Analysis of bank slope stability under strong seismic response for super long span bridges
-
摘要:
在高烈度山区设计修建公路桥梁时，耦合多种不利条件的在强震作用下超大跨径桥梁高陡岸坡稳定性最为复杂，易形成滑移、碎屑流等岸坡失稳灾害。实际震害调查结果表明不规则地形对地震动力具有明显的放大作用，对边坡的稳定性和桥梁的安全性构成不利的影响，如何考虑复杂地形的地震动力放大效应具有重要的工程价值。以位于四川省凉山彝族自治州高烈度深切峡谷地段的主跨
1200 m特大悬索桥岸坡为例，对此类超大跨径桥梁岸坡在强地震力作用下的基岩面地震危险性概率和失稳破坏模式机理进行研究，建立了含卸荷裂隙的三维坡体结构模型，采用动力时程分析方法给出了不同失稳破坏模式下岸坡上各特征点的峰值地震加速度并据此获得了修正的放大系数。基于修正的放大系数对坡体地震稳定性的拟静力计算方法进行改进，采用改进后的方法对该桥位的稳定性进行了评估。结果表明：边坡遵循峰值地震水平加速度及放大系数地表最大，随着坡体深度的增大而递减，且递减速度减缓并趋于稳定的规律，且坡度变化率对此影响极大。坡度变化率大且地貌突出部位的地震响应极为强烈。大范围分布的碎块石土覆盖层、变坡率的地貌突出的浅表层、风化卸荷带内的表层风化碎裂岩体极易在地震作用下产生变形，应当加强防护。未考虑修正放大系数的地震工况计算结果偏于不安全，安全系数的计算结果减少了2%～6%。据此提出一整套针对高烈度山区特大跨径桥梁岸坡的地质灾害风险评估方法和与考虑桥梁结构两水准抗震相适应的边坡稳定性计算方法及防护措施建议思路，为相关工程的研究与设计提供参考。Abstract:Designing and constructing highway bridges in high-intensity mountainous areas present significant challenges. The stability of high and steep bank slopes for large span bridges coupled with various unfavorable conditions under strong earthquakes is particularly complex, which is prone to formation of bank slope instability disasters such as sliding and debris flow. Investigations into earthquake damage reveal that irregular terrain has a significant amplification effect on earthquake dynamics, which has an adverse impact on the stability of slopes and the safety of bridges. Assessing the seismic dynamic amplification effect of complex terrain is of important engineering value. This study examines the bank slope of a 1200m-long suspension bridge located in the high-intensity, deep canyon region of the Liangshan Yi Autonomous Prefecture, Sichuan Province. We conduct an in-depth analysis and research on the seismic hazard probability and instability failure mode mechanisms of the bedrock surface under strong seismic forces. A three-dimensional slope structure model with unloading cracks was developed. The peak seismic acceleration of each characteristic point on the bank slope under different instability failure modes was obtained using dynamic time-history analysis method and modified amplification coefficient was derived based on these findings. Improvements were made to the static calculation method for slope seismic stability using this modified coefficient. The improved method was used to evaluate the stability of the construction site. The results indicate that the slope's peak seismic horizontal acceleration and amplification coefficient are highest at the surface and decrease with increasing slope depth, with the rate of decrease slowing and stabilizing. The rate of slope change significantly impacts this response. The seismic response is exceptionally strong in areas with high slope change rates and prominent landforms. Widely distributed fragmented rock and soil cover layers, shallow surfaces with varying slope rates, and surface weathered fragmented rock masses within weathering unloading zones are prone to deformation under seismic action, and protection should be strengthened. The calculation results of seismic conditions without considering the correction of amplification factors are unsafe, with safety factor results decreasing by 2% to 6%. A complete set of geological hazard risk assessment methods, and slope stability calculation methods, and protective measures suitable for considering the two-level seismic resistance of bridge structures are proposed based on this for the bank slopes of ultra large span bridges in high intensity mountainous areas, providing a reference for the research and design of related engineering projects in high-intensity mountainous areas.
