胶北地体荆山群禄格庄组沉积时代与物源——来自山东沐浴店地区长石石英岩碎屑锆石U-Pb年龄与稀土元素的新证据

,  ,  ,  ,  ,  ,  ,

文章导航 > 地质通报 > 2021 > 40(1): 164-188

上一篇

下一篇

张连祥, 刘平华, 田忠华, 周万蓬, 王义龙, 王宏宇, 张文, 张传恒. 胶北地体荆山群禄格庄组沉积时代与物源——来自山东沐浴店地区长石石英岩碎屑锆石U-Pb年龄与稀土元素的新证据[J]. 地质通报, 2021, 40(1): 164-188.
引用本文: 张连祥, 刘平华, 田忠华, 周万蓬, 王义龙, 王宏宇, 张文, 张传恒. 胶北地体荆山群禄格庄组沉积时代与物源——来自山东沐浴店地区长石石英岩碎屑锆石U-Pb年龄与稀土元素的新证据[J]. 地质通报, 2021, 40(1): 164-188.
shu
ZHANG Lianxiang, LIU Pinghua, TIAN Zhonghua, ZHOU Wanpeng, WANG Yilong, WANG Hongyu, ZHANG Wen, ZHANG Chuanheng. Depositional timing and provenance of the Lugezhuang Formation in the Jingshan Group in the Jiaobei terrane: New evidence from detrital zircon U-Pb ages and rare earth elements of arkose-quartzite in Mayudian, Shandong Province[J]. Geological Bulletin of China, 2021, 40(1): 164-188.
Citation: ZHANG Lianxiang, LIU Pinghua, TIAN Zhonghua, ZHOU Wanpeng, WANG Yilong, WANG Hongyu, ZHANG Wen, ZHANG Chuanheng. Depositional timing and provenance of the Lugezhuang Formation in the Jingshan Group in the Jiaobei terrane: New evidence from detrital zircon U-Pb ages and rare earth elements of arkose-quartzite in Mayudian, Shandong Province[J]. Geological Bulletin of China, 2021, 40(1): 164-188.
shu

胶北地体荆山群禄格庄组沉积时代与物源——来自山东沐浴店地区长石石英岩碎屑锆石U-Pb年龄与稀土元素的新证据

  • 1.

    中国地质大学(北京)地球科学与资源学院, 北京 100083

  • 2.

    中国地质科学院地质研究所, 北京 100037

  • 3.

    东华理工大学地球科学学院, 江西 南昌 330013

  • 基金项目:
    国家自然科学基金项目《内蒙古西部东阿拉善-狼山前寒武纪变质杂岩多期变质事件》（批准号：41672191）、《薄片原位独居石LASS与石榴子石微钻取样精细年代学研究：以弓长岭和鲁西孟家屯新太古代变质表壳岩为例》（批准号：41972205）、中国地质调查局项目《华北陆块中部与东部前寒武纪基础地质调查》（编号：DD20190003）、《全国陆域及海区地质图件更新与共享》（编号：DD20190370）
详细信息
    作者简介: 张连祥(1987-), 男, 在读博士生, 古生物学与地层学专业。E-mail: geoffreyzhang1105@163.com
    通讯作者: 刘平华(1981-), 男, 博士, 副研究员, 从事变质地质学与早前寒武纪地质研究。E-mail: lph1213@126.com

  • 中图分类号: P534.3;P588.34+.1;P597+.3

Depositional timing and provenance of the Lugezhuang Formation in the Jingshan Group in the Jiaobei terrane: New evidence from detrital zircon U-Pb ages and rare earth elements of arkose-quartzite in Mayudian, Shandong Province

  • 1.

    School of Earth Sciences and Resources, China University of Geosciences, Beijing 100083, China

  • 2.

    Institute of Geology, Chinese Academy of Geological Sciences, Beijing 100037, China

  • 3.

    School of Earth Sciences, East China University of Technology, Nanchang 330013, Jiangxi, China

More Information

    摘要

  • 荆山群禄格庄组是胶北地体古元古代变沉积岩系最重要的组成部分之一，准确测定其原岩沉积时代与物质源区，对进一步探讨荆山群与粉子山群之间的成因关系具有重要的地质意义。以山东莱阳沐浴店地区出露的禄格庄组长石石英岩为研究对象，通过对长石石英岩中碎屑锆石内部矿物包体、阴极发光图像、LA-ICP-MS U-Pb定年与稀土元素组成的综合研究发现，沐浴店地区禄格庄组长石石英岩的碎屑锆石207Pb/206Pb年龄介于2502~1970 Ma之间，其中最小一组碎屑锆石上交点年龄为2079 Ma，结合沐浴店地区禄格庄组记录了1934 Ma变质年龄，初步限定沐浴店地区荆山群禄格庄组的原岩沉积时代为2079~1934 Ma。综合以上研究及相关数据表明，荆山群禄格庄组、南辽河群里尔峪组和集安群蚂蚁河组的碎屑锆石都具有2200~2100 Ma的单峰年龄；而粉子山群小宋组-祝家夼组、北辽河群浪子山组与老岭群达台山组都以出现大于2500 Ma的峰值年龄为特征。结合胶-辽-吉带的其他地质数据，推测粉子山群小宋组与祝家夼组沉积时可能靠近被动大陆边缘的一侧，而荆山群禄格庄组可能更靠近岩浆岛弧的一侧，二者可能属于同时异相沉积的产物。

    As the Lugezhuang Formation of Jingshan Group is one of the most important parts of the Paleoproterozoic meta-sedimentary rocks in the Jiaobei terrane, accurate determination of its depositional timing and provenance is of great geological significance for further exploring the genetic relationship between the Jingshan Group and the Fenzishan Group.A comprehensive study on mineral inclusions, cathodoluminescence(CL)images, LA-ICP-MS U-Pb dates, and in-situ rare earth element(REE)compositions of detrital zircons indicates that the age of detrital zircons of the arkose-quartzite of the Lugezhuang Formation in the Muyudian area ranges from 2502 Ma to 1970 Ma, of which the youngest group age of detrital zircons is circa 2079 Ma.Combined with its metamorphic age of circa 1934 Ma of the Lugezhuang Formation, it is preliminary determined that the depositional timing of the Lugezhuang Formation ranges from 2079 Ma to 1934 Ma.On the basis of above and published data, detrital zircons from the Lugezhuang Formation of Jingshan Group, Lieryu Formation of South Liaohe Group and Mayinghe Formation of the Ji'an Group all have a single peak of 2200~2100 Ma.The Xiaosong Formation and Zhujiakuang Formation of Fenzishan Group, Liangzishan Formatin of North Liaohe Group and Dataishan Formation of Laoling Group are all characterized by peak ages greater than 2500 Ma.Combining with geology of the Jiao-Liao-Ji belt, it is speculated that the Xiaosong Formation and Zhujiakuang Formation of the Fenzishan Group might be deposited close to the passive continental margin, while the Lugezhuang Formation of the Jingshan Group might be deposited closer to the magmatic island arc.Therefore, the rocks of Fenzishan Group and Jingshan Group might be simultaneously deposited in different sedimentary facies.

    • HTML全文
  • 加载中

  • 图 1  胶北前寒武纪变质地质简图

    Figure 1.

    下载: 全尺寸图片 幻灯片

    图 2  沐浴店地区前寒武纪地质简图

    Figure 2.

    下载: 全尺寸图片 幻灯片

    图 3  胶北地体荆山群与粉子山群地层柱状图

    Figure 3.

    下载: 全尺寸图片 幻灯片

    图 4  胶北沐浴店地区荆山群禄格庄组长石石英岩野外露头照片

    Figure 4.

    下载: 全尺寸图片 幻灯片

    图 图版Ⅰ

    Figure 图版Ⅰ.

    下载: 全尺寸图片 幻灯片

    图 5  胶北沐浴店地区荆山群禄格庄组长石石英岩锆石阴极发光图像与207Pb/206Pb年龄

    Figure 5.

    下载: 全尺寸图片 幻灯片

    图 6  胶北沐浴店地区荆山群禄格庄组长石石英岩中锆石U-Pb谐和图(a、c、e)、年龄频率直方图(b) 与稀土元素配分模式图

    Figure 6.

    下载: 全尺寸图片 幻灯片

    图 7  胶北沐浴店地区荆山群禄格庄组碎屑锆石稀土元素成因图解

    Figure 7.

    下载: 全尺寸图片 幻灯片

    图 8  胶-辽-吉带古元古代变沉积岩系碎屑锆石U-Pb年龄频率直方图

    Figure 8.

