摘要:
山区高速铁路受线路平顺性及地形的限制，部分危岩发育地段无法绕避，给工程建设及运营安全提出了严峻挑战。文章在无人机三维倾斜摄影的基础上利用数字地质调绘技术对拟建济南至枣庄铁路杏花峪隧道进口危岩体的发育特征、规模、变形破坏模式进行了准确的判识，通过将3DEC数值模拟与层次分析法结合，获得了崩塌落石的影响范围和危险性分区图，开展了危险性分区评价，提出了防治措施。研究表明：三维倾斜摄影模型识别出的12处危岩带中，只有5号危岩带威胁隧道洞口和桥台安全，并建议采用“被动防护网+明洞”方式进行综合防治。研究成果为危岩落石灾害的危险性分区评价提供参考，为铁路选线及防灾减灾提供依据。
Abstract:Restricted by the surface smoothness and topography, it is impossible for some high-speed railways on mountainous regions to avoid parts of rockfall development sections, posing great safety challenges to construction projects and railway operations. In light of that, this paper laid its focus on the rockfall situated by the entrance of Xinghuayu Tunnel along the proposed Jinan-Zaozhuang Railway project, and leveraged the power of drone-captured 3D aerial photography to perform digital geological survey and mapping so as to accurately identify the development characteristics, scale, as well as modes of deformation and failure of said rockfall. Next, by cross-referencing the results of 3DEC numerical simulation with those from analytic hierarchy process (AHP), color-coded maps highlighting the scope of influence and danger levels of potential rockfalls induced were obtained. Using said maps, zone-by-zone hazard and risk assessment were then performed, based on which corresponding prevention and control measures were put forward. The findings show that among the 12 dangerous rock belts identified from the drone-captured 3D aerial photography model, only Belt No. 5 would threaten the safety of the tunnel entrance and bridge abutments, for which the combination of anti-rockfall passive protective netting and an open-cut tunnel structure was recommended as a comprehensive solution. By virtue of the solution’s effectiveness, this study can offer reliable references for not only zone-by-zone hazard and risk assessment for rockfalls, but also railway route selection and disaster prevention and mitigation.
-
-
表 1 危岩带基本特征
Table 1. Basic characteristics and scale of rockfall
分带编号 危岩体体积/m³ 落石块径/m 相对高度/m 破坏模式 WY-01 12.12 0.2～1.12 44～48 滑移式 WY-03 960 0.4～1.3 0～10 坠落式 WY-04 1.4 0.5 114 滑移式 WY-05 73.2 0.3～1.3 5 坠落式 WY-06 736 0.8～4.3 121～146 倾倒式 WY-07 1 600 0.2～2.2 109～149 倾倒式 WY-08 1 823 0.14～2.12 156～198 倾倒式、滑移式
下载: 导出CSV
表 2 结构面基本特征
Table 2. Basic characteristics of joint surface
结构面编号 产状 延伸长度
/m间距
/m起伏度 张开或
闭合充填情况 1号原生
结构面246°∠78° 3.24 0.86 平直 张开 无充填 2号节理面 66°∠88° 2.66 1.72 波状起伏 张开 无充填 3号节理面 314°∠30° 4.56 1.75 平直 张开 充填 4号节理面 155°∠80° 1.32 0.35 波状起伏 闭合 无充填
下载: 导出CSV
表 3 危岩体稳定性计算结果
Table 3. Stability calculation results of rockfall
工况危岩编号 天然工况 暴雨工况 地震工况 K 稳定性评价 K 稳定性评价 K 稳定性评价 1号危岩体 1.23 基本稳定 1.19 欠稳定 0.99 不稳定 3号危岩体 1.31 基本稳定 1.22 欠稳定 1.06 欠稳定 4号危岩体 1.15 欠稳定 1.14 欠稳定 0.94 不稳定 5号危岩体 1.24 欠稳定 1.08 欠稳定 0.86 不稳定 6号危岩体 1.23 基本稳定 1.02 欠稳定 0.94 不稳定 7号危岩体 1.61 稳定 1.08 欠稳定 0.73 不稳定 8号危岩体 1.07 欠稳定 0.99 不稳定 0.77 不稳定
下载: 导出CSV