-
-
表 1 岩土体的物理力学参数
Table 1. Physical and mechanical parameters of rock and soil
区域 弹模
/MPa泊松比 黏聚力/kPa 内摩擦角/（°） 容重/（kN·m−3） 天然 暴雨 天然 暴雨 天然 暴雨 碎块石土 60 0.32 15 13 27.0 24.0 20.0 21.0 卸荷带 300 0.28 120 108 42.2 38.0 24.0 25.0 中风化岩 800 0.27 507 456 49.9 44.9 26.5 27.0
下载: 导出CSV
表 2 监测点峰值地震水平加速度和放大系数（ξ）
Table 2. Peak seismic horizontal acceleration and amplification factor of monitoring points
编号 西昌岸 香格里拉岸 峰值地震水平加速度 ξ 峰值地震水平加速度 ξ 1 18.779 2.61 16.249 2.26 2 26.536 3.69 19.068 1.40 3 21.003 2.92 14.210 1.28 4 18.763 2.61 15.963 2.22 5 12.581 1.75 43.467 6.04 6 19.471 2.71 18.124 2.52 7 18.848 2.61 13.097 1.82 8 16.650 2.32 14.919 2.07 9 12.434 1.80 41.169 5.72 10 15.802 2.20 16.488 2.29 11 13.193 1.83 12.499 1.74 12 11.940 1.66 14.474 2.01 13 15.797 2.20 10.257 1.43 14 12.253 1.70 12.484 1.76 15 10.975 1.53 9.688 1.35
下载: 导出CSV
表 3 考虑修正放大系数下不同工况边坡FS及稳定状态
Table 3. FS and stable state of various conditions with considering the correction amplification factor
岸坡 天然工况 暴雨工况 E1地震 E2地震 FS 状态 FS 状态 FS 状态 FS 状态 西昌 1.35 稳定 1.26 稳定 1.13 稳定 0.97 失稳 香格里拉 1.26 稳定 1.12 稳定 1.06 基本稳定 0.98 失稳
下载: 导出CSV
表 4 未考虑修正放大系数下地震工况的FS及稳定状态
Table 4. FS and stable state of seismic conditions without considering the correction amplification factor
岸坡 E1地震 E2地震 FS 状态 FS 状态 西昌 1.15 稳定 0.99 失稳 香格里拉 1.11 稳定 1.04 欠稳定
下载: 导出CSV
-
[1] 彭建兵,崔鹏,庄建琦. 川藏铁路对工程地质提出的挑战[J]. 岩石力学与工程学报,2020,39(12):2377 − 2389. [PENG Jianbing,CUI Peng,ZHUANG Jianqi. Challenges to engineering geology of Sichuan—Tibet railway[J]. Chinese Journal of Rock Mechanics and Engineering,2020,39(12):2377 − 2389. (in Chinese with English abstract)]
PENG Jianbing, CUI Peng, ZHUANG Jianqi. Challenges to engineering geology of Sichuan—Tibet railway［J］. Chinese Journal of Rock Mechanics and Engineering, 2020, 39（12）: 2377 − 2389. （in Chinese with English abstract）
[2] 袁进科,陈杰. 汶川地震公路边坡灾害分析及震后边坡灾害发育特点[J]. 公路,2020,65(5):26 − 33. [YUAN Jinke,CHEN Jie. Analysis of highway slope disaster in Wenchuan earthquake and its development characteristics after earthquake[J]. Highway,2020,65(5):26 − 33. (in Chinese with English abstract)]
YUAN Jinke, CHEN Jie. Analysis of highway slope disaster in Wenchuan earthquake and its development characteristics after earthquake［J］. Highway, 2020, 65（5）: 26 − 33. （in Chinese with English abstract）
[3] 张伯艳,王璨,李德玉,等. 地震作用下水利水电工程边坡稳定分析研究进展[J]. 中国水利水电科学研究院学报,2018,16(3):168 − 178. [ZHANG Boyan,WANG Can,LI Deyu,et al. The research progress on seismic stability analysis of slopes in water conservancy and hydropower projects[J]. Journal of China Institute of Water Resources and Hydropower Research,2018,16(3):168 − 178. (in Chinese with English abstract)]
ZHANG Boyan, WANG Can, LI Deyu, et al. The research progress on seismic stability analysis of slopes in water conservancy and hydropower projects［J］. Journal of China Institute of Water Resources and Hydropower Research, 2018, 16（3）: 168 − 178. （in Chinese with English abstract）
