Comprehensive Utilization of Associated Sulfur Resources of Panxi Vanadium Titanium Magnetite and Its Significance for Low-Carbon Development
-
摘要:
这是一篇矿业工程领域的论文。以攀西钒钛磁铁矿伴生硫资源为研究对象，阐述了其综合利用路径及其低碳发展意义。硫是攀西钒钛磁铁矿典型的伴生元素之一，也是双碳时代粮食-资源-能源的新兴产业链端口元素。本文基于攀西钒钛磁铁矿伴生资源禀赋条件、硫矿物赋存状态，分析伴生硫资源的现状和特点，以钒钛磁铁矿采选产业链探讨硫在综合利用过程可能产生的环境影响。从矿产品需求和综合利用成熟度风险评价两方面探讨综合利用潜力分析。在伴生硫资源面临绿色低碳发展挑战的情况下，本文从规划顶层设计、技术攻关、产线推广等三方面，提出综合利用建议，旨在促进以绿色低碳的原则指导硫产业的发展，重点推广通过源头选硫产线介入方式进行降碳减污。本文研究能为钒钛磁铁矿伴生硫资源综合利用、环境规划及低碳发展提供新的思路及具体建议。
Abstract:This is an essay in the field of mining engineering, which takes Panxi vanadium-titanium magnetite associated sulfur resources as the research object, and expounds its comprehensive utilization path and its low-carbon development significance. Sulfur is one of the typical associated elements of Panxi vanadium-titanium magnetite, and it is also a port element of the emerging industrial chain of food-resource-energy in the double carbon era. Based on the endowment conditions of Panxi vanadium-titanium-magnetite associated resources and the occurrence status of sulfur minerals, this paper analyzes the current situation and characteristics of associated sulfur resources, and uses the mining and dressing industry chain of vanadium-titanium magnetite to discuss the possible environmental impact of sulfur in the process of comprehensive utilization. The comprehensive utilization potential analysis is discussed from two aspects of mineral product demand and comprehensive utilization maturity risk assessment. Under the circumstances that associated sulfur resources are facing the challenge of green and low-carbon development, this paper puts forward comprehensive utilization suggestions from the three aspects of planning top-level design, technical research, and production line promotion, aiming to promote the development of the sulfur industry guided by the principle of green and low-carbon, Focus on promoting carbon reduction and pollution reduction through source sulfur selection production line intervention. The research in this paper can provide new ideas and specific suggestions for the comprehensive utilization of sulfur resources associated with vanadium-titanium magnetite, environmental planning and low-carbon development.
-
-
表 1 攀西钒钛磁铁矿伴生中钴、镍、铜、硫的含量
Table 1. Associated cobalt, nickel, copper and sulfur content of Panxi vanadium titanium magnetite
伴生元素种类及含量/% 攀枝花矿区 白马矿区 太和矿区 红格矿区 TFe 33.88～23.65 22.62～22.47 28.30 31.72～26.51 Co 0.02～0.013 0.014～0.012 0.014~0.022 0.026～0.015 Ni 0.023～0.011 0.022～0.019 0.008 0.070～0.048 Cu 0.020～0.016 0.032～0.027 0.011 0.035～0.024 S 0.19~1.36 0.31~0.98 0.4~1.33 0.12~0.67