表 4 模型计算参数统计表
Table 4. Model calculation parameter
岩土体名称 密度
/（g·cm−3）弹性模量
/MPa剪切模量
/MPa抗拉强度
/MPa内摩擦角
/（°）花岗岩 2.7 58 000 29 000 3.2 65 花岗岩W3
结构面（天然）− − − − 50 花岗岩W3
结构面（暴雨）− − − − 30 花岗岩
碎块石（暴雨）− − − − 20
下载: 导出CSV
表 5 评价指标打分表及权重值
Table 5. Evaluation index score and weight value
评价指标（i） 低危险性0～25（S） 中危险性25～50（S） 高危险性50～75（S） 极高危险性75～100（S） 权重值 危岩稳定性 稳定 基本稳定 欠稳定 不稳定 0.402 落石运动速度/（m·s−1） S<0.5 0.5≤S<5 5≤S<15 15≤S 0.235 落石数量/个 0 0≤N<3 3≤N<5 5≤N 0.146 危岩体体积/m3 V≤10 10<V≤100 100<V≤10 000 10 000<V 0.083 落石块径/m <0.1 0.1≤D<0.5 0.5≤D<1 1≤D 0.083 下垫面特征 松散土质，
植被极茂盛较中等密实的土质，
植被较茂盛较密实坚硬的土质，
有植被坚硬岩质，
植被稀少0.051
下载: 导出CSV
表 6 综合评分值与危险性分区的对应关系
Table 6. The corresponding relationship between comprehensive score value and hazard zone
危险性分区
及综合
评分值F极高危险区
75＜F≤100高危险区
50＜F≤75中危险区
25＜F≤50低危险区
0＜F≤25危岩编号 无 3、5、6、7、8号 1、4号 无
下载: 导出CSV
-
[1] 王栋,张广泽,李新坡,等. 川藏铁路折多山隧道进口岩崩运动特征及防治措施[J]. 科学技术与工程,2017,17(34):118 − 123. [WANG Dong,ZHANG Guangze,LI Xinpo,et al. Movement characteristics and prevention of talus slope in Zheduoshan tunnel of Sichuan-Tibet railway[J]. Science Technology and Engineering,2017,17(34):118 − 123. (in Chinese with English abstract)
WANG Dong, ZHANG Guangze, LI Xinpo, et al. Movement characteristics and prevention of talus slope in Zheduoshan tunnel of Sichuan-Tibet railway[J]. Science Technology and Engineering, 2017, 17（34）: 118-123. （in Chinese with English abstract）][知网中文][知网英文
[2] 王栋,王剑锋,李天斌,等. 西南山区某铁路隧道口高位落石三维运动特征分析[J]. 地质力学学报,2021,27(1):96 − 104. [WANG Dong,WANG Jianfeng,LI Tianbin,et al. Analysis of three-dimensional movement characteristics of rockfall:A case study at a railway tunnel entrance in the southwestern mountainous area,China[J]. Journal of Geomechanics,2021,27(1):96 − 104. (in Chinese with English abstract)
WANG Dong, WANG Jianfeng, LI Tianbin, et al. Analysis of three-dimensional movement characteristics of rockfall: a case study at a railway tunnel entrance in the southwestern mountainous area, China[J]. Journal of Geomechanics, 2021, 27（1）: 96-104. （in Chinese with English abstract）][知网中文][知网英文
[3] 王玉锁,杨国柱. 隧道洞口段危岩落石风险评估[J]. 现代隧道技术,2010,47(6):33 − 39. [WANG Yusuo,YANG Guozhu. Rockfall risk assessment for a tunnel portal section[J]. Modern Tunnelling Technology,2010,47(6):33 − 39. (in Chinese with English abstract)
WANG Yusuo, YANG Guozhu. Rockfall risk assessment for a tunnel portal section[J]. Modern Tunnelling Technology, 2010, 47（6）: 33-39. （in Chinese with English abstract）][知网中文][知网英文
[4] 黄海宁,巨能攀,黄健,等. 郑万高铁宜万段边坡危岩崩落破坏特征[J]. 水文地质工程地质,2020,47(3):164 − 172. [HUANG Haining,JU Nengpan,HUANG Jian,et al. Caving failure characteristic of slope rockfall on Yiwan section of the Zhengzhou−Wanzhou high-speed railway[J]. Hydrogeology & Engineering Geology,2020,47(3):164 − 172. (in Chinese with English abstract)
