An attempt of risk assessment of geological hazards in different scales: A case study in Wubao County of Shaanxi Province
-
摘要:
吴堡县地处陕北黄土高原东北部,区内地质灾害发育,严重威胁当地居民生命及财产安全。在充分分析吴堡县地质灾害调查数据的基础上,针对全县域尺度选取坡度、坡向、地表曲率等评价指标,采用信息量模型基于GIS平台按25 m×25 m栅格单元进行风险评价。评价结果划分为:极高风险区、高风险区、中风险区、低风险区,分别占全区面积的0.63%、12.58%、24.40%、62.39%。针对重点区尺度,选取坡度、坡高等因子,采用层次分析模型基于GIS平台按水文法划分的斜坡单元开展风险评价,其中极高风险斜坡19个、高风险斜坡69个、中风险斜坡145个、低风险斜坡359个。选取两种尺度下同一区域(A区),对风险评价结果进行差异性分析。表明:在不同的尺度下,同一地理位置,风险高低的评价结果可能不一致。在全县域尺度下宜采用各类具备预测功能的数理统计模型,但是在更小的重点区尺度下,由于用来训练的样本数量不够,不宜采用数理统计模型。相应的,县域尺度下可采用基于GIS工具划分的栅格单元作为评价单元;重点区尺度下可采用实际的斜坡体作为评价单元。
Abstract:Wubao County is located in the northeastern part of the loess plateau in northern Shaanxi, geological disasters are developing in the area, which seriously threatens the life and property safety of local residents. On the basis of fully analyzing the geological disaster survey data in Wubao County, the evaluation indicators such as slope, slope aspect, and surface curvature were selected for the whole county scale, and the risk assessment was carried out based on the 25 m×25 m grid unit based on the information model based on the GIS platform. The evaluation results are divided into: extremely high risk area, high risk area, medium risk area and low risk area, accounting for 0.63%, 12.58%, 24.40% and 62.39% of the total area respectively. According to the scale of key areas, the factors of slope and slope height are selected, and the analytic hierarchy process model is used to carry out risk assessment of slope units divided by hydrological method based on GIS platform, including 19 extremely high-risk slopes, 69 high-risk slopes, 145 medium-risk slopes, 359 low-risk slopes. The same area (area A) under the two scales was selected to conduct variance analysis on the risk assessment results. It shows that at different scales and the same geographical location, the evaluation results of risk level may be inconsistent. At the county-wide scale, various mathematical statistical models with predictive functions should be used, but at the smaller key area scale, due to the insufficient number of samples used for training, it is not appropriate to use mathematical statistical models. Correspondingly, the grid unit based on GIS tools can be used as the evaluation unit at the county scale; the actual slope body can be used as the evaluation unit at the key area scale.
-
表 1 各因子图层分类情况及其对应的信息量值
Table 1. Classification of each factor layer and its corresponding information value
指标 类别 信息量值 指标 类别 信息量值 坡度/(°) 0~15 −0.9 270 地貌 河谷地貌 0.0 035 15~25 −0.2 098 低山丘陵地貌 0.0 277 25~35 1.2 051 黄土残塬地貌 −1.6 479 35~45 1.7 910 黄土梁峁地貌 1.6 852 >45 2.5 331 构造影响距/m 0~500 0.7 346 坡向 平面 1.3 221 500~1 000 0.5 067 N 0.2 601 1000~1 500 0.2 643 NE −0.0 998 >1 500 −0.1 185 E −0.4 112 水系影响距/m 0~50 2.8 334 SE 0.1 231 50~100 3.1 000 S −0.1 942 100~200 2.1 943 SW −0.3 190 >200 −0.8 067 NW 0.2 133 道路影响距/m 0~50 2.1 502 W 0.3 204 50~100 1.9 809 地表曲率 ≤−0.5 0.1 242 100~200 1.0 235 −0.5~0.5 0.0 054 >200 −1.0 120 ≥0.5 −0.1 718 表 2 A-B 判别矩阵
Table 2. A-B discriminant matrix
A B1 B2 B3 B4 B5 B6 Wi B1 1 2 5 3 7 3 0.37 B2 1/2 1 3 3 5 3 0.26 B3 1/5 1/3 1 1/3 3 1/3 0.07 B4 1/3 1/3 3 1 3 1/2 0.12 B5 1/7 1/5 1/3 1/3 1 1/3 0.04 B6 1/3 1/3 3 2 3 1 0.14 表 3 地质灾害危险程度量化评分表
Table 3. Quantitative scoring table of geological disaster risk degree
指标 权重 类别 赋值 指标 权重 类别 赋值 坡度/(°) 0.37 0~15 0.2 工程地质
岩组0.12 松散岩组 0.8 15~25 0.4 软硬相间岩组 0.6 25~35 0.6 较硬岩组 0.4 35~45 0.8 坚硬岩组 0.2 坡高/m 0.26 <20 0.3 构造影响
