U-Pb age and Hf isotope composition of detrital zircons from the Chengjiang Formation in Dongchuan area, Yunnan Province of the western Yangtze Block and its constraints on provenance and crustal evolution
-
摘要:
澄江组是晋宁不整合面之上最早沉积的地层之一，了解其物源对于认识扬子西缘早期地壳演化具有重要意义。对扬子西缘东川地区澄江组底部碎屑锆石进行了U-Pb定年和Lu-Hf同位素分析。结果显示，澄江组碎屑锆石的年龄谱具有780~900 Ma、约1000 Ma、约1800 Ma的峰值，最年轻一组碎屑锆石年龄加权平均值为801±5 Ma（MSWD=2.4，n=9），与区内澄江组底部火山岩的年龄十分接近，限定研究区澄江组的沉积下限为约800 Ma。综合碎屑锆石U-Pb年龄和Hf同位素组成、锆石形态及古地理特征，认为东川地区澄江组底部的物源主要来自于扬子地块西缘新元古代岩浆岩的剥蚀，其次为东川群的沉积再循环。通过扬子地块南华纪早期地层的区域对比发现，扬子西缘与北缘在新元古代之前可能具有不同的地壳演化历史。扬子西缘不同地区澄江组之间存在物源差异，与区域构造活动密切相关。
Abstract:The Chengjiang Formation is one of the earliest stratigraphic units above the Jinning unconformity.Determining the sources is of great significance for the understanding of the early crustal evolution in the western Yangtze Block.U-Pb dating and Lu-Hf isotopic composition studies were carried out on the detrital zircons from the Lower Chengjiang Formation in the Dongchuan area of the western Yangtze Block.The U-Pb ages of the zircons are clustered at 780~900 Ma, ~1000 Ma and~1800 Ma respectively, and the weighted mean age of the youngest group is 801±5 Ma(MSWD=2.4, n=9), which is consistent with the volcanic age of the Lower Chengjiang Formation.Thus, it is further confirmed that the lower age of the Chengjiang Formation should be limited at~800 Ma.Combined with the U-Pb age and Hf isotopic composition, zircon morphology and paleogeography, it is believed that the detritus was largely sourced from the widely distributed Neoproterozoic magmatic rock in the western Yangtze Block, and a small part from the recycled materials of the Dongchuan Group.Regional comparison of the early Nanhua strata of the Yangtze Block indicates that the western and northern margins of the Yangtze Block show different crustal evolution history.The provenance differences of the Chengjiang Formation in different regions of the western margin of the Yangtze are closely related to regional tectonic activities.
-
Key words:
- western Yangtze Block /
- Chengjiang Formation /
- detrital zircon /
- Hf isotope /
- crustal evolution /
- Dongchuan
-
-
表 1 东川地区澄江组底部碎屑锆石U-Th-Pb同位素数据
Table 1. U-Th-Pb isotopic data of detrital zircons from the bottom of the Chengjiang Formation in the Dongchuan area
分析点 元素/10-6 Th/U 同位素比值 年龄/Ma 谐和度 Th U 207Pb/206Pb 1σ 207Pb/235U 1σ 206Pb/238U 1σ 207Pb/206Pb 1σ 207Pb/235U 1σ 206Pb/238U 1σ PM31-1-1 99.1 201 0.49 0.0703 0.0026 1.4829 0.0507 0.1544 0.0021 1000 76 923 21 925 11 99% PM31-1-2 477 493 0.97 0.0673 0.0016 1.2740 0.0311 0.1368 0.0012 856 51 834 14 827 7 99% PM31-1-3 591 995 0.59 0.0683 0.0015 1.3051 0.0295 0.1379 0.0012 876 44 848 13 833 7 98% PM31-1-4 776 1282 0.61 0.0696 0.0014 1.4491 0.0290 0.1508 0.0013 917 43 910 12 905 7 99% PM31-1-5 637 809 0.79 0.0761 0.0017 1.8668 0.0413 0.1774 0.0014 1098 45 1069 15 1053 8 98% PM31-1-6 245 487 0.50 0.1551 0.0028 9.5969 0.1841 0.4469 0.0041 2403 31 2397 18 2381 19 99% PM31-1-7 456 768 0.59 0.0684 0.0017 1.4338 0.0387 0.1510 0.0014 880 52 903 16 906 8 99% PM31-1-8 449 632 0.71 0.0673 0.0017 1.2675 0.0332 0.1362 0.0015 856 52 831 15 823 8 99% PM31-1-9 393 406 0.97 0.0677 0.0019 1.2833 0.0366 0.1376 0.0016 861 59 838 16 831 9 99% PM31-1-10 234 991 0.24 0.0688 0.0018 1.3317 0.0365 0.1399 0.0015 894 54 860 16 844 8 98% PM31-1-11 766 1509 0.51 0.0696 0.0017 1.3441 0.0342 0.1397 0.0014 917 52 865 15 843 8 97% PM31-1-12 568 318 1.79 0.1003 0.0026 4.0739 0.1060 0.2946 0.0031 1629 48 1649 21 1664 16 99% PM31-1-13 232 558 0.42 0.0672 0.0018 1.3032 