HUANG Haining, JU Nengpan, HUANG Jian, et al. Caving failure characteristic of slope rockfall on Yiwan section of the Zhengzhou—Wanzhou high-speed railway[J]. Hydrogeology & Engineering Geology, 2020, 47（3）: 164-172. （in Chinese with English abstract）][知网中文][知网英文
[5] HE S M,YAN S X,DENG Y,et al. Impact protection of bridge piers against rockfall[J]. Bulletin of Engineering Geology and the Environment,2019,78(4):2671 − 2680. doi: 10.1007/s10064-018-1250-5
[6] 董秀军,裴向军,黄润秋. 贵州凯里龙场镇山体崩塌基本特征与成因分析[J]. 中国地质灾害与防治学报,2015,26(3):3 − 9. [DONG Xiujun,PEI Xiangjun,HUANG Runqiu. The Longchangzhen collapse in Kaili,Guizhou:Characteristics and failure causes[J]. The Chinese Journal of Geological Hazard and Control,2015,26(3):3 − 9. (in Chinese with English abstract) doi: 10.16031/j.cnki.issn.1003-8035.2015.03.02
DONG Xiujun, PEI Xiangjun, HUANG Runqiu. The Longchangzhen collapse in Kaili, Guizhou: characteristics and failure causes[J]. The Chinese Journal of Geological Hazard and Control, 2015, 26（3）: 3-9. （in Chinese with English abstract）][知网中文][知网英文 doi: 10.16031/j.cnki.issn.1003-8035.2015.03.02
[7] Federal Highway Administration of USA. 1993 Rockfall Hazard Rating System: Paricipant’s Manual[M]. FHWA SA-93-057.
[8] JABOYEDOFF M,DUDT J P,LABIOUSE V. An attempt to refine rockfall hazard zoning based on the kinetic energy,frequency and fragmentation degree[J]. Natural Hazards and Earth System Sciences,2005,5(5):621 − 632. doi: 10.5194/nhess-5-621-2005
[9] HASEGAWA A,URAKOSHI T. Hazard mapping method for rock Falls using a digital elevation model[J]. Quarterly Report of RTRI,2018,59(1):51 − 56. doi: 10.2219/rtriqr.59.1_51
[10] FANOS A M. A novel rockfall hazard assessment using laser scanning data and 3D modelling in GIS[J]. CATENA,2019,172:435 − 450. doi: 10.1016/j.catena.2018.09.012
[11] 叶四桥,唐红梅,祝辉. 基于AHP-Fuzzy方法的危岩危险度评价[J]. 武汉理工大学学报(交通科学与工程版),2006,30(5):800 − 803. [YE Siqiao,TANG Hongmei,ZHU Hui. Dangerous degree estimation of perilous rock based on AHP-fuzzy method[J]. Journal of Wuhan University of Technology (Transportation Science & Engineering),2006,30(5):800 − 803. (in Chinese with English abstract)
YE Siqiao, TANG Hongmei, ZHU Hui. Dangerous degree estimation of perilous rock based on AHP-fuzzy method[J]. Journal of Wuhan University of Technology （Transportation Science & Engineering）, 2006, 30（5）: 800-803. （in Chinese with English abstract）][知网中文][知网英文
[12] 叶四桥,陈洪凯. 隧道洞口坡段落石灾害危险性等级评价方法[J]. 中国铁道科学,2010,31(5):59 − 65. [YE Siqiao,CHEN Hongkai. The evaluation method for the hazard grading of the rockfall at the slope segment of the tunnel entrance[J]. China Railway Science,2010,31(5):59 − 65. (in Chinese with English abstract)
YE Siqiao, CHEN Hongkai. The evaluation method for the hazard grading of the rockfall at the slope segment of the tunnel entrance[J]. China Railway Science, 2010, 31（5）: 59-65. （in Chinese with English abstract）][知网中文][知网英文
