云开地区早古生代竹雅-石板辉长岩锆石U-Pb定年与Lu-Hf同位素特征

,  ,  ,

文章导航 > 地质通报 > 2017 > 36(5): 726-737

上一篇

下一篇

周岱, 龙文国, 王磊, 贾小辉. 云开地区早古生代竹雅-石板辉长岩锆石U-Pb定年与Lu-Hf同位素特征[J]. 地质通报, 2017, 36(5): 726-737.
引用本文: 周岱, 龙文国, 王磊, 贾小辉. 云开地区早古生代竹雅-石板辉长岩锆石U-Pb定年与Lu-Hf同位素特征[J]. 地质通报, 2017, 36(5): 726-737.
shu
ZHOU Dai, LONG Wenguo, WANG Lei, JIA Xiaohui. Geochronology and Lu-Hf isotope of Early Paleozoic Zhuya-Shiban gabbros in Yunkai terrane, South China[J]. Geological Bulletin of China, 2017, 36(5): 726-737.
Citation: ZHOU Dai, LONG Wenguo, WANG Lei, JIA Xiaohui. Geochronology and Lu-Hf isotope of Early Paleozoic Zhuya-Shiban gabbros in Yunkai terrane, South China[J]. Geological Bulletin of China, 2017, 36(5): 726-737.
shu

云开地区早古生代竹雅-石板辉长岩锆石U-Pb定年与Lu-Hf同位素特征

  • 1.

    中国地质调查局武汉地质调查中心, 湖北 武汉 430205

  • 2.

    中国地质调查局花岗岩成岩成矿地质研究中心, 湖北 武汉 430205

  • 基金项目:
    中国地质调查局项目《信宜-增城-龙川构造混杂岩带研究》（编号：12120114039201）、《桂东-粤西成矿带云开-抱板地区地质矿产调查》（编号：121201009000150011）和国家自然科学基金项目《粤北罗岗钾玄质侵入岩的岩石成因及其动力学意义》（批准号：41302046）
详细信息
    作者简介: 周岱(1985-), 男, 硕士, 助理研究员, 从事华南区域地质调查与研究。E-mail:281045030@qq.com

  • 中图分类号: P534.3;P597+.3;P588.12

Geochronology and Lu-Hf isotope of Early Paleozoic Zhuya-Shiban gabbros in Yunkai terrane, South China

  • 1.

    Wuhan Center of Geology Survey, CGS, Wuhan 430205, Hubei, China

  • 2.

    Research Center of Granitic Diagenesis and Mineralization, CGS, Wuhan 430205, Hubei, China

    摘要

  • 华夏地块西段的云开地区出露少量早古生代基性侵入岩，多以小岩株状侵入前寒武纪变质地层或与同期片麻状花岗岩共生，岩石类型主要为辉长岩和苏长辉长岩。LA-ICP-MS锆石U-Pb测年显示，信宜竹雅和高州石板辉长岩结晶年龄约为445Ma。辉长岩岩石地球化学以富MgO、CaO，相对贫TiO2为特征，具有极低的稀土元素总量（∑REE=20.8×10-6~26.6×10-6），轻稀土元素略微富集，亏损Nb、Zr、Ti、P等高场强元素。锆石εHf（t）均为弱的负值，Hf同位素一阶段模式年龄介于1.1~1.4Ga之间，显示富集地幔源区特征。构造环境分析表明，辉长岩与火山弧玄武岩相似。综合前人研究认为，华夏地块早古生代存在一系列具典型弧火山岩特征的基性岩类，这对早古生代构造运动的认识具有重要的限定作用。

    Early Paleozoic mafic intrusive rocks in Yunkai terrane commonly occur as small stocks that intruded into pre-Cambrian strata and/or contemporary gneissic granite, with main rock types being gabbro and norite gabbro.The gabbros in Zhuya and Yunlu yielded 206Pb/238U weighted age of ca.445Ma.The gabbros show relatively high MgO, CaO, low TiO2 content, very low ∑REE (20.8×10-6~26.6×10-6), weak enrichment of LREE and strong depletion of HFSE (Nb-Zr-Ti-P).Zircons give negative εHf(t) and TDM model ages from 1.1Ga to 1.4Ga, showing the features of an enriched mantle source.Tectonic setting analysis shows that the gab-bors acted like volcanic arc rocks.Previous studies show many Early Paleozoic mafic rocks in Cathaysia Block with characteristic fin-gerprints of arc volcanic rock features, and hence the Early Paleozoic geotectonic evolution history in Yunkai terrane (even Cathaysia Block) should be reconsidered.

