Fault characteristics and hydrocarbon accumulation in the southern Lufeng Sag, Pearl River Mouth Basin
-
摘要:
陆丰凹陷是位于珠江口盆地珠I坳陷内的富烃凹陷，凹陷南部地区古近系具有良好勘探潜力。以三维地震资料解释成果和钻井资料为基础，分析陆丰凹陷南部地区断裂发育特征及演化过程，明确断裂对油气运聚成藏的控制作用，划分油气成藏组合类型。陆丰凹陷南部发育3个半地堑结构的洼陷，分别受活动性较强的3条铲式边界断裂控制。断裂主要发育于古近纪，斜坡带部位发育密度大，平面优势走向由深层NEE向至浅层近S-N向偏转，断裂密集带自东向西迁移。断裂可分为三级，分别控制洼陷结构、局部构造带和构造圈闭的形成。依据活动期次可划分出文昌期活动断层、恩平期活动断层和文昌-恩平期活动断层。陆丰凹陷南部地区断裂控制着断鼻、断块及断背斜圈闭的形成，断裂与烃源岩的组合类型差异影响着油气运聚效率。综合油气富集层系、输导方式、断裂活动性及源-断组合类型等成藏要素，建立源内自生自储型、源内自生上储型、源外旁生侧储型和源外下生上储型等4类油气成藏组合类型，对下一步油气勘探实践具有理论指导意义。
Abstract:The Lufeng Sag is a hydrocarbon-rich sag located in Zhu I depression of the Pearl River Mouth Basin, and the Paleocene in the southern sag has good exploration potential. Based on the 3D seismic data interpretation and drilling data, we analyzed the characteristics of fault deformation and evolution in the southern Lufeng Sag, and the controls of faults on hydrocarbon transport and accumulation. In addition, the types of hydrocarbon combinations were classified. Three half-grabens in the southern Lufeng Sag were controlled by three listric boundary faults with strong activity. The faults were mainly developed during the Paleogene. The distribution density of faults is the highest in the slope zones, and the dominant trends changes from NEE to nearly SN upwards. Also, the dense zone of faults migrates from east to west. The faults can be divided into hierarchical classes 1 to 3, Class 1 the formation of sags, Class 2 determines local structural belts, and Class 3 restrains structural traps. The faults in the southern Lufeng Sag were active during the deposition periods of the Wenchang Formation, the Enping Formation, and the Wenchang-Enping Formations. The faults control the formation of fault noses, fault blocks, and fault anticlinal traps, and the difference in combination models of faults and source rocks affects the efficiency of hydrocarbon migration and accumulation. Based on the hydrocarbon accumulation factors such as enrichment strata, transportation models, fault activity, and source-faults combination types, four hydrocarbon accumulation models were established: in-source autogenous self-storage, in-source autogenous up-storage, out-source side-storage and out-source down-storage This study provided a theoretical support for further oil and gas exploration in the southern Lufeng Sag.
-
Key words:
- fault /
- trap /
- source rock-fault assemblage /
- hydrocarbon accumulation /
- Paleogene /
- southern Lufeng Sag
-
-
[1] Liang J T, Wang H L, Blum M J, et al. Modeling of hydrocarbon migration and accumulation on the Chengzikou uplift, Bohai Bay Basin, China: implications for petroleum exploration on slope belts in rift basins [J]. Journal of Petroleum Science and Engineering, 2020, 189: 106963. doi: 10.1016/j.petrol.2020.106963
[2] Vatandoust M, Faghih A, Asadi S, et al. Study of hydrocarbon generation and 1D-2D modeling of hydrocarbon migration at the Karanj and Parsi oilfields, Southern Dezful Embayment, SW Iran [J]. Marine and Petroleum Geology, 2020, 113: 104095. doi: 10.1016/j.marpetgeo.2019.104095
