Locating critical sliding surface of slopes by estimation of distribution algorithm
-
摘要:
在求解边坡临界滑动面问题的优化算法中，大多都存在结构复杂、参数取值困难或寻优效果差的缺点。为此，将基于高斯分布模型的分布估计算法与基于简化Bishop法的滑面安全系数计算模型相结合，建立具有简单生物协同和竞争思想的临界滑动面搜索新方法；然后，针对3自由度问题，设计了一种局部搜索方法，以弥补分布估计算法局部搜索性能差的劣势。将标准方法和改进方法分别应用于边坡断面复杂度依次递增的3道算例中，完成对标准方法正交试验结果的极差分析和多因素方差分析，并实现标准算法与改进算法计算结果的对比分析。结果表明：（1）标准分布估计算法可以计算出边坡的临界滑动面；（2）当算例简单时，各控制因素都不会对计算结果产生显著性差异；当算例复杂时，只有种群规模呈现出显著性；（3）改进算法比标准算法的计算结果更佳、搜索速度更快，且有效降低了种群规模大小对计算结果的影响。探索分布估计算法在边坡临界滑动面搜索问题中的应用，为解决该类问题开辟出了一条新的研究途径。初步校验表明，该模型鲁棒性更好，具有广阔的应用前景。
Abstract:Most of the optimization algorithms to solve the slope critical sliding surface have the disadvantages of complex structure, difficult to determine the parameter value, and poor optimization effect. This study introduced the estimation of the distribution algorithm based on the Gaussian distribution model, and combined with the sliding surface calculation and analysis model using the simplified Bishop method, to establish a new critical sliding surface search method with simple biological collaboration and competition ideas; secondly, a local search method for the 3-degrees of freedom was designed to compensate for the poor local search performance of the estimation of distribution algorithm. The standard and improvement methods were applied to the three calculation examples of increasing slope section complexity, respectively. The orthogonal experimental results from the standard method were validated by range analysis and multivariate analysis of variance, and the comparative analysis of the calculation of the standard algorithm and the improved algorithm was conducted. The results show that the standard estimation of distribution algorithm can be used to calculate the critical sliding surface of slopes. When the calculated case is simple, the control factors have limited influence on the calculated results; when it is complex, the population size has a significant influence. Compared to the standard algorithm, the improvement algorithm has better calculation and faster speed, and can effectively reduce the impact of the population size on the calculation. The preliminary verification shows that the model is more robust and has a broad application prospect. This study provides a new insight to explore the application of the distribution estimation algorithm in the slope critical sliding surface.
-
-
表 1 正交试验结果
Table 1. Orthogonal experimental results
试验号 控制因子 安全系数 n m/n α β 算例一 算例二 算例三 1 60 1/2 0.6 0.1 0.985 3 1.395 7 1.755 6 2 60 1/3 0.7 0.2 0.985 3 1.395 5 1.756 6 3 60 1/4 0.8 0.3 0.985 5 1.395 5 1.757 2 4 60 1/5 0.9 0.4 0.985 3 1.396 0 1.758 9 5 120 1/2 0.7 0.3 0.985 4 1.395 9 1.757 2 6 120 1/3 0.6 0.4 0.985 5 1.395 6 1.756 6 7 120 1/4 0.9 0.1 0.985 3 1.395 5 1.755 6 8 120 1/5 0.8 0.2 0.985 5 1.395 7 1.756 4 9 240 1/2 0.8 0.4 0.985 3 1.395 6 1.756 8 10 240 1/3 0.9 0.3 0.985 4 1.395 7 1.756 1 11 240 1/4 0.6 0.2 0.985 3 1.395 7 1.755 9 12 240 1/5 0.7 0.1 0.985 3 1.395 5 1.755 8 13 480 1/2 0.9 0.2 0.985 3 1.395 3 1.756 1 14 480 1/3 0.8 0.1 0.985 3 1.395 4 1.755 1 15 480 1/4 0.7 0.4 0.985 3 1.395 6 1.755 9 16 480 1/5 0.6 0.3 0.985 3 1.395 5 1.756 2