[4] 郭延辉,杨溢,高才坤,等. 云南鲁甸地震红石岩堰塞湖右岸特高边坡综合监测及变形特征分析[J]. 中国地质灾害与防治学报,2020,31(6):30 − 37. [GUO Yanhui,YANG Yi,GAO Caikun,et al. Comprehensive monitoring and deformation analysis of extra high slope on the right bank of Hongshiyan dammed lake in Ludian Earthquake[J]. The Chinese Journal of Geological Hazard and Control,2020,31(6):30 − 37. (in Chinese with English abstract)]
GUO Yanhui, YANG Yi, GAO Caikun, et al. Comprehensive monitoring and deformation analysis of extra high slope on the right bank of Hongshiyan dammed lake in Ludian Earthquake［J］. The Chinese Journal of Geological Hazard and Control, 2020, 31（6）: 30 − 37. （in Chinese with English abstract）
[5] 胡爱国,周伟. 地震与强降雨作用下堆积体滑坡变形破坏机理及防治方案分析[J]. 中国地质灾害与防治学报,2022,33(1):27 − 34. [HU Aiguo,ZHOU Wei. Deformation and failure mechanism and analysis on prevention measures of colluction landslide under earthquake and heavy rainfall[J]. The Chinese Journal of Geological Hazard and Control,2022,33(1):27 − 34. (in Chinese with English abstract)]
HU Aiguo, ZHOU Wei. Deformation and failure mechanism and analysis on prevention measures of colluction landslide under earthquake and heavy rainfall［J］. The Chinese Journal of Geological Hazard and Control, 2022, 33（1）: 27 − 34. （in Chinese with English abstract）
[6] 周洪福,冯治国,石胜伟,等. 川藏铁路某特大桥成都侧岸坡工程地质特征及稳定性评价[J]. 水文地质工程地质,2021,48(5):112 − 119. [ZHOU Hongfu,FENG Zhiguo,SHI Shengwei,et al. Slope engineering geology characteristics and stability evaluation of a grand bridge to Chengdu bank on the Sichuan—Tibet Railway[J]. Hydrogeology & Engineering Geology,2021,48(5):112 − 119. (in Chinese with English abstract)]
ZHOU Hongfu, FENG Zhiguo, SHI Shengwei, et al. Slope engineering geology characteristics and stability evaluation of a grand bridge to Chengdu bank on the Sichuan—Tibet Railway［J］. Hydrogeology & Engineering Geology, 2021, 48（5）: 112 − 119. （in Chinese with English abstract）
[7] 刘天翔,杜兆萌,程强,等. 红层软岩高边坡的时效变形特性[J]. 科学技术与工程,2020,20(27):11315 − 11322. [LIU Tianxiang,DU Zhaomeng,CHENG Qiang,et al. Time-dependent deformation characteristics of high slope in red layer soft rock[J]. Science Technology and Engineering,2020,20(27):11315 − 11322. (in Chinese with English abstract)] doi: 10.3969/j.issn.1671-1815.2020.27.050
LIU Tianxiang, DU Zhaomeng, CHENG Qiang, et al. Time-dependent deformation characteristics of high slope in red layer soft rock［J］. Science Technology and Engineering, 2020, 20（27）: 11315 − 11322. （in Chinese with English abstract） doi: 10.3969/j.issn.1671-1815.2020.27.050
[8] 陈廷君,肖世国,程强,等. 泸定大渡河桥康定岸重力锚边坡长期变形与稳定性分析[J]. 工程地质学报,2019,27(3):632 − 639. [CHEN Tingjun,XIAO Shiguo,CHENG Qiang,et al. Long-term deformation and stability analysis of gravity anchorage slope on Kangding bank of Dadu River bridge in Luding[J]. Journal of Engineering Geology,2019,27(3):632 − 639. (in Chinese with English abstract)]
