Combined application of sub-bottom and single-channel seismic profiles to marine sand and gravel resource prospecting
-
摘要:
海砂需求激增导致其勘查开发力度不断加大，埋藏海砂作为重要的海砂资源赋存类型，开发其的环境影响相对较小，但找砂难度相对较大。常用来勘查埋藏海砂的物探手段是单道地震测量，其优点是可以穿透砂层，而缺点是存在多解性。浅地层剖面由于难以穿透砂层，在以往的海砂勘查中未得到足够的重视。本文利用浅地层剖面“易穿透泥难穿透砂”的特性，通过其排除泥层间接探砂，再结合单道地震直接识别砂层。泥层的浅地层剖面特征为易于识别的均质透明或层状反射，砂层的单道地震特征为中强振幅连续性差的杂乱反射，将泥层的间接排除法与砂层的直接识别法相结合，形成"浅地层剖面排除泥层+单道地震识别砂层+钻孔验证"的埋藏海砂勘查方法，可有效提高找砂成功率。
Abstract:The demand for marine sand and gravel is sharply increasing, which leads to the intensification of prospecting and exploitation offshore. As an important type of marine sand and gravel resources, extraction of buried marine sand and gravel has less environmental impacts. However, the prospecting of the buried sand and gravel deposits is relatively difficult. Single-channel seismic survey is commonly used to search for buried marine sand and gravel. It is advantaged by penetrating sand, whereas disadvantaged by multiple solutions. Sub-bottom profile has not been paid enough attention in previous marine sand and gravel investigations, due to the difficulties in penetrating sand. However, sub-bottom profile is easy to penetrate mud, and can be used to exclude the mud. In this paper, we propose a method by integrating sub-bottom and single-channel seismic profiles together. Mud could be easily recognized with the clear transparent or bedding structure on the sub-bottom profile, which could help avoiding the thick mud. Sand might be recognized by the medium-strong amplitude chaotic reflection on the single-channel seismic profile, which could guide to selecting the thick sand. Based on the understanding mentioned above, the method of "exclusion of thick mud by sub-bottom profile, identification of sand by single-channel seismic profile and verification by boreholes" is suggested for prospecting of buried marine sand and gravel so as to effectively improve the success rate of prospecting.
-
-
表 1 钻孔岩性信息
Table 1. Lithological information of borehole
钻孔编号 水深/m 分层/m 岩性 ZK1 25.1 0～4.6 泥（流塑） 4.6～8.7 泥质中粗砂 8.7～19.0 粗砂 19.0～22.1 砾质粗砂 22.1～30.0 泥（软塑） ZK2 30.5 0～6.0 泥（流塑） 6～10.6 泥质中细砂 10.6～23.1 中砂 23.1～33.5 粗砂 33.5～34.0 泥（可塑） ZK3 34.3 0～3.8 泥（流塑） 3.8～11.8 细砂 11.8～15.7 中砂 15.7～30.0 泥（软塑） ZK4 34.9 0～14.4 泥（流塑） 14.4～27.2 泥（软塑） 27.2～29.5 泥质细砂 29.5～31.0 泥（软塑） ZK5 31.9 0～2.6 泥（流塑） 2.6～3.7 泥质细砂 3.7～15.4 中砂 15.4～18.1 泥（可塑） 18.1～21.8 泥质中细砂 21.8～30.0 泥（软塑） ZK6 29.0 0～10.8 泥（流塑） 10.8～28.1 泥（软塑） 28.1～30.0 细砂 30.0～32.8 中粗砂 32.8～33.5 泥（可塑）
下载: 导出CSV
-
[1] 倪玉根, 李建国, 习龙. 海砂粒级划分标准和沉积物命名方法探讨[J]. 热带海洋学报, 2021, 40 (3): 143-151
NI Yugen, LI Jianguo, XI Long. Discussion of the grain size grading scale and sediment classification for marine sand and gravel [J]. Journal of Tropical Oceanography, 2021, 40 (3): 143-151.
[2] Bendixen M, Best J, Hackney C, et al. Time is running out for sand [J]. Nature, 2019, 571(7763): 29-31. doi: 10.1038/d41586-019-02042-4
[3] Velegrakis A F, Ballay A, Poulos S E, et al. European marine aggregates resources: origins, usage, prospecting and dredging techniques [J]. Journal of Coastal Research, 2010(51): 1-14.
[4] Wang Y, Zhang Y Z, Zou X Q, et al. The sand ridge field of the South Yellow Sea: origin by river–sea interaction [J]. Marine Geology, 2012, 291-294: 132-146. doi: 10.1016/j.margeo.2011.01.001
[5] 贾磊, 陈太浩, 倪玉根, 等. 福建台湾浅滩二区海砂资源调查成果报告[R]. 2021.