下载: 导出CSV
表 2 各算例临界滑面统计
Table 2. Critical slip surfaces for each calculated case
算例 分类 FS Xs/m Xe/m Yo/m 算例一 maxFS 0.985 5 −0.000 4 21.314 4 28.119 2 minFS 0.985 3 0.000 3 21.265 4 28.506 8 均值 0.985 4 0.001 0 21.298 2 28.585 5 标准差 8.165 0e-05 0.007 5 0.031 0 0.269 1 算例二 maxFS 1.396 0 −0.025 2 20.961 3 17.855 1 minFS 1.395 3 −0.002 7 21.037 3 17.655 7 均值 1.395 6 −0.036 0 21.040 7 17.718 0 标准差 1.769 0e-04 0.022 3 0.048 8 0.145 5 算例三 maxFS 1.758 9 −2.305 7 20.740 1 12.127 4 minFS 1.755 1 −1.948 0 20.273 1 11.805 2 均值 1.756 4 −2.108 2 20.418 2 11.847 2 标准差 0.000 8 0.281 3 0.242 5 0.371 4
下载: 导出CSV
表 3 多因素方差分析结果
Table 3. Results of multivariate analysis of variance
算例 因子 平方和 df 均方 F p 显著性排序 算例一 种群规模 3.50×10−8 3 1.17×10−8 1.400 0 0.394 4 1 精英比例 5.00×10−9 3 1.70×10−9 0.200 0 0.890 4 4 学习因子 1.50×10−8 3 5.00×10−9 0.600 0 0.657 5 3 变异因子 2.00×10−8 3 6.70×10−9 0.800 0 0.570 6 2 残差 2.50×10−8 3 8.30×10−9 算例二 种群规模 1.37×10−7 3 4.56×10−8 0.695 2 0.613 8 1 精英比例 3.69×10−8 3 1.23×10−8 0.187 3 0.898 8 3 学习因子 1.69×10−8 3 5.60×10−9 0.085 7 0.963 2 4 变异因子 8.19×10−8 3 2.73×10−8 0.415 9 0.755 0 2 残差 1.97×10−7 3 6.56×10−8 算例三 种群规模 1.06×10−5 3 3.53×10−6 8.572 3 0.037 9 1 精英比例 1.33×10−6 3 4.42×10−7 1.072 9 0.477 6 3 学习因子 7.20×10−7 3 2.40×10−7 0.583 0 0.665 7 4 变异因子 5.14×10−6 3 1.71×10−6 4.158 0 0.136 1 2 残差 1.24×10−6 3 4.12×10−7
下载: 导出CSV
表 4 临界滑面的统计表
Table 4. Statistical values of the critical slip surface
计算方法 n Xs/m Xe/m Yo/m FS 标准分布
估计算法9 −2.614 1 20.169 8 12.037 5 1.759 9 18 −2.541 3 20.657 4 12.461 4 1.759 7 36 −2.133 8 20.614 9 12.001 3 1.756 6 72 −2.162 4 20.450 5 11.863 8 1.755 7 改进分布
估计算法9 −2.198 2 20.406 6 11.805 4 1.754 7 18 −2.243 2 20.368 3 11.8322 1.754 8 36 −2.138 1 20.510 6 11.7997 1.755 0 72 −2.264 2 20.289 6 11.804 1 1.754 6
下载: 导出CSV
-
[1] 陈建功,李会,贺自勇. 基于变分法的均质土坡稳定性分析[J]. 岩土力学,2019,40(8):2931 − 2937. [CHEN Jiangong,LI Hui,HE Ziyong. Homogeneous soil slope stability analysis based on variational method[J]. Rock and Soil Mechanics,2019,40(8):2931 − 2937. (in Chinese with English abstract)]
CHEN Jiangong, LI Hui, HE Ziyong. Homogeneous soil slope stability analysis based on variational method[J]. Rock and Soil Mechanics, 2019, 40（8）: 2931 − 2937. （in Chinese with English abstract）
[2] 唐超宏,莫海鸿,刘少跃. 模式搜索法在边坡稳定性分析中的应用[J]. 华南理工大学学报(自然科学版),2000,28(2):42 − 46. [TANG Chaohong,MO Haihong,LIU Shaoyue. The application of the pattern search method for slope stability analysis[J]. Journal of South China University of Technology (Natural Science),2000,28(2):42 − 46. (in Chinese with English abstract)] doi: 10.3321/j.issn:1000-565X.2000.02.008
TANG Chaohong, MO Haihong, LIU Shaoyue. The application of the pattern search method for slope stability analysis[J]. Journal of South China University of Technology （Natural Science）, 2000, 28（2）: 42 − 46. （in Chinese with English abstract） doi: 10.3321/j.issn:1000-565X.2000.02.008
