Analysis on the relationship between geological hazard and lithology , geological structure in Yibin City of Sichuan Province
-
摘要:
针对宜宾市地质灾害数量大、类型多、分布不均等问题,以宜宾市地质灾害隐患与地层岩性-地质构造耦合关系为切入点,在资料搜集、遥感解译、野外调查的基础上,分析总结了地层岩性、地质构造对地质灾害隐患的控制效应,可为宜宾市地质灾害防灾减灾工作的分区部署提供科学支撑。研究结果表明:宜宾市地质灾害隐患与地层岩性关系密切,滑坡(含不稳定斜坡)、崩塌、地面塌陷在软硬相间的块状-层状碎屑岩岩组中广泛分布,较坚硬层状-块状碳酸盐岩岩组与软硬相间碎屑岩岩组的过渡部位亦有利于崩塌的发育,泥石流则分布在易被风化、可提供丰富物源的岩组中。区域地质构造控制了地质灾害隐患的整体分布,主要表现为褶皱、断层走向与地质灾害隐患整体展布具有一致性。对于不同的局部构造环境,地质灾害隐患发育程度明显不同,在褶皱构造中地质灾害隐患主要分布在距褶皱核部2 km以外的区域,距离褶皱核部越远,地质灾害隐患点密度有逐渐增大的趋势;在断层构造中距断层面越近地质灾害隐患点密度越大,距离在1 km以内断层对地质灾害隐患的控制效应尤为明显。大致以高县凤滩村—江安县和平村为界,研究区北部应重点关注滑坡(含不稳定斜坡)地质灾害隐患,建议采取群测群防的防治措施,南部应重点关注崩塌、地面塌陷地质灾害隐患,建议采取专业监测、搬迁避让的防治措施。
Abstract:Based on the large number, diverse types and uneven distribution of geological disasters in Yibin City, this study takes the coupling relationship between geological disaster and lithology - structure as a starting point. Through data collection, remote sensing interpretation and field investigation, this study analyzed and summarized the control effects of formation lithology and geological structure on geological disasters. The findings can provide scientific support for the zoning and deployment of geological disaster prevention and mitigation in Yibin City. The results show that geological disasters in Yibin City are closely related to lithology. Landslides (including unstable slopes), collapses, and ground collapses are widely distributed in soft and hard massive layered clastic rock formations. Additionally, the transition zone between hard layered massive carbonate rock formation and soft hard clastic rock formation is conducive to the development of collapse. Debris flows are distributed in rock formations that are easily weathered and can provide rich material sources. Regional geological structure also influences the overall distribution of geological disasters, particularly the consistency between the strike of folds and faults and the overall distribution of geological disasters. The degree of geological disaster development varies with different local tectonic environments. In fold structures, geological disasters are primarily concentrated within 2 km of the fold core, with density increasing gradually as the distance from the fold core increases. In the fault structure, the density of geological disasters points increases as one approaches the fault plane, with the control effect of faults on geological disasters particularly evident within 1 km. This study recommends that the northern part of the study area, specifically Fengtan Village in Gaoxian County and Heping Village in Jiang’an County, prioritize landslide prevention and control measures, such as group prevention and group strategy. In contrast, the southern part should prioritize measures to prevent and control collapses and ground collapses, such as professional monitoring, relocation, and avoidance.