    下载: 全尺寸图片 幻灯片

    图 图版Ⅱ

    Figure 图版Ⅱ.

    下载: 全尺寸图片 幻灯片

    表 1  胶北沐浴店地区荆山群禄格庄组长石石英岩碎屑锆石LA-ICP-MS U-Th-Pb定年结果

    Table 1.  LA-ICP-MS U-Th-Pb data of detrital zircons from the arkose-quartzite of the Lugezhuang Formation of Jingshan Group in the Muyudian area of the Jiaobei terrane

    样品分析点 含量/10-6 Th/U 同位素比值 年龄/Ma 谐和度/%
    TotalPb CommonPb Th U 207Pb/206Pb 1σ 207Pb/235U 1σ 206Pb/238U 1σ 207Pb/206Pb 1σ 207Pb/235U 1σ 206Pb/238U 1σ
    第一组(碎屑)锆石：上交点年龄为2459±50 Ma
    D0313-2-31 342.82 1.07 130.03 673.31 0.19 0.164304 0.002192 10.317578 0.183986 0.450324 0.004813 2502 22 2464 17 2397 21 95.80
    D0313-2-47 183.02 0.00 268.32 294.70 0.91 0.160619 0.001868 10.823730 0.167921 0.486757 0.005946 2462 21 2508 15 2557 26 96.16
    D0313-2-87 309.40 0.78 328.79 602.89 0.55 0.160444 0.001869 9.809649 0.140354 0.440455 0.005126 2460 20 2417 13 2353 23 95.63
    D0313-2-09 120.03 0.00 177.57 194.75 0.91 0.159908 0.002233 10.458022 0.175396 0.471245 0.006030 2455 24 2476 16 2489 26 98.60
    D0313-2-67 266.19 1.78 389.10 538.91 0.72 0.152276 0.001734 8.211756 0.105548 0.388657 0.003433 2372 19 2255 12 2117 16 89.24
    D0313-2-49 343.92 12.63 357.36 689.22 0.52 0.150658 0.002692 8.615182 0.259699 0.407798 0.005562 2353 30 2298 27 2205 25 93.69
    D0313-2-64 218.34 0.30 239.97 453.19 0.53 0.148075 0.001869 8.368172 0.129884 0.407292 0.004881 2324 22 2272 14 2203 22 94.78
    D0313-2-20 116.41 1.22 150.86 276.69 0.55 0.146187 0.001701 7.352002 0.118077 0.362078 0.004690 2302 19 2155 14 1992 22 86.55
    D0313-2-53 657.50 62.75 1934.90 2222.35 0.87 0.144087 0.001727 5.553087 0.117791 0.282464 0.006256 2277 20 1909 18 1604 31 70.44
    D0313-2-76 630.68 15.83 706.41 2212.25 0.32 0.143485 0.001546 5.119738 0.113832 0.257597 0.005375 2269 19 1839 19 1478 28 65.11
    第二组(碎屑)锆石：上交点年龄为2079±13 Ma
    D0313-2-52 235.93 3.98 273.76 590.81 0.46 0.137678 0.001501 7.128001 0.117417 0.374441 0.005313 2198 19 2128 15 2050 25 93.26
    D0313-2-81 642.18 54.24 1214.84 4161.04 0.29 0.136880 0.001785 2.846505 0.056165 0.149788 0.002535 2188 23 1368 15 900 14 41.12
    D0313-2-28 126.53 0.32 137.53 276.57 0.50 0.136602 0.001576 7.716779 0.111095 0.407669 0.004613 2184 21 2199 13 2204 21 99.08
    D0313-2-44 76.95 0.62 87.53 161.34 0.54 0.136302 0.001657 7.839649 0.127024 0.415081 0.004799 2181 20 2213 15 2238 22 97.36
    D0313-2-35 143.29 0.61 82.67 360.42 0.23 0.135889 0.001751 7.704244 0.135063 0.408459 0.005016 2176 22 2197 16 2208 23 98.52
    D0313-2-75 149.77 0.16 139.58 326.30 0.43 0.134562 0.001588 7.620064 0.117208 0.408957 0.004929 2158 25 2187 14 2210 23 97.60
    D0313-2-10 482.38 23.66 1317.80 2367.15 0.56 0.134330 0.001780 3.199582 0.080573 0.172532 0.004337 2155 29 1457 20 1026 24 47.61
    D0313-2-84 92.89 0.06 88.97 206.91 0.43 0.133970 0.001810 7.320846 0.112504 0.392638 0.004037 2151 23 2151 14 2135 19 99.26
    D0313-2-74 276.93 1.46 224.14 637.78 0.35 0.133864 0.001656 6.967157 0.100085 0.375887 0.003666 2150 22 2107 13 2057 17 95.68
    D0313-2-50 170.21 0.00 219.74 354.46 0.62 0.133160 0.001591 7.499542 0.116743 0.407521 0.005241 2140 20 2173 14 2204 24 97.02
    D0313-2-85 137.89 0.00 180.45 280.59 0.64 0.133053 0.001704 7.616683 0.123978 0.411433 0.004985 2139 22 2187 15 2221 23 96.12
    D0313-2-36 77.67 0.46 72.97 178.34 0.41 0.132250 0.001602 7.439639 0.122668 0.406332 0.005190 2128 22 2166 15 2198 24 96.71
    D0313-2-63 265.45 1.19 414.77 514.38 0.81 0.131761 0.001575 7.521773 0.130190 0.411246 0.005823 2121 20 2176 16 2221 27 95.32
    D0313-2-65 341.59 4.82 340.22 1137.84 0.30 0.131479 0.001782 5.187172 0.100385 0.284632 0.004460 2118 24 1851 17 1615 22 76.25
    D0313-2-32 152.78 0.00 264.39 315.19 0.84 0.131309 0.001768 7.371154 0.132991 0.405714 0.005864 2117 24 2157 16 2195 27 96.29
    D0313-2-98 457.23 11.00 1071.88 1309.60 0.82 0.130825 0.001408 5.193504 0.090757 0.286554 0.004341 2109 14 1852 15 1624 22 77.02
    D0313-2-71 234.06 2.68 297.62 515.68 0.58 0.130359 0.001431 7.034199 0.105083 0.389615 0.004627 2103 19 2116 13 2121 21 99.13
    D0313-2-82 124.41 0.00 123.98 270.96 0.46 0.130244 0.001897 7.336817 0.136052 0.404550 0.005274 2102 26 2153 17 2190 24 95.81
    D0313-2-58 136.50 0.25 141.51 288.91 0.49 0.129428 0.001591 7.334105 0.125839 0.408718 0.005297 2100 27 2153 15 2209 24 94.81
    D0313-2-01 312.38 1.81 280.30 720.87 0.39 0.130061 0.001780 6.855733 0.110357 0.379755 0.004191 2099 24 2093 14 2075 20 98.86
    D0313-2-23 654.42 26.25 1413.46 2977.29 0.47 0.129830 0.001441 3.474612 0.055092 0.193113 0.002782 2095 20 1521 13 1138 15 54.32
    D0313-2-13 186.54 0.00 216.04 394.58 0.55 0.129672 0.001984 6.992268 0.116930 0.387559 0.005001 2094 27 2110 15 2111 23 99.19
    D0313-2-96 182.33 0.67 131.03 404.27 0.32 0.129591 0.001446 7.400142 0.110540 0.412027 0.004890 2092 25 2161 13 2224 22 93.70
    D0313-2-66 304.14 1.36 279.22 719.83 0.39 0.129266 0.001521 6.781121 0.097513 0.377798 0.003931 2088 16 2083 13 2066 18 98.95
    D0313-2-61 170.17 0.68 119.20 407.20 0.29 0.129148 0.001418 6.853767 0.094391 0.383014 0.004164 2087 14 2093 12 2090 19 99.84
    D0313-2-97 187.33 0.56 287.15 397.07 0.72 0.129036 0.001408 6.998725 0.099370 0.391592 0.004412 2085 20 2111 13 2130 20 97.83
    D0313-2-55 139.88 0.93 124.42 340.33 0.37 0.128695 0.001601 6.690595 0.103271 0.375636 0.004237 2080 22 2071 14 2056 20 98.84
    D0313-2-60 190.80 0.79 339.37 408.51 0.83 0.128626 0.001459 6.813556 0.099223 0.381814 0.003972 2079 20 2087 13 2085 19 99.74
    D0313-2-14 167.57 0.24 177.51 383.14 0.46 0.128087 0.002184 6.822021 0.125776 0.382597 0.005345 2072 29 2089 16 2088 25 99.20
    D0313-2-59 167.79 0.00 154.81 361.52 0.43 0.127481 0.001505 7.168968 0.116551 0.405622 0.005139 2065 21 2133 15 2195 24 93.70
    D0313-2-86 105.78 1.15 150.81 211.31 0.71 0.127495 0.001616 7.677796 0.135224 0.432704 0.005931 2065 22 2194 16 2318 27 87.74
    D0313-2-11 70.37 0.88 72.99 159.44 0.46 0.127561 0.001885 6.759441 0.116143 0.381135 0.004736 2065 26 2080 15 2082 22 99.17
