Characteristics of source rocks and reservoirs of the Funing Formation in the Subei Basin and their bearing on future shale oil exploration
-
摘要:
对苏北盆地重点凹陷的70口钻井采集395件样品进行实验分析,并结合前人资料详细研究了苏北盆地古近系古新统阜宁组阜二段、阜四段两套烃源岩地化特征、岩矿特征、储集空间类型及储集性能，在重点油井解剖的基础上，探讨了页岩油的富集机理。苏北盆地阜宁组有机碳普遍大于 1.0%，有机质类型较好，整体处于低熟-成熟阶段，具备良好的生油基础；微裂缝、孔隙较发育，具有一定的储集条件，阜二段泥页岩整体黏土矿物含量低于35%，脆性矿物含量大于50%，有利于页岩油的开采。通过对重点凹陷典型页岩油藏的两口井的数据解剖，认为页岩油藏受高有机质丰度的成熟泥页岩、脆性矿物含量、裂缝发育程度、异常高压等因素控制。苏北盆地的金湖凹陷、高邮凹陷、海安凹陷和盐城凹陷的深凹带是泥页岩油气勘探和开发的有利区带。
Abstract:395 samples collected from 70 wells in the major depressions of the Subei Basin are analyzed in this paper. Combined with the previous data analyzed, we systematically studied the geochemical and lithological characteristics, accumulation space types and their distribution patterns as well as reservoir physical properties in addition to the hydrocarbon source rock of the F2 and the F4 Member of the Paleogene Funing Formation in the Basin. Based on the case studies for typical wells and oil shows, the occurrence and accumulation mechanisms of shale oil is deeply discussed. The results reveal that the average organic carbon content of the two members is over 1.0%, dominated by the type I-II in a matured stage, that found the basis for the formation of shale oil. Many kinds of micropores and micro cracks are well developed. Clay content of the Member F2 is usually lower than 35% and the content of brittle minerals is over 50%, which is in favor of shale oil mining. The study of the two well cases in the typical shale reservoir reveals that the formation of shale oil reservoir mainly depends on the existence of mature shale with high abundance of organic matter and brittle minerals, well developed fractures and abnormal high pressure. The major depressional centers of the Jinhu Sag, Gaoyou Sag, Haian Sag and Yancheng Sag in the North Jiangsu Basin are favorable zones for shale gas exploration and mining.
-
-
表 1 苏北盆地探区阜宁组阜二段富有机质泥页岩丰度统计
Table 1. Statistical table of organic matter abundance for source rocks of the F2 Member of Funing Formation in the Subei Basin
探区 TOC（%）/样品数 氯仿沥青“A”（%）/样品数 HI（%）/样品数 S1+S2（mg/g）/样品数 高邮凹陷 1.583/38 0.034/5 362.301/38 6.823/38 金湖凹陷 1.724/42 0.208/5 328.432/42 7.854/42 海安凹陷 2.094/45 0.099/8 439.815/45 13.123/45 盐城凹陷 2.833/38 0.159/14 481.000/38 15.630/38 溱潼凹陷 1.691/19 − 393.762/19 7.351/19 泰州凸起 1.154/2 − 290.000/2 3.000/2 平均值 2.011/184 0.132/32 400.511/184 10.241/184
下载: 导出CSV
表 2 苏北盆地探区阜宁组阜四段富有机质泥页岩丰度统计
Table 2. Statistical table of organic matter abundance for source rocks of the F4 Member of Funing Formation in the Subei Basin