[13] 唐红梅,韩明明,闫凝. 基于GIS的重庆巫山县崩塌灾害危险性分区评价[J]. 重庆师范大学学报(自然科学版),2019,36(5):72 − 79. [TANG Hongmei,HAN Mingming,YAN Ning. The GIS-based danger zoning evaluation of collapse disaster in Wushan County,Chongqing[J]. Journal of Chongqing Normal University (Natural Science),2019,36(5):72 − 79. (in Chinese with English abstract)
TANG Hongmei, HAN Mingming, YAN Ning. The GIS-based danger zoning evaluation of collapse disaster in Wushan County, Chongqing[J]. Journal of Chongqing Normal University （Natural Science）, 2019, 36（5）: 72-79. （in Chinese with English abstract）][知网中文][知网英文
[14] 唐红梅,韩明明,王林峰. 基于AHP-Fuzzy法的灰岩地区崩塌体失稳危险性评价[J]. 灾害学,2019,34(3):1 − 7. [TANG Hongmei,HAN Mingming,WANG Linfeng. Hazard assessment of collapsed rock mass in limestone area based on AHP-fuzzy method[J]. Journal of Catastrophology,2019,34(3):1 − 7. (in Chinese with English abstract)
TANG Hongmei, HAN Mingming, WANG Linfeng. Hazard assessment of collapsed rock mass in limestone area based on AHP-fuzzy method[J]. Journal of Catastrophology, 2019, 34（3）: 1-7. （in Chinese with English abstract）][知网中文][知网英文
[15] 高买燕,唐红梅,曾云松,等. 崩塌灾害危险性评价方法及应用[J]. 重庆交通大学学报(自然科学版),2013,32(3):446 − 450. [GAO Maiyan,TANG Hongmei,ZENG Yunsong,et al. Rockfall hazard assessment method and its application[J]. Journal of Chongqing Jiaotong University (Natural Science),2013,32(3):446 − 450. (in Chinese with English abstract)
GAO Maiyan, TANG Hongmei, ZENG Yunsong, et al. Rockfall hazard assessment method and its application[J]. Journal of Chongqing Jiaotong University （Natural Science）, 2013, 32（3）: 446-450. （in Chinese with English abstract）][知网中文][知网英文
[16] 巩尚卿,叶四桥,杨威. 落石灾害危险性概率评价方法[J]. 灾害学,2014,29(4):215 − 219. [GONG Shangqing,YE Siqiao,YANG Wei. Evaluation method for probability of rockfall hazard[J]. Journal of Catastrophology,2014,29(4):215 − 219. (in Chinese with English abstract)
GONG Shangqing, YE Siqiao, YANG Wei. Evaluation method for probability of rockfall hazard[J]. Journal of Catastrophology, 2014, 29（4）: 215-219. （in Chinese with English abstract）][知网中文][知网英文
[17] 武中鹏,刘宏,董秀群,等. 单体危岩崩塌灾害危险性评价—以贵州威宁县新发乡樊家岩为例[J]. 中国地质灾害与防治学报,2019,30(2):30 − 34. [WU Zhongpeng,LIU Hong,DONG Xiuqun,et al. Hazard assessment of rockfall disaster of a dangerous rock:A case study at Fanjiayan,Xinfa Township,Weining County of Guizhou Province[J]. The Chinese Journal of Geological Hazard and Control,2019,30(2):30 − 34. (in Chinese with English abstract)
WU Zhongpeng, LIU Hong, DONG Xiuqun, et al. Hazard assessment of rockfall disaster of a dangerous rock: a case study at Fanjiayan, Xinfa Township, Weining County of Guizhou Province[J]. The Chinese Journal of Geological Hazard and Control, 2019, 30（2）: 30-34. （in Chinese with English abstract）][知网中文][知网英文
[18] 王栋,邹杨,张广泽,等. 无人机技术在超高位危岩勘查中的应用[J]. 成都理工大学学报(自然科学版),2018,45(6):754 − 759. [WANG Dong,ZOU Yang,ZHANG Guangze,et al. Application of photographic technique by unmanned aerial vehicle to dangerous rock exploration[J]. Journal of Chengdu University of Technology (Science & Technology Edition),2018,45(6):754 − 759. (in Chinese with English abstract)
