Research Progress on Recovery of Scandium from Vanadium Titano- Magnetite in Panzhihua
-
摘要:
综述了攀枝花钒钛磁铁矿中钪以类质同象置换Mg-Fe的方式存在，储量丰富，潜在回收价值可观。以尾矿、废渣和废液为主要回收对象，总结了提取钪工艺以焙烧-浸出-萃取法和浸出-萃取法为主。提出以钛白废酸浸出选钛尾矿和氯化渣及烟尘全面回收钪的新途径；为攀枝花“三废”治理提供新的思路。
Abstract:Review on the occurrence state of scandium in Panzhihua vanadium titano- magnetite showed as Mg-Fe isomorphism, rich reserves and the recovery of considerable potential value. Taking tailings, waste residue and waste liquid as the main recycled subject, summarized the main technology of Extracting Scandium by roasting leaching extraction and leaching extraction. Presented new ways for comprehensive extraction of scandium from titanium tailings, chlorinated slag and dust by titanium white waste acid leaching. Providing new ideas for treatment of "three wastes" in Panzhihua.
-
Key words:
- Scandium /
- Leaching /
- Vanadium titano- magnetite /
- Titanium tailings
-
-
表 1 含钪矿物
Table 1. Scandium among the various types of minerals
名称 含量/% 钪含量/（g·t−1） 钪分布率/% 主要成分 普通辉石 30.58 128 60.0 SiO2 Fe2O3 MgO 钛铁矿
钛磁铁矿15.68
18.30101
24.215.09
6.30Fe2O3 TiO2
Fe2O3 TiO2角闪石 6.50 38.2 6.70 SiO2 CaO 斜长石 5.10 2.0 0.15 SiO2 Al2O3 绿泥石及其他 20.00 15.0 11.80 SiO2 CaO Fe2O3 Al2O3
下载: 导出CSV
表 2 钪在三废中含量
Table 2. scandium content in three wastes
名称 高炉渣 高炉瓦斯泥 氯化渣 钒渣 氯化烟尘 硫酸废液 尾矿 含量/（g·t−1） 34 12.8 65.8 3.3 384 80.8 128.3 存在形态 Sc2O3 Sc2O3 Sc2O3 Sc2O3 ScCl3 Sc3+ 辉石、钛铁矿和角闪石
下载: 导出CSV
-
[1] 赵芝, 王登红, 张国华, 等. 钪-稀散家族中的稀土家族中的贵族[J]. 国土资源科普与文化, 2019(3):15-17.
ZHAO Z, WANG D H, ZHANG G H, et al. The nobles in the rare earth family in the scandium-sparse family[J]. Popular Science and Culture of Land and Resources, 2019(3):15-17.
[2] 王勋, 韩跃新, 李艳军, 等. 钒钛磁铁矿综合利用研究现状[J]. 金属矿山, 2019(6):33-37. doi: 10.19614/j.cnki.jsks.201906006
WANG X, HAN Y X, LI Y J, et al. Research status of comprehensive utilization of vanadium titanomagnetite[J]. Metal Mines, 2019(6):33-37. doi: 10.19614/j.cnki.jsks.201906006
[3] 谭其尤, 陈波, 张裕书, 等. 攀西地区钒钛磁铁矿资源特点与综合回收利用现状[J]. 矿产综合利用, 2011(6):6-10. doi: 10.3969/j.issn.1000-6532.2011.06.002
TAN Q Y, CHEN B, ZHANG Y S, et al. The characteristics of vanadium titanomagnetite resources and the status quo of comprehensive recovery and utilization in Panxi area[J]. Multipurpose Utilization of Mineral Resources, 2011(6):6-10. doi: 10.3969/j.issn.1000-6532.2011.06.002
[4] 陈露露. 我国钒钛磁铁矿资源利用现状[J]. 中国资源综合利用, 2015, 33(10):31-33. doi: 10.3969/j.issn.1008-9500.2015.10.014
CHEN L L. Current situation of vanadium titanomagnetite resource utilization in my country[J]. China Comprehensive Utilization of Resources, 2015, 33(10):31-33. doi: 10.3969/j.issn.1008-9500.2015.10.014
[5] 黄霞光, 罗国清, 李亚平. 攀西钒钛磁铁矿中钪的赋存状态研究[J]. 有色金属(选矿部分), 2016(6):1-4.
HUANG X G, LUO G Q, LI Y P. Study on the Occurrence State of Scandium in Panxi Vanadium-Titanium Magnetite[J]. Nonferrous Metals (Processing Section), 2016(6):1-4.