0.0350 0.1406 0.0015 843 56 847 15 848 9 99% PM31-1-14 233 538 0.43 0.0744 0.0017 1.8522 0.0439 0.1803 0.0017 1052 46 1064 16 1069 10 99% PM31-1-15 624 865 0.72 0.0666 0.0014 1.3041 0.0300 0.1413 0.0013 828 46 848 13 852 8 99% PM31-1-16 631 502 1.26 0.0671 0.0017 1.2650 0.0322 0.1368 0.0012 839 53 830 14 826 7 99% PM31-1-17 197 206 0.95 0.0639 0.0040 1.2539 0.0626 0.1354 0.0028 739 127 825 28 819 16 99% PM31-1-18 124 185 0.67 0.0650 0.0030 1.2580 0.0549 0.1330 0.0014 776 99 827 25 805 8 97% PM31-1-19 507 626 0.81 0.0658 0.0015 1.2464 0.0283 0.1369 0.0012 1200 47 822 13 827 7 99% PM31-1-20 139 1048 0.13 0.0718 0.0014 1.7437 0.0333 0.1755 0.0015 983 39 1025 12 1042 8 98% PM31-1-21 625 896 0.70 0.0656 0.0017 1.1766 0.0325 0.1296 0.0012 794 59 790 15 786 7 99% PM31-1-22 142 231 0.62 0.0676 0.0022 1.3051 0.0425 0.1403 0.0016 857 69 848 19 846 9 99% PM31-1-23 342 866 0.39 0.0661 0.0017 1.2607 0.0330 0.1376 0.0010 809 48 828 15 831 6 99% PM31-1-24 270 544 0.50 0.0677 0.0017 1.3017 0.0321 0.1393 0.0011 861 58 846 14 841 6 99% PM31-1-25 283 481 0.59 0.0626 0.0017 1.1733 0.0304 0.1357 0.0012 694 57 788 14 820 7 96% PM31-1-26 198 307 0.65 0.0655 0.0020 1.2787 0.0382 0.1414 0.0012 791 63 836 17 853 7 98% PM31-1-27 384 689 0.56 0.0664 0.0014 1.3243 0.0288 0.1445 0.0013 817 44 856 13 870 8 98% PM31-1-28 177 674 0.26 0.0736 0.0015 1.8171 0.0365 0.1786 0.0015 1031 41 1052 13 1059 8 99% PM31-1-29 283 372 0.76 0.1108 0.0022 4.9596 0.0984 0.3238 0.0028 1813 35 1812 17 1808 14 99% PM31-1-30 533 578 0.92 0.0656 0.0017 1.2897 0.0335 0.1422 0.0015 794 58 841 15 857 8 98% PM31-1-31 337 440 0.77 0.0661 0.0018 1.2633 0.0329 0.1388 0.0014 809 56 829 15 838 8 99% PM31-1-32 74.0 162 0.46 0.0694 0.0027 1.3650 0.0507 0.1438 0.0017 909 80 874 22 866 10 99% PM31-1-33 268 361 0.74 0.0678 0.0022 1.2830 0.0404 0.1375 0.0014 861 67 838 18 831 8 99% PM31-1-34 533 763 0.70 0.0664 0.0014 1.2789 0.0289 0.1391 0.0012 820 46 836 13 839 7 99% PM31-1-35 253 464 0.55 0.0661 0.0016 1.2631 0.0304 0.1383 0.0013 809 45 829 14 835 7 99% PM31-1-36 126 262 0.48 0.0676 0.0020 1.3050 0.0386 0.1399 0.0012 855 61 848 17 844 7 99% PM31-1-37 195 273 0.71 0.0655 0.0020 1.2236 0.0368 0.1356 0.0014 791 64 811 17 820 8 99% PM31-1-38 400 532 0.75 0.0669 0.0015 1.2776 0.0301 0.1378 0.0012 835 46 836 13 832 7 99% PM31-1-39 816 785 1.04 0.0958 0.0018 3.6873 0.0715 0.2776 0.0024 1544 40 1569 16 1579 12 99% PM31-1-40 167 238 0.70 0.0658 0.0024 1.2403 0.0455 0.1364 0.0016 800 78 819 21 824 9 99% PM31-1-41 399 573 0.70 0.0657 0.0017 1.2538 0.0330 0.1379 0.0013 796 54 825 15 833 8 99% PM31-1-42 417 866 0.48 0.0673 0.0015 1.2811 0.0283 0.1378 0.0012 856 47 837 13 832 7 99% PM31-1-43 254 523 0.49 0.0741 0.0018 1.7818 0.0447 0.1736 0.0015 1056 50 1039 16 1032 8 99% PM31-1-44 246 652 0.38 0.1214 0.0019 6.0992 0.1022 0.3627 0.0030 1977 28 1990 15 1995 14 99% PM31-1-45 463 901 0.51 0.1075 0.0017 4.7085 0.0807 0.3161 0.0026 1767 29 1769 14 1771 13 99% PM31-1-46 380 524 0.72 0.1862 0.0028 13.6378 0.2137 0.5292 0.0043 2709 30 2725 15 2738 18 99% PM31-1-47 1098 2083 0.53 0.0678 0.0011 1.3203 0.0225 0.1407 0.0011 863 35 855 10 849 6 99% PM31-1-48 213 449 0.47 0.0657 0.0017 1.2727 0.0330 0.1401 0.0012 798 54 834 15 845 7 98% PM31-1-49 255 502 0.51 0.0737 0.0018 1.7723 0.0439 0.1739 0.0017 1035 50 1035 16 1034 9 99% PM31-1-50 409 827 0.49 0.0661 0.0016 1.3304 0.0330 0.1454 0.0013 809 47 859 14 875 7 98% PM31-1-51 241 458 0.53 0.0695 0.0018 1.3678 0.0357 0.1424 0.0014 915 53 875 15 858 8 98% PM31-1-52 225 692 0.32 0.0729 0.0015 1.7428 0.0367 0.1730 0.0015 