Geophysical studies of mass transport deposits on the slope canyon floor with high-resolution autonomous underwater vehicle (AUV) in the Shenhu area and its implications for sediment transportation
-
摘要:
海底峡谷是陆源物质向深海运移的重要通道。对于远离陆地的海底峡谷，通常认为浊流是物质搬运的主要营力。受限于探测精度和复杂作业环境影响，使用常规地球物理资料对深水海底峡谷尤其是对谷底沉积体的形态和结构特征的刻画不够精细。基于水下自主航行器（AUV, Autonomous Underwater Vehicle）采集的高分辨率多波束、旁扫声呐和浅地层剖面资料，对神狐峡谷群中的一条峡谷的谷底表面及部分浅部地层的沉积特征进行了分析。结果表明，峡谷谷底浅部地层并不像它平滑的表面那么简单，而是由大量内部杂乱弱反射、厚度在8.4 m及以下的块体搬运沉积体组成。峡谷中下游块体搬运沉积体大都沿峡谷走向整体呈条带状展布，不是直接来源于相邻的峡谷脊部。研究认为在特定沉积环境下（例如高海平面时期），陆坡限定性峡谷谷底的块体搬运沉积过程的重复进行是峡谷谷底物质输运的重要途径，与浊流共同雕刻了峡谷的地形地貌。基于AUV的地球物理探测技术将是研究海底浅表层沉积过程和保障海底工程施工的重要手段。
-
关键词:
- 海底峡谷 /
- 物质输运 /
- 水下自主航行器（AUV） /
- 块体搬运沉积 /
- 神狐峡谷群
Abstract:Submarine canyons are important pathways for terrestrial sediment moving to the deep water far away from the land, and turbidity current is considered as the primary agent. Detailed sedimentary features of the canyon floor are not clear so far due to the low resolution of conventional geophysical data and complicated operating setting in deep water. Here, in this program, high-resolution autonomous underwater vehicle (AUV) based multi-beam bathymetry data, side-scan sonar data and chirp sub-bottom profiles are jointly used to map the floor of a canyon and image its shallow strata in the Shenhu area. The canyon floor looks quite flat. However, the underlying shallow strata are composed of widespread mass transport deposits (MTDs) which are a little less than 8.4 meters with weak and chaotic acoustic reflections. They are distributed along the canyon floor in an elongated shape and show little direct links with adjacent steep canyon ridges at the middle and lower segments of the canyon. Thus, we suggest the repeated mass wasting downslope on the canyon floor is an effective mechanism for sediment transportation in addition to turbidity currents. The AUV based geophysical exploration is a efficient tool for further studies of marine sedimentation and seabed installation under deep water.
-
-
表 1 峡谷谷底MTDs的几何参数
Table 1. Geometric parameters of MTDs on the canyon floor
编号 宽度/m 长度/km 长宽比 厚度/m 面积/km2 体积/km3 MTD1 80～500 5.00 10.00～62.50 1.30～8.40 0.90 4.37 MTD2 260～350 0.75 2.14～2.88 0.90～3.20 0.28 0.58 MTD3 70～600 2.00 3.33～28.57 1.20～3.00 1.10 2.31
下载: 导出CSV
-
[1] Stow D A V, Mayall M. Deep-water sedimentary systems: New models for the 21st century [J]. Marine and Petroleum Geology, 2000, 17(2): 125-135. doi: 10.1016/S0264-8172(99)00064-1
[2] Harris P T, Whiteway T. Global distribution of large submarine canyons: Geomorphic differences between active and passive continental margins [J]. Marine Geology, 2011, 285(1-4): 69-86. doi: 10.1016/j.margeo.2011.05.008
[3] Xu J P, Barry J P, Paull C K. Small-scale turbidity currents in a big submarine canyon [J]. Geology, 2013, 41(2): 143-146. doi: 10.1130/G33727.1
[4] Paull C K, Talling P J, Maier K L, et al. Powerful turbidity currents driven by dense basal layers [J]. Nature Communications, 2018, 9(1): 4114. doi: 10.1038/s41467-018-06254-6
[5] Hsu S K, Kuo J, Lo C L, et al. Turbidity currents, submarine landslides and the 2006 Pingtung earthquake off SW Taiwan [J]. Terrestrial Atmospheric and Oceanic Sciences, 2008, 19(6): 767-772. doi: 10.3319/TAO.2008.19.6.767(PT)
[6] Carter L, Milliman J D, Talling P J, et al. Near-synchronous and delayed initiation of long run-out submarine sediment flows from a record-breaking river flood, offshore Taiwan [J]. Geophysical Research Letters, 2012, 39(12): L12603.
