 全尺寸图片 幻灯片

    图 7  ZK3孔内电视揭露断层及溶洞

    Figure 7.

    下载: 全尺寸图片 幻灯片

    图 8  F16断层关键高程不同物性参数随水平距离变化规律

    Figure 8.

    下载: 全尺寸图片 幻灯片

    图 9  下坝址高密度电法三维成果图

    Figure 9.

    下载: 全尺寸图片 幻灯片

    表 1  工区地层物理参数统计

    Table 1.  Physical parameters statistics of the site stratigraphic

    地层时代 代号 岩性 电阻率/（Ω∙m） 纵波速度/（m·s−1） 横波速度/（m·s−1）
    第四系 $ {\text{Q}} $ 重粉质壤土、粉质黏土 15～50 300～400 200～300
    碎石土、泥卵石 50～200 400～1800 300～800
    灰岩、白云质灰岩、灰质白云岩 400～5000 2 000～5000 1000～3000
    奥陶系 $ {\text{O}} $ 断层角砾岩 400～5000 1500～1800 1000～1200
    断层破碎带 15～200 1000～1500 800～1000
    下载: 导出CSV

    表 2  断层和覆盖层地球物理响应特征统计表

    Table 2.  The statistical table of geophysical response characteristics of different faults and overburden

    物探方法F1断层F16断层薄覆盖层
    高密度电法未见明显异常大范围低阻异常区，局部发育低阻团电阻率分布连续稳定，局部发育低阻团
    地震反射波法同相轴错断、分叉，发育绕射波同相轴错断、分叉，发育绕射波同相轴平稳连续
    地震折射层析囊状低速带，而未下探囊状低速带，而未下探纵波速度分布连续稳定，局部发育低速度团
    瞬态瑞利面波面波不发育大范围低速异常区，局部发育低速团横波速度分布连续稳定，局部发育低速度团
    下载: 导出CSV
    • 参考文献(32)
  • [1]

    BLOUIN M,GLOAGUEN E. Comprehensive geophysical data integration and stratigraphic contacts delineation in a regional hydrogeological characterization study[J]. Journal of Environmental and Engineering Geophysics,2015,20(2):183 − 193. doi: 10.2113/JEEG20.2.183

    [2]

    METWALY M,ELAWADI E,MOUSTAFA S S R,et al. Combined inversion of electrical resistivity and transient electromagnetic soundings for mapping groundwater contamination plumes in Al quwy’yia area,Saudi Arabia[J]. Journal of Environmental and Engineering Geophysics,2014,19(1):45 − 52. doi: 10.2113/JEEG19.1.45

    [3]

    包勋,汤浩,朱照拔,等. 综合物探技术在探测隐伏断层中的应用[J]. 人民珠江,2016,37(12):29 − 32. [BAO Xun,TANG Hao,ZHU Zhaoba,et al. Application of comprehensive geophysical prospecting method to buried fault detection[J]. Pearl River,2016,37(12):29 − 32. (in Chinese with English abstract) doi: 10.3969/j.issn.1001-9235.2016.12.005

    BAO Xun, TANG Hao, ZHU Zhaoba, et al. Application of comprehensive geophysical prospecting method to buried fault detection[J]. Pearl River, 2016, 37（12）: 29 − 32. （in Chinese with English abstract） doi: 10.3969/j.issn.1001-9235.2016.12.005

    [4]

    蒋全科,雷宛,黄霄寒,等. 应用综合电阻率法勘察隐伏断层[J]. 成都理工大学学报(自然科学版),2016,43(3):378 − 384. [JIANG Quanke,LEI Wan,HUANG Xiaohan,et al. An application of prospecting concealed fault with multi-resistivity method[J]. Journal of Chengdu University of Technology (Science & Technology Edition),2016,43(3):378 − 384. (in Chinese with English abstract) doi: 10.3969/j.issn.1671-9727.2016.03.15