1011 43 1024 14 1028 8 99% PM31-1-53 328 441 0.74 0.0654 0.0018 1.2433 0.0353 0.1377 0.0014 789 62 820 16 832 8 98% PM31-1-54 168 282 0.60 0.0670 0.0021 1.2755 0.0400 0.1380 0.0015 839 65 835 18 833 9 99% PM31-1-55 562 1417 0.40 0.0744 0.0013 1.7909 0.0324 0.1739 0.0013 1052 35 1042 12 1034 7 99% PM31-1-56 309 339 0.91 0.0676 0.0018 1.3025 0.0353 0.1396 0.0013 857 62 847 16 842 7 99% PM31-1-57 333 486 0.68 0.0660 0.0016 1.2599 0.0305 0.1384 0.0012 806 52 828 14 836 7 99% PM31-1-58 248 361 0.69 0.0676 0.0018 1.2802 0.0332 0.1374 0.0013 855 (145) 837 15 830 7 99% PM31-1-59 371 453 0.82 0.0672 0.0018 1.2718 0.0336 0.1370 0.0012 844 56 833 15 827 7 99% PM31-1-60 262 424 0.62 0.0678 0.0018 1.3039 0.0331 0.1395 0.0013 861 55 847 15 842 8 99% PM31-1-61 122 1360 0.09 0.0747 0.0014 1.8172 0.0351 0.1757 0.0013 1061 39 1052 13 1043 7 99% PM31-1-62 571 828 0.69 0.0681 0.0018 1.2917 0.0389 0.1368 0.0014 872 57 842 17 826 8 98% PM31-1-63 147 192 0.77 0.0685 0.0024 1.3129 0.0446 0.1398 0.0017 883 72 851 20 843 9 99% PM31-1-64 320 361 0.89 0.1154 0.0022 5.3151 0.1047 0.3337 0.0030 1887 35 1871 17 1856 14 99% PM31-1-65 234 515 0.45 0.0666 0.0016 1.2961 0.0321 0.1408 0.0014 828 50 844 14 849 8 99% PM31-1-66 242 655 0.37 0.0658 0.0014 1.2701 0.0273 0.1398 0.0011 798 44 832 12 843 6 98% PM31-1-67 227 488 0.47 0.1866 0.0029 13.7682 0.2322 0.5339 0.0041 2712 26 2734 16 2758 17 99% PM31-1-68 450 1510 0.30 0.0659 0.0012 1.2597 0.0240 0.1385 0.0012 806 39 828 11 836 7 99% PM31-1-69 178 264 0.67 0.0654 0.0020 1.1688 0.0356 0.1303 0.0013 787 65 786 17 789 7 99% PM31-1-70 157 406 0.39 0.1127 0.0020 5.1799 0.0976 0.3335 0.0027 1843 33 1849 16 1855 13 99% PM31-1-71 628 764 0.82 0.0908 0.0017 3.1905 0.0617 0.2549 0.0021 1443 35 1455 15 1464 11 99% PM31-1-72 125 741 0.17 0.1117 0.0049 5.3436 0.3243 0.3352 0.0042 1827 80 1876 52 1863 20 99% PM31-1-73 497 594 0.84 0.0656 0.0016 1.2314 0.0323 0.1361 0.0013 794 56 815 15 823 7 99% PM31-1-74 392 615 0.64 0.0627 0.0015 1.1561 0.0296 0.1342 0.0014 698 54 780 14 812 8 96% PM31-1-75 675 824 0.82 0.0661 0.0015 1.2382 0.0310 0.1361 0.0015 809 48 818 14 823 8 99% PM31-1-76 310 506 0.61 0.0796 0.0019 2.2359 0.0563 0.2031 0.0018 1187 48 1192 18 1192 10 99% PM31-1-77 228 372 0.61 0.0663 0.0018 1.1912 0.0310 0.1304 0.0012 817 56 797 14 790 7 99% PM31-1-78 351 411 0.85 0.0648 0.0018 1.1941 0.0327 0.1336 0.0012 769 58 798 15 808 7 98% PM31-1-79 217 271 0.80 0.0656 0.0020 1.2277 0.0408 0.1351 0.0015 794 65 813 19 817 9 99% PM31-1-81 262 582 0.45 0.0663 0.0015 1.2991 0.0307 0.1415 0.0012 817 49 845 14 853 7 99% PM31-1-82 249 699 0.36 0.0653 0.0014 1.3102 0.0276 0.1453 0.0014 783 46 850 12 874 8 97% PM31-1-83 214 1704 0.13 0.0719 0.0013 1.6941 0.0297 0.1700 0.0013 983 37 1006 11 1012 7 99% PM31-1-84 550 1244 0.44 0.0649 0.0013 1.2396 0.0254 0.1377 0.0013 772 44 819 12 831 7 98% PM31-1-85 130 880 0.15 0.0709 0.0015 1.7090 0.0372 0.1736 0.0015 954 44 1012 14 1032 8 98% PM31-1-86 405 481 0.84 0.1108 0.0021 5.2868 0.1023 0.3434 0.0030 1813 34 1867 17 1903 15 98% PM31-1-87 107 1012 0.11 0.0715 0.0014 1.7002 0.0327 0.1713 0.0013 972 39 1009 12 1019 7 98% PM31-1-88 443 603 0.73 0.0660 0.0016 1.2516 0.0295 0.1371 0.0013 806 52 824 13 828 8 99% PM31-1-91 696 926 0.75 0.0647 0.0013 1.2332 0.0237 0.1375 0.0011 765 43 816 11 830 6 98% PM31-1-92 208 756 0.27 0.0720 0.0015 1.7295 0.0341 0.1732 0.0014 987 41 1020 13 1030 8 99% PM31-1-93 270 418 0.65 0.0645 0.0019 1.2370 0.0376 0.1380 0.0013 767 62 818 17 833 7 98% PM31-1-94 230 353 0.65 0.0661 0.0022 1.2713 0.0421 0.1386 0.0015 809 69 833 