    D0313-2-57 287.93 4.04 218.00 878.11 0.25 0.127559 0.001591 5.610898 0.101228 0.318702 0.004993 2065 22 1918 16 1783 24 86.38
    D0313-2-56 149.98 0.74 97.65 360.03 0.27 0.127369 0.001620 6.851884 0.126089 0.388056 0.005366 2062 23 2092 16 2114 25 97.49
    D0313-2-08 94.77 0.00 89.06 218.67 0.41 0.127179 0.001845 6.779994 0.122767 0.385056 0.005452 2061 25 2083 16 2100 25 98.12
    D0313-2-34 150.44 1.31 146.87 394.73 0.37 0.127225 0.001534 6.106284 0.096410 0.346768 0.004222 2061 21 1991 14 1919 20 93.11
    D0313-2-72 119.08 1.41 114.30 267.10 0.43 0.127132 0.001499 6.904510 0.114025 0.392171 0.005135 2059 20 2099 15 2133 24 96.41
    D0313-2-100 100.66 0.56 117.49 279.20 0.42 0.126977 0.001679 5.634378 0.095122 0.320392 0.003908 2057 23 1921 15 1792 19 87.08
    D0313-2-29 150.98 0.46 170.14 346.40 0.49 0.126841 0.001422 6.707494 0.101827 0.381283 0.004578 2055 20 2074 13 2082 21 98.65
    D0313-2-04 141.22 0.00 111.80 325.40 0.34 0.126677 0.001490 6.795830 0.102651 0.387084 0.004778 2054 21 2085 13 2109 22 97.29
    D0313-2-46 109.47 0.16 139.71 247.76 0.56 0.126579 0.001489 6.545514 0.091722 0.373593 0.003739 2051 20 2052 12 2046 18 99.77
    D0313-2-30 236.30 4.63 268.59 673.96 0.40 0.126402 0.001438 5.520984 0.089065 0.315436 0.004342 2050 20 1904 14 1767 21 86.21
    D0313-2-45 163.68 0.00 307.96 337.33 0.91 0.126440 0.001414 6.755026 0.092084 0.386185 0.004080 2050 20 2080 12 2105 19 97.31
    D0313-2-06 271.95 0.00 378.25 543.49 0.70 0.126308 0.001517 7.121264 0.114679 0.407128 0.005662 2047 21 2127 14 2202 26 92.45
    D0313-2-38 227.49 1.08 217.63 561.20 0.39 0.125912 0.001374 6.269407 0.084963 0.359896 0.003793 2043 14 2014 12 1982 18 97.02
    D0313-2-70 227.69 2.18 239.07 609.93 0.39 0.125931 0.001357 5.928160 0.114806 0.339742 0.005867 2043 14 1965 17 1885 28 92.31
    D0313-2-93 230.47 0.20 135.39 553.11 0.24 0.125901 0.001545 6.932249 0.118064 0.396201 0.005016 2043 22 2103 15 2152 23 94.67
    D0313-2-43 192.75 6.41 94.68 558.26 0.17 0.125800 0.001452 5.605520 0.073844 0.322768 0.003438 2040 20 1917 11 1803 17 88.40
    D0313-2-94 116.16 0.54 133.97 301.64 0.44 0.125769 0.001544 6.366794 0.121898 0.366297 0.006317 2040 22 2028 17 2012 30 98.63
    D0313-2-24 263.74 2.54 269.95 605.95 0.45 0.125735 0.001521 6.697823 0.109861 0.383558 0.005133 2039 22 2072 15 2093 24 97.37
    D0313-2-03 263.55 0.56 337.63 572.38 0.59 0.125684 0.001461 6.588739 0.091199 0.377619 0.003743 2039 21 2058 12 2065 18 98.70
    D0313-2-33 163.85 1.88 243.52 479.73 0.51 0.125695 0.001676 5.660775 0.101356 0.326002 0.004807 2039 23 1925 16 1819 23 89.23
    D0313-2-83 152.72 0.94 216.45 334.60 0.65 0.125514 0.001772 6.663105 0.108612 0.381358 0.004242 2036 25 2068 14 2083 20 97.72
    D0313-2-12 189.03 0.74 236.44 467.08 0.51 0.125483 0.001790 6.044789 0.095650 0.346136 0.004068 2035 25 1982 14 1916 20 94.14
    D0313-2-99 225.47 0.00 224.56 561.57 0.40 0.125434 0.001433 6.446847 0.103639 0.370850 0.004686 2035 20 2039 14 2033 22 99.93
    D0313-2-16 216.90 0.88 310.68 461.83 0.67 0.125267 0.002527 6.830259 0.146509 0.390850 0.006089 2032 40 2090 19 2127 28 95.36
    D0313-2-54 120.61 0.22 134.69 267.34 0.50 0.125241 0.001484 6.769911 0.113505 0.391783 0.005974 2032 21 2082 15 2131 28 95.14
    D0313-2-19 485.14 1.97 472.12 1108.97 0.43 0.124790 0.001392 6.630677 0.101614 0.381643 0.004418 2026 25 2063 14 2084 21 97.12
    D0313-2-39 333.22 5.22 602.04 995.43 0.60 0.124503 0.001400 4.735219 0.073201 0.275088 0.003624 2022 21 1773 13 1567 18 77.48
    D0313-2-68 255.59 0.87 284.35 614.04 0.46 0.124453 0.001338 6.320617 0.091024 0.366225 0.004237 2021 19 2021 13 2012 20 99.52
    D0313-2-22 538.67 13.52 744.82 1810.12 0.41 0.124349 0.001344 4.708030 0.069562 0.272693 0.003374 2020 -14 1769 12 1554 17 76.94
    D0313-2-77 322.81 1.25 402.57 753.05 0.53 0.124305 0.001343 6.306371 0.091075 0.366007 0.004298 2020 20 2019 13 2011 20 99.52
    D0313-2-40 295.40 0.76 144.53 733.29 0.20 0.124216 0.001434 6.679566 0.109809 0.388573 0.005295 2018 20 2070 15 2116 25 95.11
    D0313-2-78 493.17 7.03 587.80 1329.41 0.44 0.124215 0.001348 5.552684 0.081716 0.322434 0.003977 2018 19 1909 13 1802 19 89.29
    D0313-2-92 260.64 0.24 351.51 588.17 0.60 0.124072 0.001615 6.502133 0.103632 0.377317 0.004235 2017 23 2046 14 2064 20 97.67
    D0313-2-07 209.67 0.25 234.60 476.51 0.49 0.123918 0.001557 6.397028 0.096097 0.372078 0.004066 2013 22 2032 13 2039 19 98.71
    D0313-2-91 308.56 0.00 277.66 772.20 0.36 0.123926 0.001649 6.267300 0.096644 0.364332 0.004066 2013 23 2014 14 2003 19 99.47
    D0313-2-25 236.40 0.53 327.02 514.24 0.64 0.123781 0.001528 6.911795 0.111973 0.402036 0.005062 2013 21 2100 14 2178 23 91.78
    D0313-2-95 355.39 2.18 304.76 936.07 0.33 0.123689 0.001384 6.061128 0.085724 0.353956 0.004139 2010 20 1985 12 1953 20 97.18
    D0313-2-02 169.33 0.89 85.77 397.42 0.22 0.123390 0.001556 6.873036 0.116824 0.400887 0.005039 2006 23 2095 15 2173 23 91.66
    D0313-2-79 98.70 0.00 87.82 234.79 0.37 0.123185 0.001539 6.697304 0.109733 0.390841 0.004509 2003 22 2072 15 2127 21 93.81
    D0313-2-89 250.71 0.00 223.02 593.71 0.38 0.123182 0.001450 6.501680 0.102729 0.379676 0.004719 2003 25 2046 14 2075 22 96.41
    D0313-2-21 383.32 1.28 532.27 841.00 0.63 0.122822 0.001358 6.617329 0.091791 0.388683 0.004702 1998 14 2062 12 2117 22 94.07
    D0313-2-17 177.99 0.05 161.26 400.71 0.40 0.122469 0.001633 7.065806 0.117527 0.415358 0.005215 1992 24 2120 15 2239 24 87.60
    D0313-2-73 149.26 0.50 48.18 443.34 0.11 0.121992 0.001520 5.636605 0.100329 0.334491 0.005079 1987 22 1922 15 1860 25 93.61
    D0313-2-18 221.22 0.14 122.81 555.86 0.22 0.121041 0.001451 6.519722 0.115591 0.388207 0.005997 1972 22 2049 16 2115 28 92.79
    D0313-2-80 389.76 2.48 206.56 987.50 0.21 0.120948 0.001443 6.193448 0.091613 0.368775 0.004247 1970 21 2004 13 2024 20 97.28
    下载: 导出CSV