    JIANG Quanke, LEI Wan, HUANG Xiaohan, et al. An application of prospecting concealed fault with multi-resistivity method[J]. Journal of Chengdu University of Technology （Science & Technology Edition）, 2016, 43（3）: 378 − 384. （in Chinese with English abstract） doi: 10.3969/j.issn.1671-9727.2016.03.15

    [5]

    赵勇,王志辉,罗水余,等. 综合物探技术在北京山前平原隐伏断层探测中的应用[J]. 城市地质,2013,8(2):38 − 41. [ZHAO Yong,WANG Zhihui,LUO Shuiyu,et al. The application of comprehensive geophysical exploration technique to buried fault detection in piedmont plain of Beijing[J]. Urban Geology,2013,8(2):38 − 41. (in Chinese with English abstract) doi: 10.3969/j.issn.1007-1903.2013.02.011

    ZHAO Yong, WANG Zhihui, LUO Shuiyu, et al. The application of comprehensive geophysical exploration technique to buried fault detection in piedmont plain of Beijing[J]. Urban Geology, 2013, 8（2）: 38 − 41. （in Chinese with English abstract） doi: 10.3969/j.issn.1007-1903.2013.02.011

    [6]

    郑智杰,敖文龙,曾洁,等. 综合物探法在柳州泗角村岩溶塌陷区调查中的应用[J]. 水文地质工程地质,2017,44(5):143 − 149. [ZHENG Zhijie,AO Wenlong,ZENG Jie,et al. Application of integrated geophysical methods to Karst collapse investigation in the Sijiao Village near Liuzhou[J]. Hydrogeology & Engineering Geology,2017,44(5):143 − 149. (in Chinese with English abstract)

    ZHENG Zhijie, AO Wenlong, ZENG Jie, et al. Application of integrated geophysical methods to Karst collapse investigation in the Sijiao Village near Liuzhou[J]. Hydrogeology & Engineering Geology, 2017, 44（5）: 143 − 149. （in Chinese with English abstract）

    [7]

    房浩,李巧灵,雷晓东,等. 平原区深层隐伏岩溶塌陷主控因子地球物理调查方法适用性分析[J]. 水文地质工程地质,2020,47(1):153 − 160. [FANG Hao,LI Qiaoling,LEI Xiaodong,et al. Applicability of geophysical survey methods for the main controlling factors of deep covered Karst collapse in plain areas[J]. Hydrogeology & Engineering Geology,2020,47(1):153 − 160. (in Chinese with English abstract)

    FANG Hao, LI Qiaoling, LEI Xiaodong, et al. Applicability of geophysical survey methods for the main controlling factors of deep covered Karst collapse in plain areas[J]. Hydrogeology & Engineering Geology, 2020, 47（1）: 153 − 160. （in Chinese with English abstract）

    [8]

    何军,刘磊,黎清华,等. 隐伏岩溶区地下空间探测技术方法研究——以武汉市为例[J]. 水文地质工程地质,2020,47(6):47 − 56. [HE Jun,LIU Lei,LI Qinghua,et al. Techniques for detecting underground space in hidden karst region:Taking Wuhan as an example[J]. Hydrogeology & Engineering Geology,2020,47(6):47 − 56. (in Chinese with English abstract)

    HE Jun, LIU Lei, LI Qinghua, et al. Techniques for detecting underground space in hidden karst region: Taking Wuhan as an example[J]. Hydrogeology & Engineering Geology, 2020, 47（6）: 47 − 56. （in Chinese with English abstract）

    [9]

    罗尧东,代群威,董发勤,等. 九寨沟“8•8”地震背景下火花海钙华坝体无损探测分析[J]. 中国岩溶,2021,40(1):147 − 156. [LUO Yaodong,DAI Qunwei,DONG Faqin,et al. Study on non-destructive detection technology on travertine dam in sparkling lake under the background of “8•8” earthquake in Jiuzhaigou valley[J]. Carsologica Sinica,2021,40(1):147 − 156. (in Chinese with English abstract)