-
Key words:
- geological disasters /
- formation lithology /
- geological structure /
- Yibin City
-
-
表 1 研究区地质灾害类型和数量统计表
Table 1. Type and quantity statistics of geological disaster in the study area
类型 大型/处 中型/处 小型/处 合计/处 百分比/% 滑坡(含不稳定斜坡) 9 152 722 883 64.97 崩塌 5 102 291 398 29.29 地面塌陷 2 0 60 62 4.56 泥石流 0 4 12 16 1.18 表 2 研究区不同工程地质岩组中地质灾害发育情况
Table 2. Geological disasters development in different engineering geological lithologies in the study area
工程地质岩类及岩组 滑坡(含不
稳定斜坡)/处崩塌
/处地面
塌陷/处泥石流
/起岩类 岩组 地层及代号 岩浆岩类 坚硬的块状玄武岩岩组 峨眉山玄武岩组(P2β) 8 4 1 0 碎屑岩类 较硬的块状砂岩岩组 打儿函组(K1d)、窝头山组(K1w) 59 20 0 0 软硬相间的块状-层状砂岩、泥岩、页岩岩组 三合组(K2s)、天马山组(K1t)、蓬莱镇组(J3p)、
上沙溪庙组(J2s)、下沙溪庙组(J2xs)341 72 1 3 软硬相间的层状砂岩、粉砂岩、泥岩、页岩岩组 高坎坝组(K2g)、新田沟组(J2x) 3 1 0 0 软硬相间的块状-层状砂岩、粉砂岩、
泥页岩夹灰岩岩组珍珠冲组(J1z)、自流井组(J1-2z)、
长兴组(P2c)、龙潭组(P2l)97 32 16 2 软硬相间的块状砂岩夹泥页岩岩组 须家河组(T3xj) 54 14 2 3 软硬相间的层状粉砂岩、页岩、灰岩岩组 湄潭组(O1m) 28 7 0 0 软硬相间的层状页岩夹灰岩、砂岩岩组 飞仙关组(T1f) 70 80 37 0 软硬相间的层状粉砂岩、页岩夹泥灰岩、灰岩岩组 罗惹坪组(S1lr) 22 10 0 0 软弱的层状页岩夹泥灰岩岩组 龙马溪组(S1l)、五峰组(O3w)、中上志留统(S2-3) 34 25 0 1 软弱的层状页岩、泥岩岩组 遂宁组(J3s)、梁山组(P1l) 92 12 1 3 碳酸盐岩类 软硬相间的层状白云岩、灰岩夹粉砂岩、泥岩岩组 雷口坡组(T2l、)、嘉陵江组(T1j) 31 29 0 4 较坚硬的层状白云岩、白云质灰岩岩组 娄山关群(∈2-3ls)、高台组(∈2g) 17 20 1 0 较坚硬的层状-块状灰岩岩组 栖霞组(P1q)、茅口组(P1m) 15 69 3 0 软硬相间的块状—层状灰岩夹粉砂岩、
泥页岩岩组临湘组(O2l)、宝塔组(O2b)、
桐梓组(O1t)、红花园组(O1h)10 3 0 0 松散岩类 砾、砂、砂土、亚黏土类 全新统(Qhal)、更新统(Qpal) 2 0 0 0 -
[1] 王思敬. 地球内外动力耦合作用与重大地质灾害的成因初探[J]. 工程地质学报,2002,10(2):115 − 117. [WANG Sijing. Coupling of earth’s endogenic and exogenic geological processes and origins on serious geological disasters[J]. Journal of Engineering Geology,2002,10(2):115 − 117. (in Chinese with English abstract) doi: 10.3969/j.issn.1004-9665.2002.02.001
WANG Sijing. Coupling of earth’s endogenic and exogenic geological processes and origins on serious geological disasters[J]. Journal of Engineering Geology, 2002, 10(2): 115-117. (in Chinese with English abstract) doi: 10.3969/j.issn.1004-9665.2002.02.001
[2] 白永健,铁永波,倪化勇,等. 鲜水河流域地质灾害时空分布规律及孕灾环境研究[J]. 灾害学,2014,29(4):69 − 75. [BAI Yongjian,TIE Yongbo,NI Huayong,et al. Temporal-spatial distribution and environment pregnant of geohazards in Xianshui River of Sichuan,China[J]. Journal of Catastrophology,2014,29(4):69 − 75. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-811X.2014.04.014
BAI Yongjian, TIE Yongbo, NI Huayong, et al. Temporal-spatial distribution and environment pregnant of geohazards in Xianshui River of Sichuan, China[J]. Journal of Catastrophology, 2014, 29(4): 69-75. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-811X.2014.04.014
[3] 马秋红. 秦巴山区地层岩性与地质构造对地质灾害发育的控制作用分析[D]. 西安: 长安大学, 2011
MA Qiuhong. Analysis for control function of formation lithology and geologic structure for the geological hazards in Qinling-Bashan mountains[D]. Xi’an: Changan University, 2011. (in Chinese with English abstract)