距/m0.04 0~50 0.8 20~30 0.4 50~100 0.6 30~40 0.5 100~200 0.4 40~50 0.6 >200 0.2 50~60 0.7 道路影响
距/m0.14 0~50 0.8 >60 0.8 50~100 0.6 地表曲率 0.07 ≤−0.5 0.3 100~200 0.4 −0.5~0.5 0.5 >200 0.2 ≥0.5 0.7 -
[1] 滕宏泉, 范立民, 向茂西, 等. 陕北黄土粱峁沟壑区地质灾害与降雨关系浅析: 以陕北延安地区2013年强降雨引发地质灾害为例[J]. 地下水,2016,38(1):155 − 157. [TENG Hongquan, FAN Limin, XIANG Maoxi, et al. Analysis of the relationship between geological disasters and rainfall in the Liangmao gully area of northern Shaanxi—Taking geological disasters caused by heavy rainfall in Yan'an area of northern Shaanxi as an example[J]. Ground Water,2016,38(1):155 − 157. (in Chinese with English abstract) doi: 10.3969/j.issn.1004-1184.2016.01.056
[2] 陈慧敏, 杨尽, 向明顺, 等. 基于地理信息系统和加权信息量的茂县地质灾害易发性评价[J]. 科学技术与工程,2021,21(29):12490 − 12499. [CHEN Huimin, YANG Jin, XIANG Mingshun, et al. Geographic information system and weighted information value assessments of geologic hazards in Maoxian County, Sichuan[J]. Science Technology and Engineering,2021,21(29):12490 − 12499. (in Chinese with English abstract) doi: 10.3969/j.issn.1671-1815.2021.29.018
[3] UNDRO. Natural disasters and vulnerability analysis [R]. Geneva: Office of the United Nations Disaster Relief Co- ordinator, 1982.
[4] VARNES D J. Landslide hazard zonation: A review of principles and practice; UNESCO[R]. Paris: United Nations International , 1984.
[5] 唐亚明, 张茂省, 李政国, 等. 国内外地质灾害风险管理对比及评述[J]. 西北地质,2015,48(2):238 − 246. [TANG Yaming, ZHANG Maosheng, LI Zhengguo, et al. Review and comparison onInland and overseas geo-hazards risk management[J]. Northwestern Geology,2015,48(2):238 − 246. (in Chinese with English abstract) doi: 10.3969/j.issn.1009-6248.2015.02.025
[6] 吴树仁, 石菊松, 王涛. 滑坡风险评估理论与技术[M]. 北京: 科学出版社, 2012
WU Shuren, SHI Jusong, WANG Tao. Theory and technique of landslide risk assessment[M]. Beijing: Science Press, 2012. (in Chinese)
[7] 唐亚明, 冯卫, 毕银强, 等. 基于风险评价的黄土滑坡分类及特征[J]. 地质通报,2015,34(11):2092 − 2099. [TANG Yaming, FENG Wei, BI Yinqiang, et al. The classification and features of loess landslide based on risk assessment[J]. Geological Bulletin of China,2015,34(11):2092 − 2099. (in Chinese with English abstract) doi: 10.3969/j.issn.1671-2552.2015.11.015
[8] 孙冉, 王成都, 夏哲兵, 等. 基于AHP-信息量法的费县地质灾害风险评价[J]. 环境科学与技术,2015,38(增刊 1):430 − 435. [SUN Ran, WANG Chengdu, XIA Zhebing, et al. Geological disasters risk assessment in Fee County based on AHP-information method[J]. Environmental Science & Technology,2015,38(Sup 1):430 − 435. (in Chinese with English abstract)
[9] 李春燕, 孟晖, 张若琳, 等. 中国县域单元地质灾害风险评估[J]. 水文地质工程地质,2017,44(2):160 − 166. [LI Chunyan, MENG Hui, ZHANG Ruolin, et al. Risk assessment of geo-hazard of China in county unit[J]. Hydrogeology & Engineering Geology,2017,44(2):160 − 166. (in Chinese with English abstract)
[10] 王嘉君, 何亚伯, 杨琳, 等. 基于GIS的山区村镇多灾种耦合风险评估[J]. 中国地质灾害与防治学报,2018,29(1):102 − 112. [WANG Jiajun, HE Yabo, YANG Lin, et al. Comprehensive multi-hazard risk assessment of villages and towns in mountain areas based on GIS[J]. The Chinese Journal of Geological Hazard and Control,2018,29(1):102 − 112. (in Chinese with English abstract)
[11] 李泽威, 杨登银, 王明华, 等. 基于GIS的恩施市龙凤镇地质灾害风险评价[J]. 资源环境与工程,2018,32(1):113 − 118. [LI Zewei, YANG Dengyin, WANG Minghua, et al. Risk assessment of geological hazards based on GIS in the Longfeng Town of the Enshi City[J]. Resources Environment & Engineering,2018,32(1):113 − 118. (in Chinese with English abstract)
