黄河三角洲刁口叶瓣堆积过程

邢吕阳; 李广雪; 刘思雨; 李浩楠; 潘煜峰

doi:10.16562/j.cnki.0256-1492.2023040901

黄河三角洲刁口叶瓣堆积过程

1.
中国海洋大学海底科学与探测技术教育部重点实验室，青岛 266100

2.
中国海洋大学未来海洋学院，青岛 266100

基金项目: 国家自然科学基金创新群体项目“海底古地貌动态重建”(42121005)

详细信息

作者简介: 邢吕阳（1997—），男，硕士研究生，主要从事海洋沉积学研究，E-mail：21200411610@stu.ouc.edu.cn

通讯作者: 李广雪（1962—），男，教授，主要从事海洋地质研究，E-mail：gxli1962@163.com

中图分类号: P736.21

收稿日期: 2023-04-09

修回日期: 2023-04-21

录用日期: 2023-04-21

刊出日期: 2023-08-28

Formation of the Diaokou Lobe in Yellow River Delta

1.
Key Lab of Submarine Geosciences and Prospecting Techniques, Ocean University of China, Qingdao 266100, China

2.
Academy of the Future Ocean, Ocean University of China, Qingdao 266100, China

More Information

Corresponding author: LI Guangxue, gxli1962@163.com

Received Date: 09 April 2023

Revised Date: 21 April 2023

Accepted Date: 21 April 2023

Publish Date: 28 August 2023

摘要

摘要:
黄河三角洲刁口叶瓣于1964—1976年间堆积而成，中国大型滩浅海油田—埕岛油田在这个叶瓣上建设开发，该叶瓣的形成过程与地层结构对海洋工程建设影响较大。根据多年历史测深资料，研究了刁口叶瓣形成期间河口摆动与堆积体演变过程，依据堆积中心的位置变化明确了古河口摆动规律。1964—1966年河口及堆积体在叶瓣西侧发育，在柯氏力作用下，河口逐渐NNE向摆动，堆积中心移动到叶瓣东侧；1975—1976年，由于河道摆动曲率过大引发失稳，河道取直后堆积中心又回到叶瓣西侧。根据堆积速率和河口位置将形成期分为3个阶段：近岸堆积阶段（1964—1966年）、整体堆积阶段（1966—1975年）和调整堆积阶段（1975—1976年）。受黄河海港附近M₂无潮点影响下的强潮流场控制，刁口叶瓣东侧在形成早期和末期存在局部冲刷作用，而叶瓣西侧是三角洲形成期堆积最活跃的区域。
- 堆积中心 /
- 河口摆动 /
- 刁口叶瓣 /
- 黄河三角洲
Abstract:
The Diaokou Lobe in Yellow River Delta was formed from 1964 to 1976 under human intervention at the beginning, on which the Chengdao Oilfield, a large beach shallow-sea oil field in China, was constructed and developed. The formation and stratum structure of the lobe have a great impact on marine construction of the oil field. Therefore, the multiple historical sounding data were collected and analyzed, from which the process of estuarine oscillation and sedimentation evolution during the formation of the Diaokou Lobe were anatomized. Based on the changes in the position of the sedimentation center, the estuarine oscillation pattern of the lobe in the past was clarified. From 1964 to 1966, estuary deposits were developed in the west flank of the lobe. Under the Coriolis force, the river mouth gradually moved towards NNE and the sedimentation center moved to the east of the lobe. From 1975 to 1976, due to the instability resulted from excessive swing curvature of river channel, the river channel was cut straight artificially, and afterward the sedimentation center returned to the west side of the lobe. The lobe formation could be divided into three stages based on the accumulation rate and river mouth position: nearshore accumulation (1964—1966), overall accumulation (1966—1975), and adjusting accumulation (1975—1976). Controlled by the strong tidal flow field by the M₂ tidal point near the Yellow River Seaport, local erosion took place on the eastern flank of the Diaokou Lobe in the early and late stages of the lobe formation period, while the western flank of the lobe was the most active accumulation area in the delta during the lobe formation.
- sedimentation center /
- river mouth shifting /
- Diaokou Lobe /
- Yellow River delta

HTML全文

图 1 黄河三角洲研究选区

Figure 1.

下载: 全尺寸图片幻灯片

图 2 黄河利津水文站逐月平均水沙量占全年的百分比

Figure 2.

下载: 全尺寸图片幻灯片

图 3 刁口叶瓣岸线与河道演化

Figure 3.

下载: 全尺寸图片幻灯片

图 4 固定点水深变化

Figure 4.

下载: 全尺寸图片幻灯片

图 5 刁口叶瓣堆积体厚度变化

Figure 5.