[6] 柯家骏. 攀枝花矿中钪在选冶流程中的走向和冶炼提取的研究[J]. 钢铁钒钛, 1982(4):1-10. doi: 10.7513/j.issn.1004-7638.1982.04.001
KE J J. Research on the trend and smelting extraction of scandium in the beneficiation and smelting process in Panzhihua Mine[J]. Iron, Steel, Vanadium and Titanium, 1982(4):1-10. doi: 10.7513/j.issn.1004-7638.1982.04.001
[7] 吕宪俊, 程希翱, 周国华. 攀枝花铁矿钪的分布特征及其综合回收研究[J]. 西安建筑科技大学学报(自然科学版), 1991(4):460-466. doi: 10.15986/j.1006-7930.1991.04.004
LV X J, CHENG X A, ZHOU G H. Study on the distribution characteristics of scandium in Panzhihua iron ore and its comprehensive recovery[J]. Journal of Xi'an University of Architecture and Technology(Natural Science Edition), 1991(4):460-466. doi: 10.15986/j.1006-7930.1991.04.004
[8] 徐本平. 攀枝花钒钛磁铁矿冶炼过程中主要稀散元素分布走向研究[J]. 材料与冶金学报, 2018, 17(2):94-100. doi: 10.14186/j.cnki.1671-6620.2018.02.003
XU B P. Research on the distribution trend of main scattered elements in the smelting process of Panzhihua vanadium titanomagnetite[J]. Chinese Journal of Materials and Metallurgy, 2018, 17(2):94-100. doi: 10.14186/j.cnki.1671-6620.2018.02.003
[9] 柯家骏, 陆正亚, 涂桃枝, 等. 从钛氯化烟尘中提取氧化钪的研究[J]. 稀有金属, 1983(2):1-6.
KE J J, LU Z Y, TU T Z, et al. Study on extraction of scandium oxide from titanium chloride fume[J]. Rare Metals, 1983(2):1-6.
[10] 许绍权. 关于钪提取工艺的研究[J]. 广西大学学报(自然科学版), 1984(2):24-30.
XU S Q. Research on scandium extraction technology[J]. Journal of Guangxi University (Natural Science Edition), 1984(2):24-30.
[11] 孙本良, 田彦文, 翟玉春, 等. 从含钪氯化烟尘中提取钪[J]. 东北大学学报(自然科学), 1997, 18(6):606-609.
SUN B L, TIAN Y W, ZHAI Y C, et al. Extraction of scandium from chlorinated smoke containing scandium[J]. Journal of Northeastern University (Natural Science), 1997, 18(6):606-609.
[12] 杨智发, 孙世清, 李道纯. 溶剂萃取法从氯化烟尘中提取钪[J]. 稀有金属, 1989(3):217-222. doi: 10.13373/j.cnki.cjrm.1989.03.002
YANG Z F, SUN S Q, LI D C. Extraction of scandium from chlorinated fume by solvent extraction[J]. Rare Metals, 1989(3):217-222. doi: 10.13373/j.cnki.cjrm.1989.03.002
[13] 何锦林, 谭红, 蔡汝义, 等. 冶炼钛氯化烟尘提取钪的工艺研究[J]. 稀土, 1989(6):59-61. doi: 10.16533/j.cnki.15-1099/tf.1989.06.014
HE J L, TAN H, CAI R Y, et al. Study on the technology of extracting scandium from smelting titanium chloride fume[J]. Rare Earth, 1989(6):59-61. doi: 10.16533/j.cnki.15-1099/tf.1989.06.014
[14] 李亮. 从氯化渣中浸出钪的研究[J]. 钢铁钒钛, 2011, 32(2):15-19. doi: 10.7513/j.issn.1004-7638.2011.02.004
LI L. Study on leaching scandium from chloride slag[J]. Iron and Steel Vanadium Titanium, 2011, 32(2):15-19. doi: 10.7513/j.issn.1004-7638.2011.02.004
[15] Liu Songli. Experimental study of leaching scandium from chloride dust[J]. Advanced Materials Research, 2012, 548:305-308. doi: 10.4028/www.scientific.net/AMR.548.305
[16] 何永富, 卢保琦, 洪同治, 等. 从钛白水解母液中回收氧化钪试验[J]. 矿产综合利用, 1983(3):1-6.
HE Y F, LU B Q, HONG T Z, et al. Experiment of recovering scandium oxide from titanium dioxide hydrolysis mother liquor[J]. Multipurpose Utilization of Mineral Resources, 1983(3):1-6.
[17] 聂利, 李道纯, 李伟宣. 从钛白厂废酸中萃取回收钪的研究[J]. 矿冶工程, 1991(2):53-56+60.
NIE L, LI D C, LI W X. Study on extraction and recovery of scandium from waste acid in titanium dioxide plant[J]. Mining and Metallurgical Engineering, 1991(2):53-56+60.