下载: 导出CSV
表 2 不同矿区综合样主要硫化物类别含量
Table 2. Content of main sulfide categories in comprehensive samples from different mining areas
矿区 矿段 矿石类型 矿石中硫化物含量/% 硫化物各类矿物含量/% 磁黄铁矿 黄铁矿 黄铜矿 其他硫化物 攀枝花 兰家火山 辉长岩 1.62 87.51 11.74 0.67 0.17 朱家包包 辉长岩 1.50 91.86 3.64 尖包包 辉长岩 1.50 白马 岌岌坪 橄榄辉长岩 1.14～1.45 87.66 5.96 6.38 田家村 橄榄辉长岩 1.54～1.76 90.01 6.64 3.35 太和 辉长岩 1.12 24.00 75.00 1.00 红格 北矿区 辉长岩 1.70 21.18 78.14 0.54 0.14 辉石岩 1.27 79.91 17.18 2.51 0.40 橄榄岩 1.67 77.66 11.92 6.99 3.43 南矿区 辉长岩 1.44 32.17 65.43 2.19 0.21 辉石岩 1.30 67.99 26.45 3.61 1.95 橄榄岩 1.60 90.06 3.61 2.68 3.65
下载: 导出CSV
表 3 攀西硫钴精矿主要企业标准/%
Table 3. Main enterprise standards for Panxi cobalt concentrate
S Co Fe Cu Ni 标准名称 攀钢矿业
企业标准≥30.0 ≥0.25 ≥48.0 龙佰攀枝花基地
企业标准一≥28.0 ≥0.3 SGJK 0.3 龙佰攀枝花基地
企业标准二≥30.0 ≥0.5 ≥0.8 ≥1.2 SGJK 0.5
下载: 导出CSV
表 4 钒钛磁铁矿伴生硫资源综合利用成熟度风险评价
Table 4. Maturity risk assessment for comprehensive utilization of associated sulfur resources of vanadium titanium magnetite
评价指标 等级 大类 小类 完全满足 大部分满足 一般满足 不满足 A－工业基础与制造 A.1－工业基础 √ A.2－制造技术体系 √ B－设计 B.1－生产性 √ B.2－设计成熟度 √ C－技术成熟度 C.1－技术成熟度 √ D－工艺 D.1－工艺建模仿真 √ D.2－工艺成熟度 √ D.3－合格率与生产率 √ E－物料 E.1－物料成熟度 √ E.2－物料可获取性 √ E.3－供应链管理 √ E.4－特殊物料的处理 √ F－设备设施 F.1－制造设备 √ F.2－生产设施 √ G－制造人员 G.1－制造人员 √ H－制造管理 H.1－制造计划与进度安排 √ H.2－物料准备计划 √ I－质量管理 I.1－过程质量管理 √ I.2－产品质量管理 √ I.3－供应商产品质量/质量管理 √ J－成本与资金 J.1－成本模型 √ J.2－成本分析 √ J.3－制造投资预算 √
下载: 导出CSV
-
[1] 中国地质科学院矿产综合利用研究所. 攀西钒钛磁铁矿资源及综合利用技术[M]. 冶金工业出版社, 2015.
Institute of Multipurpose Utilization of Mineral Resources , Chinese Academy of Geological Sciences. Panxi vanadium titanium magnetite resources and comprehensive utilization technology [M]. Metallurgical Industry Press, 2015.
[2] 刘亚川, 丁其光, 徐明. 攀西钒钛磁铁矿共伴生资源及利用[M]. 冶金工业出版社, 2014.
LIU Y C, DING Q G, XU M. Co associated resources and utilization of Panxi vanadium titanium magnetite [M]. Metallurgical Industry Press, 2014.
[3] 朱昌洛. 我国钒资源的开发利用现状及前景[J]. 矿产综合利用, 1991(4):32-35. ZHU C L. Current situation and prospects of the development and utilization of vanadium resources in China[J]. Multipurpose Utilization of Mineral Resources, 1991(4):32-35.
ZHU C L. Current situation and prospects of the development and utilization of vanadium resources in China [J]. Multipurpose Utilization of Mineral Resources, 1991(4): 32-35
[4] 惠 博, 杨耀辉. 攀西红格矿区橄辉岩型钒钛磁铁矿矿石性质研究及对选矿工艺的影响[J]. 矿产综合利用, 2020(4):126-129. HUI B, YANG Y H. Properties of olive-pyroxene vanadium-titanium magnetite ore in Hongge mining area of Panxi research and influence on Mineral Processing Technology[J]. Multipurpose Utilization of Mineral Resources, 2020(4):126-129.