下载: 全尺寸图片幻灯片

表 1 刁口叶瓣形成期造陆统计

Table 1. Statistics of epeirogeny during the formation of the Diaokou Lobe

参数	1964年汛期	1965—1968 年	1968—1972 年	1972—1976 年
造陆速度/(km²/a)	157.20	54.70	26.28	31.33
年输沙量/(10⁸t/a)	19.00	13.48	7.23	9.74
造陆效率λ/(km²/10⁸t)	8.27	4.06	3.63	3.22

下载: 导出CSV

表 2 刁口叶瓣形成期堆积统计

Table 2. Statistics of accumulation in the Diaokou Lobe formatin

参数	近岸堆积	整体堆积	调整堆积
堆积比例Δ_max/(10⁸t·m⁻¹·a⁻¹)	2.51	0.85	1.72
堆积速度/(10⁸m³/a)	5.50	3.40	3.45
输沙量/(10⁸t/a)	13.38	10.19	8.62
含沙量/(kg/m³)	23.71	27.50	20.24
堆积效率γ/%	30.14	36.70	44.03

下载: 导出CSV

参考文献(20)

[1]	Wright L D, Wiseman W J, Yang Z S, et al. Processes of marine dispersal and deposition of suspended silts off the modern mouth of the Huanghe (Yellow River) [J]. Continental Shelf Research, 1990, 10(1): 1-40. doi: 10.1016/0278-4343(90)90033-I
[2]	陈小英, 陈沈良, 李九发, 等. 黄河三角洲孤东及新滩海岸侵蚀机制研究[J]. 海岸工程, 2005, 24(4):1-10 CHEN Xiaoying, CHEN Shenliang, LI Jiufa, et al. Study on the coastal erosion mechanism in the Yellow River Delta Gudong and Xintan Areas [J]. Coastal Engineering, 2005, 24(4): 1-10.
[3]	Wright L D, Wiseman W J, Bornhold B D, et al. Marine dispersal and deposition of Yellow River silts by gravity-driven underflows [J]. Nature, 1988, 332(6165): 629-632. doi: 10.1038/332629a0
[4]	李广雪, 成国栋, 魏合龙, 等. 现代黄河口区流场切变带[J]. 科学通报, 1994, 39(10):928-932 doi: 10.1360/csb1994-39-10-928 LI Guangxue, CHENG Guodong, WEI Helong, et al. Flow shear zone in the modern Yellow River mouth region [J]. Chinese Science Bulletin, 1994, 39(10): 928-932. doi: 10.1360/csb1994-39-10-928
[5]	时连强, 李九发, 应铭, 等. 近、现代黄河三角洲发育演变及沉积过程研究综述[C]//第八届全国海岸河口学术研讨会暨海岸河口理事会议论文摘要集. 上海: 中国海洋学会, 2004: 68 SHI Lianqiang, LI Jiufa, YING Ming, et al. A review of recent studies on the development, evolution and sedimentary process of Yellow River Delta[C]//Proceedings of the 8th National Coastal and Estuarine Academic Seminar and Coastal and Estuarine Council Meeting. Shanghai: Chinese Society of Oceanography, 2004: 68.
[6]	杨作升, 李国刚, 王厚杰, 等. 55年来黄河下游逐日水沙过程变化及其对干流建库的响应[J]. 海洋地质与第四纪地质, 2008, 28(6):9-18 YANG Zuosheng, LI Guogang, WANG Houjie, et al. Variation of daily water and sediment discharge in the Yellow River lower reaches in the past 55 years and its response to the dam operation on its main stream [J]. Marine Geology & Quaternary Geology, 2008, 28(6): 9-18.
[7]	胡春宏, 陈绪坚, 陈建国. 黄河水沙空间分布及其变化过程研究[J]. 水利学报, 2008, 39(5):518-527 doi: 10.3321/j.issn:0559-9350.2008.05.002 HU Chunhong, CHEN Xujian, CHEN Jianguo. Spatial distribution and its variation process of sedimentation in Yellow River [J]. Journal of Water Resources, 2008, 39(5): 518-527. doi: 10.3321/j.issn:0559-9350.2008.05.002
[8]	凡姚申. 黄河三角洲近岸海床侵蚀过程及其动力机制[D]. 华东师范大学博士学位论文, 2019 FAN Yaoshen. Seabed erosion and its mechanism in the littoral area of Yellow River Delta[D]. Doctor Dissertation of East China Normal University, 2019.
[9]	李安龙, 李广雪, 曹立华, 等. 黄河三角洲废弃叶瓣海岸侵蚀与岸线演化[J]. 地理学报, 2004, 59(5):731-737 LI Anlong, LI Guangxue, CAO Lihua, et al. The coast erosion and evolution of the abandoned lobe of the Yellow River Delta [J]. Acta Geographica Sinica, 2004, 59(5): 731-737.