19 837 8 99% PM31-1-95 353 323 1.09 0.0635 0.0021 1.1767 0.0367 0.1341 0.0013 724 69 790 17 811 7 97% PM31-1-96 398 637 0.62 0.0651 0.0023 1.1835 0.0391 0.1314 0.0012 776 74 793 18 796 7 99% PM31-1-97 401 609 0.66 0.0663 0.0017 1.2989 0.0318 0.1414 0.0013 817 56 845 14 852 7 99% PM31-1-98 277 732 0.38 0.0661 0.0016 1.3252 0.0319 0.1448 0.0013 809 47 857 14 872 8 98% PM31-1-99 603 1054 0.57 0.0665 0.0014 1.3077 0.0265 0.1421 0.0013 822 44 849 12 857 7 99% PM31-1-100 674 1686 0.40 0.0662 0.0014 1.3390 0.0277 0.1461 0.0014 813 43 863 12 879 8 98%
下载: 导出CSV
表 2 东川地区澄江组底部碎屑锆石Hf同位素组成
Table 2. Hf isotope compositions of detrial zircons from the bottom of the Chengjiang Formation in the Dongchuan area
分析点(同年龄点) 176Hf/177Hf 1σ 176Lu/177Hf 1σ 176Yb/177Hf 1σ U-Pb年龄/Ma εHf(0) 1σ εHf(t) 1σ TDM1/Ma TDM2/Ma fLu/Hf PM31-1-2 0.282402 0.000023 0.001675 0.000022 0.051359 0.000779 827 -13.1 1.0 4.3 1.0 1223 1369 -0.95 PM31-1-6 0.281230 0.000028 0.000725 0.000011 0.023480 0.000349 2403 -54.5 1.1 -1.9 1.2 2798 2958 -0.98 PM31-1-11 0.282112 0.000027 0.001188 0.000012 0.041144 0.000418 843 -23.3 1.1 -5.4 1.1 1613 1911 -0.96 PM31-1-12 0.281748 0.000019 0.001050 0.000013 0.032330 0.001041 1629 -36.2 0.9 -1.1 0.9 2112 2302 -0.97 PM31-1-20 0.282143 0.000028 0.000273 0.000005 0.011212 0.000361 983 -22.3 1.1 -0.7 1.1 1533 1765 -0.99 PM31-1-28 0.282082 0.000028 0.000127 0.000006 0.005261 0.000191 1031 -24.4 1.1 -1.7 1.1 1610 1858 -1.00 PM31-1-32 0.282309 0.000045 0.000376 0.000002 0.013363 0.000218 866 -16.4 1.7 2.6 1.7 1309 1494 -0.99 PM31-1-40 0.282455 0.000026 0.001098 0.000016 0.036903 0.000785 824 -11.2 1.1 6.4 1.1 1130 1250 -0.97 PM31-1-43 0.282209 0.000029 0.001739 0.000041 0.066613 0.001092 1056 -19.9 1.1 2.2 1.2 1500 1664 -0.95 PM31-1-46 0.281108 0.000021 0.000705 0.000004 0.025493 0.000593 2709 -58.9 0.9 0.8 1.0 2961 3063 -0.98 PM31-1-51 0.282210 0.000029 0.000769 0.000003 0.027199 0.000325 858 -19.9 1.2 -1.3 1.2 1460 1702 -0.98 PM31-1-54 0.282383 0.000025 0.001019 0.000016 0.037199 0.000568 833 -13.8 1.0 4.1 1.0 1228 1384 -0.97 PM31-1-56 0.282389 0.000025 0.000992 0.000008 0.036075 0.000404 842 -13.5 1.0 4.5 1.1 1219 1367 -0.97 PM31-1-59 0.282621 0.000018 0.001103 0.000008 0.036063 0.000624 827 -5.3 0.8 12.4 0.9 895 922 -0.97 PM31-1-69 0.282428 0.000030 0.001411 0.000006 0.073072 0.001315 789 -12.2 1.2 4.5 1.2 1177 1324 -0.96 PM31-1-70 0.281450 0.000015 0.000317 0.000004 0.009838 0.000184 1843 -46.7 0.7 -6.1 0.8 2473 2738 -0.99 PM31-1-72 0.281535 0.000012 0.001402 0.000011 0.036323 0.000255 1827 -43.7 0.7 -4.7 0.8 2427 2655 -0.96 PM31-1-93 0.282454 0.000022 0.001136 0.000011 0.041723 0.000357 833 -11.2 0.9 6.6 1.0 1132 1248 -0.97 PM31-1-99 0.282342 0.000038 0.000805 0.000019 0.027064 0.000484 857 -15.2 1.4 3.3 1.5 1278 1448 -0.98 PM31-1-100 0.282171 0.000017 0.001139 0.000022 0.040795 0.001369 879 -21.3 0.8 -2.5 0.8 1530 1783 -0.97 注：锆石εHf(t)值采用相应的U-Pb年龄计算，λ=1.867×10-11/a，(176Hf/177Hf)CHUR= 0.282772，(176Lu/177Hf)CHUR = 0.0332；(76Lu/177Hf)DM= 0.0384, (176Hf/177Hf)DM = 0.28325；(176Lu/177Hf)平均地壳= 0.015
下载: 导出CSV
-
[1] Wang J, Li Z X. History of Neoproterozoic rift basins in South China: implications forRodinia break-up[J]. Precambrian Research, 2003, 122: 141-158. doi: 10.1016/S0301-9268(02)00209-7
[2] 江新胜, 王剑, 崔晓庄, 等. 滇中新元古代澄江组锆石SHRIMP U-Pb年代学研究及其地质意义[J]. 中国科学: 地球科学, 2012, 42(10): 1496-1507. https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK201210005.htm
[3] 崔晓庄, 江新胜, 王剑, 等. 扬子西缘澄江组底部玄武岩形成时代新证据及其地质意义[J]. 岩石矿物学杂志, 2015, 34(1): 1-13. doi: 10.3969/j.issn.1000-6524.2015.01.001