[3] 黄玮,徐卫亚,陈鸿杰,等. 基于改进动态规划算法的堆积体边坡稳定性分析[J]. 地下空间与工程学报,2014,10(3):727 − 732. [HUANG Wei,XU Weiya,CHEN Hongjie,et al. Analysis on accumulation slope stability using improved dynamic programming algorithm[J]. Chinese Journal of Underground Space and Engineering,2014,10(3):727 − 732. (in Chinese with English abstract)]
HUANG Wei, XU Weiya, CHEN Hongjie, et al. Analysis on accumulation slope stability using improved dynamic programming algorithm[J]. Chinese Journal of Underground Space and Engineering, 2014, 10（3）: 727 − 732. （in Chinese with English abstract）
[4] 陈云敏,李育超,凌道盛. 蒙特卡洛法与有限元结合搜索边坡临界滑动面[J]. 岩土力学,2004,25(增刊2):75 − 80. [CHEN Yunmin,LI Yuchao,LING Daosheng. Locating sritical slip surfaces by a method combining Monte Carlo technique and FEM[J]. Rock and Soil Mechanics,2004,25(Sup 2):75 − 80. (in Chinese with Engish abstract)]
CHEN Yunmin, LI Yuchao, LING Daosheng. Locating sritical slip surfaces by a method combining Monte Carlo technique and FEM[J]. Rock and Soil Mechanics, 2004, 25（Sup 2）: 75 − 80. （in Chinese with Engish abstract）
[5] 邹广电. 边坡稳定分析条分法的一个全局优化算法[J]. 岩土工程学报,2002,24(3):309 − 312. [ZOU Guangdian. A global optimization method of the slice method for slope stability analysis[J]. Chinese Journal of Geotechnical Engineering,2002,24(3):309 − 312. (in Chinese with English abstract)] doi: 10.3321/j.issn:1000-4548.2002.03.009
ZOU Guangdian. A global optimization method of the slice method for slope stability analysis[J]. Chinese Journal of Geotechnical Engineering, 2002, 24（3）: 309 − 312. （in Chinese with English abstract） doi: 10.3321/j.issn:1000-4548.2002.03.009
[6] 吕文杰,李晓军,朱合华. 基于遗传算法的边坡稳定分析通用算法[J]. 岩土工程学报,2005,27(5):595 − 599. [LYU Wenjie,LI Xiaojun,ZHU Hehua. GA-based generalized slope stability analysis method[J]. Chinese Journal of Geotechnical Engineering,2005,27(5):595 − 599. (in Chinese)]
LYU Wenjie, LI Xiaojun, ZHU Hehua. GA-based generalized slope stability analysis method[J]. Chinese Journal of Geotechnical Engineering, 2005, 27（5）: 595 − 599. （in Chinese）
[7] 覃伟. 双重变异遗传算法及其在临界滑动面搜索中的应用[J]. 水文地质工程地质,2021,48(6):161 − 170. [QIN Wei. Double mutation genetic algorithm and its application to the critical slip surface search[J]. Hydrogeology & Engineering Geology,2021,48(6):161 − 170. (in Chinese with Engish abstract)]
QIN Wei. Double mutation genetic algorithm and its application to the critical slip surface search[J]. Hydrogeology & Engineering Geology, 2021, 48（6）: 161 − 170. （in Chinese with Engish abstract）
[8] 张朝贤,侯明勋,孙红,等. 基于改进蚁群系统算法与矢量和法的边坡临界滑动面搜索[J]. 中国农村水利水电,2021(2):186 − 191. [ZHANG Chaoxian,HOU Mingxun,SUN Hong,et al. Searching the noncircular critical slip surface of slope based on improved ant colony system algorithm and the vector sum analysis method[J]. China Rural Water and Hydropower,2021(2):186 − 191. (in Chinese with English abstract)]
ZHANG Chaoxian, HOU Mingxun, SUN Hong, et al. Searching the noncircular critical slip surface of slope based on improved ant colony system algorithm and the vector sum analysis method[J]. China Rural Water and Hydropower, 2021（2）: 186 − 191. （in Chinese with English abstract）