探区 TOC（%）/样品数 氯仿沥青“仿沥（%）/样品数 HI（%）/样品数 S1+S2（mg/g）/样品数 高邮凹陷 1.102/39 − 246.032/33 4.080/33 金湖凹陷 1.281/29 0.025/3 257.670/18 3.963/18 海安凹陷 0.572/1 − 144.000/1 0.834/1 盐城凹陷 1.163/17 − 348.000/2 7.891/2 溱潼凹陷 1.663/20 − 237.811/20 6.892/20 平均值 1.263/106 0.025/4 248.012/74 4.871/74
下载: 导出CSV
表 3 苏北盆地各凹陷泥页岩有机质类型百分含量统计表（%）
Table 3. Statistical table of percentage content of organic matter types in each depression of the Subei Basin
层位 分析项目 金湖凹陷 高邮凹陷 海安凹陷 盐城凹陷 溱潼凹陷 I Ⅱ1 Ⅱ2 Ⅲ I Ⅱ1 Ⅱ2 Ⅲ I Ⅱ1 Ⅱ2 Ⅲ I Ⅱ1 Ⅱ2 Ⅲ I Ⅱ1 Ⅱ2 Ⅲ 阜二段 热解 28 34 23 15 21 31 33 15 24 53 21 2 76 8 10 6 35 30 24 11 阜四段 热解 50 17 33 7 44 29 20 6 37 32 25 4 35 39 22 8 27 41 24
下载: 导出CSV
表 4 苏北盆地重点凹陷阜二段、阜四段全岩矿物组分
Table 4. The whole rock mineral components of the F2 and F4 Members of Funing Formation in the key depressions of Subei Basin
层段 重点凹陷 石英 钾长石 斜长石 方解石 白云石 铁白云石 菱铁矿 黄铁矿 石膏 方沸石 黏土矿物 脆性矿物 高邮凹陷 20.510 1.803 7.050 11.100 13.110 20.930 1.302 2.908 2.400 7.612 32.210 50.810 金湖凹陷 20.301 5.323 7.621 12.604 8.513 14.109 1.032 4.101 1.621 12.701 29.616 49.088 阜二段 海安凹陷 21.205 1.514 5.080 11.203 17.609 11.314 0.819 1.795 0.91 9.910 30.712 56.013 盐城凹陷 22.704 2.523 2.426 13.205 3.011 18.412 1.101 3.492 2.198 15.681 30.201 45.337 溱潼凹陷 32.812 1.332 9.014 6.510 15.01 1.014 3.221 2.110 9.01 28.29 64.212 高邮凹陷 30.193 1.702 7.813 12.301 2.615 4.217 0.798 2.113 1.701 38.706 52.811 金湖凹陷 25.602 2.821 5.518 8.209 5.218 19.301 1.513 2.831 1.007 41.212 43.091 阜四段 海安凹陷 22.098 1.078 4.095 11.044 2.048 5.011 2.052 53.033 40.045 盐城凹陷 20.032 1.516 12.034 7.015 2.033 1.017 4.032 2.514 49.026 40.547 溱潼凹陷 18.032 2.818 6.312 8.065 7.6 1.020 3.302 44.207 41.811
下载: 导出CSV
表 5 苏北盆地重点凹陷阜二、阜四段泥页岩孔隙度和渗透率统计表
Table 5. Statistical table of shale porosity and permeability in the 2nd and 4th Members of Funing Formation of the key sags in the Subei Basin
层段 重点凹陷 孔隙度范围/% 孔隙度平均值/% 渗透率范围/10−3 μm2 渗透率平均值/10−3 μm2 高邮凹陷 1.613～32.834 13.225 25.233 25.233 金湖凹陷 3.761～17.912 8.561 0.094 0.094 阜二段 海安凹陷 1.441～12.862 7.132 0.008 0.008 盐城凹陷 2～27.771 11.962 溱潼凹陷 1.774～19.915 9.650 0.004～0.115 0.005 高邮凹陷 4.293～27.371 17.400 金湖凹陷 11.530 11.530 阜四段 海安凹陷 盐城凹陷 16.171～20.311 17.712 溱潼凹陷 12.641～26.264 19.445 0.023 0.023
下载: 导出CSV
表 6 许X38井、盐城1井试油层地质特征统计
Table 6. Statistical table of geological characteristics of Xu X38 well and Yancheng 1 well
井号 页岩层 岩石相 TOC/% Ro/% 脆性矿物/% 黏土/% 孔隙度/% 页岩油密度/（g/cm3） 页岩油粘度/mPa·s 压力系数 盐城1井 E1f2 块状灰质泥岩 2.162 0.771 47.12 37 5.321 0.887 2170 1.600 E1f2 纹层状钙质页岩 1.884 40.431 57.401 3.711 许X38井 E1f2 块状灰质泥岩 2.951 0.922 70.101 27.542 4.131 0.858 10.544 1.233 E1f2 纹层状钙质页岩 1.532 65.21 26.040 10.852
下载: 导出CSV
-
[1] 刘平兰. 苏北海安凹陷泰州组烃源岩评价[J]. 石油实验地质, 2009, 31(4):389-393
LIU Pinglan. Source rock evaluation of Taizhou formation in Haian sag, northern Jiangsu basin [J]. Petroleum Geology & Experiment, 2009, 31(4): 389-393.