[4] 刘石磊, 崔晓庄, 汪长林, 等. 扬子西缘新元古代中期裂谷作用: 来自年代学与沉积学的新证据[J]. 地球科学, 2020, 45(8): 3082-3093. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX202008026.htm
[5] 崔晓庄, 江新胜, 王剑, 等. 滇中新元古代澄江组层型剖面锆石U-Pb年代学及其地质意义[J]. 现代地质, 2013, 27(3): 547-556. doi: 10.3969/j.issn.1000-8527.2013.03.005
[6] 刘军平, 夏彩香, 孙柏东, 等. 滇中易门地区新元古代澄江组凝灰岩锆石U-Pb年龄及其地质意义[J]. 沉积与特提斯地质, 2019, 39(1): 14-21. doi: 10.3969/j.issn.1009-3850.2019.01.002
[7] 陆俊泽, 江新胜, 王剑, 等. 滇东北巧家地区新元古界澄江组SHRIMP锆石U-Pb年龄及其地质意义[J]. 矿物岩石, 2013, 33(2): 65-71. https://www.cnki.com.cn/Article/CJFDTOTAL-KWYS201302010.htm
[8] Jing X, Yang Z, Evans D A D, et al. A pan-latitudinal Rodinia in the Tonian true polar wander frame[J]. Earth and Planetary Science Letters, 2020, 530. doi.org/10.1016/j.epsl.2019.115880. doi: 10.1016/j.epsl.2019.115880 http://www.sciencedirect.com/science/article/pii/S0012821X19305722
[9] Wang L J, Yu J H, Griffin W L, et al. Early crustal evolution in the western Yangtze Block: Evidence from U-Pb and Lu-Hf isotopes on detrital zircons from sedimentary rocks[J]. Precambrian Research, 2012, 222/223: 368-385. doi: 10.1016/j.precamres.2011.08.001
[10] Zhao X F, Zhou M F, Li J W, et al. Late Paleoproterozoic to early MesoproterozoicDongchuan Group in Yunnan, SW China: Implications for tectonic evolution of the Yangtze Block[J]. Precambrian Research, 2010, 182(1/2): 57-69. http://www.onacademic.com/detail/journal_1000035432591310_65ac.html
[11] Chen W T, Zhou M, Zhao X. Late Paleoproterozoic sedimentary and mafic rocks in theHekou area, SW China: Implication for the reconstruction of the Yangtze Block in Columbia[J]. Precambrian Research, 2013, 231: 61-77. doi: 10.1016/j.precamres.2013.03.011
[12] 李怀坤, 张传林, 姚春彦, 等. 扬子西缘中元古代沉积地层锆石U-Pb年龄及Hf同位素组成[J]. 中国科学: 地球科学, 2013, 43(8): 1287-1298. https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK201308005.htm
[13] 杜利林, 郭敬辉, 耿元生, 等. 扬子西南缘盐边群时代及构造环境: 来自碎屑沉积岩的约束[J]. 岩石学报, 2013, 29(2): 641-672. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201302022.htm
[14] 杨红, 刘福来, 杜利林, 等. 扬子地块西南缘大红山群老厂河组变质火山岩的锆石U-Pb定年及其地质意义[J]. 岩石学报, 2012, 28(9): 2994-3014. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201209026.htm
[15] Wang L J, Griffin W L, Yu J H, et al. U-Pb and Lu-Hf isotopes in detrital zircon from Neoproterozoic sedimentary rocks in the northern Yangtze Block: Implications for Precambrian crustal evolution[J]. Gondwana Research, 2013, 23(4): 1261-1272. doi: 10.1016/j.gr.2012.04.013
[16] Liu Y S, Hu Z C, Zong K Q, et al. Reappraisement and Refinement of Zircon U-Pb Isotope and Trace Element Analyses by LA-ICP-MS[J]. Chinese Science Bulletin, 2010, 55(15): 1535-1546. doi: 10.1007/s11434-010-3052-4
[17] Ludwig K R. Ageochronlogical toolkit for Microsoft excel[J]. Isoplot, 2003, 3: 1-70.
[18] Hu Z C, Liu Y S, Gao S, et al. Improved in situHf isotope ratio analysis of zircon using newly designed X skimmer cone and jet sample cone in combination with the addition of nitrogen by laser ablation multiple collector ICP-MS[J]. J. Anal. Atom. Spectrom, 2012, 27(9): 1391-1399. doi: 10.1039/c2ja30078h
[19] 卓皆文, 江新胜, 王剑, 等. 川西新元古界开建桥组底部沉凝灰岩锆石SHRIMP U-Pb年龄及其地质意义[J]. 矿物岩石, 2015, 35(1): 91-99. https://www.cnki.com.cn/Article/CJFDTOTAL-KWYS201501012.htm
[20] Li X H, Li Z X, W Z H, et al. U-Pb zircon geochronology, geochemistry and Nd isotopic study of Neoproterozoic bimodal volcanic rocks in the Kangdian Rift of South China: Implications for the initial rifting of Rodinia[J]. Precambrian Research, 2002, 113: 135-154. doi: 10.1016/S0301-9268(01)00207-8
[21] 胡世玲, 刘鸿允, 劳秋元. 震旦纪地质年代学新研究[J]. 地质科学, 1991, (4): 325-336.