    表 2  胶北沐浴店地区荆山群禄格庄组长石石英岩碎屑锆石稀土元素分析结果

    Table 2.  Rare earth element composition of detrital zircons from the arkose-quartzite of the Lugezhuang Formation of Jingshan Group in the Muyudian area of the Jiaobei terrane 10-6

    样品分析点 La Ce Pr Nd Sm Eu Gd Tb Dy Ho Er Tm Yb Lu ∑REE Eu/Eu* Ce/Ce* LuN/SmN
    第一组(碎屑)锆石
    D0313-2-31 0.01 6.05 0.03 0.64 1.56 0.34 10.04 3.53 46.40 18.00 90.47 20.65 235.52 43.81 477.06 0.20 54.81 169.37
    D0313-2-47 0.01 42.05 0.18 3.58 6.60 2.13 29.67 8.19 85.86 27.89 120.76 23.70 242.29 40.93 633.84 0.39 71.65 37.36
    D0313-2-87 0.15 13.10 0.27 2.47 3.51 0.67 14.04 4.27 47.18 16.25 72.54 15.12 161.19 27.23 377.99 0.25 12.43 46.77
    D0313-2-09 0.02 50.76 0.30 5.24 8.06 2.77 31.76 8.01 76.60 23.89 96.66 19.92 200.95 34.27 559.21 0.46 50.35 25.61
    D0313-2-67 2.02 39.24 2.00 13.66 13.07 4.45 40.56 11.41 121.88 39.23 175.82 36.89 403.19 69.56 972.98 0.54 4.34 32.06
    D0313-2-49 1.55 22.09 1.77 11.68 13.34 2.86 50.31 14.88 165.78 55.81 245.61 48.77 484.74 79.41 1198.62 0.30 2.87 35.85
    D0313-2-64 3.76 25.26 1.64 11.08 12.83 4.78 60.21 18.06 200.38 65.64 272.90 50.67 498.14 79.75 1305.10 0.44 2.49 37.44
    D0313-2-20 152.38 343.49 35.52 150.74 23.19 1.93 37.63 9.82 98.32 32.82 140.93 27.91 280.91 46.61 1382.19 0.20 1.10 12.11
    D0313-2-53 38.52 486.37 54.03 320.64 227.66 93.49 475.29 135.02 1232.10 313.81 1144.30 212.92 2017.89 280.38 7032.42 0.85 2.17 7.42
    D0313-2-76 9.48 55.81 11.37 74.85 74.81 24.23 166.29 47.77 407.84 101.57 389.96 73.57 716.70 104.37 2258.63 0.64 1.14 8.40
    第二组(碎屑)锆石
    D0313-2-52 1.60 12.61 1.53 12.37 18.15 8.65 86.73 23.85 222.84 61.97 235.80 40.41 389.56 61.73 1177.79 0.55 1.80 20.49
    D0313-2-81 43.36 304.07 61.65 399.62 343.79 139.32 684.97 187.54 1615.76 391.68 1428.82 268.25 2676.41 402.44 8947.67 0.86 1.19 7.05
    D0313-2-28 0.01 11.81 0.05 0.92 2.27 0.27 15.45 5.63 73.19 28.60 137.18 28.49 304.79 50.69 659.35 0.10 64.91 134.27
    D0313-2-44 0.13 8.00 0.30 4.27 6.38 0.58 29.36 8.93 107.60 38.38 170.99 34.16 345.60 58.97 813.66 0.11 7.03 55.71
    D0313-2-35 0.12 9.93 0.14 1.50 2.37 0.47 13.77 5.11 68.84 25.76 117.79 23.85 251.02 43.49 564.15 0.20 16.16 110.67
    D0313-2-75 0.03 14.26 0.04 0.87 2.41 0.12 13.92 4.77 62.02 23.51 109.38 22.65 236.43 40.30 530.71 0.05 82.61 100.67
    D0313-2-10 15.32 130.09 21.09 142.24 146.79 56.42 350.47 98.19 868.72 221.59 796.79 148.57 1376.17 194.60 4567.05 0.73 1.48 7.99
    D0313-2-84 0.02 14.42 0.01 0.30 0.87 0.12 5.96 2.24 32.87 14.26 77.70 18.49 224.54 43.13 434.93 0.12 230.14 297.55
    D0313-2-74 0.23 4.03 0.16 1.28 1.56 0.67 6.72 2.18 27.52 11.41 60.73 14.09 175.17 36.79 342.52 0.54 5.07 142.07
    D0313-2-50 0.00 12.62 0.05 0.83 1.64 0.34 6.20 2.03 23.40 8.56 40.94 9.07 102.67 18.48 226.83 0.29 85.77 68.03
    D0313-2-85 3.51 15.17 1.43 10.85 12.89 2.89 57.58 17.06 198.12 69.52 303.36 58.06 592.11 100.08 1442.65 0.27 1.66 46.78
    D0313-2-36 0.89 16.41 0.52 4.78 8.38 4.76 38.56 10.75 105.20 31.85 133.79 24.82 250.00 41.59 672.30 0.68 5.80 29.88
    D0313-2-63 0.32 27.90 0.56 5.93 9.97 1.86 46.31 15.02 178.89 64.11 288.55 58.52 604.24 100.52 1402.70 0.22 12.59 60.74
    D0313-2-65 3.72 34.78 4.20 26.77 26.17 8.50 77.74 23.74 238.30 75.03 314.36 60.72 604.82 96.39 1595.23 0.53 1.90 22.19
    D0313-2-32 0.03 18.18 0.23 4.29 8.15 1.39 40.44 12.45 147.47 53.74 244.48 49.60 506.84 84.42 1171.72 0.19 23.69 62.38
    D0313-2-98 15.24 88.19 16.46 102.31 96.31 43.33 245.11 75.18 727.60 191.62 712.78 129.15 1230.12 181.47 3854.88 0.82 1.21 11.35
    D0313-2-71 0.74 25.35 1.30 12.77 16.52 3.65 66.36 19.68 227.39 80.00 350.92 67.07 660.40 107.95 1640.09 0.29 4.93 39.36
    D0313-2-82 2.08 18.76 0.78 4.92 4.02 0.22 16.90 5.22 63.27 23.84 111.54 23.27 247.28 42.69 564.79 0.07 3.60 63.90
    D0313-2-58 0.03 9.71 0.11 1.45 2.74 0.22 14.11 5.04 62.78 23.54 111.64 23.49 248.47 42.99 546.35 0.09 23.57 94.36
    D0313-2-01 0.67 10.57 0.69 6.02 9.00 1.66 35.96 11.61 129.72 45.33 197.53 39.83 389.26 62.36 940.21 0.24 3.40 41.74
    D0313-2-23 35.51 215.48 37.34 251.07 252.36 92.62 512.40 134.88 1090.44 256.33 904.34 162.36 1488.38 198.26 5631.77 0.77 1.30 4.73
    D0313-2-13 0.50 14.60 0.42 5.35 7.85 0.40 36.40 12.03 145.59 55.49 254.28 51.69 530.54 89.60 1204.74 0.06 7.35 68.72
    D0313-2-96 0.70 10.49 0.96 5.94 5.28 1.39 19.81 6.48 79.12 29.13 140.09 30.32 334.79 60.75 725.26 0.37 2.63 69.31
    D0313-2-66 0.27 14.46 0.43 4.58 6.60 1.74 28.81 9.47 115.36 42.29 199.54 41.51 439.96 74.57 979.58 0.33 8.36 68.08
    D0313-2-61 0.56 6.28 0.42 5.89 6.90 0.73 23.77 6.35 65.83 22.12 97.61 19.60 205.66 35.50 497.21 0.16 3.01 31.00
    D0313-2-97 2.41 21.84 1.29 9.18 8.95 1.43 37.82 11.67 141.51 53.23 250.64 52.47 561.09 98.95 1252.48 0.20 3.00 66.61
    D0313-2-55 0.66 7.72 0.40 2.77 3.26 0.74 13.93 4.50 55.48 20.67 97.56 20.32 218.25 38.49 484.75 0.29 3.63 71.04
    D0313-2-60 0.09 10.19 0.38 5.62 10.77 0.56 60.28 21.26 264.83 93.64 407.79 76.91 735.08 114.02 1801.43 0.05 7.54 63.79
    D0313-2-14 0.16 7.67 0.48 6.07 8.44 1.72 35.25 10.22 111.47 37.21 157.35 30.72 303.47 50.15 760.39 0.26 4.41 35.78
    D0313-2-59 3.32 21.46 1.50 9.21 5.99 0.89 21.56 5.98 66.10 23.48 110.58 23.75 265.78 50.19 609.77 0.21 2.36 50.49
    D0313-2-86 0.06 16.30 0.29 4.49 6.93 2.24 30.86 8.86 102.06 37.12 171.23 35.07 378.17 66.79 860.50 0.40 15.90 58.03
    D0313-2-11 0.00 4.06 0.05 1.07 2.35 0.04 15.63 5.47 68.95 26.60 119.92 25.10 250.80 41.21 561.26 0.02 25.37 105.54
