The study of the difference of beach response under sediment supply in southeast of Xiamen Island
-
摘要:
以厦门岛东南部海滩为例，基于10条剖面连续6年野外实测地形数据，利用经验正交函数分析方法（EOF）提取海滩变化的主要模态，分析海滩中长期蚀淤变化特征及其控制因素。EOF提取方差总占比超过90%的前三种模态反映研究区海滩时空演变特征：沙源条件对海滩蚀淤过程起主导作用为第一模态，受上游沙源条件及沿岸输沙方向影响，海滩剖面在纵向上存在差异性，研究区北侧剖面持续淤积，南侧剖面则呈现侵蚀状态；第二模态为波浪季节性变化导致海滩滩肩在冬季变窄和夏季变宽之间旋回；人类活动影响滩面形态变化为第三模态，人类活动对岸滩形态及其变化产生一定影响，其中人工构筑物对研究区海滩影响较大。从多年海滩变化来看，沙源条件控制海滩响应差异性，沉积物供给充足的海滩形态变化幅度及系统可调节范围比沉积物匮乏海滩大，泥沙供给贫乏的海滩地形变化幅度虽小，其系统缓冲能力及自适应能力却弱。
Abstract:The morphological evolution of a beach in the southeastern part of Xiamen Island, Fujian, China was analyzed as an example to show the responses of the beach to different sediment supplies. Based on the topographic data from 10 beach profiles monitored for six consecutive years, the method of Empirical Orthogonal Function (EOF) analysis was applied to help identify the morphological evolution and the associated driving factors. More than 90% of the total variance of the first three empirical orthogonal functions was used to reflect the basic evolution of the beach. The first mode represents the remarkable erosion or deposition trend of beach profiles on a long time scale, indicating that sediment source plays a dominate role in long-term beach evolution. Beach profiles in the northern part of the study area show continuous seaward accretion, while those in the southern part show retreat. The second mode represents the seasonal transition in beach berm between summer and winter, which is associated with the seasonal variation in wave climate. The third mode represents the morphological changes of intertidal zone, which indicates the impacts of human activities, especially artificial structures along the coast. This study highlights the dominant role of sediment source in medium- to long-term morphological evolution of beaches. Beaches with sufficient sediment supply show a larger range of morphological adjustment and stronger adaptability than those with limited sediment supply.
-
-
表 1 剖面基本信息
Table 1. Basic information of the beach profiles
剖面名称 桩点经纬度 方位角 P1
P2
P3
P4
P5
P6
P7
P8
P9
P1024°27′21.31″N、 118°10′15.16″E
24°27′17.43″N、 118°10′10.03″E
24°27′12.87″N、 118°10′03.71″E
24°27′08.12″N、 118°09′57.30″E
24°27′04.71″N、 118°09′55.42″E
24°26′56.35″N、 118°09′43.21″E
24°26′45.10″N、 118°09′25.43″E
24°26′32.16″N、 118°09′07.47″E
24°26′22.08″N、 118°08′52.25″E
24°26′04.91″N、 118°08′37.30″E139°00′
139°11′
139°09′
139°09′
139°08′
139°43′
140°16′
146°31′
134°34′
123°10′
下载: 导出CSV
表 2 各剖面主要模态特征值及所占方差结果
Table 2. Beach profile variation explained by modes
区域 剖面 特征值 所占方差/% 累计方差/% 第一模态 第二模态 第三模态 第一模态 第二模态 第三模态 淤积区域 P1 13.03 2.12 – 84 14 – 98 P2 13.40 0.55 – 94 4 – 98 P3 4.82 0.34 – 87 6 – 93 P4 11.17 1.03 – 88 8 – 96 P5 0.55 0.39 0.05 51 36 5 92 侵蚀区域 P6 3.58 0.20 – 88 5 – 93 P7 0.66 0.27 0.10 55 22 18 95 P8 1.56 0.30 0.18 73 14 8 95 P9 3.70 1.46 0.33 64 25 6 95 P10 0.84 0.60 0.10 51 37 6 94
下载: 导出CSV
-
[1] Rosen P S. Beach processes and sedimentation. Paul D. Komar [J]. The Journal of Geology, 1978, 86(1): 155.
[2] 陈子燊. 海滩剖面形态与地形动态研究的进展[J]. 海洋通报, 1997, 16(1):86-91
CHEN Zishen. Progress in studies on the shapes and dynamics of beach profiles [J]. Marine Science Bulletin, 1997, 16(1): 86-91.
[3] Sunamura T, Horikawa K. Two dimensional beach transformation due to waves[C]//Proceedings of the 14th International Conference on Coastal Engineering. Copenhagen, Denmark: ASCE, 1974: 920-938.