[3] 徐长贵, 彭靖淞, 吴庆勋, 等. 渤海湾凹陷区复杂断裂带垂向优势运移通道及油气运移模拟[J]. 石油勘探与开发, 2019, 46(4):684-692 doi: 10.11698/PED.2019.04.06
XU Changgui, PENG Jingsong, WU Qingxun, et al. Vertical dominant migration channel and hydrocarbon migration in complex fault zone, Bohai Bay sag, China [J]. Petroleum Exploration and Development, 2019, 46(4): 684-692. doi: 10.11698/PED.2019.04.06
[4] Eng C, Tsuji T. Influence of faults and slumping on hydrocarbon migration inferred from 3D seismic attributes: Sanriku-Oki forearc basin, northeast Japan [J]. Marine and Petroleum Geology, 2019, 99: 175-189. doi: 10.1016/j.marpetgeo.2018.10.013
[5] 余一欣, 周心怀, 徐长贵, 等. 渤海海域断裂相互作用及其油气地质意义[J]. 石油与天然气地质, 2018, 39(1):11-19 doi: 10.11743/ogg20180102
YU Yixin, ZHOU Xinhuai, XU Changgui, et al. Fault interactions and their significances for hydrocarbon accumulation in offshore Bohai Bay Basin, eastern China [J]. Oil & Gas Geology, 2018, 39(1): 11-19. doi: 10.11743/ogg20180102
[6] Chen Y B, Cheng X G, Zhang H, et al. Fault characteristics and control on hydrocarbon accumulation of middle-shallow layers in the slope zone of Mahu sag, Junggar Basin, NW China [J]. Petroleum Exploration and Development, 2018, 45(6): 1050-1060. doi: 10.1016/S1876-3804(18)30108-3
[7] Xu S, Hao F, Xu C G, et al. Oil migration through preferential petroleum migration pathway (PPMP) and polycyclic faults: a case study from the Shijiutuo Uplift, Bohai Bay basin, China [J]. Marine and Petroleum Geology, 2016, 73: 539-553. doi: 10.1016/j.marpetgeo.2016.03.025
[8] 杨长清, 孙晶, 杨传胜, 等. 东海盆地南部中生界油气成藏模式[J]. 海洋地质前沿, 2021, 37(8):89-92
YANG Changqing, SUN Jing, YANG Chuansheng, et al. The Mesozoic hydrocarbon accumulation model in the southern East China Sea Basin [J]. Marine Geology Frontiers, 2021, 37(8): 89-92.
[9] 刘建, 谢睿, 徐敏, 等. 东海西部台北坳陷中生界油气成藏模式研究[J]. 海洋地质与第四纪地质, 2019, 39(6):150-158
LIU Jian, XIE Rui, XU Min, et al. Hydrocarbon accumulation model of the Mesozoic in Taibei Depression, western East China Sea [J]. Marine Geology & Quaternary Geology, 2019, 39(6): 150-158.
[10] 丁亮. 陆丰凹陷西南部文昌组资源潜力及油气成藏主控因素分析[J]. 长江大学学报: 自然科学版, 2021, 18(4):46-56
DING Liang. Resource potential and main controlling factors of hydrocarbon accumulation of Wenchang Formation in southwest Lufeng Sag [J]. Journal of Yangtze University (Natural Science Edition), 2021, 18(4): 46-56.
[11] 柳广弟, 牛子铖, 陈哲龙, 等. 珠江口盆地陆丰凹陷在洼陷迁移控制下的油气成藏规律[J]. 石油学报, 2019, 40(S1):26-40,216
LIU Guangdi, NIU Zicheng, CHEN Zhelong, et al. Hydrocarbon accumulation patterns controlled by the migrated subsags in Lufeng Sag, Pearl River Mouth Basin [J]. Acta Petrolei Sinica, 2019, 40(S1): 26-40,216.
[12] 米立军, 张向涛, 陈维涛, 等. 珠江口盆地珠一坳陷古近系油气富集规律及下一步勘探策略[J]. 中国海上油气, 2018, 30(6):1-13
MI Lijun, ZHANG Xiangtao, CHEN Weitao, et al. Hydrocarbon enrichment law of Paleogene Zhu1 depression and its next exploration strategy in Pearl River Mouth basin [J]. China Offshore Oil and Gas, 2018, 30(6): 1-13.