CHEN Tingjun, XIAO Shiguo, CHENG Qiang, et al. Long-term deformation and stability analysis of gravity anchorage slope on Kangding bank of Dadu River bridge in Luding［J］. Journal of Engineering Geology, 2019, 27（3）: 632 − 639. （in Chinese with English abstract）
[9] 郭鸿俊,姜清辉,孙金山. 大岗山水电站右岸高边坡加固方案优化研究[J]. 人民长江,2012,43(15):16 − 19. [GUO Hongjun,JIANG Qinghui,SUN Jinshan. Optimization for reinforcement plan of right-bank high slope of Dagangshan Hydropower Station[J]. Yangtze River,2012,43(15):16 − 19. (in Chinese with English abstract)] doi: 10.3969/j.issn.1001-4179.2012.15.005
GUO Hongjun, JIANG Qinghui, SUN Jinshan. Optimization for reinforcement plan of right-bank high slope of Dagangshan Hydropower Station［J］. Yangtze River, 2012, 43（15）: 16 − 19. （in Chinese with English abstract） doi: 10.3969/j.issn.1001-4179.2012.15.005
[10] 张泽鹏,朱凤贤,黄放军,等. 复杂地质条件下高边坡加固设计与综合治理研究——以梅河高速公路某高边坡治理为例[J]. 中山大学学报(自然科学版),2006,45(4):44 − 48. [ZHANG Zepeng,ZHU Fengxian,HUANG Fangjun,et al. Research on reinforcement design and comprehensive improvement for high slopes under complicated geological conditions[J]. Acta Scientiarum Naturalium Universitatis Sunyatseni,2006,45(4):44 − 48. (in Chinese with English abstract)]
ZHANG Zepeng, ZHU Fengxian, HUANG Fangjun, et al. Research on reinforcement design and comprehensive improvement for high slopes under complicated geological conditions［J］. Acta Scientiarum Naturalium Universitatis Sunyatseni, 2006, 45（4）: 44 − 48. （in Chinese with English abstract）
[11] 张江伟,李小军. 地震作用下边坡稳定性分析方法[J]. 地震学报,2015,37(1):180 − 191. [ZHANG Jiangwei,LI Xiaojun. A review on the stability analysis methods of slope under seismic loading[J]. Acta Seismologica Sinica,2015,37(1):180 − 191. (in Chinese with English abstract)] doi: 10.11939/j.issn:0253-3782.2015.01.016
ZHANG Jiangwei, LI Xiaojun. A review on the stability analysis methods of slope under seismic loading［J］. Acta Seismologica Sinica, 2015, 37（1）: 180 − 191. （in Chinese with English abstract） doi: 10.11939/j.issn:0253-3782.2015.01.016
[12] 崔玉龙,刘爱娟. 区域边坡地震危险性评价理论研究进展[J]. 地震工程学报,2022,44(3):518 − 526. [CUI Yulong,LIU Aijuan. Advances in the theory of seismic hazard assessment of regional slopes[J]. China Earthquake Engineering Journal,2022,44(3):518 − 526. (in Chinese with English abstract)]
CUI Yulong, LIU Aijuan. Advances in the theory of seismic hazard assessment of regional slopes［J］. China Earthquake Engineering Journal, 2022, 44（3）: 518 − 526. （in Chinese with English abstract）
[13] 李亮,褚雪松,庞峰,等. 地震边坡稳定性分析的拟静力方法适用性探讨[J]. 世界地震工程,2012,28(2):57 − 63. [LI Liang,CHU Xuesong,PANG Feng,et al. Discussion on suitability of pseudo-static method in seismic slope stability analysis[J]. World Earthquake Engineering,2012,28(2):57 − 63. (in Chinese with English abstract)] doi: 10.3969/j.issn.1007-6069.2012.02.010