    • HTML全文
  • 加载中

  • 图 1  云开地区地质简图

    Figure 1.

    下载: 全尺寸图片 幻灯片

    图 2  基性岩宏观（a、b）和微观（c、d）照片

    Figure 2.

    下载: 全尺寸图片 幻灯片

    图 3  岩石分类判别及岩浆系列图解（底图据参考文献[13-14]）

    Figure 3.

    下载: 全尺寸图片 幻灯片

    图 4  竹雅和石板辉长岩稀土元素球粒陨石标准化配分图（a）和微量元素蛛网图（b）

    Figure 4.

    下载: 全尺寸图片 幻灯片

    图 5  竹雅和石板辉长岩锆石U-Pb谐和图及阴极发光（CL）图像

    Figure 5.

    下载: 全尺寸图片 幻灯片

    图 6  华夏地块西部早古生代岩浆岩锆石Lu-Hf同位素特征（数据据参考文献[5, 8, 16]）（图b中辉长岩采用一阶段模式年龄，花岗岩、安山岩与英安岩采用二阶段模式年龄）

    Figure 6.

    下载: 全尺寸图片 幻灯片

    图 7  云开地区早古生代岩浆作用与中高级变质作用锆石U-Pb年龄频数图

    Figure 7.

    下载: 全尺寸图片 幻灯片

    图 8  辉长岩构造环境判别图解（底图据参考文献[24-26]）

    Figure 8.

    下载: 全尺寸图片 幻灯片

    图 9  辉长岩Ti-V和Zr-Ti构造判别图解（底图据参考文献[27-28]）

    Figure 9.

    下载: 全尺寸图片 幻灯片

    表 1  云开地区竹雅和石板辉长岩主量、微量和稀土元素分析数据

    Table 1.  Major, trace element and REE compositions of gabbros from Zhuya and Shiban in Yunkai area