    LUO Yaodong, DAI Qunwei, DONG Faqin, et al. Study on non-destructive detection technology on travertine dam in sparkling lake under the background of “8•8” earthquake in Jiuzhaigou valley[J]. Carsologica Sinica, 2021, 40（1）: 147 − 156. （in Chinese with English abstract）

    [10]

    赵虎,张泉,谭建秋,等. 基于综合物探方法的公路不稳定边坡潜在滑面探测[J]. 中国地质灾害与防治学报,2022,33(1):117 − 122. [ZHAO Hu,ZHANG Quan,TAN Jianqiu,et al. Detection of the potential failure zones of the unstable slopes along highway using comprehensive geophysical methods[J]. The Chinese Journal of Geological Hazard and Control,2022,33(1):117 − 122. (in Chinese with English abstract)

    ZHAO Hu, ZHANG Quan, TAN Jianqiu, et al. Detection of the potential failure zones of the unstable slopes along highway using comprehensive geophysical methods[J]. The Chinese Journal of Geological Hazard and Control, 2022, 33（1）: 117 − 122. （in Chinese with English abstract）

    [11]

    何正勤,陈宇坤,叶太兰,等. 浅层地震勘探在沿海地区隐伏断层探测中的应用[J]. 地震地质,2007,29(2):363 − 372. [HE Zhengqin,CHEN Yukun,YE Tailan,et al. Application of shallow seismic exploration in detection of buried fault in coastal areas[J]. Seismology and Geology,2007,29(2):363 − 372. (in Chinese with English abstract)

    HE Zhengqin, CHEN Yukun, YE Tailan, et al. Application of shallow seismic exploration in detection of buried fault in coastal areas[J]. Seismology and Geology, 2007, 29（2）: 363 − 372. （in Chinese with English abstract）

    [12]

    李华强,刘桂梅,王建新,等. 高分辨率二维地震勘探在城市活动断层探测中的应用[J]. 中国地质灾害与防治学报,2013,24(2):87 − 91. [LI Huaqiang,LIU Guimei,WANG Jianxin,et al. Application of high-resolution two-dimensional seismic exploration for urban active fault[J]. The Chinese Journal of Geological Hazard and Control,2013,24(2):87 − 91. (in Chinese with English abstract)

    LI Huaqiang, LIU Guimei, WANG Jianxin, et al. Application of high-resolution two-dimensional seismic exploration for urban active fault[J]. The Chinese Journal of Geological Hazard and Control, 2013, 24（2）: 87 − 91. （in Chinese with English abstract）

    [13]

    酆少英,龙长兴,高锐,等. 高分辨折射和浅层反射地震方法在活断层探测中的联合应用[J]. 地震学报,2010,32(6):718 − 724. [FENG Shaoying,LONG Changxing,GAO Rui,et al. Joint application of high-resolution refraction and shallow reflection seismic exploration approach to active fault survey[J]. Acta Seismologica Sinica,2010,32(6):718 − 724. (in Chinese with English abstract)

    FENG Shaoying, LONG Changxing, GAO Rui, et al. Joint application of high-resolution refraction and shallow reflection seismic exploration approach to active fault survey[J]. Acta Seismologica Sinica, 2010, 32（6）: 718 − 724. （in Chinese with English abstract）

    [14]

    李建军,张军龙. 探地雷达在探测隐伏活动断层中的应用[J]. 地震,2015,35(4):83 − 89. [LI Jianjun,ZHANG Junlong. Application of GPR in surveying underlied active faults[J]. Earthquake,2015,35(4):83 − 89. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-3274.2015.04.009

    LI Jianjun, ZHANG Junlong. Application of GPR in surveying underlied active faults[J]. Earthquake, 2015, 35（4）: 83 − 89. （in Chinese with English abstract） doi: 10.3969/j.issn.1000-3274.2015.04.009

    [15]

    姜国庆,徐士银,金永念,等. 薄覆盖隐伏断层电场响应特征研究——以废黄河断裂为例[J]. 地球物理学进展,2016,31(4):1824 − 1833. [JIANG Guoqing,XU Shiyin,JIN Yongnian,et al. Electric field response characteristics of buried fault with thin overburden layer:The example of Feihuanghe fault[J]. Progress in Geophysics,2016,31(4):1824 − 1833. (in Chinese with English abstract)