[12] TANG Y M, FENG F, GUO Z Z, et al. Integrating principal component analysis with statistically-based models for analysis of causal factors and landslide susceptibility mapping: A comparative study from the loess plateau area in Shanxi (China)[J]. Journal of Cleaner Production,2020,277:124159. doi: 10.1016/j.jclepro.2020.124159
[13] 杨柳, 牟鑫亮, 李晨, 等. 延安市宝塔区地质灾害风险评价[J]. 山地学报,2020,38(5):679 − 690. [YANG Liu, MU Xinliang, LI Chen, et al. Risk assessment of geological hazards in Baota District, Yan'an City, Shaanxi, China[J]. Mountain Research,2020,38(5):679 − 690. (in Chinese with English abstract)
[14] 邱维蓉, 吴帮玉, 潘学树, 等. 几种聚类优化的机器学习方法在灵台县滑坡易发性评价中的应用[J]. 西北地质,2020,53(1):222 − 233. [QIU Weirong, WU Bangyu, PAN Xueshu, et al. Application of several cluster-optimization-based machine learning methods in evaluation of landslide susceptibility in Lingtai County[J]. Northwestern Geology,2020,53(1):222 − 233. (in Chinese with English abstract)
[15] 李冠宇, 李鹏, 郭敏, 等. 基于聚类分析法的地质灾害风险评价: 以韩城市为例[J]. 科学技术与工程,2021,21(25):10629 − 10638. [LI Guanyu, LI Peng, GUO Min, et al. Application of cluster analysis method in geological hazard risk assessment: A case study of Hancheng City[J]. Science Technology and Engineering,2021,21(25):10629 − 10638. (in Chinese with English abstract) doi: 10.3969/j.issn.1671-1815.2021.25.010
[16] 李阳春, 刘黔云, 李潇, 等. 基于机器学习的滑坡崩塌地质灾害气象风险预警研究[J]. 中国地质灾害与防治学报,2021,32(3):118 − 123. [LI Yangchun, LIU Qianyun, LI Xiao, et al. Exploring early warning and forecasting of meteorological risk of landslide and rockfall induced by meteorological factors by the approach of machine learning[J]. The Chinese Journal of Geological Hazard and Control,2021,32(3):118 − 123. (in Chinese with English abstract)
[17] 刘福臻, 王灵, 肖东升. 机器学习模型在滑坡易发性评价中的应用[J]. 中国地质灾害与防治学报,2021,32(6):98 − 106. [LIU Fuzhen, WANG Ling, XIAO Dongsheng. Application of machine learning model in landslide susceptibility evaluation[J]. The Chinese Journal of Geological Hazard and Control,2021,32(6):98 − 106. (in Chinese with English abstract)
[18] 张斌. 大型泥石流的基本特征和防治研究: 以吴堡县城北井沟特大型泥石流为例[D]. 西安: 长安大学, 2018
ZHANG Bin. Research on the basic characteristics and control of large debris flow—Example for the extra large debris flow in Jinggou of northern Wubao Country[D]. Xi’an: Changan University, 2018. (in Chinese with English abstract)
[19] 薛强, 张茂省, 李林. 基于斜坡单元与信息量法结合的宝塔区黄土滑坡易发性评价[J]. 地质通报,2015,34(11):2108 − 2115. [XUE Qiang, ZHANG Maosheng, LI Lin. Loess landslide susceptibility evaluation based on slope unit and information value method in Baota District, Yan’an[J]. Geological Bulletin of China,2015,34(11):2108 − 2115. (in Chinese with English abstract) doi: 10.3969/j.issn.1671-2552.2015.11.017
[20] 冯卫, 唐亚明, 马红娜, 等. 基于层次分析法的咸阳市多灾种自然灾害综合风险评价[J]. 西北地质,2021,54(2):282 − 288. [FENG Wei, TANG Yaming, MA Hongna, et al. Comprehensive risk assessment of multi-hazard natural disasters in Xianyang City based on AHP[J]. Northwestern Geology,2021,54(2):282 − 288. (in Chinese with English abstract)
[21] 申怀飞, 董雨, 杨梅, 等. 基于AHP与信息量法的甘肃省滑坡易发性评估[J]. 水土保持研究,2021,28(6):412 − 419. [SHEN Huaifei, DONG Yu, YANG Mei, et al. Assessment on landslide susceptibility in Gansu Province based on AHP and information quantity method[J]. Research of Soil and Water Conservation,2021,28(6):412 − 419. (in Chinese with English abstract)
[22] JIA N, MITANI Y, XIE M, et al. Shallow landslide hazard assessment using a three-dimensional deterministic model in a mountainous area[J]. Computers and Geotechnics,2012,45:1 − 10. doi: 10.1016/j.compgeo.2012.04.007