HUI B, YANG Y H. Properties of olive-pyroxene vanadium-titanium magnetite ore in Hongge mining area of Panxi research and influence on Mineral Processing Technology[J]. Multipurpose Utilization of Mineral Resources, 2020(4): 126-129.
[5] 胡厚勤. 攀枝花钒钛磁铁矿中硫化物的工艺矿物学研究[J]. 钢铁钒钛, 2015(5):57-62. HU H Q. Study on process mineralogy of sulfides in Panzhihua vanadium titanium magnetite[J]. Steel, Vanadium and Titanium, 2015(5):57-62.
HU H Q. Study on process mineralogy of sulfides in Panzhihua vanadium titanium magnetite [J]. Steel, vanadium and titanium, 2015 (5): 57-62
[6] 曾钦林, 谢应龙. 浅析钒钛铁精矿中硫的来源与影响[J]. 攀钢技术, 1997(5):46-47+58. ZENG Q L, XIE Y L. Analysis of the source and influence of sulfur in vanadium titanium iron concentrate[J]. Pangang Technology, 1997(5):46-47+58.
ZENG Q L, XIE Y L. Analysis of the source and influence of sulfur in vanadium titanium iron concentrate [J]. Pangang Technology, 1997 (5). 46-47+58.
[7] 薛忠言, 曾令熙, 刘应冬. 太和钒钛磁铁矿中硫化物的工艺矿物学研究[J]. 矿产综合利用, 2019(3):78-81. XUE Z Y, ZENG L X, LIU Y D. Process mineralogy of the sulfide in the Taihe vanadium titanomagnetite[J]. Multipurpose Utilization of Mineral Resources, 2019(3):78-81.
XUE Z Y, ZENG L X, LIU Y D. Process mineralogy of the sulfide in the Taihe vanadium titanomagnetite[J]. Multipurpose Utilization of Mineral Resources, 2019(3): 78-81.
[8] 李潇雨, 周满赓, 王婧, 等. 攀西钒钛磁铁矿硫族元素工艺矿物学研究[J]. 中国矿业, 2016(1):118-124,134. LI X Y, ZHOU M G, WANG J, et al. Research on mineralogy of sulfur group element process of Panxi vanadium titanium magnetite[J]. China Mining, 2016(1):118-124,134.
LI X Y, ZHOU M G, WANG J , et al. Research on mineralogy of sulfur group element process of Panxi vanadium titanium magnetite [J]. China Mining, 2016 (1). 118-124, 134
[9] 郝建璋, 曾冠武. 钒钛磁铁矿铁、钒、钛一步分离试验[J]. 矿产综合利用, 2020(6):73-78. HAO J Z, ZENG G W. New technique for the separation of iron, vanadium and titanium in vanadium titanium magnetite[J]. Multipurpose Utilization of Mineral Resources, 2020(6):73-78.
HAO J Z, ZENG G W. New technique for the separation of iron, vanadium and titanium in vanadium titanium magnetite[J]. Multipurpose Utilization of Mineral Resources, 2020(6): 73-78.
[10] 刘应冬, 徐力, 王先达, 等. 攀枝花钒钛磁铁矿尾矿中主要金属元素淋滤浸出行为研究[J]. 矿产综合利用, 2020(6):84-90. LIU Y D, XU L, WANG X D, et al. Study on leaching behavior of main metal elements from Panzhihua vanadium-titanium magnetite tailings[J]. Multipurpose Utilization of Mineral Resources, 2020(6):84-90.
LIU Y D, XU L, WANG X D, et al. Study on leaching behavior of main metal elements from Panzhihua vanadium-titanium magnetite tailings[J]. Multipurpose Utilization of Mineral Resources, 2020(6): 84-90.
[11] 汤铁. 攀枝花钒钛磁铁矿综合利用研究及未来发展方向[J]. 攀枝花科技与信息, 2016(3):1-5. TANG T. Panzhihua vanadium titanium magnetite comprehensive utilization research and future development direction[J]. Panzhihua Science and Technology and Information, 2016(3):1-5.