    JIANG Guoqing, XU Shiyin, JIN Yongnian, et al. Electric field response characteristics of buried fault with thin overburden layer: The example of Feihuanghe fault[J]. Progress in Geophysics, 2016, 31（4）: 1824 − 1833. （in Chinese with English abstract）

    [16]

    李文鹏,邵新民,祁晓凡,等. 黑河中游盆地南部山区地下水对平原区侧向径流补给量的估算[J]. 水文地质工程地质,2022,49(3):1 − 10. [LI Wenpeng,SHAO Xinmin,QI Xiaofan,et al. Estimation of groundwater lateral flow in the southern mountainous area of the middle Heihe River Basin[J]. Hydrogeology & Engineering Geology,2022,49(3):1 − 10. (in Chinese with English abstract)

    LI Wenpeng, SHAO Xinmin, QI Xiaofan, et al. Estimation of groundwater lateral flow in the southern mountainous area of the middle Heihe River Basin[J]. Hydrogeology & Engineering Geology, 2022, 49（3）: 1 − 10. （in Chinese with English abstract）

    [17]

    林承灏,王雷,黎哲君,等. 电成像与浅层地震联合在浅覆盖区隐伏断层探测中的应用[J]. 地质与勘探,2017,53(1):133 − 140. [LIN Chenghao,WANG Lei,LI Zhejun,et al. Application of collocated resistivity tomography and shallow seismic method to the detection of concealed faults in areas with thin covers[J]. Geology and Exploration,2017,53(1):133 − 140. (in Chinese with English abstract)

    LIN Chenghao, WANG Lei, LI Zhejun, et al. Application of collocated resistivity tomography and shallow seismic method to the detection of concealed faults in areas with thin covers[J]. Geology and Exploration, 2017, 53（1）: 133 − 140. （in Chinese with English abstract）

    [18]

    李富,周洪福,唐文清,等. 物化探方法在隐伏活动断裂探测中综合研究——以安宁河秧财沟断裂为例[J]. 地球物理学进展,2019,34(3):1199 − 1205. [LI Fu,ZHOU Hongfu,TANG Wenqing,et al. Comprehensive study of geophysical and geochemical methods in detecting buried active faults:Taking the Yangcaigou fault in Anning River as an example[J]. Progress in Geophysics,2019,34(3):1199 − 1205. (in Chinese with English abstract)

    LI Fu, ZHOU Hongfu, TANG Wenqing, et al. Comprehensive study of geophysical and geochemical methods in detecting buried active faults: Taking the Yangcaigou fault in Anning River as an example[J]. Progress in Geophysics, 2019, 34（3）: 1199 − 1205. （in Chinese with English abstract）

    [19]

    朱瑞,李朝辉,时向阳,等. 三维高密度电法在隐伏断层探测中的应用[J]. 人民黄河,2019,41(11):106 − 109. [ZHU Rui,LI Zhaohui,SHI Xiangyang,et al. Application of 3D electrical resistivity tomography to buried fault detection[J]. Yellow River,2019,41(11):106 − 109. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-1379.2019.11.022

    ZHU Rui, LI Zhaohui, SHI Xiangyang, et al. Application of 3D electrical resistivity tomography to buried fault detection[J]. Yellow River, 2019, 41（11）: 106 − 109. （in Chinese with English abstract） doi: 10.3969/j.issn.1000-1379.2019.11.022

    [20]

    康继武,严希敏,张庆智. 河南修武西村至焦作龙洞地质构造特征——兼论太行山东南麓压扭性正断层的形成机制[J]. 焦作矿业学院学报,1981(1):45 − 55. [KANG Jiwu,YAN Ximin,ZHANG Qingzhi. Geological structural characteristics from Xiuwuxi Village to Jiaozuo Longdong,Henan Province:Also on the formation mechanism of compression-torsion normal fault at the southern foot of Taihang Mountain[J]. Journal of Henan Polytechnic University (Natural Science),1981(1):45 − 55. (in Chinese)