WANG Dong, ZOU Yang, ZHANG Guangze, et al. Application of photographic technique by unmanned aerial vehicle to dangerous rock exploration[J]. Journal of Chengdu University of Technology （Science & Technology Edition）, 2018, 45（6）: 754-759. （in Chinese with English abstract）][知网中文][知网英文
[19] 李嘉雨,李欣,樊金,等. Ⅰ类轻型无人机在铁路地质勘察中的应用与展望[J]. 铁道勘察,2020,46(4):28 − 31. [LI Jiayu,LI Xin,FAN Jin,et al. The application and prospect of type Ⅰ light unmanned aerial vehicle in railway geological survey[J]. Railway Investigation and Surveying,2020,46(4):28 − 31. (in Chinese with English abstract)
LI Jiayu, LI Xin, FAN Jin, et al. The application and prospect of type Ⅰ light unmanned aerial vehicle in railway geological survey[J]. Railway Investigation and Surveying, 2020, 46（4）: 28-31. （in Chinese with English abstract）][知网中文][知网英文
[20] 李嘉雨, 张广泽, 陈明浩, 等. 一种获取危岩体地形剖面的方法: CN113946982A[P]. 2022-01-18
LI Jiayu, ZHANG Guangze, CHEN Minghao, et al. Method for acquiring dangerous rock body terrain profile: CN113946982A[P]. 2022-01-18. （in Chinese）
[21] 李嘉雨,王崇艮,毛邦燕,等. 基于滑距计算与危险性评价的某平推式滑坡防治对策研究[J]. 长江科学院院报,2021,38(4):63 − 69. [LI Jiayu,WANG Chonggen,MAO Bangyan,et al. Prevention and control countermeasures of translational landslide based on sliding distance calculation and hazard evaluation[J]. Journal of Yangtze River Scientific Research Institute,2021,38(4):63 − 69. (in Chinese with English abstract)
LI Jiayu, WANG Chonggen, MAO Bangyan, et al. Prevention and control countermeasures of translational landslide based on sliding distance calculation and hazard evaluation[J]. Journal of Yangtze River Scientific Research Institute, 2021, 38（4）: 63-69. （in Chinese with English abstract）][知网中文][知网英文
[22] 李嘉雨,毛邦燕,陈亮,等. 基于3DEC模拟的既有铁路单体滑坡危险性分区与评价—以川黔线裁缝岩滑坡为例[J]. 铁道勘察,2019,45(1):40 − 46. [LI Jiayu,MAO Bangyan,CHEN Liang,et al. The hazard division and evaluation of single landslide based on 3 dimension distinct element simulation of the existing Chuan-Qian railway[J]. Railway Investigation and Surveying,2019,45(1):40 − 46. (in Chinese with English abstract)
LI Jiayu, MAO Bangyan, CHEN Liang, et al. The hazard division and evaluation of single landslide based on 3 dimension distinct element simulation of the existing Chuan-Qian railway[J]. Railway Investigation and Surveying, 2019, 45（1）: 40-46. （in Chinese with English abstract）][知网中文][知网英文
[23] SAATY T L. The analytic hierarchy process[M]. New York: McGraw-Hill, 1980: 35 − 40.
[24] 中国地质灾害防治工程行业协会. 崩塌防治工程设计规范: T/CAGHP032—2018[S]. 武汉: 中国地质大学出版社, 2018
China Association of Geological Hazard Prevention. Code for design of rock fall control engineering: T/CAGPH032-2018[S]. Wuhan: China University of Geosciences Press, 2018. （in Chinese）
-