[22] 杜秋定, 王剑, 汪正江, 等. 扬子地块新元古代裂谷盆地莲沱组沉积分异及其物源分析[J]. 地球科学, 2021, 46(7): 2529-2543. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX202107020.htm
[23] 徐琼, 江拓, 侯林春, 等. 扬子陆块三峡地区莲沱组砂岩中碎屑U-Pb年龄、Hf同位素组成及其地质意义[J]. 地球科学, 2021, 46(4): 1217-1230. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX202104005.htm
[24] 王剑, 李献华, Duan Z T, 等. 沧水铺火山岩锆石SHRIMP U-Pb年龄及"南华系"底界新证据[J]. 科学通报, 2003, 48(16): 1726-1731. doi: 10.3321/j.issn:0023-074X.2003.16.003
[25] Liu Y, Yang K, Polat A, et al. Reconstruction of the Cryogenian palaeogeography in the Yangtze Domain: constraints from detrital age patterns[J]. Geological Magazine, 2019, 156(7): 1247-1264. doi: 10.1017/S0016756818000535
[26] 高林志, 陈建书, 戴传固, 等. 黔东地区梵净山群与下江群凝灰岩SHRIMP锆石U-Pb年龄[J]. 地质通报, 2014, 33(7): 949-959. doi: 10.3969/j.issn.1671-2552.2014.07.002 http://dzhtb.cgs.cn/gbc/ch/reader/view_abstract.aspx?file_no=20140702&flag=1
[27] 汪正江, 王剑, 杜秋定, 等. 扬子克拉通内存在太古代成熟陆壳: 来自岩石学、同位素年代学和地球化学证据[J]. 科学通报, 2013, 58(17): 1651-1660. https://www.cnki.com.cn/Article/CJFDTOTAL-KXTB201317011.htm
[28] Lan Z, Li X, Zhu M, et al. A rapid and synchronous initiation of the wide spreadCryogenian glaciations[J]. Precambrian Research, 2014, 255: 401-411. doi: 10.1016/j.precamres.2014.10.015
[29] 高林志, 陆济璞, 丁孝忠, 等. 桂北地区新元古代地层凝灰岩锆石U-Pb年龄及地质意义[J]. 中国地质, 2013, 40(5): 1443-1452. doi: 10.3969/j.issn.1000-3657.2013.05.009
[30] 李献华, 李武显, 何斌. 华南陆块的形成与Rodinia超大陆聚合-裂解——观察、解释与检验[J]. 矿物岩石地球化学通报, 2012, (6): 543-559. doi: 10.3969/j.issn.1007-2802.2012.06.002
[31] Zhou M F, Yan D P, Kennedy A K, et al. SHRIMP U-Pb zircon geochronological and geochemical evidence for Neoproterozoic arc-magmatism along the western margin of the Yangtze Block, South China[J]. Earth and Planetary Science Letters, 2002, 196: 51-67. doi: 10.1016/S0012-821X(01)00595-7
[32] 李献华, 李正祥, 周汉文, 等. 川西南关刀山岩体的SHRIMP锆石U-Pb年龄、元素和Nd同位素地球化学——岩石成因与构造意义[J]. 中国科学(D辑), 2003, (S2): 60-68. https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK2002S1006.htm
[33] Sun W, Zhou M, Yan D, et al. Provenance and tectonic setting of the NeoproterozoicYanbian Group, western Yangtze Block(SW China)[J]. Precambrian Research, 2008, 167: 213-236. doi: 10.1016/j.precamres.2008.08.001
[34] Du L L, Guo J H, Nutman A P, et al. Implications for Rodinia reconstructions for the initiation of Neoproterozoic subduction at ~860Ma on the western margin of the Yangtze Block: Evidence from the Guandaoshan Pluton[J]. Lithos, 2014, 196/197: 67-82. doi: 10.1016/j.lithos.2014.03.002
[35] 郭春丽, 王登红, 陈毓川, 等. 川西新元古代花岗质杂岩体的锆石SHRIMP U-Pb年龄、元素和Nd-Sr同位素地球化学研究: 岩石成因与构造意义[J]. 岩石学报, 2007, 10(10): 2457-2470. doi: 10.3969/j.issn.1000-0569.2007.10.014
[36] 耿元生, 杨崇辉, 王新社, 等. 扬子地台西缘结晶基底的时代[J]. 高校地质学报, 2007, 13(3): 429-441. doi: 10.3969/j.issn.1006-7493.2007.03.012
[37] Meng E, Liu F, Du L, et al. Petrogenesis and tectonic significance of the Baoxing granitic and mafic intrusions, southwestern China: Evidence from zircon U-Pb dating and Lu-Hf isotopes, and whole-rock geochemistry[J]. Gondwana Research, 2015, 28(2): 800-815. doi: 10.1016/j.gr.2014.07.003
[38] Zhou M F, Ma Y X, Yan D P, et al. TheYanbian Terrane(Southern Sichuan Province, SW China): A Neoproterozoic arc assemblage in the western margin of the Yangtze Block[J]. Precambrian Research, 2006, 144(1/2): 19-38. http://www.onacademic.com/detail/journal_1000035432895610_b292.html
[39] Wu T, Zhou J, Wang X, et al. Identification of ca. 850 Ma high-temperature stronglyperaluminous granitoids in southeastern Guizhou Province, South China: A result of early extension along the southern margin of the Yangtze Block[J]. Precambrian Research, 2018, 308: 18-34. doi: 10.1016/j.precamres.2018.02.007