    KANG Jiwu, YAN Ximin, ZHANG Qingzhi. Geological structural characteristics from Xiuwuxi Village to Jiaozuo Longdong, Henan Province: Also on the formation mechanism of compression-torsion normal fault at the southern foot of Taihang Mountain[J]. Journal of Henan Polytechnic University （Natural Science）, 1981（1）: 45 − 55. （in Chinese）

    [21]

    马凤山,底青云,李克蓬,等. 高密度电阻率法在海底金矿含水构造探测中的应用[J]. 地球物理学报,2016,59(12):4432 − 4438. [MA Fengshan,DI Qingyun,LI Kepeng,et al. Application of high-density resistivity method in detecting water-bearing structures at a seabed gold mine[J]. Chinese Journal of Geophysics,2016,59(12):4432 − 4438. (in Chinese with English abstract)

    MA Fengshan, DI Qingyun, LI Kepeng, et al. Application of high-density resistivity method in detecting water-bearing structures at a seabed gold mine[J]. Chinese Journal of Geophysics, 2016, 59（12）: 4432 − 4438. （in Chinese with English abstract）

    [22]

    李世峰,金瞰昆,周俊杰. 资源与工程地球物理勘探[M]. 北京:化学工业出版社,2008. [LI Shifeng,JIN Kankun,ZHOU Junjie. Geophysical exploration of resources and engineering[M]. Beijing:Chemical Industry Press,2008. (in Chinese)

    LI Shifeng, JIN Kankun, ZHOU Junjie. Geophysical exploration of resources and engineering[M]. Beijing: Chemical Industry Press, 2008. （in Chinese）

    [23]

    单娜琳,程志平,刘云祯. 工程地震勘探[M]. 北京:冶金工业出版社,2006. [SHAN Nalin,CHENG Zhiping,LIU Yunzhen. Engineering seismic exploration[M]. Beijing:Metallurgical Industry Press,2006. (in Chinese)

    SHAN Nalin, CHENG Zhiping, LIU Yunzhen. Engineering seismic exploration[M]. Beijing: Metallurgical Industry Press, 2006. （in Chinese）

    [24]

    邓起东,徐锡伟,张先康,等. 城市活动断裂探测的方法和技术[J]. 地学前缘,2003,10(1):93 − 104. [DENG Qidong,XU Xiwei,ZHANG Xiankang,et al. Methods and techniques for surveying and prospecting active faults in urban areas[J]. Earth Science Frontiers,2003,10(1):93 − 104. (in Chinese with English abstract)

    DENG Qidong, XU Xiwei, ZHANG Xiankang, et al. Methods and techniques for surveying and prospecting active faults in urban areas[J]. Earth Science Frontiers, 2003, 10（1）: 93 − 104. （in Chinese with English abstract）

    [25]

    杨歧焱,彭远黔,尼玛,等. 日喀则城市活断层地球物理勘探方法和成果[J]. 地球物理学报,2015,58(6):2137 − 2147. [YANG Qiyan,PENG Yuanqian,NIMA,et al. Methods and results of geological prospecting along active faults in urban Xigazê[J]. Chinese Journal of Geophysics,2015,58(6):2137 − 2147. (in Chinese with English abstract)

    YANG Qiyan, PENG Yuanqian, NIMA, et al. Methods and results of geological prospecting along active faults in urban Xigazê[J]. Chinese Journal of Geophysics, 2015, 58（6）: 2137 − 2147. （in Chinese with English abstract）

    [26]

    王立会,梁久亮,彭刘亚. 初至波层析成像技术在隐伏断裂探测中的应用[J]. CT理论与应用研究,2015,24(1):29 − 36. [WANG Lihui,LIANG Jiuliang,PENG Liuya. Application of first break tomography technology in detecting hidden fault[J]. Computerized Tomography Theory and Applications,2015,24(1):29 − 36. (in Chinese with English abstract) doi: 10.15953/j.1004-4140.2015.24.01.04