[9] 孙聪,郑宏,李春光,等. 基于蚁群算法的严格最大剩余推力临界滑动面搜索[J]. 岩土力学,2014,35(10):3021 − 3026. [SUN Cong,ZHENG Hong,LI Chunguang,et al. Critical slip surface search by using rigorous maximum residual thrust method based on ant colony algorithm[J]. Rock and Soil Mechanics,2014,35(10):3021 − 3026. (in Chinese with English abstract)]
SUN Cong, ZHENG Hong, LI Chunguang, et al. Critical slip surface search by using rigorous maximum residual thrust method based on ant colony algorithm[J]. Rock and Soil Mechanics, 2014, 35（10）: 3021 − 3026. （in Chinese with English abstract）
[10] 黄晓锋,石崇,朱珍德,等. 基于粒子群优化算法的边坡临界滑动面搜索方法[J]. 防灾减灾工程学报,2014,34(6):751 − 757. [HUANG Xiaofeng,SHI Chong,ZHU Zhende,et al. Determination method of critical slip surface based on PSO algorithm[J]. Journal of Disaster Prevention and Mitigation Engineering,2014,34(6):751 − 757. (in Chinese with English abstract)]
HUANG Xiaofeng, SHI Chong, ZHU Zhende, et al. Determination method of critical slip surface based on PSO algorithm[J]. Journal of Disaster Prevention and Mitigation Engineering, 2014, 34（6）: 751 − 757. （in Chinese with English abstract）
[11] 杨善统,姜清辉,尹涛,等. 边坡临界滑面搜索的改进粒子群优化算法[J]. 岩土工程学报,2015,37(8):1411 − 1417. [YANG Shantong,JIANG Qinghui,YIN Tao,et al. Search of critical slip surface of slopes using improved particle swarm optimization method[J]. Chinese Journal of Geotechnical Engineering,2015,37(8):1411 − 1417. (in Chinese with English abstract)] doi: 10.11779/CJGE201508008
YANG Shantong, JIANG Qinghui, YIN Tao, et al. Search of critical slip surface of slopes using improved particle swarm optimization method[J]. Chinese Journal of Geotechnical Engineering, 2015, 37（8）: 1411 − 1417. （in Chinese with English abstract） doi: 10.11779/CJGE201508008
[12] 张明瑞,陈征宙,刘裕华,等. 引入退火机制的智能单粒子算法在复杂边坡最危险滑动面搜索中的应用[J]. 工程地质学报,2011,19(2):181 − 186. [ZHANG Mingrui,CHEN Zhengzhou,LIU Yuhua,et al. Application of intelligent single particle optimizer with simulated annealing mechanism to searching for critical slip surface of complex slope[J]. Journal of Engineering Geology,2011,19(2):181 − 186. (in Chinese with English abstract)] doi: 10.3969/j.issn.1004-9665.2011.02.006
ZHANG Mingrui, CHEN Zhengzhou, LIU Yuhua, et al. Application of intelligent single particle optimizer with simulated annealing mechanism to searching for critical slip surface of complex slope[J]. Journal of Engineering Geology, 2011, 19（2）: 181 − 186. （in Chinese with English abstract） doi: 10.3969/j.issn.1004-9665.2011.02.006
[13] 刘国东,戴振学,邢冰,等. 仿生算法在地下水模型反演中的应用现状与展望[J]. 水文地质工程地质,2016,43(1):41 − 49. [LIU Guodong,DAI Zhenxue,XING Bing,et al. Application of bio-inspired algorithms for inverse problems of groundwater models:Status and prospects[J]. Hydrogeology & Engineering Geology,2016,43(1):41 − 49. (in Chinese with English abstract)]
LIU Guodong, DAI Zhenxue, XING Bing, et al. Application of bio-inspired algorithms for inverse problems of groundwater models: Status and prospects[J]. Hydrogeology & Engineering Geology, 2016, 43（1）: 41 − 49. （in Chinese with English abstract）