[40] 卓皆文, 江新胜, 王剑, 等. 华南扬子古大陆西缘新元古代康滇裂谷盆地的开启时间与充填样式[J]. 中国科学: 地球科学, 2013(12): 1952-1963. https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK201312006.htm
[41] 任光明, 庞维华, 孙志明, 等. 四川喜德地区九盘营组变英安岩锆石U-Pb年龄: 兼论登相营群新认识[J]. 矿物岩石, 2016, 36(3): 79-86. https://www.cnki.com.cn/Article/CJFDTOTAL-KWYS201603010.htm
[42] Wang W, Zhou M. Sedimentary records of the Yangtze Block(South China) and their correlation with equivalent Neoproterozoic sequences on adjacent continents[J]. Sedimentary Geology, 2012, 265/266: 126-142. http://www.onacademic.com/detail/journal_1000035084229110_4113.html
[43] 杨崇辉, 耿元生, 杜利林, 等. 扬子地块西缘Grenville期花岗岩的厘定及其地质意义[J]. 中国地质, 2009, 36(3): 647-657. doi: 10.3969/j.issn.1000-3657.2009.03.011
[44] Li Z X, Li X H, Zhou H W, et al. Grenvillian continental collision in South China: new SHRIMP U-Pb zircon results and implications for the configuration of Rodinia[J]. Geology, 2002, 30(2): 163-166. doi: 10.1130/0091-7613(2002)030<0163:GCCISC>2.0.CO;2
[45] Wang Y, Zhu W, Huang H, et al. Ca. 1.04 Ga hot Grenville granites in the western Yangtze Block, southwest China[J]. Precambrian Research, 2019, 328: 217-234. doi: 10.1016/j.precamres.2019.04.024
[46] 王生伟, 廖震文, 孙晓明, 等. 会东菜园子花岗岩的年龄、地球化学——扬子地台西缘格林威尔造山运动的机制探讨[J]. 地质学报, 2013, 87(1): 55-70. doi: 10.3969/j.issn.0001-5717.2013.01.006
[47] Zhu W, Zhong H, Li Z, et al. SIMS zircon U-Pb ages, geochemistry and Nd-Hf isotopes of ca. 1.0Ga mafic dykes and volcanic rocks in the Huili area, SW China: Origin and tectonic significance[J]. Precambrian Research, 2016, 273: 67-89. doi: 10.1016/j.precamres.2015.12.011
[48] Chen W T, Sun W H, Wang W, et al. "Grenvillian" intra-plate mafic magmatism in the southwestern Yangtze Block, SW China[J]. Precambrian Research, 2014, 242: 138-153. doi: 10.1016/j.precamres.2013.12.019
[49] 李怀坤, 张传林, 相振群, 等. 扬子克拉通神农架群锆石和斜锆石U-Pb年代学及其构造意义[J]. 岩石学报, 2013, 29(2): 673-697. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201302023.htm
[50] 张传恒, 高林志, 武振杰, 等. 滇中昆阳群凝灰岩锆石SHRIMP U-Pb年龄: 华南格林威尔期造山的证据[J]. 科学通报, 2007, 52(7): 818-824. doi: 10.3321/j.issn:0023-074X.2007.07.016
[51] 尹福光, 孙志明, 白建科. 东川、滇中地区中元古代地层格架[J]. 地层学杂志, 2011, 35(1): 49-54. https://www.cnki.com.cn/Article/CJFDTOTAL-DCXZ201101009.htm
[52] Greentree M R, Li Z X, Li X H, et al. Late Mesoproterozoic to earliest Neoproterozoic basin record of the Sibao orogenesis in western South China[J]. Precambrian Research, 2006, 151: 79-100. doi: 10.1016/j.precamres.2006.08.002
[53] Song G, Wang X, Shi X, et al. New U-Pb age constraints on the upper Banxi Group and synchrony of the Sturtian glaciation in South China[J]. Geoscience Frontiers, 2017, 8(5): 1161-1173. doi: 10.1016/j.gsf.2016.11.012
[54] Wang L, Griffin W L, Yu J, et al. Precambrian crustal evolution of the Yangtze Block tracked by detrital zircons from Neoproterozoic sedimentary rocks[J]. Precambrian Research, 2010, 177: 131-144. doi: 10.1016/j.precamres.2009.11.008
[55] 魏亚楠, 江新胜, 崔晓庄, 等. 黔东南新元古代清水江组碎屑锆石U-Pb年代学研究及其地质意义[J]. 矿物岩石, 2015, 35(3): 61-71. https://www.cnki.com.cn/Article/CJFDTOTAL-KWYS201503009.htm
[56] Wang X, Li X, Li Z, et al. Episodic Precambrian crust growth: Evidence from U-Pb ages and Hf-O isotopes of zircon in the Nanhua Basin, central South China[J]. Precambrian Research, 2012, 222/223: 386-403. doi: 10.1016/j.precamres.2011.06.001
[57] 宋芳, 牛志军, 何垚砚, 等. 中扬子地区南华纪早期碎屑锆石U-Pb年龄及其对物源特征和古地理格局的约束[J]. 地质学报, 2016, 90(10): 2661-2680. doi: 10.3969/j.issn.0001-5717.2016.10.009
[58] Zhu G, Yu J, Zhou X, et al. The western boundary between the Yangtze andCathaysia blocks, new constraints from the Pingbian Group sediments, southwest South China Block[J]. Precambrian Research, 2019, 331: 105350. doi: 10.1016/j.precamres.2019.105350