    样号 1209-1 1209-2 1209-3 1209-4 1210-1 1210-2 1210-3 1210-4
    信宜竹雅辉长岩 高州石板（苏长）辉长岩
    SiO2 52.30 46.59 47.60 42.82 47.50 46.57 47.54 44.33
    TiO2 0.28 0.66 0.42 1.19 0.55 0.57 0.51 0.87
    Al2O3 5.28 18.36 16.23 16.27 17.38 17.44 17.65 15.51
    Fe2O3 2.50 3.66 2.38 5.76 2.12 3.17 2.05 3.45
    FeO 9.20 7.00 8.50 10.40 6.48 6.75 7.60 8.45
    MnO 0.26 0.15 0.21 0.19 0.15 0.17 0.19 0.21
    MgO 19.39 7.45 9.55 7.17 9.40 9.29 9.17 9.81
    CaO 8.48 12.16 10.91 12.07 12.45 11.81 12.49 12.88
    Na2O 0.56 0.96 0.93 0.84 0.92 0.76 0.76 0.91
    K2O 0.20 0.21 0.33 0.32 0.32 0.40 0.22 0.23
    P2O5 0.02 0.02 0.03 0.03 0.03 0.03 0.05 0.04
    LOST 1.78 3.56 4.52 4.29 4.49 4.92 2.28 5.21
    Total 100.25 100.78 101.60 101.35 101.79 101.88 100.51 101.90
    Mg# 79 65 67 55 72 71 68 67
    Sc 68.5 45.2 36.2 43.7 35.1 31.7 30.7 42.4
    V 215.0 471.1 272.3 963.1 220.4 264.8 212.3 339.1
    Cr 780.1 85.7 165.6 35.6 166.9 179.6 172.6 254.7
    Co 95.2 94.8 48.2 70.1 63.5 44.3 45.4 49.9
    Ni 289.6 78.8 86.6 40.2 80.7 86.2 78.5 79.1
    Cu 150.1 108.0 71.1 140.6 48.7 80.5 76.3 77.3
    Zn 77.8 72.1 88.2 90.2 68.1 69.9 79.4 128.1
    Ga 7.5 18.8 14.1 18.7 17.0 16.4 16.3 15.3
    Rb 10.8 8.9 11.5 11.5 14.0 17.9 7.6 6.6
    Sr 33.4 141.6 114.7 146.7 284.9 314.3 301.8 236.1
    Y 8.5 7.7 7.8 9.3 6.6 6.4 7.0 11.9
    Zr 22.6 19.7 18.8 18.4 17.9 14.2 17.3 13.1
    Nb 1.5 2.6 1.4 1.4 2.3 0.9 1.2 1.2
    Cs 1.2 1.5 3.5 2.2 2.4
    Ba 129.5 81.8 55.9 50.3 28.6 67.2 45.6 38.1
    La 3.0 3.5 3.4 3.2 4.1 3.3 4.0 2.7
    Cc 6.3 7.3 7.4 7.1 8.1 6.3 8.7 7.0
    Pr 0.8 1.0 1.0 1.0 1.1 1.0 1.2 1.1
    Nd 3.8 4.5 4.2 4.6 5.1 4.3 4.9 5.6
    Sm 1.0 1.1 1.2 1.3 1.2 1.1 1.3 1.7
    Eu 0.3 0.4 0.4 0.5 0.5 0.4 0.4 0.6
    Gd 1.2 1.3 1.2 1.5 1.2 1.2 1.3 2.0
    Tb 0.2 0.2 0.2 0.3 0.2 0.2 0.2 0.4
    Dy 1.5 1.4 1.4 1.7 1.3 1.2 1.3 2.3
    Ho 0.3 0.3 0.3 0.3 0.2 0.2 0.3 0.4
    Er 1.0 0.9 0.8 0.9 0.8 0.6 0.7 1.2
    Tm 0.2 0.1 0.1 0.1 0.1 0.1 0.1 0.2
    Yb 1.1 0.9 0.8 1.0 0.8 0.7 0.8 1.2
    Lu 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.2
    Hf 1.0 0.8 0.6 0.6 0.8 0.5 0.6 0.6
    Ta 0.2 0.9 0.1 0.1 2.8 0.1 0.1 0.1
    Tl 0.1 0.1 0.1 0.0 0.0
    Pb 2.4 1.4 3.4 3.4 2.7 3.6 3.0 2.1
    Th 1.4 1.1 1.3 1.1 0.7 0.5 1.3 0.5
    U 0.3 0.1 0.3 0.2 0.1 0.1 0.3 0.1
    ∑REE 21.0 23.1 22.6 23.6 24.9 20.8 25.4 26.6
    (La/Sm)N 1.9 2.0 1.8 1.6 2.1 1.9 2.0 1.0
    (La/Yb)N 2.0 2.8 2.9 2.4 3.7 3.6 3.8 1.6
    Eu* 0.8 1.1 1.0 1.0 1.2 1.1 1.1 1.0
      注：主量元素含量单位为%，稀土和微量元素含量单位为10-6；Mg#=100×Mg/(Mg+Fe2+)
    下载: 导出CSV

    表 2  云开地区竹雅辉长岩LA-ICP-MS锆石U-Th-Pb同位素分析结果

    Table 2.  LA-ICP-MS zircon U-Th-Pb analytical data of gabbros from Zhuya in Yunkai area