JIA Lei, CHEN Taihao, NI Yugen, et al. Report of marine sand and gravel resources investigation in Taiwan Shoal II area off Fujian coast[R]. 2021.
[6] 梁开, 倪玉根, 陈太浩, 等. 三亚新机场海砂填料调查成果报告(海南省东方-乐东海域海砂调查报告)[R]. 2020.
LIANG Kai, NI Yugen, CHEN Taihao, et al. Report of marine sand and gravel resources investigation for Sanya new airport reclamation (Report of marine sand and gravel resources investigation off Dongfang-Ledong coast, Hainan Province)[R]. 2020.
[7] 马胜中, 倪玉根, 林进清, 等. 1: 5万珠江口内伶仃洋海洋区域地质调查(试点)成果报告[R]. 2015.
MA Shengzhong, NI Yugen, LIN Jinqing, et al. Report of 1: 50000 marine regional geological survey of the inner Lingdingyang in the Pearl River Estuary[R]. 2015.
[8] 倪玉根, 雷勇, 夏真, 等. 广东省海砂资源调查项目成果报告[R]. 2017.
NI Yugen, LEI Yong, XIA Zhen, et al. Report of marine sand and gravel resources investigation off Guangdong coast[R]. 2017.
[9] 赵铁虎, 张训华, 王修田, 等. 广东珠江口-东平近海浅地层剖面的声学特征及地质意义[J]. 物探化探计算技术, 2007, 29(3):183-188 doi: 10.3969/j.issn.1001-1749.2007.03.002
ZHAO Tiehu, ZHANG Xunhua, WANG Xiutian, et al. Sub-Bottom Profiling (SBP) acoustic characteristics and geological interpretation on offshore from Pearl River Estuary to Dongping in Guangdong province [J]. Computing Techniques for Geophysical and Geochemical Exploration, 2007, 29(3): 183-188. doi: 10.3969/j.issn.1001-1749.2007.03.002
[10] 赵铁虎, 李军, 张异彪, 等. 舟山海域海砂资源声地层剖面探测研究[J]. 物探化探计算技术, 2011, 33(3):340-345 doi: 10.3969/j.issn.1001-1749.2011.03.022
ZHAO Tiehu, LI Jun, ZHANG Yibiao, et al. Study of high-resolution SBP exploration for sea sand resources in the Zhoushan offshore [J]. Computing Techniques for Geophysical and Geochemical Exploration, 2011, 33(3): 340-345. doi: 10.3969/j.issn.1001-1749.2011.03.022
[11] 夏真, 林进清, 郑志昌, 等. 珠江口近岸海洋地质环境综合研究[M]. 北京: 科学出版社, 2015.
XIA Zhen, LIN Jinqing, ZHENG Zhichang, et al. Comprehensive Study of Marine Geological Environment in the Pearl River Estuary[M]. Beijing: Science Press, 2015.
[12] 冯志强, 冯文科, 薛万俊, 等. 南海北部地质灾害及海底工程地质条件评价[M]. 南京: 河海大学出版社, 1996.
FENG Zhiqiang, FENG Wenke, XUE Wanjun, et al. Evaluation of Marine Geologic Hazards and Engineering Geological Conditions in the Northern South China Sea[M]. Nanjing: Hohai University Press, 1996.
[13] 冯志强, 李学杰, 林进清, 等. 广东大亚湾海洋地质环境综合评价[M]. 武汉: 中国地质大学出版社, 2002.
FENG Zhiqiang, LI Xuejie, LIN Jinqing, et al. Comprehensive Evaluation of Marine Geological Environment in Daya Bay, Guangdong[M]. Wuhan: China University of Geosciences Press, 2002.
[14] 夏真, 林进清, 郑志昌, 等. 深圳大鹏湾海洋地质环境综合评价[M]. 北京: 地质出版社, 2004.
XIA Zhen, LIN Jinqing, ZHENG Zhichang, et al. Comprehensive Evaluation of Marine Geological Environment in Dapeng Bay, Shenzhen[M]. Beijing: Geological Publishing House, 2004.
[15] 夏真, 林进清, 郑志昌, 等. 北部湾广西近岸海洋地质环境综合研究[M]. 北京: 海洋出版社, 2019.
XIA Zhen, LIN Jinqing, ZHENG Zhichang, et al. Comprehensive Study of Marine Geological Environment off Guangxi Coast in Beibu Gulf[M]. Beijing: Ocean Press, 2019.
-