LI Liang, CHU Xuesong, PANG Feng, et al. Discussion on suitability of pseudo-static method in seismic slope stability analysis［J］. World Earthquake Engineering, 2012, 28（2）: 57 − 63. （in Chinese with English abstract） doi: 10.3969/j.issn.1007-6069.2012.02.010
[14] 郑颖人,叶海林,肖强,等. 基于全动力分析法的地震边坡与隧道稳定性分析[J]. 防灾减灾工程学报,2010,30(增刊1):279 − 285. [ZHENG Yingren,YE Hailin,XIAO Qiang,et al. Stability analysis of earthquake slope and tunnel based on full dynamic analysis method[J]. Journal of Disaster Prevention and Mitigation Engineering,2010,30(Sup 1):279 − 285. (in Chinese with English abstract)]
ZHENG Yingren, YE Hailin, XIAO Qiang, et al. Stability analysis of earthquake slope and tunnel based on full dynamic analysis method［J］. Journal of Disaster Prevention and Mitigation Engineering, 2010, 30（Sup 1）: 279 − 285. （in Chinese with English abstract）
[15] 张迎宾,柳静,唐云波,等. 考虑边坡地形效应的地震动力响应分析[J]. 地震工程学报,2021,43(1):142 − 153. [ZHANG Yingbin,LIU Jing,TANG Yunbo,et al. Dynamic response analysis of seismic slopes considering topographic effect[J]. China Earthquake Engineering Journal,2021,43(1):142 − 153. (in Chinese with English abstract)]
ZHANG Yingbin, LIU Jing, TANG Yunbo, et al. Dynamic response analysis of seismic slopes considering topographic effect［J］. China Earthquake Engineering Journal, 2021, 43（1）: 142 − 153. （in Chinese with English abstract）
[16] 王来贵,向丽,赵娜,等. 地震作用下顺倾多弱层岩质边坡动力响应[J]. 中国地质灾害与防治学报,2021,32(6):18 − 25. [WANG Laigui,XIANG Li,ZHAO Na,et al. Dynamic response of down-dip multi-weak-layer rock slope under earthquake[J]. The Chinese Journal of Geological Hazard and Control,2021,32(6):18 − 25. (in Chinese with English abstract)]
WANG Laigui, XIANG Li, ZHAO Na, et al. Dynamic response of down-dip multi-weak-layer rock slope under earthquake［J］. The Chinese Journal of Geological Hazard and Control, 2021, 32（6）: 18 − 25. （in Chinese with English abstract）
[17] 林峻岑,严松宏,孙纬宇,等. 三向地震作用下错距岩质边坡共振特性研究[J]. 水文地质工程地质,2023,50(2):95 − 102. [LIN Juncen,YAN Songhong,SUN Weiyu,et al. A study of the resonance characteristics of a staggered rock slope under the tri-dimension earthquake wave[J]. Hydrogeology & Engineering Geology,2023,50(2):95 − 102. (in Chinese with English abstract)]
LIN Juncen, YAN Songhong, SUN Weiyu, et al. A study of the resonance characteristics of a staggered rock slope under the tri-dimension earthquake wave［J］. Hydrogeology & Engineering Geology, 2023, 50（2）: 95 − 102. （in Chinese with English abstract）
[18] 李郑梁,李建春,刘波,等. 浅切割的高山峡谷复杂地形的地震动放大效应研究[J]. 工程地质学报,2021,29(1):137 − 150. [LI Zhengliang,LI Jianchun,LIU Bo,et al. Seismic motion amplification effect of shallow-cutting hill-canyon composite topography[J]. Journal of Engineering Geology,2021,29(1):137 − 150. (in Chinese with English abstract)]