    分析点号 含量/10-6 Th/U 同位素比值 同位素年龄/Ma
    Th U 207Pb/206Pb 1σ 207Pb/235U 1σ 206Pb/238U 1σ 207Pb/206Pb 1σ 207Pb/235U 1σ 206Pb/238U 1σ
    1209-1 1469 1406 1.05 0.05637 0.00187 0.2146 0.0067 0.02761 0.00054 467 75 197 6 176 3
    1209-2 226 1251 0.18 0.08857 0.00082 2.950 0.030 0.2416 0.0037 1395 18 1395 8 1395 19
    1209-3 725 765 0.95 0.05646 0.00131 0.5841 0.0129 0.07504 0.00130 471 53 467 8 466 8
    1209-4 714 465 1.54 0.06495 0.00177 1.145 0.029 0.1279 0.0024 773 59 775 14 776 14
    1209-5 1325 1361 0.97 0.05053 0.00154 0.1864 0.0054 0.02675 0.00049 219 72 174 5 170 3
    1209-6 308 1264 0.24 0.10695 0.00456 2.473 0.098 0.1677 0.0027 1748 80 1264 29 1000 15
    1209-7 744 432 1.72 0.05924 0.00241 0.5903 0.0223 0.07228 0.00161 576 91 471 14 450 10
    1209-8 947 1722 0.55 0.09141 0.00068 3.182 0.028 0.2525 0.0038 1455 14 1453 7 1451 20
    1209-9 1523 814 1.87 0.05582 0.00158 0.5534 0.0147 0.07190 0.00135 445 64 447 10 448 8
    1209-10 388 305 1.27 0.05680 0.00270 0.5537 0.0246 0.07071 0.00168 484 108 447 16 440 10
    1209-11 305 327 0.93 0.05669 0.00159 0.5540 0.0148 0.07089 0.00132 479 63 448 10 442 8
    1209-12 423 308 1.37 0.07743 0.00207 0.7683 0.0190 0.07197 0.00140 1132 54 579 11 448 8
    1209-13 525 435 1.21 0.05573 0.00109 0.5504 0.0105 0.07163 0.00121 442 45 445 7 446 7
    1209-14 292 227 1.29 0.06770 0.00188 0.6738 0.0176 0.07220 0.00138 859 59 523 11 449 8
    1209-15 1428 785 1.82 0.08352 0.00122 0.8210 0.0117 0.07130 0.00119 1281 29 609 7 444 7
    1209-16 483 604 0.80 0.04998 0.00201 0.1929 0.0073 0.02800 0.00059 194 95 179 6 178 4
    1209-17 237 237 1.00 0.05610 0.00202 0.5520 0.0187 0.07137 0.00148 456 82 446 12 444 9
    1209-18 1372 752 1.83 0.06108 0.00130 0.6257 0.0127 0.07430 0.00132 642 47 493 8 462 8
    1209-19 250 203 1.23 0.05566 0.00248 0.5408 0.0225 0.07047 0.00163 439 102 439 15 439 10
    1209-20 179 186 0.96 0.05556 0.00220 0.5501 0.0206 0.07182 0.00153 435 90 445 13 447 9
    下载: 导出CSV

    表 3  云开地区石板辉长岩LA-ICP-MS锆石U-Th-Pb分析结果

    Table 3.  LA-ICP-MS zircon U-Th-Pb analytical data of gabbros from Shiban in Yunkai area