[2] 程海生, 刘世丽, 段宏亮. 苏北盆地阜宁组泥页岩储层特征[J]. 复杂油气藏, 2015, 8(3):10-16
CHENG Haisheng, LIU Shili, DUAN Hongliang. Shale reservoir characteristics of Funing Formation in Subei Basin [J]. Complex Hydrocarbon Reservoirs, 2015, 8(3): 10-16.
[3] 仇永峰, 陈平原, 崔晓晓. 高邮凹陷北斜坡中部泰州组烃源岩评价[J]. 上海地质, 2010, 31(S1):236-239
QIU Yongfeng, CHEN Pingyuan, CUI Xiaoxiao. Source rock evaluation of Taizhou Formation in the cetral north slope of Gaoyou Depresstion [J]. Shanghai Geology, 2010, 31(S1): 236-239.
[4] 姜生玲, 聂海宽, 荆铁亚, 等. 高邮凹陷阜宁组烃源岩特征及油源对比[J]. 特种油气藏, 2014, 21(2):66-69
JIANG Shengling, NIE Haikuan, JING Tieya, et al. Characteristics and oil source comparison of the Funing Formation hydrocarbon source rock in the Gaoyou sag [J]. Special Oil and Gas Reservoirs, 2014, 21(2): 66-69.
[5] 昝灵, 骆卫峰, 马晓东. 苏北盆地溱潼凹陷阜二段烃源岩生烃潜力及形成环境[J]. 非常规油气, 2016, 3(3):1-8
ZAN Ling, LUO Weifeng, MA Xiaodong. Hydrocarbon generation potential and genetic environments of second member of Funing formation in Qintong Sag, Subei Basin [J]. Unconventional Oil & Gas, 2016, 3(3): 1-8.
[6] 纪亚琴, 刘义梅, 冯武军. 苏北盆地盐城凹陷阜宁组烃源岩研究与成藏模式[J]. 石油实验地质, 2013, 35(4):449-452
JI Yaqin, LIU Yimei, FENG Wujun. Source rock study and accumulation pattern of Funing Formation in Yancheng Sag, Northern Jiangsu Basin [J]. Petroleum Geology & Experiment, 2013, 35(4): 449-452.
[7] 方朝合, 张枝焕, 王义凤, 等. 苏北盆地溱潼凹陷第三系烃源岩地球化学特征[J]. 西安石油大学学报: 自然科学版, 2008, 23(6):1-5
FANG Chaohe, ZHANG Zhihuan, WANG Yifeng, et al. Geochemical characteristics of the lower tertiary source rock in Qintong Sag, Subei Basin [J]. Journal of Xi′an Shiyou University: Natural Science Edition, 2008, 23(6): 1-5.
[8] 胡维强, 马立涛, 刘玉明, 等. 苏北盆地海安凹陷曲塘次凹阜宁组二段烃源岩地球化学特征[J]. 东北石油大学报, 2018, 42(5):73-81
HU Weiqiang, MA Litao, LIU Yuming, et al. Geochemical characteristics of hydrocarbon source rocks in Fu2 member of Qutang subsag, Haian sag, Subei basin [J]. Journal of Northeast Petroleum University, 2018, 42(5): 73-81.
[9] 刘世丽, 段宏亮, 章亚, 等. 苏北盆地阜二段陆相页岩油气勘探潜力分析[J]. 海洋石油, 2014, 34(3):27-33
LIU ShiLi, DUAN Hongliang, ZHANG Ya, et al. Analysis of oil and gas exploration potential in F2 member continental shale of Subei Basin [J]. Offshore Oil, 2014, 34(3): 27-33.
[10] 毛凤鸣, 梁兵, 刘启东. 高邮凹陷断层——岩性油气藏勘探技术与实践[M]. 北京: 石油工业出版社, 2013: 24-58.
MAO Fengming, LIANG Bin, LIU Qidong. Fault-Lithologic Reservoir Exploration Technology and Practice in Gaoyou Sag[M]. Beijing: Petroleum Industry Press, 2013: 24-58.
[11] 吴向阳, 高德群. 苏北盆地高邮凹陷阜宁组油气成藏期研究[J]. 中国石油勘探, 2011, 16(4):37-41, 86
WU Xiangyang, GAO Dequn. Analysis on hydrocarbon accumulation period of Funing formation in Gaoyou Sag, Subei Basin [J]. China Petroleum Exploration, 2011, 16(4): 37-41, 86.