LI Zhengliang, LI Jianchun, LIU Bo, et al. Seismic motion amplification effect of shallow-cutting hill-canyon composite topography［J］. Journal of Engineering Geology, 2021, 29（1）: 137 − 150. （in Chinese with English abstract）
[19] 孙强强,薄景山,孙有为,等. 隧道结构地震反应分析研究现状[J]. 世界地震工程,2016,32(2):159 − 169. [SUN Qiangqiang,BO Jingshan,SUN Youwei,et al. A state-of-the-art review of seismic response analysis of tunnels[J]. World Earthquake Engineering,2016,32(2):159 − 169. (in Chinese with English abstract)]
SUN Qiangqiang, BO Jingshan, SUN Youwei, et al. A state-of-the-art review of seismic response analysis of tunnels［J］. World Earthquake Engineering, 2016, 32（2）: 159 − 169. （in Chinese with English abstract）
[20] 邓鹏. 单体边坡地形的地震动力响应及其放大效应的数值分析[J]. 地震学报,2020,42(3):349 − 361. [DENG Peng. Numerical parametric study of seismic dynamic response and amplification effects of slope topography[J]. Acta Seismologica Sinica,2020,42(3):349 − 361. (in Chinese with English abstract)] doi: 10.11939/jass.20190133
DENG Peng. Numerical parametric study of seismic dynamic response and amplification effects of slope topography［J］. Acta Seismologica Sinica, 2020, 42（3）: 349 − 361. （in Chinese with English abstract） doi: 10.11939/jass.20190133
[21] 门妮,孙有为,薄景山,等. 地震作用下边坡动力响应及影响因素研究[J]. 世界地震工程,2017,33(3):110 − 120. [MEN Ni,SUN Youwei,BO Jingshan,et al. Study on dynamic response and influence factors of slope under earthquake[J]. World Earthquake Engineering,2017,33(3):110 − 120. (in Chinese with English abstract)]
MEN Ni, SUN Youwei, BO Jingshan, et al. Study on dynamic response and influence factors of slope under earthquake［J］. World Earthquake Engineering, 2017, 33（3）: 110 − 120. （in Chinese with English abstract）
[22] 张江伟,周爱红,迟明杰,等. 边坡地震响应数值模拟中最优边界范围研究[J]. 防灾减灾工程学报,2022,42(1):34 − 41. [ZHANG Jiangwei,ZHOU Aihong,CHI Mingjie,et al. Research on boundary range in seismic response simulation of slope[J]. Journal of Disaster Prevention and Mitigation Engineering,2022,42(1):34 − 41. (in Chinese with English abstract)]
ZHANG Jiangwei, ZHOU Aihong, CHI Mingjie, et al. Research on boundary range in seismic response simulation of slope［J］. Journal of Disaster Prevention and Mitigation Engineering, 2022, 42（1）: 34 − 41. （in Chinese with English abstract）
[23] 郑颖人,叶海林,黄润秋,等. 边坡地震稳定性分析探讨[J]. 地震工程与工程振动,2010,30(2):173 − 180. [ZHENG Yingren,YE Hailin,HUANG Runqiu,et al. Study on the seismic stability analysis of a slope[J]. Journal of Earthquake Engineering and Engineering Vibration,2010,30(2):173 − 180. (in Chinese with English abstract)]
ZHENG Yingren, YE Hailin, HUANG Runqiu, et al. Study on the seismic stability analysis of a slope［J］. Journal of Earthquake Engineering and Engineering Vibration, 2010, 30（2）: 173 − 180. （in Chinese with English abstract）
-