[4] 徐伟,冉涛,田凯. 西南红层地区地质灾害发育规律与成灾模式:以云南彝良县为例[J]. 中国地质灾害与防治学报,2021,32(6):127 − 133. [XU Wei,RAN Tao,TIAN Kai. Developing law and disaster modes of geohazards in red bed region of southwestern China:A case study of Yiliang County of Yunnan Province[J]. The Chinese Journal of Geological Hazard and Control,2021,32(6):127 − 133. (in Chinese with English abstract)
XU Wei, RAN Tao, TIAN Kai. Developing law and disaster modes of geohazards in red bed region of southwestern China: a case study of Yiliang County of Yunnan Province[J]. The Chinese Journal of Geological Hazard and Control, 2021, 32(6): 127-133. (in Chinese with English abstract)
[5] 刘云,康卉君. 江西崩塌滑坡泥石流灾害空间时间分布特征分析[J]. 中国地质灾害与防治学报,2020,31(4):107 − 112. [LIU Yun,KANG Huijun. Spatial-temporal distribution of landslide,rockfall and debris flow hazards in Jiangxi Province[J]. The Chinese Journal of Geological Hazard and Control,2020,31(4):107 − 112. (in Chinese with English abstract)
LIU Yun, KANG Huijun. Spatial-temporal distribution of landslide, rockfall and debris flow hazards in Jiangxi Province[J]. The Chinese Journal of Geological Hazard and Control, 2020, 31(4): 107-112. (in Chinese with English abstract)
[6] 曾琳洁,张涛,冯文凯. 河南南召县地质灾害形成条件与分布规律[J]. 中国地质灾害与防治学报,2014,25(1):82 − 89. [ZENG Linjie,ZHANG Tao,FENG Wenkai. Formation conditions and distribution law about geological disasters in Nanzhao County,Henan Province[J]. The Chinese Journal of Geological Hazard and Control,2014,25(1):82 − 89. (in Chinese with English abstract) doi: 10.16031/j.cnki.issn.1003-8035.2014.01.013
ZENG Linjie, ZHANG Tao, FENG Wenkai. Formation conditions and distribution law about geological disasters in Nanzhao County, Henan Province[J]. The Chinese Journal of Geological Hazard and Control, 2014, 25(1): 82-89. (in Chinese with English abstract) doi: 10.16031/j.cnki.issn.1003-8035.2014.01.013
[7] 房浩,李媛,杨旭东,等. 2010—2015年全国地质灾害发育分布特征分析[J]. 中国地质灾害与防治学报,2018,29(5):1 − 6. [FANG Hao,LI Yuan,YANG Xudong,et al. Distribution characters of geo-hazards in China during the period of 2010—2015[J]. The Chinese Journal of Geological Hazard and Control,2018,29(5):1 − 6. (in Chinese with English abstract)
FANG Hao, LI Yuan, YANG Xudong, et al. Distribution characters of geo-hazards in China during the period of 2010—2015[J]. The Chinese Journal of Geological Hazard and Control, 2018, 29(5): 1-6. (in Chinese with English abstract)
[8] 廖小平,徐风光,蔡旭东,等. 香丽高速公路边坡地质灾害发育特征与易发性区划[J]. 中国地质灾害与防治学报,2021,32(5):121 − 129. [LIAO Xiaoping,XU Fengguang,CAI Xudong,et al. Development characteristics and susceptibality zoning of slope geological hazards in Xiangli expressway[J]. The Chinese Journal of Geological Hazard and Control,2021,32(5):121 − 129. (in Chinese with English abstract)
LIAO Xiaoping, XU Fengguang, CAI Xudong, et al. Development characteristics and susceptibality zoning of slope geological hazards in Xiangli expressway[J]. The Chinese Journal of Geological Hazard and Control, 2021, 32(5): 121-129. (in Chinese with English abstract)