    D0313-2-57 2.24 21.62 3.24 20.57 19.70 8.03 46.25 13.97 132.13 36.67 145.82 28.42 291.73 46.20 816.60 0.78 1.62 14.12
    D0313-2-56 0.28 3.29 0.37 3.03 6.47 1.19 39.92 15.82 212.78 82.83 394.24 80.56 850.30 141.77 1832.87 0.17 2.10 131.92
    D0313-2-08 0.10 4.75 0.36 5.02 7.84 0.53 35.37 10.25 110.92 38.36 160.51 30.24 286.66 47.37 738.28 0.08 3.68 36.41
    D0313-2-34 0.56 6.42 0.72 6.40 9.24 3.69 40.18 13.21 153.07 48.82 207.75 39.42 386.54 60.50 976.51 0.50 2.11 39.44
    D0313-2-72 0.00 9.46 0.05 1.15 2.96 0.25 19.31 7.16 95.51 37.66 177.81 36.79 380.69 63.86 832.68 0.08 52.60 129.81
    D0313-2-100 0.32 6.78 0.55 5.97 9.21 1.38 50.86 16.45 194.59 70.00 306.21 58.64 593.42 98.39 1412.77 0.15 3.12 64.38
    D0313-2-29 0.04 5.12 0.38 5.93 9.90 2.11 48.83 13.94 153.23 52.18 226.51 43.81 445.16 74.07 1081.20 0.24 4.06 45.09
    D0313-2-04 0.00 2.64 0.07 1.47 4.06 0.09 25.84 9.05 113.98 42.59 190.38 38.24 379.76 62.21 870.40 0.02 10.81 92.25
    D0313-2-46 0.01 19.07 0.09 1.66 3.64 0.18 19.66 6.57 77.38 28.36 128.68 25.73 265.19 44.42 620.62 0.05 66.18 73.46
    D0313-2-30 7.29 37.79 6.03 34.33 25.37 9.34 58.51 17.54 172.53 48.87 201.14 40.74 420.71 65.56 1145.74 0.71 1.31 15.57
    D0313-2-45 0.05 25.41 0.50 8.10 13.09 1.31 56.63 16.77 193.38 67.43 295.66 57.00 575.17 95.84 1406.34 0.13 15.28 44.10
    D0313-2-06 203.90 506.95 65.49 307.77 76.06 2.81 118.62 27.24 236.31 70.62 282.74 54.33 517.15 83.19 2553.19 0.09 1.07 6.59
    D0313-2-38 0.31 5.59 0.38 3.49 6.57 0.65 34.40 11.82 147.64 54.11 250.06 49.91 509.12 83.09 1157.16 0.11 3.40 76.16
    D0313-2-70 0.63 24.37 1.09 7.96 10.19 2.95 24.30 6.50 56.92 14.99 57.88 11.30 115.53 17.48 352.07 0.55 5.66 10.33
    D0313-2-93 0.10 3.72 0.17 1.87 3.38 0.59 18.66 6.36 82.80 32.63 159.81 35.24 400.40 75.32 821.07 0.18 5.40 134.10
    D0313-2-43 0.67 6.92 0.87 6.03 8.31 2.18 31.81 9.07 86.33 24.58 98.90 19.16 195.85 31.10 521.78 0.36 1.89 22.54
    D0313-2-94 1.54 16.63 0.96 6.62 7.85 1.73 35.67 11.78 141.38 51.80 240.16 49.50 523.66 90.04 1179.33 0.27 3.26 69.10
    D0313-2-24 0.20 16.34 0.37 4.45 5.78 0.93 24.29 6.99 74.94 24.97 107.36 21.01 215.95 35.43 539.03 0.21 11.18 36.92
    D0313-2-03 0.11 16.97 0.50 7.65 14.16 0.99 66.24 19.89 222.96 77.93 334.34 64.04 612.02 98.73 1536.52 0.08 9.73 42.00
    D0313-2-33 1.58 13.73 1.53 10.49 11.34 5.03 40.10 13.04 138.52 41.61 171.09 33.08 337.04 54.27 872.46 0.64 1.97 28.82
    D0313-2-83 0.01 18.81 0.11 2.41 5.57 0.45 32.46 11.11 139.97 52.39 237.94 45.88 459.10 74.92 1081.15 0.08 50.63 80.96
    D0313-2-12 0.78 13.94 0.73 6.22 8.54 2.32 36.19 11.41 127.42 44.64 200.03 40.82 417.54 70.77 981.34 0.34 4.13 49.91
    D0313-2-99 0.58 8.26 0.82 5.78 7.96 1.21 36.63 11.73 136.85 48.35 213.50 41.77 424.35 70.59 1008.39 0.18 2.45 53.39
    D0313-2-16 0.26 17.05 0.24 3.13 4.54 1.25 22.72 7.87 101.02 41.14 253.29 45.67 508.78 93.39 1100.34 0.31 15.38 123.97
    D0313-2-54 0.03 15.71 0.26 4.08 7.07 1.16 26.04 6.65 65.30 19.53 81.07 15.39 155.76 26.11 424.15 0.23 18.01 22.26
    D0313-2-19 1.84 20.02 2.64 19.92 22.40 4.35 86.80 25.66 285.16 96.90 431.15 85.42 888.21 145.78 2116.24 0.26 1.84 39.21
    D0313-2-39 4.49 60.44 6.22 40.47 37.70 14.98 94.09 28.31 271.42 75.09 289.58 55.31 549.78 82.56 1610.46 0.73 2.34 13.19
    D0313-2-68 0.80 20.91 0.42 3.52 4.12 0.54 17.27 5.20 57.70 19.68 87.77 18.36 194.73 33.16 464.20 0.17 8.72 48.51
    D0313-2-22 26.11 145.32 24.83 153.31 130.62 53.85 280.46 81.68 766.31 192.87 689.98 124.81 1166.42 157.16 3993.73 0.84 1.28 7.25
    D0313-2-77 0.11 13.94 0.50 7.99 14.73 1.63 66.12 19.28 214.08 71.21 306.08 59.28 587.59 96.85 1459.38 0.13 7.92 39.61
    D0313-2-40 0.24 4.61 0.23 1.82 2.84 0.43 15.28 5.01 62.95 24.08 118.50 26.36 300.89 53.94 617.19 0.16 4.38 114.48
    D0313-2-78 4.66 55.78 5.54 38.30 40.20 14.81 97.18 26.88 238.16 61.90 229.95 43.03 414.92 61.69 1333.01 0.69 2.34 9.24
    D0313-2-92 0.93 29.12 0.73 7.23 9.03 0.82 34.79 10.39 115.33 39.70 176.86 36.17 378.38 65.52 904.99 0.12 8.23 43.70
    D0313-2-07 0.02 12.36 0.25 4.56 9.42 1.08 49.45 15.46 176.36 62.04 267.92 52.08 503.04 83.23 1237.25 0.12 15.06 53.22
    D0313-2-91 0.15 9.22 0.23 2.84 6.05 0.35 36.95 12.67 153.67 56.11 251.50 48.65 484.36 79.33 1142.10 0.05 9.68 78.98
    D0313-2-25 0.47 21.11 0.51 6.22 9.76 1.19 43.36 12.12 130.54 43.36 188.55 36.14 362.50 58.51 914.33 0.15 9.45 36.12
    D0313-2-95 1.37 16.84 1.56 10.31 11.29 3.39 40.14 12.62 145.79 50.51 233.57 48.15 503.70 82.46 1161.69 0.43 2.48 44.01
    D0313-2-02 0.03 2.34 0.07 1.31 3.28 0.28 21.49 7.87 102.98 40.15 190.79 41.08 429.21 73.47 914.38 0.08 8.88 134.96
    D0313-2-79 0.92 9.49 0.39 2.76 2.79 0.25 15.38 4.93 59.97 22.45 101.72 20.91 218.36 36.81 497.14 0.09 3.89 79.40
    D0313-2-89 0.29 13.32 0.11 1.26 2.11 0.21 10.70 3.55 43.42 16.05 75.91 15.96 173.16 29.48 385.53 0.11 18.46 84.25
    D0313-2-21 1.43 42.41 1.29 8.82 8.43 3.27 26.82 7.69 86.13 29.46 135.73 29.77 337.82 60.12 779.18 0.61 7.08 42.94
    D0313-2-17 0.06 8.92 0.15 2.05 4.10 0.40 22.52 7.03 84.63 30.83 141.46 28.70 299.07 49.76 679.68 0.10 16.32 73.05
    D0313-2-73 0.25 1.83 0.29 1.80 1.25 0.58 3.41 1.01 8.68 2.24 8.58 1.63 15.42 2.01 48.97 0.81 1.44 9.72
    D0313-2-18 0.72 8.15 0.52 3.66 5.51 1.15 25.09 8.21 94.99 33.43 153.42 30.65 322.37 53.29 741.17 0.25 3.14 58.27
    D0313-2-80 3.76 20.71 2.97 16.69 12.02 3.77 36.27 11.32 121.60 39.42 174.84 37.11 395.39 65.74 941.63 0.51 1.44 32.93
    下载: 导出CSV
    • 参考文献(80)
  • [1]