    分析点号 含量/10-6 Th/U 同位素比值 同位素年龄/Ma
    Th U 207Pb/206Pb 1σ 207Pb/235U 1σ 206Pb/238U 1σ 207Pb/206Pb 1σ 207Pb/235U 1σ 206Pb/238U 1σ
    1210-1 881 674 1.31 0.05947 0.00120 0.5822 0.0113 0.07104 0.00116 584 45 466 7 442 7
    1210-2 2698 3%3 0.68 0.05732 0.00057 0.5726 0.0062 0.07249 0.00107 504 22 460 4 451 6
    1210-3 1048 759 1.38 0.06558 0.00151 0.6550 0.0142 0.07248 0.00125 793 49 512 9 451 8
    1210-4 2168 2532 0.86 0.05881 0.00070 0.5956 0.0073 0.07348 0.00111 560 27 474 5 457 7
    1210-5 427 336 1.27 0.05845 0.00169 0.5624 0.0155 0.06982 0.00123 547 65 453 10 435 7
    1210-6 531 411 1.29 0.03024 0.00153 0.2858 0.0143 0.06858 0.00117 -273 68 255 11 428 7
    1210-7 380 530 0.72 0.05571 0.00160 0.5349 0.0145 0.06967 0.00126 441 65 435 10 434 8
    1210-8 615 530 1.16 0.06036 0.00151 0.5979 0.0142 0.07187 0.00125 617 55 476 9 447 8
    1210-9 634 485 1.31 0.05564 0.00150 0.5332 0.0136 0.06952 0.00122 438 61 434 9 433 7
    1210-10 581 394 1.47 0.05588 0.00156 0.5479 0.0146 0.07115 0.00126 448 63 444 10 443 8
    1210-11 321 255 1.26 0.05545 0.00283 0.5222 0.0248 0.06833 0.00171 430 117 427 17 426 10
    1210-12 458 531 0.86 0.05732 0.00121 0.6373 0.0128 0.08068 0.00139 504 48 501 8 500 8
    1210-13 291 216 1.35 0.05610 0.00201 0.5706 0.0192 0.07379 0.00149 456 81 458 12 459 9
    1210-14 1038 836 1.24 0.05594 0.00112 0.5564 0.0107 0.07217 0.00123 450 46 449 7 449 7
    1210-15 191 160 1.19 0.05606 0.00214 0.5648 0.0205 0.07311 0.00148 455 87 455 13 455 9
    1210-16 584 550 1.06 0.07502 0.00154 0.7448 0.0143 0.07204 0.00127 1069 42 565 8 448 8
    1210-17 689 549 1.25 0.05648 0.00129 0.5862 0.0127 0.07532 0.00133 471 52 468 8 468 8
    1210-18 541 548 0.99 0.05643 0.00145 0.5820 0.0141 0.07483 0.00137 469 58 466 9 465 8
    1210-19 473 226 2.09 0.05610 0.00237 0.5515 0.0217 0.07133 0.00160 456 96 446 14 444 10
    1210-20 362 299 1.21 0.05536 0.00143 0.5109 0.0126 0.06697 0.00120 427 59 419 8 418 7
    下载: 导出CSV

    表 4  云开地区竹雅和石板辉长岩锆石Lu-Hf同位素组成

    Table 4.  Zircon Lu-Hf isotopic compositions of gabbros from Zhuya and Shiban in Yunkai area