[9] 秦宇龙,吴建亮,詹涵钰,等. 川西甘孜地区活动断裂与地质灾害分布相关性探讨[J]. 地质力学学报,2021,27(3):463 − 474. [QIN Yulong,WU Jianliang,ZHAN Hanyu,et al. Discussion on the correlation between active fault and geological disaster distribution in the Ganzi area,western Sichuan Province,China[J]. Journal of Geomechanics,2021,27(3):463 − 474. (in Chinese with English abstract) doi: 10.12090/j.issn.1006-6616.2021.27.03.042
QIN Yulong, WU Jianliang, ZHAN Hanyu, et al. Discussion on the correlation between active fault and geological disaster distribution in the Ganzi area, western Sichuan Province, China[J]. Journal of Geomechanics, 2021, 27(3): 463-474. (in Chinese with English abstract) doi: 10.12090/j.issn.1006-6616.2021.27.03.042
[10] 冯卫,毕银强,唐亚明,等. 甘肃礼县至罗家堡断裂带沿线地质灾害分布规律及断层效应研究[J]. 自然灾害学报,2021,30(2):183 − 190. [FENG Wei,BI Yinqiang,TANG Yaming,et al. Research on the distribution law of geological disasters and fault effect along the Lixian-Luojiabu fault zone in Gansu[J]. Journal of Natural Disasters,2021,30(2):183 − 190. (in Chinese with English abstract) doi: 10.13577/j.jnd.2021.0219
FENG Wei, BI Yinqiang, TANG Yaming, et al. Research on the distribution law of geological disasters and fault effect along the Lixian-Luojiabu fault zone in Gansu[J]. Journal of Natural Disasters, 2021, 30(2): 183-190. (in Chinese with English abstract) doi: 10.13577/j.jnd.2021.0219
[11] 聂进,王孔伟,路永强. 湖北省竹溪县地质灾害成因机理与局部构造关系[J]. 三峡大学学报(自然科学版),2020,42(1):52 − 56. [NIE Jin,WANG Kongwei,LU Yongqiang. Relationship between cause mechanism of geological disaster and local structure in Zhuxi County of Hubei Province[J]. Journal of China Three Gorges University (Natural Sciences),2020,42(1):52 − 56. (in Chinese with English abstract)
NIE Jin, WANG Kongwei, LU Yongqiang. Relationship between cause mechanism of geological disaster and local structure in Zhuxi County of Hubei Province[J]. Journal of China Three Gorges University (Natural Sciences), 2020, 42(1): 52-56. (in Chinese with English abstract)
[12] 涂美义, 李德果. 湖北省地质灾害与地质构造耦合关系研究[J]. 人民长江, 2012, 43(增刊2): 1 − 3
TU Meiyi, LI Deguo. Study on coupling relationship between geological disasters and geological structures in Hubei Province[J]. Yangtze River, 2012, 43(Sup 2): 1 − 3. (in Chinese with English abstract)
[13] 黄润秋,李为乐. 汶川大地震触发地质灾害的断层效应分析[J]. 工程地质学报,2009,17(1):19 − 28. [HUANG Runqiu,LI Weile. Fault effect analysis of geo-hazard triggered by Wenchaun earthquake[J]. Journal of Engineering Geology,2009,17(1):19 − 28. (in Chinese with English abstract) doi: 10.3969/j.issn.1004-9665.2009.01.003
HUANG Runqiu, LI Weile. Fault effect analysis of geo-hazard triggered by wenchaun earthquake[J]. Journal of Engineering Geology, 2009, 17(1): 19-28. (in Chinese with English abstract) doi: 10.3969/j.issn.1004-9665.2009.01.003