    刘福来, 刘平华, 王舫, 等. 胶-辽-吉古元古代造山/活动带巨量变沉积岩系的研究进展[J]. 岩石学报, 2015, 31(10): 2816-2846. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201510002.htm

    [2]

    刘平华, 刘福来, 王舫, 等. 胶北地体多期变质事件的P-T-t轨迹及其对胶-辽-吉带形成与演化的制约[J]. 岩石学报, 2015, 31(10): 2889-2941. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201510005.htm

    [3]

    张秋生, 杨振生, 刘连登. 辽东半岛早期地壳演化与矿产[M]. 北京: 地质出版社, 1988: 218-332.

    [4]

    辽宁省地质矿产局. 辽宁省区域地质志[M]. 北京: 地质出版社, 1989: 1-856.

    [5]

    白瑾. 华北陆台北缘前寒武纪地质及铅锌矿成矿作用[M]. 北京: 地质出版社, 1993: 102-104.

    [6]

    刘文军, 翟明国, 李永刚. 胶东莱西地区基性高压麻粒岩的变质作用[J]. 岩石学报, 1998, 14(4): 449-459.

    [7]

    Zhai M G, Santosh M. The Early Precambrian odyssey of North China Craton: A synoptic overview[J]. Gondwana Research, 2011, 20(1): 6-25. doi: 10.1016/j.gr.2011.02.005

    [8]

    Zhai M G, Santosh M. Metallogeny of the North China Craton: Link with secular changes in the evolving Earth[J]. Gondwana Research, 2013, 24: 275-297. doi: 10.1016/j.gr.2013.02.007

    [9]

    Zhao G C, Cawood P A, Li S Z, et al. Amalgamation of the North China Craton: key issues and discussion[J]. Precambrian Research, 2012, 222/223: 56-76. http://www.sciencedirect.com/science/article/pii/S0301926812002318

    [10]

    杨振升, 李三忠, 刘永江. 大陆造山带中的隆-滑构造: 一种前造山期伸展构造形式[J]. 长春地质学院学报, 1995, 25(4): 361-367. https://www.cnki.com.cn/Article/CJFDTOTAL-CCDZ504.000.htm

    [11]

    Peng Q M, Palmer M R. The Palaeoproterozoic boron deposits in eastern Liaoning, China: a metamorphosed evaporite[J]. Precambrian Research, 1995, 72(3/4): 185-197. http://www.sciencedirect.com/science/article/pii/0301926894000878

    [12]

    陈荣度, 李显东, 张福生. 对辽东古元古代地质若干问题的讨论[J]. 中国地质, 2003, 30(2): 207-213. doi: 10.3969/j.issn.1000-3657.2003.02.015

    [13]

    Li S Z, Zhao G C, Sun M, et al. Deformation history of the Paleoproterozoic Liaohe assemblage in the Eastern Block of the North China Craton[J]. Journal of Asian Earth Sciences, 2005, 24(5): 659-674. doi: 10.1016/j.jseaes.2003.11.008

    [14]

    Li S Z, Zhao G C, Santosh M, et al. Palaeoproterozoic tectonothermal evolution and deep crustal processes in the Jiao-Liao-Ji Belt, North China Craton: a review[J]. Geological Journal, 2011, 46: 525-543. doi: 10.1002/gj.1282

    [15]

    白瑾, 黄学光, 郭进京, 等. 中国前寒武纪地壳演化(第二版)[M]. 北京: 地质出版社, 1996: 65-79.

    [16]

    贺高品, 叶慧文. 辽东-吉南地区早元古代两种类型变质作用及其构造意义[J]. 岩石学报, 1998, 14(2): 152-162. doi: 10.3321/j.issn:1000-0569.1998.02.003

    [17]

    Faure M, Lin W, Monié P, et al. Paleoproterozoic arc magmatism and collision in Liaodong Peninsula(north-east China)[J]. Terra Nova, 2004, 16(2): 75-80. doi: 10.1111/j.1365-3121.2004.00533.x

    [18]

    Lu X P, Wu F Y, Guo J H, et al. Zircon U-Pb geochronological constraints on the Paleoproterozoic crustal evolution of the Eastern block in the North China Craton[J]. Precambrian Research, 2006, 146(3/4): 138-164. http://www.sciencedirect.com/science/article/pii/S0301926806000210

    [19]

    王惠初, 陆松年, 初航, 等. 辽阳河栏地区辽河群中变质基性熔岩的锆石U-Pb年龄与形成构造背景[J]. 吉林大学学报(地球科学版), 2011, 41(5): 1322-1334. https://www.cnki.com.cn/Article/CJFDTOTAL-CCDZ201105007.htm

    [20]

    王惠初, 任云伟, 陆松年, 等. 辽吉古元古代造山带的地层单元划分与构造属性[J]. 地球学报, 2015, 36(5): 583-598. https://www.cnki.com.cn/Article/CJFDTOTAL-DQXB201505010.htm

    [21]

    Xu W, Liu F. Geochronological and geochemical insights into the tectonic evolution of the Paleoproterozoic Jiao-Liao-Ji Belt, Sino-Korean Craton[J]. Earth-Science Reviews, 2019, 193: 162-198. doi: 10.1016/j.earscirev.2019.04.019

    [22]

    曹国权, 王致本, 张成基. 山东沂沭断裂带以东前寒武纪地层研究动态[J]. 山东地质, 1991, 7(2): 123-131. https://www.cnki.com.cn/Article/CJFDTOTAL-SDDI199102010.htm

    [23]

    张增奇, 宋志勇. 鲁东前寒武纪岩石地层清理意见[J]. 山东地质, 1994, 10(B06): 14-27. https://www.cnki.com.cn/Article/CJFDTOTAL-SDDI4S1.002.htm

    [24]

    山东地质矿产开发局. 山东省区域地质志[M]. 北京: 地质出版社, 1991: 1-594.

    [25]

    卢良兆, 徐学纯, 刘福来. 中国北方早前寒武纪孔兹岩系[M]. 长春: 长春出版社, 1996: 219-230.