[4] 陈子燊, 于吉涛, 罗智丰. 近岸过程与海岸侵蚀机制研究进展[J]. 海洋科学进展, 2010, 28(2):250-256 doi: 10.3969/j.issn.1671-6647.2010.02.017
CHEN Zishen, YU Jitao, LUO Zhifeng. Progresses on study of nearshore processes and coastal erosion mechanisms [J]. Advances in Marine Science, 2010, 28(2): 250-256. doi: 10.3969/j.issn.1671-6647.2010.02.017
[5] 约翰R. 克拉克. 海岸带管理手册[M]. 吴克勤, 杨德全, 盖明举, 译. 北京: 海洋出版社, 2000: 22-45.
Clark J R. Coastal Zone Management Handbook[M]. WU Keqin, YANG Dequan, GAI Mingju, trans. Beijing: China Ocean Press, 2000: 22-45.
[6] 李平, 杜军, 张志卫, 等. 粤东南澳岛青澳海滩侵蚀退化风险评价及其安全调控[J]. 海洋科学进展, 2020, 38(1):171-181 doi: 10.3969/j.issn.1671-6647.2020.01.018
LI Ping, DU Jun, ZHANG Zhiwei, et al. Erosion risk assessment and safety regulatory of Qing’ao Beach in the Nan’ao Island, Guangdong province [J]. Advances in Marine Science, 2020, 38(1): 171-181. doi: 10.3969/j.issn.1671-6647.2020.01.018
[7] 黎奕宏, 雷刚, 蔡锋, 等. 我国硬式护岸、渔港工程和人工岛等3类典型海岸工程对相邻海滩的影响研究[J]. 应用海洋学学报, 2019, 38(1):118-125 doi: 10.3969/J.ISSN.2095-4972.2019.01.013
LI Yihong, LEI Gang, CAI Feng, et al. Study on the influence of hard revetment, harbor engineering and artificial island on the adjacent beach in China [J]. Journal of Applied Oceanography, 2019, 38(1): 118-125. doi: 10.3969/J.ISSN.2095-4972.2019.01.013
[8] Guevara-Riba A, Sahuquillo A, Rubio R, et al. Assessment of metal mobility in dredged harbour sediments from Barcelona, Spain [J]. Science of the Total Environment, 2004, 321(1-3): 241-255. doi: 10.1016/j.scitotenv.2003.08.021
[9] 于吉涛, 丁圆婷, 程璜鑫, 等. 波控中等潮差海滩剖面时空变化过程研究[J]. 海洋通报, 2015, 34(5):540-546 doi: 10.11840/j.issn.1001-6392.2015.05.007
YU Jitao, DING Yuanting, CHENG Huangxin, et al. Spatial and temporal variability of the wave-dominated, meso-tidal beach profile [J]. Marine Science Bulletin, 2015, 34(5): 540-546. doi: 10.11840/j.issn.1001-6392.2015.05.007
[10] 李志龙, 陈子燊, 戴志军. 粤东汕尾岬间海滩体积短期变化分析[J]. 中山大学学报:自然科学版, 2004, 43(2):112-116
LI Zhilong, CHEN Zishen, DAI Zhijun. Analysis of beach volume variations over a month for a beach between Headlandsin Shanwei, eastern Guangdong [J]. Acta Scientiarum Naturalium Universitatis Sunyatseni, 2004, 43(2): 112-116.
[11] 戴仕宝, 杨世伦, 郜昂, 等. 近50年来中国主要河流入海泥沙变化[J]. 泥沙研究, 2007(2):49-58 doi: 10.3321/j.issn:0468-155X.2007.02.008
DAI Shibao, YANG Shilun, GAO Ang, et al. Trend of sediment flux of main rivers in China in the past 50 years [J]. Journal of Sediment Research, 2007(2): 49-58. doi: 10.3321/j.issn:0468-155X.2007.02.008
[12] Wijnberg K M, Terwindt J H J. Extracting decadal morphological behaviour from high-resolution, long-term bathymetric surveys along the Holland coast using eigenfunction analysis [J]. Marine Geology, 1995, 126(1-4): 301-330. doi: 10.1016/0025-3227(95)00084-C
[13] Bosma K F, Dalrymple R A. Beach profile analysis around Indian River Inlet, Delaware, U. S. A. [C]//Proceedings of the 25th International Conference on Coastal Engineering. Orlando, Florida: ASCE, 1996: 2829-2842.