[13] 高阳东, 林鹤鸣, 汪旭东, 等. 珠江口盆地陆丰凹陷文昌组沉积地球化学特征及古环境意义[J]. 现代地质, 2022, 36(1):118-129 doi: 10.19657/j.geoscience.1000-8527.2021.198
GAO Yangdong, LIN Heming, WANG Xudong, et al. Geochemical constraints on the sedimentary environment of Wenchang formation in pearl river mouth basin and its paleoenvironmental implications [J]. Geoscience, 2022, 36(1): 118-129. doi: 10.19657/j.geoscience.1000-8527.2021.198
[14] 杨超群, 雷永昌, 邱欣卫, 等. 珠江口盆地陆丰凹陷A油田断层封堵性综合评价[J]. 海洋地质前沿, 2021, 37(2):54-61
YANG Chaoqun, LEI Yongchang, QIU Xinwei, et al. An integrated assessment of fault sealing for oilfield a in Lufeng Sag of Pearl River Mouth Basin [J]. Marine Geology Frontiers, 2021, 37(2): 54-61.
[15] 代一丁, 牛子铖, 汪旭东, 等. 珠江口盆地陆丰凹陷古近系与新近系油气富集规律的差异及其主控因素[J]. 石油学报, 2019, 40(S1):41-52
DAI Yiding, NIU Zicheng, WANG Xudong, et al. Differences of hydrocarbon enrichment regularities and their main controlling factors between Paleogene and Neogene in Lufeng Sag, Pearl River Mouth Basin [J]. Acta Petrolei Sinica, 2019, 40(S1): 41-52.
[16] 朱筱敏, 葛家旺, 吴陈冰洁, 等. 珠江口盆地陆丰凹陷深层砂岩储层特征及主控因素[J]. 石油学报, 2019, 40(S1):69-80
ZHU Xiaomin, GE Jiawang, WU Chenbingjie, et al. Reservoir characteristics and main controlling factors of deep sandstone in Lufeng Sag, Pearl River Mouth Basin [J]. Acta Petrolei Sinica, 2019, 40(S1): 69-80.
[17] 葛家旺, 朱筱敏, 张向涛, 等. 珠江口盆地陆丰凹陷文昌组构造-沉积演化模式[J]. 中国矿业大学学报, 2018, 47(2):308-322
GE Jiawang, ZHU Xiaomin, ZHANG Xiangtao, et al. Tectono-sedimentation model of the Eocene Wenchang formation in the Lufeng depression, Pearl River Mouth basin [J]. Journal of China University of Mining & Technology, 2018, 47(2): 308-322.
[18] 于福生, 汪旭东, 邱欣卫, 等. 珠江口盆地陆丰凹陷断裂构造特征及“人”字型构造成因[J]. 石油学报, 2019, 40(S1):166-177 doi: 10.7623/syxb2019S1014
YU Fusheng, WANG Xudong, QIU Xinwei, et al. Characteristics of fault structure and the genesis of herringbone structure in Lufeng Sag, Pearl River Mouth Basin [J]. Acta Petrolei Sinica, 2019, 40(S1): 166-177. doi: 10.7623/syxb2019S1014
[19] 朱明, 张向涛, 黄玉平, 等. 珠江口盆地烃源岩特征及资源潜力[J]. 石油学报, 2019, 40(S1):53-68 doi: 10.7623/syxb2019S1005
ZHU Ming, ZHANG Xiangtao, HUANG Yuping, et al. Source rock characteristics and resource potential in Pearl River Mouth Basin [J]. Acta Petrolei Sinica, 2019, 40(S1): 53-68. doi: 10.7623/syxb2019S1005
[20] 蒋德鑫, 姜正龙, 张贺, 等. 烃源岩总有机碳含量测井预测模型探讨: 以陆丰凹陷文昌组为例[J]. 岩性油气藏, 2019, 31(6):109-117
JIANG Dexin, JIANG Zhenglong, ZHANG He, et al. Well logging prediction models of TOC content in source rocks: a case of Wenchang Formation in Lufeng Sag [J]. Lithologic Reservoirs, 2019, 31(6): 109-117.
[21] 施和生. 油气勘探“源-汇-聚”评价体系及其应用: 以珠江口盆地珠一坳陷为例[J]. 中国海上油气, 2015, 27(5):1-12
SHI Hesheng. “Source-migration-accumulation” evaluation system and its application in hydrocarbon exploration: a case study of Zhu I depression in Pearl River Mouth basin [J]. China Offshore Oil and Gas, 2015, 27(5): 1-12.