[59] 彭敏, 吴元保, 汪晶, 等. 扬子崆岭高级变质地体古元古代基性岩脉的发现及其意义[J]. 科学通报, 2009, (5): 641-647. https://www.cnki.com.cn/Article/CJFDTOTAL-KXTB200905018.htm
[60] 熊庆, 郑建平, 余淳梅, 等. 宜昌圈椅埫A型花岗岩锆石U-Pb年龄和Hf同位素与扬子大陆古元古代克拉通化作用[J]. 科学通报, 2009, 53(22): 2782-2792. https://www.cnki.com.cn/Article/CJFDTOTAL-KXTB200822022.htm
[61] 刘文中, 徐士进, 王汝成, 等. 攀西麻粒岩锆石U-Pb年代学: 新元古代扬子陆块西缘地质演化新证据[J]. 地质论评, 2005, 51(4): 470-476. doi: 10.3321/j.issn:0371-5736.2005.04.016
[62] 王冬兵, 孙志明, 尹福光, 等. 扬子地块西缘河口群的时代: 来自火山岩锆石LA-ICP-MS U-Pb年龄的证据[J]. 地层学杂志, 2012, 36(3): 630-635. https://www.cnki.com.cn/Article/CJFDTOTAL-DCXZ201203014.htm
[63] 任光明, 庞维华, 孙志明, 等. 扬子西缘会理地区通安组角闪岩锆石U-Pb定年及其地质意义[J]. 矿物岩石, 2014, 34(2): 33-39. https://www.cnki.com.cn/Article/CJFDTOTAL-KWYS201402007.htm
[64] Greentree M R, Li Z X. The oldest known rocks in south-western China: SHRIMP U-Pb magmatic crystallisation age and detrital provenance analysis of the Paleoproterozoic Dahongshan Group[J]. Journal of Asian Earth Sciences, 2008, 33(5/6): 289-302. http://www.sciencedirect.com/science/article/pii/S1367912008000047
[65] 关俊雷, 郑来林, 刘建辉, 等. 四川省会理县河口地区辉绿岩体的锆石SHRIMP U-Pb年龄及其地质意义[J]. 地质学报, 2011, 85(4): 482-490. https://www.cnki.com.cn/Article/CJFDTOTAL-DZXE201104005.htm
[66] 王冬兵, 尹福光, 孙志明, 等. 扬子陆块西缘古元古代基性侵入岩LA-ICP-MS锆石U-Pb年龄和Hf同位素及其地质意义[J]. 地质通报, 2013, 32(4): 617-630. doi: 10.3969/j.issn.1671-2552.2013.04.010 http://dzhtb.cgs.cn/gbc/ch/reader/view_abstract.aspx?file_no=20130410&flag=1
[67] Sun W H, Zhou M F, Gao J F, et al. Detrital zircon U-Pb geochronological and Lu-Hf isotopic constraints on the Precambrian magmatic and crustal evolution of the western Yangtze Block, SW China[J]. Precambrian Research, 2009, 172(1/2): 99-126. http://www.sciencedirect.com/science/article/pii/S0301926809000722
[68] Zheng J P, Griffin W L, O' Reilly S Y. Widespread Archean basement beneath the Yangtze Craton[J]. Geology, 2006, 34(6): 417-420. doi: 10.1130/G22282.1
[69] Han P, Guo J, Chen K, et al. Widespread Neoarchean(~2.7-2.6Ga) magmatism of the Yangtze craton, South China, as revealed by modern river detrital zircons[J]. Gondwana Research, 2017, 42: 1-12. doi: 10.1016/j.gr.2016.09.006
[70] Wang Z J, Wang J, Du Q D, et al. The evolution of the Central Yangtze Block during early Neoarchean time: Evidence from geochronology and geochemistry[J]. Journal of Asian Earth Sciences, 2013, 77(21): 31-44. http://www.onacademic.com/detail/journal_1000036243058610_1d4e.html
[71] Cui X, Wang J, Sun Z, et al. Early Paleoproterozoic(ca. 2.36 Ga) post-collisional granitoids in Yunnan, SW China: Implications for linkage between Yangtze and Laurentia in the Columbia supercontinent[J]. Journal of Asian Earth Sciences, 2019, 169: 308-322. doi: 10.1016/j.jseaes.2018.10.026
[72] 宋高源. 扬子地台东南缘新元古代地层碎屑锆石年龄及其意义[D]. 中国地质大学(北京) 博士学位论文, 2017.
[73] Peng S, Kusky T M, Jiang X F, et al. Geology, geochemistry, and geochronology of the Miaowan ophiolite, Yangtze craton: Implications for South China's amalgamation history with the Rodinian supercontinent[J]. Gondwana Research, 2012, 21: 577-594. doi: 10.1016/j.gr.2011.07.010
[74] Shi Y R, Liu D Y, Zhang Z Q, et al. SHRIMP zircon U-Pb dating of Gabbro and Granite from the Huashan Ophiolite, Qinling Orogenic Belt, China: Neoproterozoic Suture on the Northern Margin of the Yangtze Craton[J]. Acta Geologica Sinica, 2007, 81: 239-243. doi: 10.1111/j.1755-6724.2007.tb00947.x
[75] 魏亚楠. 扬子陆块南部新元古代碎屑锆石U_Pb年龄谱及其地质意义[D]. 中国地质大学(武汉) 硕士学位论文, 2016.
[76] 张昆昆. 滇东南建水地区新元古代澄江组碎屑锆石年代学及其地质意义[D]. 中国地质大学(武汉) 硕士学位论文, 2016.
-