[14] Medellín G, Torres-Freyermuth A, Tomasicchio G R, et al. Field and numerical study of resistance and resilience on a Sea Breeze Dominated Beach in Yucatan (Mexico) [J]. Water, 2018, 10(12): 1806. doi: 10.3390/w10121806
[15] Aubrey D G. Seasonal patterns of onshore/offshore sediment movement [J]. Journal of Geophysical Research:Oceans, 1979, 84(C10): 6347-6354. doi: 10.1029/JC084iC10p06347
[16] Hoang V C, Tanaka H, Mitobe Y. Morphological recovery of beach severely damaged by the 2011 great east Japan tsunami [J]. Estuarine, Coastal and Shelf Science, 2019, 226: 106274. doi: 10.1016/j.ecss.2019.106274
[17] 陈子燊. 海滩剖面时空变化过程分析[J]. 海洋通报, 2000, 19(2):42-48 doi: 10.3969/j.issn.1001-6392.2000.02.008
CHEN Zishen. Analysis on spatial and temporal processes of beach profile variations [J]. Marine Science Bulletin, 2000, 19(2): 42-48. doi: 10.3969/j.issn.1001-6392.2000.02.008
[18] 曹惠美, 蔡锋, 郑勇玲. 人工养护后厦门香山-长尾礁海滩的演变特征[J]. 应用海洋学学报, 2015, 34(1):24-33 doi: 10.3969/J.ISSN.2095-4972.2015.01.004
CAO Huimei, CAI Feng, ZHENG Yongling. Evolution characteristics of nourished beach from Xiangshan to Changweijiao in Xiamen [J]. Journal of Applied Oceanography, 2015, 34(1): 24-33. doi: 10.3969/J.ISSN.2095-4972.2015.01.004
[19] 岳保静, 窦衍光, 廖晶, 等. 山东半岛南北岸砂质海滩剖面时空变化过程分析[J]. 海洋科学, 2018, 42(3):53-62 doi: 10.11759/HYKX20170411002
YUE Baojing, DOU Yanguang, LIAO Jing, et al. Spatial and temporal variabilities of northern and southern sandy-coast beach profiles on the eastern Shandong Peninsula [J]. Marine Sciences, 2018, 42(3): 53-62. doi: 10.11759/HYKX20170411002
[20] 朱士兵, 胡丹妮, 张会领, 等. 海口湾中间岸段海滩剖面短期时空变化及沉积动态分析[J]. 热带海洋学报, 2019, 38(5):77-85
ZHU Shibing, HU Danni, ZHANG Huiling, et al. Analysis of short-term temporal and spatial changes and sedimentary dynamics at the Middle section of Haikou Bay Beach [J]. Journal of Tropical Oceanography, 2019, 38(5): 77-85.
[21] 张学宏, 俞慕耕, 江伟, 等. 台湾周边海区的海浪特点[J]. 海洋预报, 2000, 17(1):75-83 doi: 10.3969/j.issn.1003-0239.2000.01.010
ZHANG Xuehong, YU Mugeng, JIANG Wei, et al. Characteristics of waves in the sea area around Taiwan [J]. Marine Forecasts, 2000, 17(1): 75-83. doi: 10.3969/j.issn.1003-0239.2000.01.010
[22] 张国友, 张绪东, 俞慕耕. 台湾海区的风浪特点及分布规律[J]. 海洋通报, 2002, 21(1):23-30 doi: 10.3969/j.issn.1001-6392.2002.01.004
ZHANG Guoyou, ZHANG Xudong, YU Mugeng. Characteristics and distribution pattern of wind and wave in sea area of Taiwan [J]. Marine Science Bulletin, 2002, 21(1): 23-30. doi: 10.3969/j.issn.1001-6392.2002.01.004
[23] 石谦, 蔡爱智. 厦门岛黄厝沙滩蚀退的原因与防护工程[J]. 台湾海峡, 2008, 27(1):92-98
SHI Qian, CAI Aizhi. Erosion factors and prevention engineering on Huangcuo beach of Xiamen Island [J]. Journal of Oceanography in Taiwan Strait, 2008, 27(1): 92-98.