[14] 郭进京,韩文峰,李雪峰. 西秦岭断裂构造格架和活动特征对地质灾害的控制作用分析[J]. 地质调查与研究,2009,32(4):241 − 248. [GUO Jinjing,HAN Wenfeng,LI Xuefeng. Analysis for control function of the fault framework and its active characteristics for the geological hazards in the west Qinling[J]. Geological Survey and Research,2009,32(4):241 − 248. (in Chinese with English abstract) doi: 10.3969/j.issn.1672-4135.2009.04.001
GUO Jinjing, HAN Wenfeng, LI Xuefeng. Analysis for control function of the fault framework and its active characteristics for the geological hazards in the west Qinling[J]. Geological Survey and Research, 2009, 32(4): 241-248. (in Chinese with English abstract) doi: 10.3969/j.issn.1672-4135.2009.04.001
[15] 廖勇,徐闯,陈军,等. 四川长宁“6·17”地震诱发的次生地质灾害类型及其发育特征[J]. 中国地质灾害与防治学报,2021,32(1):77 − 83. [LIAO Yong,XU Chuang,CHEN Jun,et al. Types and their characteristics of geological hazards triggered by“6·17” earthquake in Changning,Sichuan Province[J]. The Chinese Journal of Geological Hazard and Control,2021,32(1):77 − 83. (in Chinese with English abstract) doi: 10.16031/j.cnki.issn.1003-8035.2021.01.11
LIAO Yong, XU Chuang, CHEN Jun, et al. Types and their characteristics of geological hazards triggered by“6·17” earthquake in Changning, Sichuan Province[J]. The Chinese Journal of Geological Hazard and Control, 2021, 32(1): 77-83. (in Chinese with English abstract) doi: 10.16031/j.cnki.issn.1003-8035.2021.01.11
[16] 尹欣欣,郭安宁,赵韬,等. 四川长宁MS6.0地震区域构造应力场特征分析[J]. 地震工程学报,2019,41(5):1215 − 1220. [YIN Xinxin,GUO Anning,ZHAO Tao,et al. Characteristics of the regional tectonic stress field of the Changning MS6.0 earthquake,Sichuan Province[J]. China Earthquake Engineering Journal,2019,41(5):1215 − 1220. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-0844.2019.05.1215
YIN Xinxin, GUO Anning, ZHAO Tao, et al. Characteristics of the regional tectonic stress field of the Changning MS6.0 earthquake, Sichuan Province[J]. China Earthquake Engineering Journal, 2019, 41(5): 1215-1220. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-0844.2019.05.1215
[17] 宫悦,王宇玺,梁明剑,等. 2019年四川长宁6.0级地震序列时空演化特征及其地震构造环境研究[J]. 地震,2020,40(4):90 − 102. [GONG Yue,WANG Yuxi,LIANG Mingjian,et al. Study on the spatio-temporal evolution characteristics and seismic structure environment of the 2019 M6.0 Changning Sichuan earthquake sequence[J]. Earthquake,2020,40(4):90 − 102. (in Chinese with English abstract) doi: 10.12196/j.issn.1000-3274.2020.04.007
GONG Yue, WANG Yuxi, LIANG Mingjian, et al. Study on the spatio-temporal evolution characteristics and seismic structure environment of the 2019 M6.0 Changning Sichuan earthquake sequence[J]. Earthquake, 2020, 40(4): 90-102. (in Chinese with English abstract) doi: 10.12196/j.issn.1000-3274.2020.04.007
[18] 常祖峰,张艳凤,王光明,等. 2019年四川长宁MS6.0地震的地质构造成因:区域性构造节理贯通、破裂结果[J]. 地球学报,2020,41(4):469 − 480. [CHANG Zufeng,ZHANG Yanfeng,WANG Guangming,et al. The geological genesis of the 2019 Changning MS6.0 earthquake in Sichuan: Connecting and rupturing of regional structural joints[J]. Acta Geoscientica Sinica,2020,41(4):469 − 480. (in Chinese with English abstract) doi: 10.3975/cagsb.2020.030202