[7] 陈芳, 苏新, 周洋. 南海神狐海域水合物钻探区钙质超微化石生物地层与沉积速率[J]. 地球科学—中国地质大学学报, 2013, 38(1):1-9 doi: 10.3799/dqkx.2013.001
CHEN Fang, SU Xin, ZHOU Yang. Late Miocene-Pleistocene calcareous nannofossil biostratigraphy of Shenhu gas hydrate drilling area in the South China Sea and variations in sedimentation rates [J]. Earth Science—Journal of China University of Geosciences, 2013, 38(1): 1-9. doi: 10.3799/dqkx.2013.001
[8] He Y, Zhong G F, Wang L L, et al. Characteristics and occurrence of submarine canyon-associated landslides in the middle of the northern continental slope, South China Sea [J]. Marine and Petroleum Geology, 2014, 57: 546-560. doi: 10.1016/j.marpetgeo.2014.07.003
[9] Chen D X, Wang X J, Völker D, et al. Three dimensional seismic studies of deep-water hazard-related features on the northern slope of South China Sea [J]. Marine and Petroleum Geology, 2016, 77: 1125-1139. doi: 10.1016/j.marpetgeo.2016.08.012
[10] 罗进华, 朱培民. 琼东南盆地陆坡区重力流沉积体系超高精度解析[J]. 地质科技情报, 2019, 38(6):42-50
LUO Jinhua, ZHU Peimin. Gravity induced deposits in the continental slope of Qiongdongnan basin based on ultrahigh resolution AUV data [J]. Geological Science and Technology Information, 2019, 38(6): 42-50.
[11] 冯湘子, 朱友生. 南海北部陵水陆坡重力流沉积调查与分析[J]. 海洋地质与第四纪地质, 2020, 40(5):25-35
FENG Xiangzi, ZHU Yousheng. Investigation of gravity flow deposits on the Lingshui slope of the northern South China Sea [J]. Marine Geology & Quaternary Geology, 2020, 40(5): 25-35.
[12] Paull C K, Anderson K, Caress D W, et al. Fine-scale morphology of tubeworm slump, Monterey canyon[M]//Lamarche G. Submarine Mass Movements and their Consequences. Cham: Springer, 2016: 155-162.
[13] Gwiazda R, Paull C K, Caress D W, et al. Eel canyon slump scar and associated fluid venting[M]//Lamarche G. Submarine Mass Movements and Their Consequences. Cham: Springer, 2016: 411-418.
[14] Tubau X, Paull C K, Lastras G, et al. Submarine canyons of Santa Monica Bay, Southern California: Variability in morphology and sedimentary processes [J]. Marine Geology, 2015, 365: 61-79. doi: 10.1016/j.margeo.2015.04.004
[15] 李硕, 刘健, 徐会希, 等. 我国深海自主水下机器人的研究现状[J]. 中国科学: 信息科学, 2018, 48(9):1152-1164 doi: 10.1360/N112017-00264
LI Shuo, LIU Jian, XU Huixi, et al. Research status of autonomous underwater vehicles in China [J]. Scientia Sinica: Informationis, 2018, 48(9): 1152-1164. doi: 10.1360/N112017-00264
[16] Clift P, Lin J, Barckhausen U. Evidence of low flexural rigidity and low viscosity lower continental crust during continental break-up in the South China Sea [J]. Marine and Petroleum Geology, 2002, 19(8): 951-970. doi: 10.1016/S0264-8172(02)00108-3
[17] 庞雄, 陈长民, 邵磊, 等. 白云运动: 南海北部渐新统-中新统重大地质事件及其意义[J]. 地质论评, 2007, 53(2):145-151 doi: 10.3321/j.issn:0371-5736.2007.02.001
PANG Xiong, CHEN Changmin, SHAO Lei, et al. Baiyun movement, a great tectonic event on the Oligocene-Miocene boundary in the northern South China Sea and its implications [J]. Geological Review, 2007, 53(2): 145-151. doi: 10.3321/j.issn:0371-5736.2007.02.001
[18] 陈端新. 南海北部陆缘深水盆地流体渗漏构造研究[D]. 中国科学院大学中国科学院海洋研究所博士学位论文, 2012: 51-75.
CHEN Duanxin. Focused fluid flow structure in the deepwater basins of northern South China Sea margin[D]. Doctor Dissertation of Institute of Oceanology, Chinese Academy of Science, 2012: 51-75.
[19] Ma B J, Wu S G, Sun Q L, et al. The late Cenozoic deep-water channel system in the Baiyun Sag, Pearl River Mouth Basin: Development and tectonic effects [J]. Deep Sea Research Part II: Topical Studies in Oceanography, 2015, 122: 226-239. doi: 10.1016/j.dsr2.2015.06.015
[20] Zhu M Z, Graham S, Pang X, et al. Characteristics of migrating submarine canyons from the middle Miocene to present: Implications for paleoceanographic circulation, northern South China Sea [J]. Marine and Petroleum Geology, 2010, 27(1): 307-319. doi: 10.1016/j.marpetgeo.2009.05.005
[21] Gong C L, Wang Y M, Rebesco M, et al. How do turbidity flows interact with contour currents in unidirectionally migrating deep-water channels? [J]. Geology, 2018, 46(6): 551-554. doi: 10.1130/G40204.1
[22] Li X S, Zhou Q J, Su T Y, et al. Slope-confined submarine canyons in the Baiyun deep-water area, northern South China Sea: variation in their modern morphology [J]. Marine Geophysical Research, 2016, 37(2): 95-112. doi: 10.1007/s11001-016-9269-0
[23] Su M, Lin Z X, Wang C, et al. Geomorphologic and infilling characteristics of the slope-confined submarine canyons in the Pearl River Mouth Basin, northern South China Sea [J]. Marine Geology, 2020, 424: 106166. doi: 10.1016/j.margeo.2020.106166
[24] Wu L Y, Xiong X J, Li X L, et al. Bottom currents observed in and around a submarine valley on the continental slope of the northern South China Sea [J]. Journal of Ocean University of China, 2016, 15(6): 947-957. doi: 10.1007/s11802-016-3054-1
-