    [26]

    Zhao R, Wang, Q F, Liu X F, et al. Architecture of the Sulu crustal suture between the North China Craton and Yangtze Craton: Constraints from Mesozoic granitoids[J]. Lithos, 2016, 266/267: 348-361. doi: 10.1016/j.lithos.2016.10.018

    [27]

    Zhao R, Wang Q F, Deng J, et al. Characterizing episodic orogenesis and magmatism in eastern China based on detrital zircon from the Jiaolai Basin[J]. American Journal of Science, 2019, 319(6): 500-525. doi: 10.2475/06.2019.03

    [28]

    朱光, 徐嘉炜. 鲁东胶北地区的变形与变质演化史[J]. 合肥工业大学学报(自然科学版), 1994, 17(3): 148-162. https://www.cnki.com.cn/Article/CJFDTOTAL-HEFE403.027.htm

    [29]

    Jahn B M, Liu D Y, Wan Y S, et al. Archean crustal evolution of the Jiaodong Peninsula, China, as revealed by zircon SHRIMP geochronology, elemental and Nd-isotope geochemistry[J]. American Journal of Science, 2008, 308(3): 232-269. doi: 10.2475/03.2008.03

    [30]

    Wu M L, Zhao G C, Sun M, et al. Zircon U-Pb geochronology and Hf isotopes of major lithologies from the Jiaodong Terrane: Implications for the crustal evolution of the Eastern Block of the North China Craton[J]. Lithos, 2014, 190/191: 71-84. doi: 10.1016/j.lithos.2013.12.004

    [31]

    Jiang N, Guo J H, Fan W B, et al. Archean TTGs and sanukitoids from the Jiaobei terrain, North China craton: Insights into crustal growth and mantle metasomatism[J]. Precambrian Research, 2016, 281: 656-672. doi: 10.1016/j.precamres.2016.06.019

    [32]

    Shan H X, Zhai M G, Oliveira E P, et al. Convergent margin magmatism and crustal evolution during Archean-Proterozoic transition in the Jiaobei terrane: Zircon U-Pb ages, geochemistry, and Nd isotopes of amphibolites and associated grey gneisses in the Jiaodong complex, North China Craton[J]. Precambrian Research, 2015, 264: 98-118. doi: 10.1016/j.precamres.2015.04.008

    [33]

    万渝生, 宋志勇, 王来明, 等. 华北克拉通太古宙典型地区栖霞县幅1: 5万地质图修编——野外地质调查和SHRIMP锆石U-Pb定年[J]. 地质通报, 2017, 36(11): 1927-1941. doi: 10.3969/j.issn.1671-2552.2017.11.004 http://dzhtb.cgs.cn/gbc/ch/reader/view_abstract.aspx?file_no=20171104&flag=1

    [34]

    万渝生, 郭瑞朋, 田京祥, 等. 华北克拉通胶东莱州地区中太古代-新太古代早期TTG岩石的发现——锆石SHRIMP U-Pb定年[J]. 山东国土资源, 2019, 35(4): 1-16. https://www.cnki.com.cn/Article/CJFDTOTAL-SDDI201904001.htm

    [35]

    Liu J H, Liu F L, Ding Z J, et al. The growth, reworking and metamorphism of early Precambrian crust in the Jiaobei terrane, the North China Craton: constraints from U-Th-Pb and Lu-Hf isotopic systematics, and REE concentrations of zircon from Archean granitoid gneisses[J]. Precambrian Research, 2013, 224: 287-303. doi: 10.1016/j.precamres.2012.10.003

    [36]

    Tang J, Zheng Y F, Wu Y B, et al. Geochronology and geochemistry of metamorphic rocks in the Jiaobei terrane: Constraints on its tectonic affinity in the Sulu orogen[J]. Precambrian Research, 2007, 152(1/2): 48-82. http://www.sciencedirect.com/science/article/pii/S0301926806002191

    [37]

    Wan Y S, Liu D Y, Dong C Y, et al. U-Th-Pb behavior of zircons under high-grade metamorphic conditions: A case study of zircon dating of meta-diorite near Qixia, eastern Shandong[J]. Geoscience Frontiers, 2011, 2(2): 37-146. http://d.wanfangdata.com.cn/Periodical_dxqy-e201102003.aspx

    [38]

    Wang W, Zhai M G, Li T S, et al. Archean-Paleoproterozoic crustal evolution in the eastern North China Craton: Zircon U-Th-Pb and Lu-Hf evidence from the Jiaobei terrane[J]. Precambrian Research, 2014, 141: 146-160. http://www.sciencedirect.com/science/article/pii/S0301926813003525

    [39]

    Xie S W, Qie H Q, Wang S J, et al. Ca. 2.9 Ga granitoid magmatism in eastern Shandong, North China Craton: Zircon dating, Hf-in-zircon isotopic analysis and whole-rock geochemistry[J]. Precambrian Research, 2014, 255: 534-562. http://www.sciencedirect.com/science/article/pii/S0301926814003222

    [40]

    Yao J C, Wang W, Liu S W, et al. Crust-mantle geodynamic origin of ~2.7 Ga granitoid diversification in the Jiaobei terrane, North China Craton[J]. Precambrian Research, 2020, 346: 1-22. http://www.sciencedirect.com/science/article/pii/S0301926819306035

    [41]

    Liu P H, Liu F L, Liu C H, et al. Petrogenesis, P-T-t path, and tectonic significance of high-pressure mafic granulites from the Jiaobei terrane, North China Craton[J]. Precambrian Research, 2013, 233: 237-258. doi: 10.1016/j.precamres.2013.05.003

    [42]

    Li S Z, Zhao G C, Santosh M, et al. Paleoproterozoic structural evolution of the southern segment of the Jiao-Liao-Ji Belt, North China Craton[J]. Precambrian Research, 2012, 200/203: 59-73. doi: 10.1016/j.precamres.2012.01.007

    [43]

    Wu M L, Zhao G C, Sun M, et al. Petrology and P-T path of the Yishui mafic granulites: implications for tectonothermal evolution of the Western Shandong Complex in the Eastern Block of the North China Craton[J]. Precambrian Research, 2012, 222/223: 312-324. doi: 10.1016/j.precamres.2011.08.008

    [44]

    Liu P H, Liu F L, Yang H, et al. Protolith ages and timing of peak and retrograde metamorphism of the high pressure granulites in the Shandong Peninsula, eastern North China Craton[J]. Geosciences Frontiers, 2012, 3(6): 923-943. doi: 10.1016/j.gsf.2012.04.001

    [45]

    刘喜山. 大青山造山带中基底再造杂岩的特征及其指示意义[J]. 岩石学报, 1994, 10(4): 413-426. doi: 10.3321/j.issn:1000-0569.1994.04.005

    [46]

    Liu P H, Liu F L, Liu C H, et al. Multiple mafic magmatic and high-grade metamorphic events revealed by zircons from meta-mafic rocks in the Daqingshan-Wulashan Complex of the Khondalite Belt, North China Craton[J]. Precambrian Research, 2014, 246: 334-357. doi: 10.1016/j.precamres.2014.02.015

    [47]

    董春艳, 王世进, 刘敦一, 等. 华北克拉通古元古代晚期地壳演化和荆山群形成时代制约——胶东地区变质中-基性侵入岩锆石SHRIMP U-Pb定年[J]. 岩石学报, 2011, 27(6): 1699-1706. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201106011.htm

    [48]

    刘平华, 刘福来, 王舫, 等. 胶北西留古元古代~2.1 Ga变辉长岩岩石学与年代学初步研究[J]. 岩石学报, 2013, 29(7): 2371-2390. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201307009.htm

    [49]

    Liu J H, Liu F L, Ding Z J, et al. Geochronology, petrogenesis and tectonic implications of Paleoproterozoic granitoid rocks in the Jiaobei Terrane, North China Craton[J]. Precambrian Research, 2014, 255: 685-698. doi: 10.1016/j.precamres.2013.12.004

    [50]

    Liu L S, Liu F L, Santosh M, et al. Paleoproterozoic and Triassic metamorphic events in the Jiaobei terrane, Jiao-Liao-Ji Belt, China: Hidden clues on multiple metamorphism and new insights into complex tectonic evolution[J]. Gondwana Research, 2018, 60: 105-128. doi: 10.1016/j.gr.2018.04.008

    [51]

    Lan T G, Fan H R, Yang K F, et al. Geochronology, mineralogy and geochemistry of alkali-feldspar granite and albite granite association from the Changyi area of Jiao-Liao-Ji Belt: implications for Paleoproterozoic rifting of eastern North China Craton[J]. Precambrian Research, 2015, 266: 86-107. doi: 10.1016/j.precamres.2015.04.021

    [52]

    Li Y L, Zhang H F, Guo J H, et al. Petrogenesis of the Huili Paleoproterozoic leucogranite in the Jiaobei Terrane of the North China Craton: A highly fractionated albite granite forced by K-feldspar fractionation[J]. Chemical Geology, 2017, 450: 165-182. doi: 10.1016/j.chemgeo.2016.12.029

    [53]