CHANG Zufeng, ZHANG Yanfeng, WANG Guangming, et al. The geological genesis of the 2019 Changning MS6.0 earthquake in Sichuan: connecting and rupturing of regional structural joints[J]. Acta Geoscientica Sinica, 2020, 41(4): 469-480. (in Chinese with English abstract) doi: 10.3975/cagsb.2020.030202
[19] 胡承林. 宜宾市地质灾害成因及特征浅析[J]. 资源与人居环境,2013(9):30 − 31. [HU Chenglin. Analysis on causes and characteristics of geological disasters in Yibin City[J]. Resources Environment Inhabitant,2013(9):30 − 31. (in Chinese with English abstract) doi: 10.3969/j.issn.1672-822X.2013.09.014
HU Chenglin. Analysis on causes and characteristics of geological disasters in Yibin city[J]. Resources Environment Inhabitant, 2013(9): 30-31. (in Chinese with English abstract) doi: 10.3969/j.issn.1672-822X.2013.09.014
[20] 肖汉全. 宜宾市地质灾害及其防治对策[J]. 四川地质科技情报,1997(3):30 − 32. [XIAO Hanquan. Geological disasters and their control countermeasures in Yibin City[J]. Sichuan Geological Science and Technology Information,1997(3):30 − 32. (in Chinese with English abstract)
XIAO Hanquan. Geological disasters and their control countermeasures in Yibin City[J]. Sichuan Geological Science and technology information, 1997, (3): 30-32. (in Chinese with English abstract)
[21] 辜学达, 刘啸虎. 四川省岩石地层[M]. 武汉: 中国地质大学出版社, 1997
GU Xueda, LIU Xiaohu. Stratigraphy(lithostratic) of Sichuan Province[M]. Wuhan: China University of Geosciences Press, 1997. (in Chinese with English abstract)
[22] ABRAHAMSON N A,SOMERVILLE P G. Effects of the hanging wall and footwall on ground motions recorded during the Northridge earthquake[J]. Bulletin of the Seismological Society of America,1996,86(1B):93 − 99. doi: 10.1785/BSSA08601B0S93
[23] 张田田,杨为民,万飞鹏. 浑河断裂带地质灾害发育特征及其成因机制[J]. 吉林大学学报(地球科学版),2022,52(1):149 − 161. [ZHANG Tiantian, YANG Weimin, WAN Feipeng. Characteristics and Formation Mechanism of Geohazards in Hunhe Fault Zone[J]. Journal of Jilin University (Earth Science Edition),2022,52(1):149 − 161. (in Chinese)
[ZHANG Tiantian, YANG Weimin, WAN Feipeng. Characteristics and Formation Mechanism of Geohazards in Hunhe Fault Zone [J]. Journal of Jilin University (Earth Science Edition), 2022, 52(1): 149-161.(in Chinese)
[24] 曲雪妍,李媛, 房浩, 等. 基于时空维度耦合的地质灾害发育程度评价研究[J]. 水文地质工程地质,2022,49(1):137 − 145. [QU Xueyan,LI Yuan,FANG Hao,et al. A study of the evaluation of geo-hazards development degree based on time-space coupling[J]. Hydrogeology & Engineering Geology,2022,49(1):137 − 145. (in Chinese with English abstract)
QU Xueyan, LI Yuan, FANG Hao, et al. A study of the evaluation of geo-hazards development degree based on time-space coupling[J]. Hydrogeology & Engineering Geology, 2022, 49(1): 137-145.(in Chinese with English abstract)
-