[10]	刘玲, 李广雪, 李季. 黄河三角洲钓口叶瓣河道与岸线演化分析[J]. 海洋地质前沿, 2013, 29(6):1-6 doi: 10.16028/j.1009-2722.2013.06.009 LIU Ling, LI Guangxue, LI Ji. Evolution of river channel and shoreline of the Diaokou lobe of Yellow River delta [J]. Marine Geology Frontiers, 2013, 29(6): 1-6. doi: 10.16028/j.1009-2722.2013.06.009
[11]	刘鹏, 王庆, 战超, 等. 基于DSAS和FA的1959—2002年黄河三角洲海岸线演变规律及影响因素研究[J]. 海洋与湖沼, 2015, 46(3):585-594 LIU Peng, WANG Qing, ZHAN Chao, et al. Quantitative analysis of coastline change in the Yellow River Delta from 1959 to 2002 [J]. Oceanologia et Limnologia Sinica, 2015, 46(3): 585-594.
[12]	高伟. 现代黄河三角洲钓口叶瓣地层层序研究[D]. 中国海洋大学博士学位论文, 2011 GAO Wei. Stratigraphy sequence of Diaokou lobe in the Modern Yellow River Delta[D]. Doctor Dissertation of Ocean University of China, 2011.
[13]	庞家珍. 黄河三角洲流路演变及对黄河下游的影响[J]. 海洋湖沼通报, 1994(3):1-9 PANG Jiazhen. Fluvial process on the Huanghe River Delta and its influence on lower reaches [J]. Transactions of Oceanology and Limnology, 1994(3): 1-9.
[14]	李广雪, 薛春汀. 黄河水下三角洲沉积厚度、沉积速率及砂体形态[J]. 海洋地质与第四纪地质, 1993, 13(4):35-44 doi: 10.16562/j.cnki.0256-1492.1993.04.004 LI Guangxue, XUE Chunting. Sediment thickness, sedimentation rate, and silt body shape of the Yellow River subaqueous delta lobe [J]. Marine Geology & Quaternary Geology, 1993, 13(4): 35-44. doi: 10.16562/j.cnki.0256-1492.1993.04.004
[15]	成国栋, 薛春汀. 黄河三角洲沉积地质学[M]. 北京: 地质出版社, 1997 CHENG Guodong, XUE Chunting. Sedimentary Geology of Yellow River Delta[M]. Beijing: Geology Press, 1997.
[16]	何孝海. 黄河三角洲动力沉积及冲淤演变研究[D]. 中国海洋大学硕士学位论文, 2006 HE Xiaohai. Study on dynamic sedimentation and Erosion-deposition evolution of Yellow River Delta[D]. Master Dissertation of Ocean University of China, 2006.
[17]	王厚杰, 原晓军, 王燕, 等. 现代黄河三角洲废弃神仙沟-钓口叶瓣的演化及其动力机制[J]. 泥沙研究, 2010(4):51-60 doi: 10.16239/j.cnki.0468-155x.2010.04.009 WANG Houjie, YUAN Xiaojun, WANG Yan, et al. Evolution of the abandoned Shenxiangou-Diaokou delta lobe: processes and mechanism [J]. Journal of Sediment Research, 2010(4): 51-60. doi: 10.16239/j.cnki.0468-155x.2010.04.009
[18]	刘勇, 李广雪, 邓声贵, 等. 黄河废弃三角洲海底冲淤演变规律研究[J]. 海洋地质与第四纪地质, 2002, 22(3):27-34 doi: 10.16562/j.cnki.0256-1492.2002.03.004 LIU Yong, LI Guangxue, DENG Shenggui, et al. Evolution of erosion and accumulation in the abandoned subaqueous delta lobe of the Yellow River [J]. Marine Geology & Quaternary Geology, 2002, 22(3): 27-34. doi: 10.16562/j.cnki.0256-1492.2002.03.004
[19]	Zhang M W, Dong Q, Cui T W, et al. Suspended sediment monitoring and assessment for Yellow River estuary from Landsat TM and ETM + imagery [J]. Remote Sensing of Environment, 2014, 146: 136-147. doi: 10.1016/j.rse.2013.09.033
[20]	Li G X, Wei H L, Yue S H, et al. Sedimentation in the Yellow River delta, part II: suspended sediment dispersal and deposition on the subaqueous delta [J]. Marine Geology, 1998, 149(1-4): 113-131. doi: 10.1016/S0025-3227(98)00032-2