[14] 宋子岭,杨添,赵立春. 含多层软弱夹层的顺向岩质边坡稳定性评价方法对比分析[J]. 中国地质灾害与防治学报,2016,27(2):20 − 25. [SONG Ziling,YANG Tian,ZHAO Lichun. Applicatyion of combination algorithm in stability analysis of rock slope with contains multilayer weak bedrock layers[J]. The Chinese Journal of Geological Hazard and Control,2016,27(2):20 − 25. (in Chinese with English abstract)]
SONG Ziling, YANG Tian, ZHAO Lichun. Applicatyion of combination algorithm in stability analysis of rock slope with contains multilayer weak bedrock layers[J]. The Chinese Journal of Geological Hazard and Control, 2016, 27（2）: 20 − 25. （in Chinese with English abstract）
[15] 朱大勇,邓建辉,台佳佳. 简化Bishop法严格性的论证[J]. 岩石力学与工程学报,2007,26(3):455 − 458. [ZHU Dayong,DENG Jianhui,TAI Jiajia. Theoretical verification of rigorous nature of simplified bishop method[J]. Chinese Journal of Rock Mechanics and Engineering,2007,26(3):455 − 458. (in Chinese with English abstract)] doi: 10.3321/j.issn:1000-6915.2007.03.002
ZHU Dayong, DENG Jianhui, TAI Jiajia. Theoretical verification of rigorous nature of simplified bishop method[J]. Chinese Journal of Rock Mechanics and Engineering, 2007, 26（3）: 455 − 458. （in Chinese with English abstract） doi: 10.3321/j.issn:1000-6915.2007.03.002
[16] 王圣尧,王凌,方晨,等. 分布估计算法研究进展[J]. 控制与决策,2012,27(7):961 − 966. [WANG Shengyao,WANG Ling,FANG Chen,et al. Advances in estimation of distribution algorithms[J]. Control and Decision,2012,27(7):961 − 966. (in Chinese with English abstract)]
WANG Shengyao, WANG Ling, FANG Chen, et al. Advances in estimation of distribution algorithms[J]. Control and Decision, 2012, 27（7）: 961 − 966. （in Chinese with English abstract）
[17] 杨启文,余诗琦,张美琳,等. 多种群伪正态分布估计算法[J]. 模式识别与人工智能,2021,34(7):619 − 630. [YANG Qiwen,YU Shiqi,ZHANG Meilin,et al. Multiple populations based estimation of pseudo-normal distribution algorithm[J]. Pattern Recognition and Artificial Intelligence,2021,34(7):619 − 630. (in Chinese with English abstract)]
YANG Qiwen, YU Shiqi, ZHANG Meilin, et al. Multiple populations based estimation of pseudo-normal distribution algorithm[J]. Pattern Recognition and Artificial Intelligence, 2021, 34（7）: 619 − 630. （in Chinese with English abstract）
[18] 王旭,刘东升,宋强辉,等. 基于极限平衡法的边坡稳定性可靠度分析[J]. 地下空间与工程学报,2016,12(3):839 − 844. [WANG Xu,LIU Dongsheng,SONG Qianghui,et al. Slope stability reliability analysis based on limit equilibrium methods[J]. Chinese Journal of Underground Space and Engineering,2016,12(3):839 − 844. (in Chinese with English abstract)]
WANG Xu, LIU Dongsheng, SONG Qianghui, et al. Slope stability reliability analysis based on limit equilibrium methods[J]. Chinese Journal of Underground Space and Engineering, 2016, 12（3）: 839 − 844. （in Chinese with English abstract）
[19] 陈祖煜. 土质边坡稳定分析——原理·方法·程序[M]. 北京:中国水利水电出版社,2003. [CHEN Zuyu. Soil slope stability analysis:theory,methods and programs[M]. Beijing:China Water & Power Press,2003. (in Chinese)]
CHEN Zuyu. Soil slope stability analysis: theory, methods and programs[M]. Beijing: China Water & Power Press, 2003. （in Chinese）
-