[24] 雷刚, 刘根, 蔡锋. 厦门岛会展中心海滩养护及其对我国海岸防护的启示[J]. 应用海洋学学报, 2013, 32(3):305-315 doi: 10.3969/J.ISSN.2095-4972.2013.03.002
LEI Gang, LIU Gen, CAI Feng. Enlightenment to China's coastal protection from the coast beach nourishment at Huizhan Zhongxin of Xiamen Island [J]. Journal of Applied Oceanography, 2013, 32(3): 305-315. doi: 10.3969/J.ISSN.2095-4972.2013.03.002
[25] 夏非, 张永战, 吴蔚. EOF分析在海岸地貌与沉积学研究中的应用进展[J]. 地理科学进展, 2009, 28(2):174-186 doi: 10.11820/dlkxjz.2009.02.003
XIA Fei, ZHANG Yongzhan, WU Wei. Progress in applications of the EOF analysis in the research of coastal geomorphology and sedimentology [J]. Progress in Geography, 2009, 28(2): 174-186. doi: 10.11820/dlkxjz.2009.02.003
[26] Lemke L, Miller J K. EOF analysis of shoreline and beach slope variability at a feeder beach constructed within a groin field at Long Branch, New Jersey [J]. Coastal Engineering, 2017, 121: 14-25. doi: 10.1016/j.coastaleng.2016.11.001
[27] 戚洪帅, 蔡锋, 雷刚, 等. 华南海滩风暴响应特征研究[J]. 自然科学进展, 2009, 19(9):975-985 doi: 10.3321/j.issn:1002-008X.2009.09.011
QI Hongshuai, CAI Feng, LEI Gang, et al. Study on storm response characteristics of beaches in South China [J]. Progress in Natural Science, 2009, 19(9): 975-985. doi: 10.3321/j.issn:1002-008X.2009.09.011
[28] 陈吉余. 中国海岸侵蚀概要[M]. 北京: 海洋出版社, 2010: 3-9.
CHEN Jiyu. Overview of Coastal Erosion in China[M]. Beijing: China Ocean Press, 2010: 3-9.
[29] 王永红. 海岸动力地貌学: 海岸动力地貌学[M]. 北京: 科学出版社, 2012: 103-112.
WANG Yonghong. Coastal Dynamic Geomorphology[M]. Beijing: Science Press, 2012: 103-112.
[30] 陈坚, 蔡锋. 厦门岛东南部海岸演变与泥沙输移[J]. 台湾海峡, 2001, 20(2):135-141
CHEN Jian, CAI Feng. Coast evolution and sand transportation in East-southern Xiamen Island [J]. Journal of Oceanography in Taiwan Strait, 2001, 20(2): 135-141.
[31] Liu G, Cai F, Qi H S, et al. Morphodynamic evolution and adaptability of nourished beaches [J]. Journal of Coastal Research, 2019, 35(4): 737-750. doi: 10.2112/JCOASTRES-D-18-00037.1
[32] 蔡锋, 戚洪帅, 夏东兴. 华南海滩动力地貌过程[M]. 北京: 海洋出版社, 2008: 36-37.
CAI Feng, QI Hongshuai, XIA Dongxing. The Dynamic Geomorphological Process of the Beach in South China[M]. Beijing: China Ocean Press, 2008: 36-37.
[33] 朱君, 蔡锋, 戚洪帅, 等. 基于数值模拟的厦门湾波浪特征研究[J]. 应用海洋学学报, 2017, 36(3):341-348 doi: 10.3969/J.ISSN.2095-4972.2017.03.006
ZHU Jun, CAI Feng, QI Hongshuai, et al. A study on characteristics of Xiamen waves based on numerical simulation [J]. Journal of Applied Oceanography, 2017, 36(3): 341-348. doi: 10.3969/J.ISSN.2095-4972.2017.03.006
[34] 郑承忠, 翁宇斌, 杨顺良. 厦门岛东南岸沙滩近期剖面变化研究[J]. 热带海洋学报, 2005, 24(4):73-80 doi: 10.3969/j.issn.1009-5470.2005.04.011
ZHENG Chengzhong, WENG Yubin, YANG Shunliang. A study on recent changes of beach profiles along southeast shore of Xiamen Island, Fujian province, China [J]. Journal of Tropical Oceanography, 2005, 24(4): 73-80. doi: 10.3969/j.issn.1009-5470.2005.04.011
[35] Abessolo G O, Almar R, Jouanno J, et al. Beach adaptation to intraseasonal sea level changes [J]. Environmental Research Communications, 2020, 2(5): 051003. doi: 10.1088/2515-7620/ab8705
[36] 陈沈良, 张国安, 谷国传. 黄河三角洲海岸强侵蚀机理及治理对策[J]. 水利学报, 2004(7):1-6,13 doi: 10.3321/j.issn:0559-9350.2004.07.001
CHEN Shenliang, ZHANG Guoan, GU Guochuan. Mechanism of heavy coastal erosion on Yellow River delta and its countermeasures [J]. Journal of Hydraulic Engineering, 2004(7): 1-6,13. doi: 10.3321/j.issn:0559-9350.2004.07.001
[37] Miselis J L, Mcninch J E. Calculating shoreline erosion potential using nearshore stratigraphy and sediment volume: outer Banks, North Carolina [J]. Journal of Geophysical Research:Earth Surface, 2006, 111(F2): F02019.
[38] Burvingt O, Masselink G, Russell P, et al. Classification of beach response to extreme storms [J]. Geomorphology, 2017, 295: 722-737. doi: 10.1016/j.geomorph.2017.07.022
-