[12] 邱旭明, 钱诗友, 于雯泉, 等. 苏北盆地“十二五”油气勘探主要成果、新认识和技术进展[J]. 中国石油勘探, 2016, 21(3):62-73
QIU Xuming, QIAN Shiyou, YU Wenquan, et al. Main achievements, new understanding and technological progress for oil and gas exploration in North Jiangsu Basin during the 12th Five-Year Plan [J]. China Petroleum Exploration, 2016, 21(3): 62-73.
[13] 龚永杰. 苏北盆地泰州组、阜宁组油气成藏机理及富集规律[D]. 中国石油大学硕士学位论文, 2008.
GONG Yongjie. Forming mechanism and enrichment rules of reservoirs in Taizhou and Funing formations, Subei Basin[D]. Master Dissertation of China University of Petroleum, 2008.
[14] 王海方. 苏北盆地古近系页岩油储层有效裂缝识别[J]. 西南石油大学学报: 自然科学版, 2016, 38(3):21-27
WANG Haifang. Recognition of effective fractures within the oil shale in the fourth member of Funing formation in Northern Jiangsu Basin [J]. Journal of Southwest Petroleum University: Science & Technology Edition, 2016, 38(3): 21-27.
[15] 邱旭明, 刘玉瑞, 傅强. 苏北盆地上白垩统——第三系层序地层与沉积演化[M]. 北京: 地质出版社, 2006.
QIU XuMing, LIU YuRui, FU Qiang.Sequence stratigraphy and sedimentary evolution of Upper Cretaceous Tertiary in Subei Basin[M]. Beijing: Geological Publishing House, 2006.
[16] 陈庆, 史建南, 朱利东, 等. 西藏中仓盆地古近系丁青湖组生烃潜力与沉积有机相分析[J]. 东北石油大学学报, 2017, 41(4):71-78
CHEN Qing, SHI Jiannan, ZHU Lidong, et al. Analysis of hydrocarbon generating potential and characteristics of organic facies of Paleogene Dingqinghu formation in Zhongcang basin, Tibet [J]. Journal of Northeast Petroleum University, 2017, 41(4): 71-78.
[17] 杨力. 苏北盆地中新生代构造演化及其与油气的关系[D]. 长江大学硕士学位论文, 2015.
YANG Li. The structural evolution in the Cenozoic of Subei basin and its relationship with oil and gas[D]. Master Dissertation of Changjiang University, 2015.
[18] 姜敏. 东营、潍北及沾化凹陷深层烃源岩有机地球化学特征研究[D]. 成都理工大学硕士学位论文, 2011.
JIANG Min. Study on organic geochemistry features of deep source rocks in Dongying、Zhanhua and Weibei Sag[D]. Master Dissertation of Chengdu University of Technology, 2011.
[19] 陈安定. 苏北盆地第三系烃源岩排烃范围及油气运移边界[J]. 石油与天然气地质, 2006, 27(5):630-636
CHEN Anding. Range of hydrocarbon expulsion from the Tertiary source rocks and hydrocarbon migration boundary in Subei basin [J]. Oil & Gas Geology, 2006, 27(5): 630-636.
[20] 李贤庆, 王铁冠, 钟宁宁, 等. 未熟—低熟烃源岩的有机岩石学研究的若干进展[J]. 地学前缘, 2000, 7(3):103-110
LI Xianqing, WANG Tieguan, ZHONG Ningning, et al. Some advances in organic petrology studies on immature source rocks [J]. Earth Science Frontiers, 2000, 7(3): 103-110.
[21] 曲长胜, 邱隆伟, 操应长, 等. 吉木萨尔凹陷二叠系芦草沟组烃源岩有机岩石学特征及其赋存状态[J]. 中国石油大学学报: 自然科学版, 2017, 41(2):30-38
QU Changsheng, QIU Longwei, CAO Yingchang, et al. Organic petrology characteristics and occurrence of source rocks in Permian Lucaogou Formation, Jimsar sag [J]. Journal of China University of Petroleum, 2017, 41(2): 30-38.
[22] 陈建平, 黄第藩. 烃源岩中矿物沥青基质成烃潜力探讨[J]. 地球化学, 1997, 26(6):18-24
CHEN Jianping, HUANG Difan. Hydrocarbon generation potential of mineral-bituminous matrix in source rocks [J]. Geochimica, 1997, 26(6): 18-24.