[18] 冯彦琳, 王靖芳, 王海林. 用萃取法从硫酸法钛白废酸中提取钪[J]. 稀土, 1997(2):48-49+62. doi: 10.16533/j.cnki.15-1099/tf.1997.02.011
FENG Y L, WANG J F, WANG H L. Extraction of scandium from titanium dioxide waste acid in sulfuric acid process by extraction method[J]. Rare Earth, 1997(2):48-49+62. doi: 10.16533/j.cnki.15-1099/tf.1997.02.011
[19] 李勇明, 陈建军. 对钛白水解母液中提钪工艺流程的改进研究[J]. 稀有金属与硬质合金, 1997(1):1-4.
LI Y M, CHEN J J. Research on the improvement of the process flow of extracting scandium from titanium dioxide hydrolysis mother liquor[J]. Rare Metals and Cemented Carbide, 1997(1):1-4.
[20] 刘卫, 杨泱, 崔小震. 钛白废酸提钪工艺中锆钪分离的研究[J]. 稀土, 2014, 35(6):79-83.
LIU W, YANG Y, CUI X Z. Study on the separation of zirconium and scandium in the process of extracting scandium from waste titanium dioxide[J]. Rare Earth, 2014, 35(6):79-83.
[21] 李玉华, 李青刚, 张贵清, 等. 钛白水解废酸中钪的回收[J]. 化工学报, 2017, 68(7):2818-2825. doi: 10.11949/j.issn.0438-1157.20170061
LI Y H, LI Q G, ZHANG G Q, et al. Recovery of scandium from titanium dioxide hydrolysis waste acid[J]. Chinese Journal of Chemical Industry, 2017, 68(7):2818-2825. doi: 10.11949/j.issn.0438-1157.20170061
[22] 卢阶主, 张亮玖. 硫酸法钛白废液萃取富集钪[J]. 山西冶金, 2019, 42(2):10-12. doi: 10.16525/j.cnki.cn14-1167/tf.2019.02.05
LU J Z, ZHANG L J. Extraction and enrichment of scandium from titanium dioxide waste liquid by sulfuric acid method[J]. Shanxi Metallurgy, 2019, 42(2):10-12. doi: 10.16525/j.cnki.cn14-1167/tf.2019.02.05
[23] Hongbin Qiu, Mengliang Wang, Yingming Xie, et al. From trace to pure: Recovery of scandium from the waste acid of titanium pigment production by solvent extraction[J]. Process Safety and Environmental Protection, 2019, 121:118-124. doi: 10.1016/j.psep.2018.10.027
[24] 黄雯孝, 卢可可. 攀西钒钛磁铁矿尾矿中钪的提取工艺研究[J]. 矿产综合利用, 2020(2):135-139. doi: 10.3969/j.issn.1000-6532.2020.02.024
HUANG W X, LU K K. Study on scandium extraction technology for Panxi vanadium titanium magnetite tailings[J]. Multipurpose Utilization of Mineral Resources, 2020(2):135-139. doi: 10.3969/j.issn.1000-6532.2020.02.024
[25] 林维聪, 温涛, 刘起明, 等. 从广西某钒钛磁铁矿选钛尾矿中回收钪的试验研究[J]. 矿产综合利用, 1986(2):16-19+44.
LI W C, WEN T, LIU Q M, et al. Experimental study on recovery of scandium from titanium tailings of a vanadium-titanium magnetite in Guangxi[J]. Multipurpose Utilization of Mineral Resources, 1986(2):16-19+44.
[26] 毛建军, 范剑琴, 佘宗华. 攀枝花选钛尾矿提钪工艺的研究[J]. 矿冶工程, 1996, 16(4):48-52.
MAO J J, FAN J Q, SHE Z H. Study on the technology of extracting scandium from titanium tailings in Panzhihua[J]. Mining and Metallurgy Engineering, 1996, 16(4):48-52.
[27] 张总华, 张桂芳. 选钛尾矿分选钪实验研究[J]. 中国矿业, 2003(11):36-38. doi: 10.3969/j.issn.1004-4051.2003.11.011
ZHANG Z H, ZHANG G F. Experimental study on the separation of scandium from titanium tailings[J]. China Mining Industry, 2003(11):36-38. doi: 10.3969/j.issn.1004-4051.2003.11.011
[28] 刘猛. 攀西钒钛磁铁矿中钪浸出实验研究[J]. 山东化工, 2017, 46(11):47-48. doi: 10.3969/j.issn.1008-021X.2017.11.017
LIU M. Experimental study on scandium leaching from Panxi vanadium titanomagnetite[J]. Shandong Chemical Industry, 2017, 46(11):47-48. doi: 10.3969/j.issn.1008-021X.2017.11.017
-