[22] 于汪, 郭建华, 刘辰生, 等. 珠江口盆地AB凹陷古近系文昌组资源量估算及勘探方向[J]. 地质科技情报, 2015, 34(4):132-138
YU Wang, GUO Jianhua, LIU Chensheng, et al. Estimation of Paleogene Wenchang Formation resources and exploration direction in AB Depression, Pearl River Mouth Basin [J]. Geological Science and Technology Information, 2015, 34(4): 132-138.
[23] 叶青. 南海北部陆缘晚中生代构造体系: 动力学以及对珠江口盆地新生代构造的制约[D]. 中国地质大学博士学位论文, 2019
YE Qing. The late mesozoic structure systems in the northern South China Sea margin: geodynamics and their influence on the cenozoic structures in the Pearl River Mouth Basin[D]. Doctor Dissertation of China University of Geosciences, 2019.
[24] Ye Q, Mei L F, Shi H S, et al. The Late Cretaceous tectonic evolution of the South China Sea area: an overview, and new perspectives from 3D seismic reflection data [J]. Earth-Science Reviews, 2018, 187: 186-204. doi: 10.1016/j.earscirev.2018.09.013
[25] Ryan L, Magee C, Jackson C A L. The kinematics of normal faults in the Ceduna Subbasin, offshore southern Australia: implications for hydrocarbon trapping in a frontier basin [J]. AAPG Bulletin, 2017, 101(3): 321-341. doi: 10.1306/08051615234
[26] 唐旭, 孙永河, 胡慧婷, 等. 苏北盆地高邮凹陷古近系阜宁组断层形成过程及其砂箱物理模拟[J]. 石油与天然气地质, 2021, 42(2):469-480
TANG Xu, SUN Yonghe, HU Huiting, et al. Fault development and its analogue modeling in the Paleogene Funing Formation in Gaoyou Sag, Subei Basin [J]. Oil & Gas Geology, 2021, 42(2): 469-480.
[27] 孙永河, 李雪松, 刘志达, 等. 尼日尔三角洲东部斜向背斜形成演化特征[J]. 石油勘探与开发, 2018, 45(1):51-61
SUN Yonghe, LI Xuesong, LIU Zhida, et al. Formation and evolution of oblique anticline in eastern Niger Delta [J]. Petroleum Exploration and Development, 2018, 45(1): 51-61.
[28] 刘晓凤, 曾溅辉, 张忠涛, 等. 白云凹陷东部A井区油气输导体系及其控藏作用[J]. 地球物理学进展, 2019, 34(3):1061-1073
LIU Xiaofeng, ZENG Jianhui, ZHANG Zhongtao, et al. Hydrocarbon pathway systems and their control on hydrocarbon migration and accumulation in A area, eastern Baiyun Sag [J]. Progress in Geophysics, 2019, 34(3): 1061-1073.
[29] 付晓飞, 许鹏, 魏长柱, 等. 张性断裂带内部结构特征及油气运移和保存研究[J]. 地学前缘, 2012, 19(6):200-212
FU Xiaofei, XU Peng, WEI Changzhu, et al. Internal structure of normal fault zone and hydrocarbon migration and conservation [J]. Earth Science Frontiers, 2012, 19(6): 200-212.
[30] 褚榕, 刘海涛, 王海学, 等. 不同类型断层控制油气垂向富集的差异: 以渤海湾盆地歧口凹陷歧南斜坡区为例[J]. 石油学报, 2019, 40(8):928-940 doi: 10.7623/syxb201908004
CHU Rong, LIU Haitao, WANG Haixue, et al. Differences of vertical hydrocarbon enrichment controlled by different types of faults: a case study of Qi'nan slope of Qikou depression, Bohai Bay Basin [J]. Acta Petrolei Sinica, 2019, 40(8): 928-940. doi: 10.7623/syxb201908004
[31] 彭光荣, 庞雄奇, 徐帜, 等. 珠江口盆地陆丰南地区古近系全油气系统特征与油气藏有序分布[J]. 地球科学, 2022, 47(7):2494-2508
PENG Guangrong, PANG Xiongqi, XU Zhi, et al. Characteristics of paleogene whole petroleum system and orderly distribution of oil and gas reservoirs in South Lufeng depression, Pearl River Mouth Basin [J]. Earth Science, 2022, 47(7): 2494-2508.
-