    Cheng S B, Liu Z J, Wang Q F, et al. SHRIMP zircon U-Pb dating and Hf isotope analyses of the Muniushan Monzogranite, Guocheng, Jiaobei Terrane, China: Implications for the tectonic evolution of the Jiao-Liao-Ji Belt, North China Craton[J]. Precambrian Research, 2017, 301: 37-48. http://www.sciencedirect.com/science/article/pii/S0301926817301729

    [54]

    朱光, 徐嘉炜, Fitc W R, 等. 胶北蓬莱群的同位素年龄及其区域大地构造意义[J]. 地质学报, 1994, 68(2): 158-172. https://www.cnki.com.cn/Article/CJFDTOTAL-DZXE199402004.htm

    [55]

    Liu J H, Liu F L, Ding Z J, et al. U-Pb dating and Hf isotope study of detrital zircons from the Zhifu Group, Jiaobei Terrane, North China Craton: provenance and implications for Precambrian crustal growth and recycling[J]. Precambrian Research, 2013, 235: 230-250. doi: 10.1016/j.precamres.2013.06.014

    [56]

    Li X H, Chen F K, Guo J H, et al. South China provenance of the lower-grade Penglai Group north of the Sulu UHP orogenic belt, eastern China: Evidence from detrital zircon ages and Nd-Hf isotopic composition[J]. Geochemical Journal, 2007, 41(1): 29-45. doi: 10.2343/geochemj.41.29

    [57]

    初航, 陆松年, 王惠初, 等. 山东长岛地区蓬莱群辅子夼组碎屑锆石年龄谱研究[J]. 岩石学报, 2011, 7(4): 1017-1028 https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201104013.htm

    [58]

    曹汇, Vervoort J, 王达, 等. 胶北粉子山群石榴云母片岩的三叠纪独居石年龄及其地质意义[J]. 岩石学报, 2016, 32(12): 3800-3816. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201612016.htm

    [59]

    Hu Z C, Liu Y S, Chen L, et al. Contrasting matrix induced elemental fractionation in NIST SRM and rock glasses during laser ablation ICP-MS analysis at high spatial resolution[J]. Journal of Analytical Atomic Spectrometry, 2011, 26(2): 425-430. doi: 10.1039/C0JA00145G

    [60]

    Liu Y S, Hu Z C, Zong K Q, et al. Reappraisement and refinement of zircon U-Pb isotope and trace element analyses by LA-ICP-MS[J]. Chinese Science Bulletin, 2010, 55(15): 1535-1546. doi: 10.1007/s11434-010-3052-4

    [61]

    Liu Y S, Gao S, Hu Z C, et al. Continental and oceanic crust recycling-induced melt-peridotite interactions in the Trans-North China Orogen: U-Pb dating, Hf isotopes and trace elements in zircons from mantle xenoliths[J]. Journal of Petrology, 2010, 51(1/2): 537-571. http://ci.nii.ac.jp/naid/10030175250

    [62]

    Wu Y B, Zheng Y F. Genesis of zircon and its constraints on interpretation of U-Pb age[J]. Chinese Science Bulletin, 2004, 49(16): 1589-1604. doi: 10.1360/csb2004-49-16-1589

    [63]

    Sun S S, McDonough W F. Chemical and Isotopic Systematics of Oceanic Basalts: Implications for Mantle Composition and Processes[J]. Geological Society, London, Special Publications, 1989, 42(1): 313-345. doi: 10.1144/GSL.SP.1989.042.01.19

    [64]

    Hoskin P W O, Ireland T R. Rare earth element chemistry of zircon and its use as a provenance indicator[J]. Geology, 2000, 28: 627-630. doi: 10.1130/0091-7613(2000)28<627:REECOZ>2.0.CO;2

    [65]

    Hoskin P W O, Kinny P D, Wyborn D, et al. Identifying accessory mineral saturation during differentiation in granitoid magmas: an integrated approach[J]. Journal of Petrology, 2000, 41(9): 1365-1396. doi: 10.1093/petrology/41.9.1365

    [66]

    Rubatto D. Zircon trace element geochemistry: Partitioning with garnet and the link between U-Pb ages and metamorphism[J]. Chemical Geology, 2002, 184: 123-138. doi: 10.1016/S0009-2541(01)00355-2

    [67]

    曹国权, 王致本, 张成基. 山东沂沭断裂带以东前寒武纪地层研究动态[J]. 山东地质, 1991, 7(2): 123-131. https://www.cnki.com.cn/Article/CJFDTOTAL-SDDI199102010.htm

    [68]

    林润生, 于志臣. 山东胶北隆起区荆山群[J]. 山东地质, 1988, 4(1): 4-24. https://www.cnki.com.cn/Article/CJFDTOTAL-SDDI198801000.htm

    [69]

    刘平华, 刘福来, 王舫, 等. 山东半岛荆山群富铝片麻岩锆石U-Pb定年及其地质意义[J]. 岩石矿物学杂志, 2011, 30(5): 829-843. doi: 10.3969/j.issn.1000-6524.2011.05.007

    [70]

    Zou Y, Zhai M, Zhou L, et al. Relics of a Paleoproterozoic orogen: new petrological, phase equilibria and geochronological studies on high-pressure pelitic granulites from the Pingdu-Laiyang areas, southwest of the Jiaobei terrane, North China Craton[J]. Precambrian Research, 2019, 322: 136-159. doi: 10.1016/j.precamres.2018.12.011

    [71]

    Hoskin P W O. Trace-element composition of hydrothermal zircon and the alteration of Hadean zircon from the Jack Hills, Australia[J]. Geochimica et Cosmochimica Acta, 2005, 69: 637-648. doi: 10.1016/j.gca.2004.07.006

    [72]

    刘建辉, 刘福来, 刘平华, 等. 胶北地体早前寒武多期岩浆、变质事件的LA-ICP-MS锆石U-Pb年代学证据及其地质意义[J]. 岩石学报, 2011, 14(1): 135-143.

    [73]

    冯波, 李红梅, 魏兴亮, 等. 胶东郭城地区牧牛山岩体年代学研究及其地质意义[J]. 黄金, 2013, 34(4): 24-28. https://www.cnki.com.cn/Article/CJFDTOTAL-HJZZ201304007.htm

    [74]

    王惠初, 康健丽, 任云伟, 等. 华北克拉通~2.7Ga的BIF: 来自莱州-昌邑地区含铁建造的年代学证据[J]. 岩石学报, 2015, 31(10): 2991-3011. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201510009.htm

    [75]

    田瑞聪, 李大鹏, 侯建华, 等. 胶东昌邑地区古元古代二长花岗岩锆石U-Pb定年、Hf同位素组成及其构造岩浆演化意义[J]. 地质学报, 2017, 91(12): 2710-2726. doi: 10.3969/j.issn.0001-5717.2017.12.009

    [76]

    Xu W, Liu F, Liu P, et al. Paleoproterozoic transition in tectonic regime recorded by the Eastern Block of the North China Craton: evidence from detrital zircons of the Langzishan Formation, Jiao-Liao-Ji Belt[J]. International Geology Review, 2020, (62)2: 168-185.

    [77]

    谢士稳, 王世进, 颉颃强, 等. 华北克拉通胶东地区粉子山群碎屑锆石SHRIMP U-Pb定年[J]. 岩石学报, 2014, 30(10): 2989-2998. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201410014.htm

    [78]

    肖志斌, 王惠初, 康健丽, 等. 胶东昌邑地区新太古代石英岩的锆石U-Pb年代学和Hf同位素特征及其地质意义[J]. 岩石学报, 2017, 33(9): 2925-2938. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201709017.htm

    [79]

    Zhang W, Liu F L, Cai J, et al. Geochemistry, zircon U-Pb dating and tectonic implications of the Palaeoproterozoic Ji'an and Laoling groups, northeastern Jiao-Liao-Ji Belt, North China Craton[J]. Precambrian Research, 2018, 314: 264-287. doi: 10.1016/j.precamres.2018.06.010

    [80]

    Wang F, Liu F L, Schertl H P, et al. Detrital zircon U-Pb geochronology and Hf isotopes of the Liaohe Group, Jiao-Liao-Ji Belt: Implications for the Paleoproterozoic tectonic evolution[J]. Precambrian Research, 2020, 340: doi.org/10.1016/j.precamres.2020.105633. doi: 10.1016/j.precamres.2020.105633

    • 相关文章
  • 施引文献
  • 资源附件(0)
  • 加载中

图(10)

表(2)

计量
  • 文章访问数:  1679
  • PDF下载数:  12
  • 施引文献:  0
出版历程
收稿日期:  2020-08-10
修回日期:  2020-10-05
刊出日期:  2021-01-15

目录

    版权所有：中国地质调查局发展研究中心 copyright @2020
    返回