    WANG Lihui, LIANG Jiuliang, PENG Liuya. Application of first break tomography technology in detecting hidden fault[J]. Computerized Tomography Theory and Applications, 2015, 24（1）: 29 − 36. （in Chinese with English abstract） doi: 10.15953/j.1004-4140.2015.24.01.04

    [27]

    刘江平,王莹莹,刘震,等. 近地表反射和折射法的进展及应用[J]. 地球物理学报,2015,58(9):3286 − 3305. [LIU Jiangping,WANG Yingying,LIU Zhen,et al. Progress and application of near-surface reflection and refraction method[J]. Chinese Journal of Geophysics,2015,58(9):3286 − 3305. (in Chinese with English abstract)

    LIU Jiangping, WANG Yingying, LIU Zhen, et al. Progress and application of near-surface reflection and refraction method[J]. Chinese Journal of Geophysics, 2015, 58（9）: 3286 − 3305. （in Chinese with English abstract）

    [28]

    李满树,方伍宝,周腾,等. 初至波走时信息在复杂地区近地表速度反演中的应用[J]. 石油物探,2004,43(1):72 − 75. [LI Manshu,FANG Wubao,ZHOU Teng,et al. Inversion of near-surface velocity through first-arrival traveltime in complex region[J]. Geophysical Prospecting for Petrole,2004,43(1):72 − 75. (in Chinese with English abstract)

    LI Manshu, FANG Wubao, ZHOU Teng, et al. Inversion of near-surface velocity through first-arrival traveltime in complex region[J]. Geophysical Prospecting for Petrole, 2004, 43（1）: 72 − 75. （in Chinese with English abstract）

    [29]

    陈爱萍,梁波,邹文,等. 初至波地震层析技术及其在四川复杂地区的应用[J]. 世界地质,2006,25(4):440 − 444. [CHEN Aiping,LIANG Bo,ZOU Wen,et al. First-arrival seismic tomography and its application in complex area of Sichuan[J]. Global Geology,2006,25(4):440 − 444. (in Chinese with English abstract) doi: 10.3969/j.issn.1004-5589.2006.04.020

    CHEN Aiping, LIANG Bo, ZOU Wen, et al. First-arrival seismic tomography and its application in complex area of Sichuan[J]. Global Geology, 2006, 25（4）: 440 − 444. （in Chinese with English abstract） doi: 10.3969/j.issn.1004-5589.2006.04.020

    [30]

    RAYLEIGH L. On waves propagated along the plane surface of an elastic solid[J]. Proceedings of the London Mathematical Society,1885(1):4 − 11.

    [31]

    张维,何正勤,胡刚,等. 用面波联合勘探技术探测浅部速度结构[J]. 地球物理学进展,2013,28(4):2199 − 2206. [ZHANG Wei,HE Zhengqin,HU Gang,et al. Detection of the shallow velocity structure with surface wave prospection method[J]. Progress in Geophysics,2013,28(4):2199 − 2206. (in Chinese with English abstract)

    ZHANG Wei, HE Zhengqin, HU Gang, et al. Detection of the shallow velocity structure with surface wave prospection method[J]. Progress in Geophysics, 2013, 28（4）: 2199 − 2206. （in Chinese with English abstract）

    [32]

    安好收,罗传根. 浅层纵横波联合勘探在活动断层探测中的应用[J]. 物探与化探,2019,43(3):543 − 550. [AN Haoshou,LUO Chuangen. The application of combined exploration of shallow P-wave and S-wave to active fault detection[J]. Geophysical and Geochemical Exploration,2019,43(3):543 − 550. (in Chinese with English abstract)

    AN Haoshou, LUO Chuangen. The application of combined exploration of shallow P-wave and S-wave to active fault detection[J]. Geophysical and Geochemical Exploration, 2019, 43（3）: 543 − 550. （in Chinese with English abstract）