[23] 赵俊峰, 刘池洋, 王晓梅. 镜质体反射率测定结果的影响因素[J]. 煤田地质与勘探, 2004, 32(6):15-17
ZHAO Junfeng, LIU Chiyang, WANG Xiaomei. The factors influencing the measurement results of vitrinite reflectance [J]. Coal Geology & Exploration, 2004, 32(6): 15-17.
[24] 李志明, 秦建中, 徐旭辉, 等. 镜质体反射率抑制与烃源岩质量关系——以渤海湾盆地东营凹陷烃源岩为例[J]. 石油实验地质, 2008, 30(3):276-280
LI Zhiming, QIN Jianzhong, XU Xuhui, et al. The relationship between vitrinite reflectance suppression and source rock quality-A case study on source rocks from the Dongying sag, Bohai bay basin [J]. Petroleum Geology & Experiment, 2008, 30(3): 276-280.
[25] 江夏, 周荔青. 苏北盆地富油气凹陷形成与分布特征[J]. 石油实验地质, 2010, 32(4):319-325
JIANG Xia, ZHOU Liqing. Characteristics of formation and distribution of prolific sags in the northern Jiangsu Basin [J]. Petroleum Geology & Experiment, 2010, 32(4): 319-325.
[26] 边瑞康, 武晓玲, 包书景, 等. 美国页岩油分布规律及成藏特点[J]. 西安石油大学学报: 自然科学版, 2014, 29(1):1-9, 14
BIAN Ruikang, WU Xiaoling, BAO Shujing, et al. Distribution law and reservoir forming characteristics of shale oil in America [J]. Journal of Xi′an Shiyou University: Natural Science Edition, 2014, 29(1): 1-9, 14.
[27] 王红伟, 段宏亮. 盐城凹陷阜二段页岩油形成条件及富集规律研究[J]. 复杂油气藏, 2016, 9(3):14-18
WANG Hongwei, DUAN Hongliang. Formation condition and enrichment rule of shale oil in the second member of Funing Formation in Yancheng Sag [J]. Complex Hydrocarbon Reservoirs, 2016, 9(3): 14-18.
[28] 刘平, 陈书平, 刘世丽, 等. 苏北盆地阜宁组泥页岩裂缝类型及形成期次[J]. 西安石油大学学报: 自然科学版, 2014, 29(6):13-20, 28
LIU Ping, CHEN Shuping, LIU Shili, et al. Types and forming epochs of the fractures in the shale of Funing Formation of Subei Basin [J]. Journal of Xi′an Shiyou University: Natural Science Edition), 2014, 29(6): 13-20, 28.
[29] 杨元. 苏北盆地阜二段泥页岩储层非均质性研究[D]. 中国石油大学硕士学位论文, 2015.
YANG Yuan. Shale reservoir heterogeneity of the second member of Funing formation in Subei Basin[D]. Master Dissertation of China University of Petroleum (East China), 2015.
[30] 马存飞. 湖相泥页岩储集特征及储层有效性研究[D]. 中国石油大学博士学位论文, 2017.
MA Cunfei. Study on characteristics and effectiveness of lacustrine shale reservoir[D]. Doctor Dissertation of China University of Petroleum (East China), 2017.
[31] 张林晔, 李钜源, 李政, 等. 北美页岩油气研究进展及对中国陆相页岩油气勘探的思考[J]. 地球科学进展, 2014, 29(6):700-711
ZHANG Linye, LI Juyuan, LI Zheng, et al. Advances in shale oil/gas research in North America and considerations on exploration for continental shale oil/gas in China [J]. Advances in Earth Science, 2014, 29(6): 700-711.
[32] 贾承造, 邹才能, 李建忠, 等. 中国致密油评价标准、主要类型、基本特征及资源前景[J]. 石油学报, 2012, 33(3):343-350
JIA Chengzao, ZOU Caineng, LI Jianzhong, et al. Assessment criteria, main types, basic features and resource prospects of the tight oil in China [J]. Acta Petrolei Sinica, 2012, 33(3): 343-350.
[33] 邹才能, 朱如凯, 白斌, 等. 致密油与页岩油内涵、特征、潜力及挑战[J]. 矿物岩石地球化学通报, 2015, 34(1):1-17
ZOU Caineng, ZHU Rukai, BAI Bin, et al. Significance, geologic characteristics, resource potential and future challenges of tight oil and shale oil [J]. Bulletin of Mineralogy, Petrology and Geochemistry, 2015, 34(1): 1-17.
-