    年龄/M 176Yb/177Hf 176Lu/177Hf 176Hf/177Hf 2σ 176Hf/177Hfi εHf(0) εHf(t) TDM /Ga T2DM/Ga fLu/Hf
    1209-3 466 0.019549 0.000787 0.282388 0.000044 0.282381 -13.6 -3.6 1.22 1.67 -0.98
    1209-7 450 0.023178 0.000880 0.282415 0.000042 0.282407 -12.6 -3.0 1.18 1.62 -0.97
    1209-9 448 0.042697 0.001486 0.282389 0.000039 0.282377 -13.5 -4.1 1.24 1.69 -0.96
    1209-12 448 0.021612 0.000868 0.282366 0.000029 0.282359 -14.3 -4.8 1.25 1.73 -0.97
    1209-13 446 0.026636 0.000984 0.282364 0.000035 0.282355 -14.4 -4.9 1.26 1.74 -0.97
    1209-14 449 0.017491 0.000644 0.282381 0.000036 0.282376 -13.8 -4.1 1.22 1.69 -0.98
    1209-15 444 0.038846 0.001271 0.282386 0.000037 0.282376 -13.6 -4.3 1.23 1.70 -0.96
    1209-17 444 0.023793 0.000838 0.282440 0.000032 0.282433 -11.7 -2.2 1.14 1.57 -0.97
    1209-18 462 0.027732 0.000971 0.282391 0.000030 0.282383 -13.5 -3.6 1.22 1.67 -0.97
    1209-19 439 0.026891 0.000985 0.282375 0.000033 0.282367 -14.0 -4.7 1.24 1.72 -0.97
    1209-20 447 0.015456 0.000580 0.282374 0.000035 0.282369 -14.1 -4.4 1.23 1.71 -0.98
    1210-1 442 0.282331 0.000270 0.008584 0.000082 0.282329 -15.6 -5.9 1.28 1.80 -0.99
    1210-2 451 0.282346 0.003443 0.104210 0.002853 0.282317 -15.1 -6.2 1.37 1.82 -0.90
    1210-4 457 0.282333 0.000631 0.018892 0.000674 0.282328 -15.5 -5.7 1.29 1.80 -0.98
    1210-5 435 0.282289 0.000577 0.018257 0.000475 0.282284 -17.1 -7.7 1.35 1.91 -0.98
    1210-7 434 0.282306 0.001595 0.051492 0.003301 0.282293 -16.5 •7.4 1.36 1.89 -0.95
    1210-8 447 0.282322 0.000772 0.022515 0.000455 0.282315 -15.9 -6.3 1.31 1.83 -0.98
    1210-9 433 0.282325 0.000600 0.018128 0.000739 0.282320 -15.8 -6.5 1.30 1.83 -0.98
    1210-10 443 0.282342 0.000400 0.013523 0.000260 0.282339 -15.2 -5.6 1.27 1.78 -0.99
    1210-11 426 0.282319 0.000317 0.009780 0.000516 0.282317 -16.0 -6.7 1.29 1.84 -0.99
    1210-13 459 0.282323 0.000364 0.012040 0.000355 0.282320 -15.9 -5.9 1.29 1.81 -0.99
    1210-14 449 0.282323 0.000906 0.028109 0.001158 0.282315 -15.9 -6.3 1.31 1.83 -0.97
    1210-15 445 0.282314 0.000267 0.008719 0.000475 0.282312 -16.2 -6.5 1.30 1.84 -0.99
    1210-17 468 0.282331 0.000579 0.017119 0.001275 0.282326 -15.6 •5.5 1.29 1.79 -0.98
    1210-18 465 0.282327 0.000966 0.024710 0.000748 0.282319 -15.7 -5.8 1.31 1.81 -0.97
    1210-19 444 0.282338 0.000420 0.015472 0.000904 0.282334 -15.3 -5.7 1.27 1.79 -0.99
    1210-20 418 0.282319 0.000406 0.014226 0.000721 0.282316 -16.0 -7.0 1.30 1.85 -0.99
    下载: 导出CSV
    • 参考文献(30)
  • [1]

    彭松柏, 金振民, 刘云华, 等.云开造山带强过铝深熔花岗岩地球化学、年代学及构造背景[J].地球科学——中国地质大学学报, 2006, 31(1):110-120. http://www.cnki.com.cn/Article/CJFDTOTAL-DQKX200601015.htm

    [2]

    Wang Y J, Fan W M, Zhao G C, et al. Zircon U-Pb geochronology of gneissic rocks in the Yunkai massif and its implications on the Caledonian event in the South China Block[J]. Gondwana Research, 2007, 12(4):404-416. doi: 10.1016/j.gr.2006.10.003

    [3]

    Li Z X, Li X H, Wartho J A, et al. Magmatic and metamorphic events during the early Paleozoic Wuyi-Yunkai orogeny, southeastern South China:New age constraints and pressure-temperature conditions[J]. Geological Society of America Bulletin, 2010, 122(5/6):772-793.

    [4]

    Zhao K D, Jiang S Y, Sun T, et al. Zircon U-Pb dating, trace element and Sr-Nd-Hf isotope geochemistry of Paleozoic granites in the Miao' ershan-Yuechengling batholith, South China:Implication for petrogenesis and tectonic-magmatic evolution[J]. Journal of Asian Earth Sciences, 2013, 25:244-264.

    [5]

    Wang Y J, Zhang A M, Fan W M, et al. Kwangsian crustal anatexis within the eastern South China Block:Geochemical, zircon U-Pb geochronological and Hf isotopic fingerprints from the gneissoid granites of Wugong and Wuyi-Yunkai Domains[J]. Lithos, 2011, 127(1/2):239-260.