TANG T. Panzhihua vanadium titanium magnetite comprehensive utilization research and future development direction [J]. Panzhihua Science and Technology and Information, 2016(3). 1-5.
[12] 赵国君, 申文金, 赵祺彬, 等. 攀西红格矿区钒钛磁铁矿开发利用探讨[J]. 中国国土资源经济, 2018(10):36-38+73. ZHAO G J, SHEN W J, ZHAO Q B, et al. Discussion on the development and utilization of vanadium titanium magnetite in Panxi Hongge mining area[J]. China Land Resources Economy, 2018(10):36-38+73.
ZHAO G J, SHEN W J, ZHAO Q B, et al. Discussion on the development and utilization of vanadium titanium magnetite in Panxi Hongge mining area [J]. China Land Resources Economy, 2018 (10): 36-38+73.
[13] 杨保祥, 伍良英. 国内外钴生产—消费—营销趋势及攀枝花硫钴精矿的综合利用[J]. 攀钢技术, 1998(3):23. YANG B X, WU L Y. Trends in cobalt production, consumption, and marketing at home and abroad and the comprehensive utilization of Panzhihua cobalt concentrate[J]. Pangang Technology, 1998(3):23.
YANG B X, WU L Y. Trends in cobalt production, consumption, and marketing at home and abroad and the comprehensive utilization of Panzhihua cobalt concentrate [J]. Pangang Technology, 1998 (3): 23.
[14] 严伟平, 曾小波. 攀西地区钒钛磁铁矿资源开发利用水平评估方法研究[J]. 矿产综合利用, 2020(6):79-83. YAN W P, ZENG X B. Study on the evaluation method of development and utilization level of vanadium-titanium magnetite mine in Panxi district[J]. Multipurpose Utilization of Mineral Resources, 2020(6):79-83.
YAN W P, ZENG X B. Study on the evaluation method of development and utilization level of vanadium-titanium magnetite mine in Panxi district[J]. Multipurpose Utilization of Mineral Resources, 2020(6): 79-83.
[15] 陈燃, 唐中相, 李发斌. 攀西地区主要矿区钒钛磁铁矿“三率”指标现状及影响因素分析[J]. 西部探矿工程, 2019(10):159-164. CHEN R, TANG Z X, LI F B. Analysis on the status quo and influencing factors of the "three rates" index of vanadium titanium magnetite in the main mining areas in Panxi area[J]. Western Exploration Project, 2019(10):159-164.
CHEN R, TANG Z X, LI F B. Analysis on the status quo and influencing factors of the "three rates" index of vanadium titanium magnetite in the main mining areas in Panxi area [J]. Western Exploration Project, 2019 (10): 159-164.
[16] 吴宁. 攀西某钒钛磁铁精矿浮选脱硫实验[J]. 矿产综合利用, 2022(3):126-131. WU N. Experimental study on the flotation desulfurization of vanadium titanium magnetite concentrate in Panxi[J]. Multipurpose Utilization of Mineral Resources, 2022(3):126-131.
WU N. Experimental Study on the Flotation Desulfurization of Vanadium Titanium Magnetite Concentrate in Panxi[J]. Multipurpose Utilization of Mineral Resources, 2022 (3): 126-131.
[17] 李城, 王伟之. 钒钛磁铁矿中钛的柱机联合全浮工艺试验研究[J]. 矿产综合利用, 2019(3):40-43. LI C, WANG W Z. Experimental research on column-cell integration full flotation technology of titanium in vanadium titanium magnetite[J]. Multipurpose Utilization of Mineral Resources, 2019(3):40-43.
LI C, WANG W Z. Experimental research on column-cell integration full flotation technology of titanium in vanadium titanium magnetite[J]. Multipurpose Utilization of Mineral Resources, 2019(3): 40-43.
-