    [6]

    Li X H, Li Z X, He B, et al. The Early Permian active continental margin and crustal growth of the Cathaysia Block:In situ U-Pb, Lu-Hf and O isotope analyses of detrital zircons[J]. Chemical Geology, 2012, 328:195-207. doi: 10.1016/j.chemgeo.2011.10.027

    [7]

    彭松柏, 金振民, 付建明, 等.两广云开隆起区基性侵入岩的地球化学特征及其构造意义[J].地质通报, 2006, 25(4):434-441. http://dzhtb.cgs.cn/ch/reader/view_abstract.aspx?flag=1&file_no=20060472&journal_id=gbc

    [8]

    Wang Y J, Zhang A M, Fan W M, et al. Origin of paleosubductionmodified mantle for Silurian gabbro in the Cathaysia Block:Geochronological and geochemical evidence[J]. Lithos, 2013, 160-161:37-54. doi: 10.1016/j.lithos.2012.11.004

    [9]

    Zhang Q, Jiang Y H, Wang G C, et al. Origin of Silurian gabbros and I-type granites in central Fujian, SE China:Implications for the evolution of the early Paleozoic orogen of South China[J]. Lithos, 2015, 216/217:285-297. doi: 10.1016/j.lithos.2015.01.002

    [10]

    Zhang C L, Santosh M, Zhu Q B, et al. The Gondwana connection of South China:Evidence from monazite and zircon geochronology in the Cathaysia Block[J]. Gondwana Research, 2014, 28(3):1137-1151. https://www.researchgate.net/publication/266561595_The_Gondwana_connection_of_South_China_Evidence_from_monazite_and_zircon_geochronology_in_the_Cathaysia_Block

    [11]

    Liu Y S, Zong K Q, Kelemen P B, et al. Geochemistry and magmatic history of eclogites and ultramafic rocks from the Chinese continental scientific drill hole:subduction and ultrahigh-pressure metamorphism of lower crustal cumulates[J]. Chemical Geology, 2008, 247:133-153. doi: 10.1016/j.chemgeo.2007.10.016

    [12]

    Hu Z C, Liu Y S, Gao S, et al. Improved in situ Hf isotope ratio analysis of zircon using newly designed X skimmer cone and Jet sample cone in combination with the addition of nitrogen by laser ablation multiple collector ICP-MS[J]. Journal of Analytical Atomic Spectrometry, 2012, 27:1391-1399. doi: 10.1039/c2ja30078h

    [13]

    Winchester J A, Floyd P A. Geochemical magma type discrimination:application to altered and metamorphosed basic igneous rocks[J]. Earth Planet. Sci. Lett., 1976, 28:459-469. doi: 10.1016/0012-821X(76)90207-7

    [14]

    Miyashiro A. Volcanic rock series in island arc and active continental margins[J]. Am. J. Sci., 1974, 274:321-355. doi: 10.2475/ajs.274.4.321

    [15]

    Sun S S, McDonough W F. Chemical and isotopic systematics of oceanic basalt:implications for mantle composition and processes[C]//Saundera A D, Norry M J. Magmatism in the Ocean Basins. Geol. Soc. Spec. Publ., 1989, 42:528-548.

    [16]

    Yao W H, Li Z X, Li W X, et al. Post-kinematic lithospheric delamination of the Wuyi-Yunkai orogen in South China:Evidence from ca. 435Ma high-Mg basalts[J]. Lithos, 2012, 154:115-129. doi: 10.1016/j.lithos.2012.06.033

    [17]

    覃小锋, 潘元明, 李江, 等.桂东南云开地区变质杂岩锆石SHRIMP U-Pb年代学[J].地质通报, 2006, 25(5):553-559. http://dzhtb.cgs.cn/ch/reader/view_abstract.aspx?flag=1&file_no=20060598&journal_id=gbc

    [18]

    Wang Y J, Wu C M, Zhang A M, et al. Kwangsian and Indosinian reworking of the eastern South China Block:Constraints on zircon U-Pb geochronology and metamorphism of amphibolites and granulites[J]. Lithos, 2012, 150:227-242. doi: 10.1016/j.lithos.2012.04.022

    [19]

    Wang Y J, Fan W M, Zhang G W, et al. Phanerozoic tectonics of the South China Block:Key observations and controversies[J]. Gondwana Research, 2013, 23:1273-1305. doi: 10.1016/j.gr.2012.02.019

    [20]

    Wan Y S, Liu D Y, Wilde S A, et al. Evolution of the Yunkai Terrane, South China:Evidence from SHRIMP zircon U-Pb dating, geochemistry and Nd isotope[J]. Journal of Asian Earth Sciences, 2010, 37(2):140-153. doi: 10.1016/j.jseaes.2009.08.002

    [21]

    Chen Z H, Liu Y H, Lee C Y, et al. Geochronology of granulite, charnockite and gneiss in the poly-metamorphosed Gaozhou Complex (Yunkai massif), South China:Emphasis on the in-situ EMP monazite dating[J]. Lithos, 2012, 144/145:109-129. doi: 10.1016/j.lithos.2012.04.009

    [22]

    Wang D, Zheng J P, Ma Q, et al. Early Paleozoic crustal anatexis in the intraplate Wuyi-Yunkai orogen, South China[J]. Lithos, 2013, 175/176:124-145. doi: 10.1016/j.lithos.2013.04.024

    [23]

    王磊, 龙文国, 周岱.云开地区加里东期花岗岩锆石U-Pb年龄及其地质意义[J].中国地质, 2013, 40(4):1016-1029. http://www.cnki.com.cn/Article/CJFDTOTAL-DIZI201304004.htm

    [24]

    Wood D A. The application of a Th-Hf-Ta diagram to problems of tectono-magmatic classification and to establishing the nature of crust contamination of basaltic lavas of the British Tertiary volcanic province[J]. Earth and Planetary Science Letters, 1980, 50:11-30. doi: 10.1016/0012-821X(80)90116-8

    [25]

    Meschede M. A method of discriminating between different types of mid-ocean ridge basalts and continental tholeiites with the NbZr-Y diagram[J]. Chemical Geology, 1986, 56:207-218. doi: 10.1016/0009-2541(86)90004-5

    [26]

    Cabanis B, Lecolle M. Le diagramme La/10-Y/15-Nb/8:un outil pour la discrimination des series volcaniques et la mise en evidence des processus de mé1ange et/ou de contamination crustale[J]. CR Acad. Sci. Ser. Ⅱ, 1989, 309:2023-2029. http://ci.nii.ac.jp/naid/80004995562

    [27]

    Shervais J W. Ti-V plots and the petrogenesis of modern ophiolitic lavas[J]. Earth and Planetary Science Letter, 1982, 59:101-118. doi: 10.1016/0012-821X(82)90120-0

    [28]

    Pearce JA. Trace element characteristics of lavas from destructive plate boundaries[C]//Thorpe R S. Andesites:Orogenic Andesites and Related Rocks. Wiley, Chichester, 1982:525-548.

    [29]

    覃小锋, 王宗起, 胡贵昂, 等.两广交界地区壶垌片麻状复式岩体的年代学和地球化学:对云开地块北缘早古生代构造-岩浆作用的启示[J].岩石学报, 2013, 29(9):3115-3130. http://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201309013.htm

    [30]

    陈武钦, 王漂元, 林建华.粤北始兴县城南志留纪火山岩的基本特征[J].中国西部科技, 2006, 16:29-30. doi: 10.3969/j.issn.1671-6396.2006.36.017

    • 相关文章
  • 施引文献
  • 资源附件(0)
  • 加载中

图(9)

表(4)

计量
  • 文章访问数:  1236
  • PDF下载数:  14
  • 施引文献:  0
出版历程
收稿日期:  2016-07-25
修回日期:  2017-03-07
刊出日期:  2017-05-25

目录

    版权所有：中国地质调查局发展研究中心 copyright @2020
    返回
